A Framework for Behavioral Engineering of Software Systems

1
A Framework forBehavioral Engineeringof
Software Systems

• Swaminathan Natarajan
• Dept. of Computer Science
• Rochester Institute of Technology
• sxn_at_cs.rit.edu

2
Behavioral Engineering

• Typically, much of the design focus for software
  systems on functionality
• The behavior of the system depends on its
  ilities all its different non-functional
  attributes
• Performance, dependability, usability
• Tradeoffs with evolvability, business attributes
• Engineering involves a systematic approach to
  identify the best tradeoffs among the design
  goals

3
Need for Behavioral Engineering

• High architecture and design emphasis on making
  software modular, layered, easy to modify and
  extend
• Performance terrible, project scrapped
• Very fancy user interface, latest technology,
  lots of bells and whistles, online help given
• Users still complain about the interface
• Customers very pleased with product, want to
  increase capacity, put on other platforms
• Product is very hard to port, does not scale well

4

• Customers view of quality

reliability
usability
performance
scalability
extensibility
security
availability
portability
cost
operability
safety
5

• Developers view of quality

maintainability
portability
Documentation
extensibility
cycletime
reusability
Testability
cost
correctness
performance
6
An Attribute Classification
Evolvability Extensibility Maintainability Scalabi
lity Portability
Business Cycletime Cost Reusability
Behavior Performance Dependability Usability
Not exhaustive list Not mutually independent
?Tradeoffs
Usability Operability Learnability Helpfulness Int
eroperability Control, Affect Adaptability
Dependability Reliability Availability Timeliness
Robustness Precision Security, Safety

• Performance
• Response time
• Throughput
• Capacity
• Resources Usage
• Space
• Bandwidth

• Platform
• Power

7
ISO9126 Attribute Classification
Functionality Suitability Accurateness Interoperab
ility Compliance Security
Reliability Maturity Fault-tolerance Recoverabilit
y
Usability Understandability Learnability Operabili
ty
Maintainability Analyzability Changeability Stabil
ity Testability
Portability Adaptability Installability Conformanc
e Replaceability
Efficiency Time behavior Resource behavior
8
A Framework for Behavioral Engg
Specify
Design
Analyze
Attribute goals Criticality of goals Preferred
tradeoffs
Measure
Quantitative / Qualitative Fidelity varies with
effort, available info
Testing Field data Customer feedback (needs
work)
9
Background

• SEI architecture program basic approach of
  attribute-focused design
• Work on attribute analysis
• Performance analysis
• Reliability engineering and fault-tolerance
• SUMI for usability analysis
• SAAM evolvability, other qualitative attributes
• ATA for tradeoff approach
• This particular integrative framework developed
  at Motorola India

10
Product Definition Activities
Business
Customer Feedback
Planning Business Feasibility Analysis
Prototyping
Requirements Elicitation
Requirements Specification
Product Profile
Requirements Analysis
Modeling Analysis
Architecture
Functionality
Behavior
11
Lifecycle View
12
Attribute Specification

• Identify and prioritize attributes of interest
• Create specifications for both quantitative and
  qualitative attributes
• Typically 20-50 specifications for a medium-size
  system (100KLOC)
• If possible, create tradeoff specifications
• Customer preferences among alternative profiles
• Attribute specification is part of requirements
  elicitation and capture
• Works well with use case approach

13
Attribute Specification Examples

Performance

• Response Time
• Call setup lt 250ms
• System startup lt 2 minutes
• Resume service within 1.5 sec on channel
  switchover
• Throughput
• 1000 call requests /sec
• 800 traps (SNMP) / day
• Capacity
• 70 simultaneous calls
• 50 concurrent users
• Resource Utilization
• Max 50 CPU usage on full load
• Max 16MB run time memory
• Max bandwidth 96 kb/sec

14
Attribute Specification Examples Usability,
Dependability

• Usability
• User types Administrators Operators
• Look and feel same as Windows packages
• Server invocation in lt 60 ms
• Invocation command shall have lt 5 Command line
  arguments
• Expert user should be able to complete the task
  in lt 5 sec
• New users to start using the system in one hour
  without training
• Dependability
• lt 20 min downtime for upgrades
• No more than 3 failures per 100,000 operations
• Results accurate upto 3 decimal places
• Recover automatically if configuration files
  corrupted or deleted
• No more than 6 hours downtime per year
• The system should be resistant to
  man-in-the-middle attacks

15
Attribute Specification Examples Evolution

• Portability
• Application Should run on Windows-NT as well
• Should be able to use different databases
  Oracle/Sybase/...
• Scalability
• Increase the number of SVs in the space-network
  from 66 to 110
• Extensibility
• Should be easy to incorporate password protection
• Medium effort to add content sensitive help
  feature to the GUI
• Diagnostic monitoring tool should be extensible
  w.r.t. analysis capabilities for monitored data
• Maintainability
• The tool should allow easy addition of new
  message formats
• The tool should be customizable for new business
  processes

