MICROBIOLOGY RESEARCH AT SOUTHERN CALIFORNIA COASTAL WATER RESEARCH PROJECT SCCWRP

1
MICROBIOLOGY RESEARCH ATSOUTHERN CALIFORNIA
COASTAL WATER RESEARCH PROJECT(SCCWRP)
Stephen B. WeisbergExecutive Director
2
WHAT IS SCCWRP?

• Joint Powers Agency founded in 1969
• Initiated to address regional monitoring and
  research needs
• Cumulative regional assessments
• Methods development
• Data integration
• Member organizations include city, county, state,
  and federal agencies
• Unique combination of regulators and regulated

3
MEMBER ORGANIZATIONS

• City of San Diego
• City of Los Angeles
• Ventura County Flood Control District
• Los Angeles County Department of Public Works
• Los Angeles County Sanitation Districts
• Orange County Sanitation District
• San Diego Regional Water Quality Board
• Santa Ana Regional Water Quality Board
• Los Angeles Regional Water Quality Board
• State Water Resources Control Board
• U.S Environmental Protection Agency

4
SOME DIFFICULTIES WITH BACTERIAL MONITORING
SYSTEMS

• Laboratory processing is slow
• You should not have been swimming yesterday
• Relationship to health risk is not well
  established
• Santa Monica Bay Epidemiology study is the only
  one to evaluate urban runoff
• Poor relationship between bacteria and pathogens
• Hard to fix if we dont know the source
• Difficult to define appropriate clean-up levels
• Background is not zero

5
SOME DIFFICULTIES WITH BACTERIAL MONITORING
SYSTEMS

• Laboratory processing is slow
• You should not have been swimming yesterday
• Relationship to health risk is not well
  established
• Santa Monica Bay Epidemiology study is the only
  one to evaluate urban runoff
• Poor relationship between bacteria and pathogens
• Hard to fix problems if we dont know the source
• Difficult to define appropriate clean-up levels
• Background is not zero

6
SCCWRPs MICROBIOLOGICAL RESEARCH

• Rapid microbiological measurement methods
  development
• Mission Bay epidemiology study
• Microbiological source tracking evaluation
• Natural sources loading

7
NEED FOR RAPID MEASUREMENT METHODS

• Present methods are slow
• Culture-based
• Take 24-96 hours
• Slow speed compromises the warning system
• Exposure occurs during sample processing
• Most events last less than 24 hours
• Slow speed also compromises upstream tracking
• Need a Geiger counter

8
Surface Proteins
Small molecules
ATP
Nucleic Acids
Molecules released into medium
Things to Measure in a Bacterium
9
CONCENTRATION TECHNIQUES IMMUNOMAGNETIC
SEPARATION (IMS)
Magnetic Beads
Antibody
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Magnetic Bead
Y Antibody
10
MIX BEADS WITH ENVIRONMENTAL SAMPLE
Y
silica
Clay
Algae
Bacterium
Clay
Clay
Algae
11
EXPOSE MIXTURE TO MAGNET SYSTEM FOR SEPARATION
(E.G. MILTENYI, IMMUNICON OR DYNAL)
Add Buffer Dye
Place tube in field
Collect Bacteria
30 min.
Remove Non-magnetic Debris
Bacteria move to tube walls
S
N
N
S
12
FLOW CYTOMETRY OPTICS
Labeled bacterium
Scatter Detector
Scatter signal
Fluorescence Detector
Laser excitation
Fluorescence signal
High performance filters
13
Near Real Time Microbial Analysis
14
APPROACH

• Adapt technology from other industries
• Drinking water
• Hospital testing
• Food service
• Counter bioterrorism
• Partner with specialists in these areas
• Held a workshop in Monterey in May
• Shared developments to date
• Defined method evaluation protocols
• Will conduct blind testing this summer

15
MISSION BAY EPIDEMIOLOGY STUDY

• Is there a health risk of swimming in Mission
  Bay?
• Comparison of swimmers and non-swimmers
• Can we relate to bacterial indicator
  concentration?
• Comparison among swimmers at different times and
  locations
• Can we relate health risk to non-traditional
  microbiological indicators?
• Virus
• Phage
• Bacteroides

16
SAMPLING DESIGN

• Six beaches
• 32 sampling days
• Between 2 and 5 sampling sites per beach
• Dependent on beach length and swimmer density
• Sampled hourly from 1230 to 330
• Total and fecal coliforms by MF
• Enterococcus by Idexx
• Single beach composite at 1230
• Phage, virus, Bacteroides
• Total and fecal by Idexx
• Enterococcus by MF

