Recent work on Language Identification

1
Recent work on Language Identification
Pietro Laface POLITECNICO di TORINO
Brno 28-06-2009 Pietro
LAFACE
2
Team
POLITECNICO di TORINO Pietro Laface Professor Fab
io Castaldo Post-doc Sandro Cumani PhD
student Ivano Dalmasso Thesis Student
LOQUENDO Claudio Vair Senior
Researcher Daniele Colibro Researcher Emanuele
Dalmasso Post-doc
3
Outline

• Acoustic models
• Fast discriminative training of GMMs
• Language factors
• Phonetic models
• 1-best tokenizers
• lattice tokenizers
• LRE09
• Incremental acquisition of segments for the
  development sets

4
Our technology progress

• Inter-speaker compensation in feature space
• GLDS / SVM models (ICASSP 2007) - GMMs
• SVM using GMM super-vectors (GMM-SVM)
• Introduced by MIT-LL for speaker recognition
• Fast discriminative training of GMMs
• Alternative to MMIE
• Exploiting the GMM-SVM separation hyperplanes
• MIT discriminative GMMs
• Language factors

5
Acoustic Language Identification

• Task similar to text-independent Speaker
  Recognition

Gaussian Mixture Models (GMM) - MAP adapted from
an Universal Background Model (UBM)
UBM
MAP
6
GMM super-vectors
Appending the mean value of all Gaussians in a
single stream we get a super-vector
We use GMM super-vectors
7
Using an UBM in LID

• The frame based inter-speaker variation
  compensation approach estimates the inter-speaker
  compensation factors using the UBM
• In the GMM-SVM approach all language GMMs share
  the same weights and variances of the UBM
• The UBM is used for fast selection of Gaussians

8
Speaker/channel compensationin feature space

• U is a low rank matrix (estimated offline)
  projecting the speaker/channel factors subspace
  in the supervector domain.
• x(i) is a low dimensional vector, estimated using
  the UBM, holding the speaker/channel factors for
  the current utterance i.
• is the occupation probability of the
  m-th Gaussian

9
Estimating the U matrix

• Estimating the U matrix with a large set of
  differences between models generated using
  different utterances of the same speaker we
  compensate the distortions due to the
  inter-session variability ? Speaker recognition
• Estimating the U matrix with a large set of
  differences between models generated using
  different speaker utterances of the same language
  we compensate the distortions due to
  inter-speaker/channel variability within the same
  language ? Language recognition

10
GMM-SVM

• A GMM model is trained for each utterance, both
  in train and in test
• Each GMM is represented by a normalized GMM
  super-vector
• The normalization is necessary to define a
  meaningful comparison between GMM supervectors

11
Kullback-Leibler divergence

• Two GMMs (i and j) can be compared using an
  approximation of the Kullback-Leibler divergence

The interesting property of this measure is that
12
Kullback-Leibler normalization

• normalizing each supervector component according
  to

• The normalized UBM supervector defines the origin
  of a new space
• The KL divergence becomes an Euclidean distance
• The SVM language models are created using a
  linear kernel in this KL space

13
GMM-SVM weakness

• GMM-SVM models perform very well with rather long
  test utterances

It is difficult to estimate a robust GMM with a
short test utterance
Exploit the discriminative information given by
the GMM-SVM for fast estimation of discriminative
GMMs
14
SVM discriminative directions
w normal vector to the class-separation
hyperplane
15
GMM discriminative training
Utterance GMM
Language GMM
KL Space

• Shift each Gaussian of a language model along its
  discriminative direction, given by the vector
  normal to the class-separation hyperplane in the
  KL space

16
Rules for selection of ak

• A discriminative GMM moves away from its original
  - MAP adapted - model, which best matches the
  training (and test) data.
• A large value of ak (shift size) ?
• more discriminative model, but
• worse likelihood than less discriminative models
• Use a development set for estimating a

17
Experiments with 2048 GMMs
Pooled EER() of Discriminative 2048 GMMs, and
GMM-SVM on the NIST LRE tasks. In parentheses,
the average of the EERs of each language.
Year Models Models Models
Year Discriminative GMMs Discriminative GMMs GMM-SVM
Year 3s 10s 30s
1996 11.71 (13.71) 3.62 (4.92) 1.01 (1.37)
2003 13.56 (14.40) 5.50 (6.02) 1.42 (1.64)
2005 16.94 (17.85) 9.73 (11.07 ) 4.67 (5.81 )
256-MMI (Brno University 2006 IEEE Odyssey ) 256-MMI (Brno University 2006 IEEE Odyssey ) 256-MMI (Brno University 2006 IEEE Odyssey )
2005 17.1 8.6 4.6
18
Pushed GMMs (MIT-LL)
19
Language Factors

• Eigenvoice modeling, , and
  the use of speaker factors as input features to
  SVMs, has recently been demonstrated to give good
  results for speaker recognition compared to the
  standard GMM-SVM approach (Dehak et al. ICASSP
  2009).
• Analogy
• Estimate an eigen-language space, and use the
  language factors as input features to SVM
  classifiers (Castaldo et al. submitted to
  Interspeech 2009).