16
Design

• Design space of feasible alternatives
• Goodness of designs determined by attribute
  satisfaction
• Identify critical design drivers
• Attribute requirements that are hard to meet,
  have most impact on customer satisfaction
• Core design choices to optimize critical drivers
• Decomposition style strategy (i.e. software
  architecture), technology and platform choices,
  algorithms data structures
• Analyze design(s) to determine attribute profile
• Add mechanisms to improve attributes (tradeoffs)
• Iterate design to optimize attribute satisfaction

17
Attribute Modifiers

• Blocks that can be inserted into a design to
  improve some quality attributes, usually at the
  expense of others
• Lookup tables (performance, -memory)
• Compression (memory, -performance)
• Hotspot optimization (performance,
  -evolvability)
• Passwords (security, -memory, -performance,
  -usability)
• Certificates (security, -cost,
  -interoperability?)
• Context-sensitive help (usability, -memory,
  -cycletime, -cost)
• Middleware (evolvability, interoperability,
  -performance, -cost

18
Analysis

• For both quantitative and qualitative attributes
• Including subjective attributes
• Iterate between design and analysis
• Basket of analysis technologies
• Approaches include modeling, estimation,
  closed-form analysis, expert inputs, reviews and
  surveys
• Based on representations
• Different design views facilitate different
  analyses
• Useful to create views that focus on key
  attributes
• Different levels of fidelity based on
• How complete and detailed the design is
• Level of effort put into analysis
• Prototypes, benchmarking, testing inputs to
  improve analysis fidelity

19
Performance AnalysisScheduling Theory

• Execution time estimation for individual modules
• Inputs code structure (algorithm) and
  benchmarking data
• Views Detailed design, control flow diagrams
• Computation time (work) estimation for operations
• Views Sequence diagrams / state diagrams /
  control flow
• Wait times blocked waiting on resources
• Inputs Tasking and resource contention patterns
• Views Process views, enhanced with shared
  resource usage
• Response times for operations
• Inputs Scheduling information, operational
  profiles
• Views Use cases annotated with request arrival
  patterns
• Timeliness derived directly from response times
• Fidelity factor of 2-10, useful for worst-case
  analysis, bottleneck identification,
  understanding

20
Performance Analysis ResourcesMemory usage
analysis, network scheduling algorithms

• Code/data/heap/stack analysis for memory usage
• Inputs Operational profiles, dimensioning
  information
• Views Block structure diagrams, class diagrams
• Network analysis
• Inputs Request patterns and sizes, network
  bandwidth allocation algorithm, network
  scheduling algorithm
• Views Communication view (enhancement to process
  view showing interactions)
• Can perform contention analysis for any shared
  resource (process view enhanced with resource
  dependencies)

21
Response Time Analysis Concept
Database

Database Interface Layer
Server
Application Processing Layer
Client Interface Layer
Message Queue
Network
Client-n
Client-1
..
22
Performance Analysis ModelingDiscrete-event
simulations

• Build model of system and run simulations
• Inputs
• Operational profiles (request arrival patterns)
• System architecture, sequence diagrams
• Operation computation times
• Tasking and resource usage patterns
• Value
• Fidelity /- 20 (factor of 2 with less detail)
• Identification of bottlenecks
• What-if analysis, sensitivity analysis
• Throughput and capacity analysis
• More effort, can handle high complexity

23
Reliability AnalysisSoftware Reliability
Engineering

• Design operation test cases that generate random
  inputs within equivalence classes
• Design test scripts that select test cases
  randomly based on operational profiles
• Perform system testing and record failures
• Plot failures over time to obtain reliability
  growth curves
• Release guidance based on reliability objectives
• Estimation of test effort based on reliability
  objectives
• Software Reliability Engineering is actually a
  complete end-to-end methodology for developing
  reliable software

24
Operational Profile - Example
25
Robustness, Availability AnalysisFault trees,
FMEA, Fault injection

• Identify set of failure modes
• Identify the set of possible faults
• Draw (AND/OR) fault trees showing relationship
  between faults and failure modes
• FMEA (failure modes effects analysis) to
  determine relationships
• Add exception handling and fault-tolerance to
  weaken linkages between faults and failures
  (introduce AND nodes)
• Use failure impact and probability data to guide
  need for choices between fault-tolerance
  approaches
• Fault injection testing and reliability analysis
  to gauge effectiveness of design
• Approach can also be used for safety, security

