Title: Lesson 4' More on Class Diagram


1
Lesson 4.More on Class Diagram
2
Contents
  • Stereotypes
  • Multiple Classification
  • Aggregation and Composition
  • Interfaces and Abstract Class
  • Qualified Association
  • Association Class
  • Parameterized Class

3
Stereotypes
  • Definition
  • A high-level classification of an object
  • A stereotype indicates what kind of object(class)
    it is.
  • Stereotypes of classes, relations, or
    generalizations
  • Examples
  • Controller and Coordinator
  • Interface Class, Control Class, Entity Class
  • Notation

ltltPurchase Ordergtgt
UML notation for Stereotype Object
4
Multiple Classification
  • Definition
  • An object may be described by several types that
    are not necessarily connected by inheritance.
  • Multiple types of an Object
  • Different from multiple inheritance
  • Discriminator
  • An indication of the basis of the subtyping
  • Make it clear which combinations are legal
  • It can be marked as complete, meaning that any
    instance of the superclass must be an instance of
    one of the subclass in that group.

5
Multiple Classification
Surgeon
discriminator
Doctor
Female
Family Doctor
role
Person
Nurse
sex complete
Male
Physio- therapist
patient
Patient
  • Legal combination
  • (Female, Patient, Nurse)
  • (Male, Physiotherapist)
  • (Female, Patient)
  • (Female, Doctor, Surgeon)
  • Illegal combination
  • (Patient, Doctor)
  • (Male, Doctor, Nurse)

6
Dynamic Classification
  • Definition
  • Objects can change type within the subtyping
    structure
  • Static classification does not allow the type
    change of objects

Manager
Female
job ltltdynamicgtgt
Person
Engineer
sex complete
Male
Saleman
7
Aggregation and Composition
  • Aggregation
  • Aggregation is the part of relationship.
  • Different with association
  • Composition
  • A stronger variety of aggregation
  • The part object may belong to only one whole
    object.
  • The part objects are usually expected to live and
    die with the whole object.
  • Orderlines are deleted when the Order is deleted.

8
Aggregation and Composition
Polygon
Composition
Aggregation
1
1
1
Graphics Bundle
ordered
3..
Point
Color Texture
9
Interface and Abstract Class
  • Interface(as in Java)
  • A class with no implementation
  • Has function declarations but no method bodies.
  • Primarily used to declare an interface.
  • Abstract Class(as in Java and C)
  • Allows implementation of some of the methods
  • Syntax
  • Use a stereotype, ltltinterfacegtgt
  • Use a constraint, abstract

10
Interface and Abstract Class
Windows Window
  • Example of Abstract Class

toFont() toBack()
Window abstract
X11 Window
Text Editor
toFont() toBack()
toFont() toBack()
Mac Window
toFont() toBack()
11
Interface and Abstract Class
  • Example of Interface

InputStream abstract
ltltinterfacegtgt DataInput
OrderReader
Generalization
DataInputStream
Refinement
12
Qualified Associations
  • Definition
  • Argument(or identity) required to access the
    objects of the class in an association
  • UML equivalent of associative arrays and
    dictionaries.
  • Example

One order line for each instance of Product
OrderLine
Order
0..
Product
amount Number
line item
class Order public Orderline
lineItem(Product aProduct) public void
addLineItem(Number amount, Product
forProduct)
13
Association Class
  • Definition
  • An association class has attributes and operation
    for the given association.

Person
Company
employer

0..1
Association Class
Employment
peroiddateRange
14
Parameterized Class
  • C template
  • class SetltTgt
  • void insert (T newElement)
  • void remove(T newElement)
  • Set ltEmployeegt employeeSet

Template Parameter
T
Set
ltltbindgtgt
EmployeeSet
ltEmployeegt
insert(T) remove(T)
Template Class
Set ltEmployeesgt
15
Lesson 5.Interaction Diagram
16
Contents
  • Introduction
  • Sequence Diagram
  • Collaboration Diagram
  • Concurrent Processes

17
Interaction Diagram
  • Interaction Diagram
  • describes how groups of objects collaborate in
    some behavior.
  • captures the behavior of a single use-cases.
  • shows a number of objects and the messages passed
    between these objects within the use-case.
  • Two kinds
  • Sequence Diagram
  • Collaboration Diagram

18
Collaborations
  • The objects interact the other objects to perform
    some task together.
  • Use case Order Stock
  • 1) Order Entry Window sends prepare message to
    an Order.
  • 2) Order sends prepare message to each Order
    line.
  • 3) Order line checks the given Stock line
  • If true, remove the quantity of Stock Item.
  • Otherwise, request a new delivery.
  • A collaboration consists of
  • Objects
  • Links
  • Actors

