As the world Turns

1
(No Transcript)
2
Presented by Dr. Johar Iqbal
3
(No Transcript)
4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
VERTIGO

• BY DR. JOHAR IQBAL
• TMO, FCPS II,
• ENT, HMC.

10
CONTENTS

• Difference between dizziness and vertigo.
• Diagnostic approach to True vertigo.
• Characteristics of Peripheral vertigo.
• Characteristics of Central vertigo.
• Treatment Considerations.

11
Patients refer to Dizziness as

• Light headedness
• Sense of strangeness
• Faintness
• Giddy
• Imbalanced

12
Most dizzy patients can be placed in to one of
four categories

• 1-True Vertigo (50)
• 2-Pre-syncope
• 3-Dysequilibrium
• 4-Vague lightheadedness

13
Most dizzy patients can be placed in to one of
four categories

• 1-True Vertigo (50)
• 2-Pre-syncope
• Transient sensation that a faint is about to
  occur.
• May present as nausea ,weakness, SOB or change
  in vision.

14
Most dizzy patients can be placed in to one of
four categories

• 3-Dysequilibrium
• A sensation of imbalance when standing or
  walking.
• No illusion.
• No sense of faintness.
• 4-Vague lightheadedness
• Psychiatric disorders,
• Hyperventilation syndrome
• Encephalopathies

15
What is Vertigo?
16
True vertigo

• Defined as an illusion or hallucination of
  movement.
• Both vertigo and dysequilibrium imply a loss of
  balance,
• but vertigo involves a sense of motion.

17
How do we maintain equilibrium?
18
Visual input
EQUILIBRIUM
Proprioceptiual input
Vestibular input labyrinths.
19
(No Transcript)
20
(No Transcript)
21
Anatomy Semicircular canals

• Semicircular Canals (SCC)
• Horizontal
• Anterior
• Posterior
• Cupula
• End organ receptors
• Endolymph

22
Anatomy Utricle

• Utricle
• Connected to SCC
• Contains endolymph
• Otoliths (otoconia)
• Calcium carbonate
• Attached to hair cells
• Maculae (end organ)

23
(No Transcript)
24
(No Transcript)
25
Sensory hair cells of the vestibular organs.
TypeI (left) and Type II (right).
26
VESTIBULAR SYSTEM

• Tells brain which way the head moves without
  looking
• SCC Angular acceleration
• Utricle Saccule Static Linear acceleration

27
4
Scarpas ganglion
28
CENTRAL VESTIBULAR CONNECTION

• The fibres of vestibular nerve end in vestibular
  nuclei and some go to the cerebellum directly.
• Vestibular nuclei are four in number,
• Superior,
• Medial,
• Lateral and
• Descending.
• Afferents to these nuclei come from
• (i) Peripheral vestibular receptors (semicircular
  canals,utricle and saccule)
• (ii) Cerebellum
• (iii) Reticular formation
• (iv) Spinal cord
• (v ) Contralateral vestibular nuclei.

29
CENTRAL VESTIBULAR CONNECTION

• Efferents from vestibular nuclei go to
• (i) Nuclei of CN Ill,IV,VI via medial
  longitudinal bundle.
• It is the pathway for vestibulo-ocular reflexes
  and this explains the genesis of nystagmus.
• (ii) Motor part of spinal cord (vestibulospinal
  fibres).
• This coordinates the movements of head, neck and
  body in the maintenance of balance.

30
CENTRAL VESTIBULAR CONNECTION

• (iii) Cerebellum (vestibulocerebellar fibres).
• It helps to coordinate input information to
  maintain the body balance.
• (iv) Autonomic nervous system.
• This explains nausea,vomiting,palpitation,sweating
  and pallor seen in vestibular disorders
  (e.g.Meniere's disease).
• (v) Vestibular nuclei of the opposite side.
• (vi) Cerebral cortex (temporal lobe).
• This is responsible for subjective awareness of
  motion.