26
Usability AnalysisSoftware Usability Measurement
Inventory

• SUMI is a survey-based approach for usability
  analysis (HFRG, UCC (univ), UK)
• Standard user questionnaire 50 questions
• Pre-calibrated response analysis tool
• Score of 0-10 along 5 dimensions efficiency,
  learnability, helpfulness, control, affect
• Inputs Actual interface and software behavior,
  prototypes
• Can augment with quantitative and qualitative
  internal goals for usability and analyze against
  them

27
Evolvability AnalysisSoftware Architecture
Analysis Method

• Scenarios identified during specification
• e.g. should be easy to add context-sensitive help
• During design review, identify what work needs to
  be done for this scenario
• Each reviewer rates this easy/moderate/hard
• Ratings can be translated to design score if
  desired
• Views Block structure diagrams with dependencies
• Can be used for any qualitative attribute
  security, safety, usability, reusability
• Allows for subjective inputs but well-defined
  scenarios and goals provide basis for resolution
• Can do scalability analysis based on complexity
  theory

28
Business Attribute AnalysisProject Estimation
and Planning

• Cycletime and cost analysis based on planning
  data
• Views Work-breakdown structure, Wideband delphi
  or other estimation data, GANTT chart
• Reusability analysis using SAAM
• Identify specific targets for reuse
• Effort estimation for different designs provides
  critical inputs to design decision making
• Just enough design vs. best possible design
• Include just enough within concept of best
  possible

29
Testing

• Attribute testing as part of product testing
• Performance testing (measurement)
• Reliability testing (reliability growth testing /
  reliability certification testing on stable
  version)
• Error, fault injection testing
• Security testing (attacks)
• Usability testing (attribute focus during alpha
  testing, observing users, surveys)
• Validating evolvability estimates during
  modifications, development of subsequent versions
• Provides inputs to subsequent design iterations

30
Product Quality Data Chart
Key Product-Quality Attributes(Performance,
Usability)
Availability Goal
Usability score from SUMI (if used)
Product Evolution Goals
? Motorola India Electronics Ltd, 2000
31
Metrics

• Simplest metric customer satisfaction with
  attributes survey data for each product
• Measurements such as of design goals
  satisfied hard to translate to meaningful
  metrics
• SUMI, reliability, availability have ready
  metrics
• Need more work to identify good metrics

32
Deployment

• Deployed at Motorola India for the last 3 years
  20 projects
• Specification practiced on most projects
• Analysis and testing focus on some projects
• Product Quality Data Chart part of monthly
  project review presentations
• Product Quality satisfaction questions part of
  periodic customer satisfaction surveys

33
Results

• Most attribute ratings improved from around 7.0
  to 7.5-8.0 on 10-point scale
• Room for further improvement
• Strong positive subjective feedback from
  customers and from internal project managers and
  technical staff, on some projects
• Some gaps in product quality continue to exist,
  including both specification gaps and design gaps
• 2-3 cases where analysis had huge impact on
  reworking requirements and preventing disasters
• Success in identifying bottlenecks and critical
  drivers
• Rated Motorola emerging best practice in 2000

34
Summary

• It is possible to take a systematic approach
  towards engineering the product profile for
  software systems
• There exist a full basket of specification and
  analysis technologies
• Diagramming is critical to analysis
• The individual practices have been around a long
  time, and proven extensively in many environments
• The framework has also been deployed and found
  useful
• However, this is not yet widely accepted
  practice
• Partly because universities do not focus on it
  (my opinion)
• Partly because of poor tool support (catch-22)

35
References

• "Quality Attributes", Barbacci et al, 1995,
  CMU/SEI-95-TR-021
• "The Architecture Trade-off Analysis Method",
  Kazman et al, http//www.sei.cmu.edu
• "Scenario-Based Analysis of Software
  Architecture", Kazman et al, IEEE Software,
  13(6)47-56, 1996.
• "Using the WinWin Spiral Model A Case Study",
  Boehm et al, IEEE Computer, July 1998, pp.
  33-44.
• Software Reliability Engineered Testing, Musa et
  al, McGraw-Hill, 1998.
• Product Quality Framework, Krishnan et al, ACM
  Software Engineering Notes, July 2001.
• FMEA http//www.fmeainfocentre.com/
• SUMI http//www.ucc.ie/hfrg/
• ISO Product Quality http//www.cse.dcu.ie/essisco
  pe/

36
Comparison to ISO/IEC-9126

• Characteristics-- Sub-Characteristics --
  Measurements
• Characteristics Functionality, Reliability,
  Usability, Maintainability, Portability,
  Efficiency
• Characteristic Maintainability
• Sub-characteristic Analyzability
• Metrics Cyclomatic number, comment density,..
• Intrinsic Vs Extrinsic Metrics
• Post Measurement Certification Vs Focus
  throughout the Lifecycle