17
ENROLLMENT ACTUAL VS. GOAL
18
DEMOGRAPHICS OF STUDY POPULATIONRACE AND GENDER
19
PRIOR LARGE RECREATIONAL WATER STUDIES
20
SCCWRPs MICROBIOLOGICAL RESEARCH

• Rapid microbiological measurement methods
  development
• Mission Bay epidemiology study
• Microbiological source tracking evaluation
• Natural sources loading

21
MICROBIOLOGICAL SOURCE TRACKING

• MST tools potentially allow managers to
  discriminate between human and non-human sources
• Some even discriminate among non-human sources
• There are more than a dozen proposed MST methods
• Most have had limited testing
• No marine testing
• Which methods are most cost-effective?
• How reliable are the results?

22
STUDY DESIGN

• Characterize five sources
• Human (direct samples)
• Human (sewage influent)
• Dog
• Cow
• Seagull
• Place these sources in combination into blind
  water matrix samples
• Three matrices
• Freshwater
• Saltwater
• Freshwater with humic acid addition

23
EXAMPLE TEST MATRIX
24
(No Transcript)
25
(No Transcript)
26
STUDY CONCLUSIONS

• No method predicted source material perfectly
• Genetic techniques did best
• Identified dominant sources in about 75 of
  samples
• Phenotypic techniques produced many false
  positives
• Host-specific PCR showed the most promise
• Not yet quantitative
• Only developed for two sources so far
• Viral measures accurately identified sewage, but
  did not identify individual human sources

27
NATURAL LOADING PROJECT

• Determine properties of waterbodies in
  undeveloped watersheds
• Measure a wide array of constituents
• Bacteria
• Metals
• Nutrients
• Provide perspective for various activities
• 303D listing
• Model calibration
• TMDL development

28
SAMPLING DESIGN

• 12 sampling sites
• Stratified based on geology and land cover
• Dry season sampling
• Twice per year (fall and spring)
• Two years (2004-2005)
• Wet season sampling
• Two three storms at each site
• Multiple samples over duration of the storm
• Sampled burned vs. unburned catchments twice this
  winter

29
Questions or Comments?
Steve Weisberg Southern Ca. Coastal Water
Research Project 714-372-9203 stevew_at_sccwrp.org
30
SOME TOUGH ISSUES

• Measuring low concentrations
• Many detectors are based on 1 ml sample
• State standard is 104 bacteria per 100 ml
• Dead or alive?
• Do our standards apply when measuring fragments?
• Intercalibration tests are necessary
• How do we use real-time information in a patchy
  environment?
• Rapid processing allows adaptive sampling
• Lesser processing cost allows more samples
• Capital equipment and training costs
• Many technologies require up-front investment
• Some require specialized training
• Per sample cost is typically lower

31
REPORTED ILLNESSES
32
COMPARISON TO THRESHOLDS
33
POTENTIAL TOOLSNATURAL SOURCES IDENTIFICATION

• Microbial source tracking bacteria
• Iron-normalization metals
• Chiral chemistry organics
• Compound specific istotope analysis - organics

34
IRON NORMALIZATION
35
CHIRAL ENVIRONMENTAL CHEMISTRYENANTIOMERS
MIRROR IMAGES
The Ultimate in Pollutant Speciation
R-(-) o,p-DDT
S-() o,p-DDT
36
COMPOUND SPECIFIC ISOTOPE ANALYSIS

• Elements occur in various isotope ratios (e.g.
  12C/13C)
• IRs are affected by many natural and
  anthropogenic processes
• Can be extremely effective for source
  identification

37
OUR APPROACH

• Held a workshop jointly with USEPA to develop
  method evaluation protocols
• Defined four phases of testing
• Sequentially increasing level of complexity
• Conducted an evaluation test last year
• 22 research labs
• Tested 12 different MST methods

38
EXAMPLE MST METHODS

• Phenotypic
• Antibiotic resistance profiling
• Carbon source utilization
• Genotypic
• Ribotyping
• Pulsed field gel electrophoresis
• Polymerase chain reaction
• Library-independent genotypic
• Terminal restriction fragment length polymorphism
• Host-specific PCR
• Toxin genes
• Direct pathogen measurement
• Adenovirus
• Enterovirus
• Phage

39
EVALUATION CRITERIA

• Distinguish presence/absence of human source
• Correctly identify all sources
• Accurately determine relative contribution from
  each source
• Stability across matrices