19
Sequence Diagram
anOrderEntry Window
anOrder
anOrderLine
aStockItem
prepare()
prepare()
condition
check()
Checktrue remove
message
iteration
needsToReorder()
self-delegation
needToReorder()true
return
new
aReorderItem
Checktrue new
aDeliveryItem
lifeline
creation
20
Notation
  • Lifeline
  • Represents the objects life during the
    interaction.
  • Message Flow
  • Each message is represented by an arrow between
    the lifelines of two objects.
  • Each message is labeled with the message name,
    and possibly arguments and control information.
  • Self-Delegation
  • A message that an object sends to itself.

21
Notation
  • Condition(Guard)
  • A message is sent only if the condition is true.
  • needToOrder() true
  • Iteration Marker
  • A message is sent many times to multiple receiver
    objects.
  • When a collection is iterated over.
  • Return
  • Indicates the return from a message.
  • However, returns are implied for all messages.
  • Hence, it is used to improve clarity.

22
Variants of Message Sending
Interaction type Symbol Meaning Synchrono
us or call The normal procedural
situation. The sender loses control until
the receiver finishes handling the
message. Return Not a message, but a return
from an earlier message. Flat The
message doesnt expect a reply. Control
passes from the sender to the receiver, so
the next message will be sent by the receiver
of this message. Asynchronous The message
doesnt expect a reply, but unlike the flat
case, the sender stays active and may send
further messages.
23
Case Study Library System
theLibraryMember LibraryMember
theCopy Copy
theBook Book
aMember BookBorrower
borrow(theCopy)
1okToBorrow
2borrow
2.1 borrowed
24
System Sequence Diagram
  • Events that external actors generate
  • Use case Buy-items
  • POST checkout with items to purchase
  • Cashier records UPC from each item. If same item,
    enter the quantity.
  • System determines the item price and adds item
    information to the running sales transaction.

25
System Sequence Diagram
System
Cashier
enterItem(UPC, quantity)
Actor
endSale()
System event
makePayment(amount)
  • System Operations

System
endSale() enterItem() makePayment()
26
Concurrent Processes
aTransaction
Asynchoronous Message
aTransaction Coordinator
new
aFirst Transaction Checker
Activation
new
aSecond Transaction Checker
new
ok
Other processing suppressed
all done?
ok
bevalid
all done?
self delegation
27
Concurrent Notation
  • Activation
  • is used to indicate a transaction
  • Asynchronous Message
  • Notation Half-arrow heads
  • Does not block the caller, so the caller carry on
    with its own processing
  • Deletion
  • Object deletion can be marked with a large X.
  • It can self-destruct or be destructed by another
    message.

28
Asynchoronous Message
  • do one of three things
  • create a new thread
  • create new object
  • communicate with thread
  • Text blocks
  • When a Transaction
  • is created.
  • . it creates a
  • Coordinator to
  • message the checking.
  • The coordinator
  • creates a series
  • of Checker, one
  • for each kind of
  • check.

aTransaction
aTransaction Coordinator
new
aFirst Transaction Checker
new
new
ok
all done?
29
Collaboration Diagram
  • Definition
  • Collaboration diagram represents object
    interactions in a graph or network format.

1message2() 2 message3()
message1()
ClassAInstance
ClassBInstance
  • Numbering messages
  • Single number 1, 2, 3, .
  • Decimal number 1, 1.1, 1.1.1, 1.1.2, .

30
Collaboration Diagram
  • Single Numbering Scheme

Object
OrderEnrtyWindow
Message
1 prepare()
Sequence Number
Order
5 needToReorder()
3 check() 4checktrue remove()
2 prepare()
MacallanlineOrderLine
Macllan stock Stock Item
Self delegation
6 new
7checktrue new
Delivery Item
Reorder Item
31
Collaboration Diagram
  • Decimal Numbering Scheme

Object
OrderEnrtyWindow
Message
1 prepare()
Sequence Number
Order
1.1.2.1 needToReorder()
1.1.1 check() 1.1.2checktrue remove()
1.1 prepare()
MacallanlineOrderLine
Macllan stock Stock Item
Self delegation
1.1.2.2 new
1.1.3checktrue new
Delivery Item
Reorder Item
32
Creation and Deletion of Objects
  • Sequence Diagram