31
How can we clinically evaluate the patient with
vertigo?
32
CN VIII (Vestibular portion)
Labyrinth
Vertigo
Cerebellum
Brainstem
Vestibular nuclei
33
Vertigo
Central (5)
Peripheral (95)
34
CAUSES OF VERTIGO

• PERIPHERAL
• BPPV
• Meniers disease
• Acute labyrinthitis
• Vestibular neuronitis
• Vestibulotoxic drugs
• Head trauma
• Perilymphatic fistula
• Syphilis

• CENTRAL
• Vertebrobasillar insufficiency
• Cerebellopontine angle tumor
• Cerebrovascular disease
• Basilar Migraine
• Multiple sclerosis
• Posterior inferior cerebellar artery syndrome
• Cervical vertigo

35
VARIETY OF DISORDERS THAT GIVE RISE TO VESTIBULAR
DYSFUNCTION

• Ocular pathology LABYRINTHINE pathology
  CNS Disease
• CVS disorders Psychiatric morbidity
• Renal disease
• Genetic disorders Haematological disorders
  Endocrine disorders
• Orthopedic/ Rheumatological Autoimmune disease

VESTIBULAR DYSFUNCTION
36
NONVESTIBULAR CAUSES OF DIZZINESS

• Endocrine HypogIycemia
•
  Adrenal failure
•
  Pheochromocytoma
• Cardiovascular Vasovagal syncope
•
  Orthostatic hypotension
•
  Embolic disease
•
  Cardiac dysrrhythmias
• Hematological Hyperviscosity syndromes
•
  Anaemias
• Psychological Anxiety
•
  Phobias
•
  Panic attacks

37

• Both dr. and patient get depressed.
• WHY?
• Because they are not at same wave length.
• So a good Hx is of paramount importance.
• In 80 of cases if no Dx is made at the end of
  Hx. Then no Dx can be made at the end of
  examination and investigations.

38
HISTORY

• Details of first and recent attacks.
• Duration.
• Body posture
• Episodic or prolonged
• If rotatry Hx and Dx is easy
• If unsteady Hx and Dx is difficult.
• History of systemic disease
• Drug history

39

• Associated symptoms such as
• Chronic ear discharge
• Deafness
• Tinnitus
• Nausea
• Vomiting
• Diplopia
• Blurring of vision
• Headache
• Anaesthesia of face.
• Sudden attack of fall and unconsciousness

40
SHORT LIVED EPISODIC VERTIGO

• Benign Paroxysmal positional vertigo.
• Labyrinthine fistula.
• Vertebrobasilar insufficiency.

41
Vertigo Lasting from few minutes hours

• Menieres disease.
• Syphilitic hydrops.
• Following middle ear surgery.
• Perilymph fistula
• Hyperventilation
• Travel sickness
• Drug induced
• Functional

42
Vertigo lasting from days weeks

• Vestibular neuronitis
• Labyrinthitis
• Labyrinthectomy vestibular neuronectomy
• Acoustic neuroma (bilateral)

43
EXAMINATION

• Otological Examination (otoscopy,hearing test,
  fistula test) .
• Eye examination (Nystagmus)
• Positional test (Dix- halpike)
• Rapid assessment of cranial nerve.
• Full Neurological examination.
• Cerebellum and balance tests (Romberg test, gait
  test, past pointing falling).
• Peripheral and central pulses, B.P.

44
INVESTIGATIONS

• Pure tone audiogram (PTA)
• Caloric tests.
• Electronystagmography.
• Radiological examination CT/MRI.

45
PTA IN MENIERS DISEASE
46
CALORIC TEST
47
At the end of work up, one should be able to know

• Is true vertigo present?

• Have there been auditory symptoms?

• What is the pattern of onset ?

• What is the duration of the symptoms?

• Are there associated neurologic symptoms?

48
NYSTAGMUS

• Involuntary Rhythmic oscillation of eyes.
• Visual impulses regulates the position of the
  eyes in relation to the object of visual
  interest.
• Vestibular impulses regulates the position of the
  eyes in relation to head movement via Vestibulo
  ocular reflex.
• video

49
DEGREE OF NYSTAGMUS

• 1st degree It is weak nystagmus and is
  present when patient looks in the direction
  of fast component.
• 2nd degree It is stronger than the 1st
  degree nystagmus and is present when patient
  looks straight ahead,
• 3rd degree It is stronger than 2nd
  degree nystagmus and is present even when
  patient looks in the direction of the slow
  component.
• (Alexander' s law)

50
Direction of Head rotation Right
Vestibulo-ocular reflex Slow phase of nystagmus
to LEFT
Increased afferent activity Right vestibular
nucleous
Decreased afferent activity Left vestibular
nucleous
-
-
Lateral Rectus
Lateral Rectus
51

• In Irritative/Inflammatory lesion, the vestibular
  nuclei on same side become hyperactive i.e.
• Lesion on Rt. Side will stimulate vestibular
  nuclei on Rt. Side,
• Slow phase of nystgmus will be towards Lt.
• While corrective fast component will bring back
  eyes to Rt., so nystgmus will be to Rt.
• I (Irritative)----I (Ipsilateral).
• While reverse occur in paralytic lesion.
• P (Paralytic)----C (Contralateral).