20
Language Factors advantages

• Language factors are low-dimension vectors
• Training and evaluating SVMs with different
  kernels is easy and fast it requires the dot
  product of normalized language factors
• Using a very large number of training examples is
  feasible
• Small models give good performance

21
Toward an eigen-language space

• After compensation of the nuisances of a GMM
  adapted from the UBM using a single utterance,
  residual information about the channel and the
  speaker remains.
• However, most of the undesired variation is
  removed as demonstrated by the improvements
  obtained using this technique

22
Speaker compensated eigenvoices

• First approach
• Estimating the principal directions of the GMM
  supervectors of all the training segments before
  inter-speaker nuisance compensation would produce
  a set of language independent, universal
  eigenvoices.
• After nuisance removal, however, the speaker
  contribution to the principal components is
  reduced to the benefit of language
  discrimination.

23
Eigen-language space

• Second approach
• Computing the differences between the GMM
  supervectors obtained from utterances of a
  polyglot speaker would compensate the speaker
  characteristics and would enhance the acoustic
  components of a language with respect to the
  others.
• We do not have labeled databases including
  polyglot speakers
• compute and collect the difference between GMM
  supervectors produced by utterances of speakers
  of two different languages irrespective of the
  speaker identity, already compensated in the
  feature domain

24
Eigen-language space

• The number of these differences would grow with
  the square of utterances of the training set.
• Perform Principal Component Analysis on the set
  of the differences between the set of the
  supervectors of a language and the average
  supervector of every other language.

25
Training corpora

• The same used for LRE07 evaluation
• All data of the 12 languages in the Callfriend
  corpus
• Half of the NIST LRE07 development corpus
• Half of the OSHU corpus provided by NIST for
  LRE05
• The Russian through switched telephone network
• Automatic segmentation

26
Eigenvalues of two language subspaces
The language subspace has higher eigenvalues, and
both curves show a sharp decrease for their first
13 eigenvalues, corresponding to the main
language discrimination directions.
27
LRE07 30s closed set test
Language factors minDCF is always better and
more stable
28
Pushed GMMs (MIT-LL)
29
Pushed eigen-language GMMs
The same approach to obtain discriminative GMMs
from the language factors
30
Min DCFs and (EER)
Models 30s 10s 3s
GMM-SVM (KL kernel) 0.029 (3.43) 0.085 (9.12) 0.201 (21.3)
GMM-SVM (Identity kernel) 0.031 (3.72) 0.087 (9.51) 0.200 (21.0)
LF-SVM (KL kernel) 0.026 (3.13) 0.083 (9.02) 0.186 (20.4)
LF-SVM (Identity kernel) 0.026 (3.11) 0.083 (9.13) 0.187 (20.4)
Discriminative GMMs 0.021 (2.56) 0.069 (7.49) 0.174 (18.45)
LF-Discriminative GMMs (KL kernel) 0.025 (2.97) 0.084 (9.04) 0.186 (19.9)
LF-Discriminative GMMs (Identity kernel) 0.025 (3.05) 0.084 (9.05) 0.186 (20.0)
31
Loquendo-Polito LRE09 System
Model Training
32
Phonetic models

• Output layer
• 700-1000 states for the language dependent
  phonetic units

• Stationary units
• 23 - 47

• ASR Recognizer
• phone-loop grammar with diphone transition
  constraints

33
Phone transcribers

• ASR Recognizer
• phone-loop grammar with diphone transition
  constraints

• 12 phone transcribers for
• French, German, Greek, Italian, Polish,
  Portuguese, Russian, Spanish, Swedish, Turkish,
  UK and US English.
• The statistics of the n-gram phone occurrences
  collected from the best decoded string of each
  conversation segment

34
Phone transcribers

• ANN models
• Same phone-loop grammar - different engine

• 10 phone transcribers for
• Catalan, French, German, Greek, Italian, Polish,
  Portuguese, Russian, Spanish, Swedish, Turkish,
  UK and US English.
• The statistics of the n-gram phone occurrences
  collected from the expected counts from a lattice
  of each conversation segment