Lecturer
UTO
1ngetName()
DirectorOfStudies
2 new DirectorOfStudies(n)
3 destroy()
33
Creation and Deletion of Objects
  • Collaboration Diagram

Lecturer destroyed
1 ngetName()
3destroy()
UTO
2 new DirectorOfStudies(n)
DirectorOfStudies new
34
Timing
theLibraryMember LibraryMember
theCopy Copy
theBook Book
aMember BookBorrow
borrow(theCopy)
1okToBowwor
A
2borrow
C-Alt5 sec
2.1 borrowed
B
B
C
35
Conditional Behavior
  • A message may be guarded by a condition.
  • The message is sent only if the guard is true.
  • Condition in square brackets
  • Mutually exclusive/Concurrent conditions

mMung
mMung
I0 foo()
I0 foo()
I1 bar()
I1 bar()
36
Iteration
  • Send message number of times
  • A message is marked with asterisk.
  • Iteration clause describes how many times the
    messages will be sent.
  • ex) i1..10, x , 10, item not found,
    true

tFoo
Bar
Baz
3.1I1..2a()
3.1.1 b()
37
Iteration
  • Collaboration Diagram

msg1()
1I1..10 msg2()
A
myB B
2I1..10msg3()
myC C
msg1() for(I1 Ilt10 I)
myB.msg2() myC.msg3()
38
Comparison
  • Sequence Diagram
  • easy to see order
  • simple
  • Collaboration Diagram
  • more complex behavior
  • indicate how objects are statically connected

39
Lesson 6.The Other Diagrams
40
Contents
  • Package Diagram
  • State Diagram
  • Activity Diagram
  • Deployment Diagram

41
Part 1Package Diagram
42
Motivation
  • How break a large system into smaller systems?
  • Structured Methods
  • Functional decomposition
  • Like use cases in OO methods
  • Information Engineering
  • Grouping data records into subject area
  • Produces metrics to show how the functions and
    records interact.
  • UML
  • Grouping classes together into high-level units,
    packages.

43
Package Diagram
  • Definition
  • A diagram that shows packages of classes and the
    dependencies among them.
  • It is just a form of class diagram.
  • Dependencies
  • Between Classes(on Class Diagram)
  • One class send a message to another.
  • One class has another as part of its data.
  • One class mentions another as a parameter to an
    operation.
  • Between Packages(on Package Diagrams)
  • Exist if any dependency exists between any two
    classes in the packages.
  • Notation
  • Put the name of the package inside the main box
  • Minimize dependency

44
Package Diagram
Package
Dependency
45
Package Dependency
  • Package Dependency is not a compilation
    dependency.
  • Not a transitive relationship
  • The sementics of the Java import behavior

46
Package Visibility
  • Visibility shows subpackage.
  • Definition
  • a class contains methods that can be seen by
    other objects within the same package, but not by
    objects that belong to other packages.
  • Types
  • see into nested packages - transparent
  • cannot see - opaque
  • Java has package visibility.

47
Advanced Package Diagram
Domain
48
Part 2State Diagram
49
State Diagram
  • Concept
  • A state diagram describes all the possible states
    of an object and the transitions between the
    states.
  • Objects state changes as a result of events
  • Syntax and Semantics of Transition
  • Event Guard / Action
  • When the event happens, then transition can
    begin.
  • If the Guard part is specified, the transition
    occurs only when the guard condition is evaluated
    to true.
  • Then, the Action is performed and the object
    gets into the new state.

50
Behavior Inside a State
  • entry/action
  • The entry action is executed whenever the given
    state is entered via a transition.
  • do/activity
  • While staying in the state,
  • the activity is performed.
  • exit/action
  • The exit action is executed whether the state is
    left via a transition.
  • event/action(argument)
  • If a state responds to an event with an action
    that does not cause a transition.

entry/action do/activity exit/action event/actio
n(arguments)
Dispaching
51
State Diagram
/get first item
get next item Not all items checked
All items checked all items available
Item Received All items available
All items checked some items not in stock
Activity
Delivered
Ungarded Transition
Self-transition
transition
Item Received Some items not in stock
state
52
Superstates
  • Concept
  • When several states have common transitions, the
    states can be grouped into a superstate.
  • Then, the substates inherit any transition on the
    superstate.

