Test Automation Framework
Overview and Strategy
2
Contents

• Software Framework
• The Easy Way
• The Better Way
• Introduction
• PageObject Pattern
• Automation Framework Approaches
• Data/Table Driven Framework
• Keyword Driven Framework
• Hybrid Framework
• Generic Architecture
• Guidelines and Lessons Learnt
• Test Organization
• Test Writing Style
• Browser Updates

2
3
Software Framework What is a software framework?
3
4
Software FrameworkThe definition and key
components

• A software framework is a universal, reusable
  software platform used to develop applications,
  products and solutions.
• Software Frameworks include,
• Support Programs
• Compilers
• Code Libraries
• APIs
• A tool set to integrate different components

4
5
Software FrameworkFramework properties

• A Software framework contain key distinguishing
  features that separate them from normal
  libraries.
• They are,
• Inversion of Control (IOC) the overall program's
  flow of control is not dictated by the caller,
  but by the framework.
• Default behaviour must actually be some useful
  behavior and not a series of instructions.
• Extensibility can be extended by the user usually
  by selective overriding or specialized by user
  code providing specific functionality.
• Non modifiable framework code is not allowed to
  be modified.

5
6
The Easy WayWhat is the easy way to automate?
6
7
The easy way - Records all user activities and
play back

• Typically a software testing suite will allow the
  tester to use the SUT as a user would, through
  the browser.
• In the background the testing suite records all
  of the clicks and key presses and discards any
  context.
• Later, the recorded events are played back and
  various assertions are made to ensure the output
  matches that which is expected.

7
8
The easy way Pros and Cons

• Pros
• Easy and does not required highly skilled
  software developers
• Large portions of the application can be covered
  quickly
• Cons
• Small changes to the SUT cause massive disruption
  in the tests
• Entire suites of tests can be rendered useless
  resulting in reduce testing coverage for extended
  periods of time
• Test maintenance becomes hard
• Tests begin to stagnate
• Team confidence, in the tests, is reduced.

8
9
The Better WayWhat could be a better way of
automating?
9
10
The better wayIntroduction

• Treat automated testing as software development.

• Tests should be created with the same concern for
  software design principles such as,
• Reduced coupling
• High cohesion
• Proper separation of concerns
• Maintainability
• Reusability

10
11
The better wayPageObject class

11
12
The better wayDos and Donts

• In PageObjects,
• The public methods represent the services
  that the page offers
• Try not to expose the internals of the page
• Generally don't make assertions
• Methods return other PageObjects
• Need not represent an entire page
• Different results for the same action are
  modeled as different methods

12
13
The better wayPros and Cons

• Pros
• Selenium WebDriver supports
• Increased maintainability
• Increase test stability
• Readable tests
• Tests are easy to author
• Cons
• Larger up-front cost for creating PageObjects
• More skill is required to create PageObjects

13
14
Automation Framework ApproachesWhat are the
available automation frameworks?
14
15
Automation FrameworkApproachesData/Table Driven
Framework

• Data driven is the design of possible inputs what
  may given by the end user. This would cover
  maximum probabilities of an input data. It can be
  a spread sheet or a DB. We have to connect and
  pass the values to the respective field or
  element.
• Take advantage of testers familiarity with
  test case creation using tables and matrices
• Accommodate localization projects
• Recognize the importance of patterns in test
  cases
• Enable testers to catalog test cases with
  Excel spreadsheets
• Enable testers to specify expected results in
  spreadsheets

15
16
Automation Framework ApproachesData/Table Driven
Framework
16
17
Automation FrameworkApproachesKeyword Driven
Framework

• Keyword driven framework is an action based test
  method used in planning and implementation of
  automation.

17
18
Automation FrameworkApproachesHybrid Framework

• A mix of Data driven and Keyword driven
  frameworks.

18
19
Automation FrameworkApproachesGeneric
Architecture

• A Test Automation Framework should have a
  multi-tiered architecture. It should consists of
  the following tiers.
• Engine Components in this tier are completely
  responsible for interacting with the WebDriver
  interfaces.
• Domain This tier is meant to contain only page
  objects that work against the engine.
• Utils This tier is meant to contain very generic,
  reusable functionality across all the other
  tiers.
• Functional Tests This tier will contain tests
  that are built on top of MSTest to create actual
  test scenarios by using page objects in the
  Domain.

19
20
Guidelines and Lessons LearntSome important
points to keep in mind
20
21
Automation Framework ApproachesGuidelines for
Automation framework design

• Selection of a framework
• Dont reinvent the wheel - Make use of
  Selenium WebDriver functionalities
• Reusability
• Support of different application versions
• Support of script versioning
• Different environment for development and
  production
• Externally Configurable
• Minimal changes required for any object
  changes
• Execution - Individual, batch, only failed
  etc
• Status monitoring , Reporting
• Minimum dependency on Automation tool for
  changes

21
22
Automation Framework ApproachesGuidelines for
Automation framework design

• Easy debugging
• Logging - Errors, warnings, etc
• Easy to Use
• Flexible - Should not impact existing test
  if changes are required
• Performance impacts
• Coding Standards

22
23
Functional test organizationPhysical file
organization

• Test script files (.cs files) are organized into
  a folder structure much similar to the web
  applications page structure.
• Reasons to select this approach
• Easy access to tests
• Testing a section of the application is easy

23
24
Functional test organizationTest class naming
convention

• Test class name should start with the containing
  folder name.
• Reasons to select this approach
• Easy to group tests based on test class
• Testing a section of the application is easy

24
25
Functional test writing style Behavior Driven
Development Style Tests

• It is important to be able to break down a test
  scenario into the components of a behavior driven
  test to ensure clarity. Very concisely the test
  writer should be able to dictate a test scenario
  as
• Given lta preconditiongt
• When ltan action takes placegt
• Then ltexpected outcome should be presentgt

25
26
Functional test writing styleBehavior Driven
Development Style Tests

26
27
Functional test writing styleBehavior Driven
Development Style Tests

• Reasons for selecting this approach
• This style of test writing allows for a test case
  to be easily verbalized and comparable to the
  system requirements being validated.
• Since this effort is heavily focused on UI
  automation, it makes sense to capture test cases
  dictating every behavior of the system and the
  user.

27
28
Browser Upgrades What if the browser upgrades
automatically?

• Have a portable version of the browser
• Package it with your framework
• Starts when the test suite starts

28
29
Summary

• Automation should be considered as a development
  project and not just record and playback of
  events. Starting automated testing with a good
  framework ensures low maintenance. Guidelines
  discussed in this paper can be used as input for
  developing requirements for a framework.

29
