Title: Things You Did not Want to Know About Digital Communications


1
Things You Did not Want to Know About Digital
Communications
  • Curt Schurgers
  • Davor McRay

2
Basic Digital Communication Principles
3
How Information is Communicated
0 1 0 1 1 1 0 0 1 0 1 0
Information
V, I
Electrical waveform
Electro-magnetic waveform
  • The basic information can be digital (e.g.
    computer data) or analog (e.g. traditional tv or
    radio). I will only discuss digital communication
    systems.
  • The actual transmission uses electro-magnetic
    waves (Maxwell).
  • A communication system transforms the information
    into an analog electrical signal, which is
    converted to the EM-wave by the antenna.

4
Grouping the Information
  • Information can be grouped together into
    waveforms
  • If M ? ? the performance goes up, but at a cost
    of complexity
  • (Shannon limit)

b bits/symbol M possible waveforms
1 bit/symbol
0
1
11
10
01
00
2 bits/symbol
5
Signal Space Representation
  • The basic idea is that we can transmit
    information in parallel over a set of orthogonal
    waveforms with respect to the symbol interval T.
    The inverse of this interval is called the symbol
    rate Rs 1/T.

6
Detection of the Symbols
  • Correlation or matched filter detector (basically
    equivalent)

7
Amplitude Scaling
  • Instead of sending only s1, s2, s3 sL etc.
    combine these with a set of possible scaling
    factors a1, a2, a3 aK

s1(t)
Sample at t T
X
s2(t)
Y
8
Information Mapping Examples
M 4
M 2
Send s1, s2, both or none of them.
Send either s1 or s2.
M 8
M 4
Send any of these combinations.
Send ?s1 or ?s2.
9
Common Elementary Modulation Schemes
10
Some Elementary Schemes
FSK (Frequency Shift Keying)
Baseband PAM (Pulse Amplitude Modulation)
s1
Passband PAM (Pulse Amplitude Modulation)
f1
11
Sinusoidal Waveforms
Quadrature (Q)
In-phase (I)
s2
s1
12
Transmitter Structure
13
Frequency Domain
T
1/T
time
frequency
Baseband
BW (bandwidth)
fc
Passband
BW (bandwidth)
14
Modulation and Demodulation
Modulation
Demodulation
2.cos(2?.fc.t)
a(t)
ri(t)
b(t)
-2.sin(2?.fc.t)
15
Alternative Interpretation
16
QAM and PSK
QAM (Quadrature Amplitude Modulation)
16-QAM
64-QAM
4-QAM
PSK (Phase Shift Keying)
8-PSK
16-PSK
4-PSK
17
Bandpass Representation
Modulation
  • This is just a mathematical abstraction to simply
    analysis. The waveforms can never be complex of
    course.

Demodulation
18
Performance
19
Transmit Power and Energy
This is the average power consumption when each
symbol is transmitted with an equal probability
20
White Noise
  • In an AWGN (Additive White Gaussian Noise)
    channel, random uncorrelated fluctuations are
    added to the transmitted waveform. This models
    thermal noise phenomena inside the receiver
    electronics. The noise has approximately a flat
    power spectral density.
  • The final impact on the signals can be modeled as
    an addition of uncorrelated random numbers with a
    Gaussian distribution.

21
White Noise (continued )
Consider the mathematical abstraction
Consider the real waveforms
Ideal filters, average signal energy normalized
to 1
22
Performance Evaluation
100
101
000
001
111
011
110
010
  • The demodulator chooses the symbol that is
    closest to the received one (maximum likelihood
    decoding)
  • If the noise (and distortions) is such that we
    are closer to another symbol than the correct
    one, a symbol error occurs.
  • Each symbol error results in a number of bit
    errors. By carefully choosing the mapping from
    bits to symbols (Gray encoding), one symbol error
    typically results in just one bit error.

23
Flat Fading Channel
At receiver !!!
?1 ? d-n
Path loss
B
A
?2
A
B
Shadowing
B
Fading (amplitude and phase component)
B
A
?3
24
Inter-Symbol Interference (ISI)
  • The previous symbols interfere with the current
    one.
  • An equalizer is needed to resolve this issue.

25
Frequency Synchronization
  • If the carrier frequency fc of the receiver has a
    certain offset ? compared to the one at the
    transmitter, the constellation is rotated.
  • Solution Phase Locked Loop (PLL)
  • Lock the frequency
  • Track variations over time

26
Time Synchronization
  • The A/D convertor need to know the correct sample
    time, or equivalently needs to be time
    synchronized
  • Solution oversample the incoming signal and
    choose the best sample times based on maximum
    likelihood of training sequence or incoming data
    (blind synchronization).

Oversampled
27
Spread Spectrum (SS)
28
Principle of Direct Sequence SS (DSSS)
  • The input sequence is multiplied by a faster
    sequence, called the chip sequence.
  • This chip sequence is PN (pseudo noise)
  • The received sequence is multiplied by the same
    chip sequence and integrated over one symbol
    time.

1 1 -1 1 -1 -1 1 -1
Chip time Tc
Receiver with incorrect code
Receiver with correct code
29
Benefits of DSSS
Frequency domaint
user
Despreading
Spreading
jammer
jammer
interferer
interferer
AWGN
user
user
AWGN
  • The input power is spread over a large band hard
    to intercept
  • The noise is reduced (compared to the noise in
    the total bandwidth used) by the spreading gain
    ?c.
  • To synchronize, we multiple with all possible
    shifted versions of the PN sequence. This
    requires a good auto-correlation.

30
CDMA
Spreading code 2
Spreading code 1
  • CDMA (Code Division Multiple Access) uses DSSS as
    a multi-access technique. Transmissions with
    different spreading codes to not interfere.
  • However, the number of correlators in the
    receiver is limited (so the number of
    simultaneous receptions).
  • Spreading codes need good cross-correlation
    properties (for all different shifts).
  • Graceful degradation the performance worsens
    gradually as more users are added to the system.
  • Near-far problem even with good
    cross-correlation, a nearby interferer can swamp
    the reception of a far away transmitter.

31
Frequency-hopped SS (FHSS)
  • Jump around between frequency bands in a pseudo
    random fashion.
  • Avoids being stuck in a bad frequency band.
  • As a multi-access technique, transmissions can
    collide, but occurrences are infrequent.
  • Fast FHSS jump multiple times during one symbol
  • Slow FHSS multiple symbols per jump

32