35
Multigrams

• Two different TFLLR kernels
• trigrams
• pruned multigrams
• multigrams can provide useful information about
  the language by capturing word parts within the
  string sequences

36
Pruned Multigrams
For each phonetic transcriber, we discard all the
n-grams appearing in the training set less than
0.05 of the average occurrence of the unigrams
Total number of n-grams for 12 language transcribers Total number of n-grams for 12 language transcribers Total number of n-grams for 12 language transcribers Total number of n-grams for 12 language transcribers Total number of n-grams for 12 language transcribers Total number of n-grams for 12 language transcribers Total number of n-grams for 12 language transcribers
N-gram 1 2 3 4 5 6
Pruned 461 11477 120200 114396 10738 443
37
Scoring

• The total number of models that we use for
  scoring an unknown segment is 34
• 11 channel dependent models (11 x 2)
• 12 single channel models (2 telephone and 10
  broadcast models only).
• 23 x 2 for MMIE GMMs (channel independent but
  M/F)

38
Calibration and fusion
Multi-class FoCal
max of the channel dependent scores
39
Language pair recognition

• For the language-pair evaluation only the
  back-ends have been re-trained, keeping unchanged
  the models of all the sub-systems.

40
Telephone development corpora

• CALLFRIEND - Conversations split into slices of
  150s
• NIST 2003 and NIST 2005
• LRE07 development corpus
• Cantonese and Portuguese data in the 22 Language
  OGI corpus
• RuSTeN -The Russian through Switched Telephone
  Network corpus

41
Broadcast development corpora

• Incrementally created to include as far as
  possible the variability within a language due to
  channel, gender and speaker differences
• The development data, further split in training,
  calibration and test subsets, should cover the
  mentioned variability

42
Problems with LRE09 dev data

• Often same speaker segments
• Scarcity of segments for some languages after
  filtering same speaker segments
• Genders are not balanced
• Excluding French, the segments of all languages
  are either telephone or broadcast.
• No audited data available for Hindi, Russian,
  Spanish and Urdu on VOA3, only automatic
  segmentation was provided
• No segmentation was provided in the first release
  of the development data for Cantonese, Korean,
  Mandarin, and Vietnamese
• For these 8 missing languages only the language
  hypotheses provided by BUT were available for
  VOA2 data.

43
Additional audited data

• For the 8 languages lacking broadcast data,
  segments have been generated accessing the VOA
  site looking for the original MP3 files
• Goal collect 300 broadcast segments per
  language, processed to detect narrowband
  fragments
• The candidates were checked to eliminate segments
  including music, bad channel distortions, and
  fragments of other languages

44
Development data for bootstrap models

• The segments were distributed to these sets so
  that same speaker segments were included in the
  same set.
• A set of acoustic (pushed GMMs) bootstrap models
  has been trained

45
Additional not-audited data from VOA3

• Preliminary tests with the bootstrap models
  indicate the need of additional data
• Selected from VOA3 to include new speakers in the
  train, calibration and test sets
• assuming that the file label correctly identify
  the corresponding language

46
Speaker selection

• Performed by means of a speaker recognizer
• We process the audited segments before the others
• A new speaker model is added to the current set
  of speaker models whenever the best recognition
  score obtained by a segment is less than a
  threshold

47
Additional not-audited data from VOA2

• Enriching the training set
• Language recognition has been performed using a
  system combining the acoustic bootstrap models
  and a phonetic system
• A segment has been selected only if
• the 1-best language hypothesis of our system had
  associated a score greater than a given (rather
  high) threshold
• matched the 1-best hypothesis provided by the BUT
  system

48
Total number of segments for this evaluation
Set Corpora Corpora Corpora Corpora Corpora Corpora
Set voa3_A voa2_A ftp_C voa3_S voa2_S ftp_S
Train 529 116 316 1955 590 66
Extended train 114 22 65 2483 574 151
Development 396 85 329 1866 449 45

• Suffix
• A audited
• C checked
• S automatic segmentation
• ftp ftp//8475.ftp.storage.akadns.net/mp3/voa/

49
Hausa- Decision Cost Function
DCF
50
Hindi- Decision Cost Function
DCF
51
Results on the development set
Test on Systems Systems Systems Systems Systems Systems
Test on Pushed GMMs MMIE GMMs 3-grams Multi-grams Lattice Fusion
Broadcast telephone 1.48 1.70 1.09 1.12 1.06 0.86
Broadcast subset 1.54 1.69 1.24 1.26 1.14 0.91
Telephone subset 2.00 2.51 1.45 1.49 1.42 1.21
Average minDCFx100 on 30s test segments
52
Korean - score cumulative distribution
t-t
t-b
b-t