52
CHARACTERISTICS OF PERIPHERAL NYSTAGMUS

• Associated with sensation of vertigo
• Has a latent period
• Unidirectional and horizontal and has a fast and
  slow components except in few cases.
• More marked when looking in direction of fast
  phase.
• Is enhanced by removal of optic fixation either
  in darkness or by using frenzels glasses.
• Fatiguable.

53
CHARACTERISTICS OF CENTRAL NYSTAGMUS

• Has no latent period.
• Not fatiguable
• May be direction changing, rotatory or
  disconjugate.
• Not affected by removal of optic fixation.

54
SPINNED
PERIPHERAL
CENTRAL
Sudden (Onset) Yes Slow, gradual
Positional Yes No
Intensity Severe ill defined
Nausea/Diaphoresis Frequent Infrequent
Nystagmus Horizontal/ torsional Vertical/ direction changing
Ear Can be present Absent
Duration Paroxysmal Constant
CNS signs Absent Usually present
55
PERIPHERAL VERTIGO

• Approximation 95 of ED patients with vertigo.

• Due to dysfunction of one of vestibular organs.

• Asymmetry of input

• Sensation of rotation

• Associated with nausea, pallor and diaphoresis.

56
PERIPHERAL (Lesions of end organvestibular
nerve)

• Benign paroxysmal positional vertigo
• Meniere's disease
• Vestibular neuronitis
• Labyrinthitis
• Vestibulotoxic drugs
• Head trauma
• Perilymph fistula
• Syphilis
• Acoustic neuroma

57
BPPV

• Benign Paroxysmal Positional Vertigo
• Age 60-70 years
• FM, 21
• Head trauma
• Commonest cause of peripheral vertigo
• Brief violent attacks of vertigo provoked by
  certain head positions
• No auditory symptoms

58
Characteristic of BPPV

• Turn head
• After a few seconds delay, vertigo occurs
• Resolves within 1 minute if you dont move
• If you turn your head back, vertigo recurs in the
  opposite direction

59
BPPV

• B Benign
• Not a brain tumor
• Can be severe and disabling

• P Paroxysmal
• Episodic, not persistent
• Helpful feature in the differential diagnosis

• P Positional
• Occurs with position of head
• Turning over in bed
• Looking up
• Bending over

• V Vertigo
• An illusion of motion
• The room is spinning

60
PATHOPHYSIOLOGY OF BPPV

• Otoliths become detached from hair cells in
  utricle
• Inappropriately enter the posterior semicircular
  canal

61
Structure of macula, the sensory end organ of
the utricle and the saccule.
62
PHYSIOLOGY

• Normal situation
• As one turns head to the right
• Endolymph moves ?SCC receptors fire ? head
  turning right
• Stop turning head? endolymph stops moving ? SCC
  receptors stop firing ? head has stopped moving

63
PATHOPHYSIOLOGY OF BPPV

• BPPV
• Stop turning head ? otoliths keep moving ? drag
  endolymph ? receptors continue to fire
  inappropriately ? head is still moving
• Eyes ? head is NOT moving
• Brain ? room must be spinning in the opposite
  direction

64
DIX-HALLPIKE MANEUVER

• The diagnosis of BPPV is generally from the
• history.

• Can confirm the diagnosis of BPPV

65
DIX-HALLPIKE MANEUVER
They include
1- Nystagmus
2- Provocative head position
3- Brief latency to symptoms after change in
position
4- Short duration of attack
5- Fatigability of nystagmus on repeat testing
6-Reverse of nystagmus on returning to upright
position.
66
DIX-HALLPIKE MANEUVER
67
EPLEY MANEUVER

• 1. Repeat Hallpike
• Previously performed diagnostic Hallpike test
  tells you the starting position (right or left)

68
EPLEY MANEUVER

• 2. Turn head 90 degrees in the other direction

69
EPLEY MANEUVER

• 3. Patient rolls onto shoulder, rotates head and
  looks down towards floor

70
EPLEY MANEUVER
71
(No Transcript)
72
MENIERES DISEASE

• Characterized by triad of
• Vertigo
• Tinnitus
• Hearing loss (sensorineural)
• Chronic relapsing illness (? familial)
• Due to a build-up of endolymphatic pressure in
  the labyrinth.
• Investigations
• Pure tone audiogram
• Electrocochleography