53
Without Superstates
get next item Not all items checked
/get first item
All items checked all items available
Item Received All items available
All items checked some items not in stock
Delivered
cancel
Waiting
cancel
Item Received Some items not in stock
cancel
Delivered
Cancelled
54
With Superstate
superstate name
get next item Not all items checked
Active
/get first item
All items checked all items available
Item Received All items available
All items checked some items not in stock
Waiting
Delivered
Item Received Some items not in stock
cancel
Delivered
Cancelled
55
Concurrent State Diagram
  • Concept
  • If an object exhibits a combination of behaviors,
    then the associated states can be combined on a
    concurrent state diagram.
  • Concurrent state diagrams are useful when a given
    object has sets of independent behaviors.
  • Example
  • Order Processing and Payment Authorization can be
    combined.
  • The given Order object is in two different
    states.

56
Concurrent State Diagrams
  • State Diagram for
  • Payment Authorization

Authorizing do/check payment
Authorized
Rejected
Delivered
57
Concurrent State Diagrams
cancelled
Cancelled
Waiting
Checking
Dispaching
Delivered
Authorizing
Autorized
Rejected
58
Concurrent State
  • Object exhibits a combination of the behaviors
  • Order State
  • availability of items
  • payment authorization

59
Part 3Activity Diagrams
60
Concept
  • Origins
  • Event Diagram of Jim Odell, SDL State Modeling
    technique, and Petri-nets.
  • Activity
  • Conceptually, a some task to be carried out
  • Specifically, a Method on a class
  • Activity Flow
  • Flow Order of the Activities
  • Guard
  • Logical expression evaluated prior to running
    activity

61
Elements of Activity Diagram
  • Activity
  • represented with rounded box
  • Transition
  • arrow with guard, represent activity flow
  • Synchronization Bar
  • Activities under a synchronization bar occur in
    parallel, and their order is irrelevant.
  • Concurrent activities can be implemented in an
    interleaving or simultaneous fashion.
  • Decision Diamond
  • alternative to guards on separate transition
  • Start and Stop markers

62
Usage of Activity Diagram
  • Activity diagram is used to describe
  • A method
  • Complicated methods
  • One Use-case
  • Multiple use-cases

63
Example Serving Beverage
no cola
no coffee
Find Beverage
Guard
Synchronization Bar
found coffee
Decision Activity
found cola
Put Coffee in filter
Add Water to Reservior
Get Cups
Get Can of Cola
Put Filter in Machine
Activity
Turn On Machine
coffeePot.TurnOn
End
Brew Coffee
light goes out
Pour Coffee
Drink Beverage
64
Example Receive Order
  • Multiple Trigger
  • Indicate the basis
  • of the trigger

Receive Order
Multiple Trigger
For each line item on order

Cancel Order
Authorize Payment
Check Line Item
failed
in stock
succeeded
Assign to Order
Synchronization Condition
stock assigned to all line items and payment
authorized
need to reorder
Reorder Item
Dispatch Order
65
Example Receive Supply
Receive Order
Choose Outstanding Order Items
For each chosen order item
Assign Goods to Order
stock assigned to all line items and payment
authorized
all outstanding order items filled
Dispatch Order
Reorder Item
66
Example Combining two Diagrams
Receive Order
Receive Order
For each line item on order

Authorize Payment
Check Line Item
Choose Outstanding Order Items
Cancel Order
failed
in stock
Assign to Order
succeeded
For each chosen order item
Assign Goods to Order
need to reorder
Reorder Item
stock assigned to all line items and payment
authorized
all outstanding order items filled
Dispatch Order
Reorder Item
67
Swimlanes
Order Processing
Finance
Receive Order
Receive Order
For each line item on order
Stock Manager

Authorize Payment
Check Line Item
Choose Outstanding Order Items
in stock
Reorder Item
Assign to Order
For each chosen order item
Assign Goods to Order
need to reorder
Reorder Item
stock assigned to all line items and payment
authorized
all outstanding order items filled
Reorder Item
Dispatch Order
68
Part 4Deployment Diagrams
69
Concept
  • Definition
  • Deployment diagrams shows the physical
    relationships among software and hardware
    components in the target systems.
  • Node represents some kind of computation unit.
  • Often a piece of hardware
  • Connections among nodes show the communication
    paths.
  • Components represent physical modules of code.
  • Dependencies are same as package dependencies.

70
Example
Diabetes Unit Server
Object Database
Connection
Health Care Domain
Liver Unit Server
Object Domain
ltltcommunicationgtgt
Health Care Domain
Liver Unit configuration
Configure Medical Knowledge
Liver Unit Server Application
Node
Configure Unit
Configuration
Application
A Windows PC
Contained Object
Interface
Liver Unit Client Function
Component
Liver Unit Client Function
Write a Comment
User Comments (0)
About PowerShow.com