73
MENIERES DISEASE

• Medical Treatment
• Bed rest
• Fluid and salt restriction
• Vestibular sedatives / vasodilators.
• Systemic steroids / intra tympanic injection.
• Surgical Treatment
• Sac decompression
• Cervical sympathectomy
• Vestibular nerve section
• Labyrinthectomy

74
VESTIBULAR NEURONITIS

• Acute unilateral loss of peripheral vestibular
  function
• Voilent attacks of rotatory vertigo, nausea and
  vomiting
• Worsened by head movement
• Followed by slow but gradual recovery over a
  period of 10 days to 03 weeks.
• Occurs in healthy young to middle-aged adults
• Often after respiratory infections
• Hearing is normal.
• Self-limiting

75
LABYRINTHITIS

• Viral and bacterial
• Serous or purulent
• Severe rotatory vertigo, vomiting and profound
  sensorineural deafness
• Irritative nystagmus in the initial stage
  followed by paralytic nystagmus.
• IV Antibiotics in the initial stage with
  labyrnthine sedatives
• Mastoidectomy

76
VESTIBULOTOXIC DRUGS

• By damaging the inner hair cells of the inner
  ear.
• Aminoglycoside antibiotics particularly
• Streptomycin,
• Gentamicin,
• Kanamycin
• Affect hair cells of the crista ampullaris and to
  some extent those of the maculae.
• Other drugs
• Antihypertensives,
• Labyrinthine sedatives,
• Oestrogen preparations,
• Diuretics,
• Anti microbials (nalidixic acid,metronidazole)
  and
• Antimalarial.

77
HEAD TRAUMA

• Head injury may cause concussion of labyrinth,
• Completely disrupt the bony labyrinth or VIllth
  nerve,or cause a perilymph fistula.
• Severe acoustic trauma,such as caused by an
  explosion can also disturb the vestibular end
  organ (otoliths) and result in vertigo.

78
PERILYMPH FISTULA

• Perilymph leaks into the middle ear through the
  oval or round window.
• Follow as a complication of stapedectomy,or ear
  surgery when stapes is accidentally dislocated.
• Also result from sudden pressure changes in the
  middle ear e.g barotrauma,diving,forceful
  Valsalva or raised intracranial pressure (weight
  lifting or vigorous coughing).
• Causes intermittent vertigo and fluctuating
  sensorineural hearing loss,sometimes with
  tinnitus and sense of fullness in the ear.

79
ACOUSTIC NEUROMA

• Classified in peripheral vestibular disorders as
  it arises from CN VIII within internal acoustic
  meatus.
• Causes only unsteadiness or vague sensation of
  motion.
• Severe episodic vertigo,as seen in the end organ
  disease,is usually missing.
• Other tumours of temporal bone (e.g. glomus
  tumour,carcinoma of external or middle ear and
  secondaries),destroy the labyrinth directly and
  cause vertigo.

80
Rehabilitation Plan

• General Fitness Programme
• Systematic exercise programme
• Cawthorne Cooksey exercises

81
CAWTHORNE COOKSEY EXERCISES

• A. Resting
• Eye movements
• At first slow then quick, up and down
• From side to side focusing on finger moving from
  the face three feet to one feet.
• Head movements
• At first slow then quick
• Later with eye close
• Bending forward and backwards
• Turning by side to side.

82
CAWTHORNE COOKSEY EXERCISES

• B. Sitting
• First two points are as above
• Shoulder shrugging and circling
• Bending forward and picking objects from the
  ground

83
CAWTHORNE COOKSEY EXERCISES

• C. Standing
• A-1,2 and B3.
• Changing from setting to standing position, the
  eyes open and closed
• Throwing a ball from hand to hand above eye
  level.
• Changing from sitting to standing and turning
  around in between.

84
CAWTHORNE COOKSEY EXERCISES

• D. Moving About
• Walk across the room with eyes open and then
  closed.
• Walk up and down the slope with eyes open and
  then close
• Walk up and down steps with eyes open and then
  close
• Any game involving stoping or stretching and
  aiming such as basket ball.

85
PSYCHOLOGICAL SUPPORT
86
THANKS
