Systems Physiology II 6010
Lecture 6 Motor system The Cerebellum
Bradley Greger, PhD
2
The Cerebellum

• The little brain

3
The Cerebellum

• Two hemispheres
• Three lobes
• Anterior
• Posterior
• Floculonodular

4
The Cerebellum

• Three layered cortex
• Molecular
• Purkinje
• Granular
• Six cell types
• Purkinje
• Granular
• Half the neurons in the brain
• Crystalline architecture
• Should be simple to figure out

5
Cerebellar purkinje cells have both simple and
complex spikes

• Simple spikes high frequency, correlated with
  ipsilateral limb movements in anterior lobe
• Complex spikes low frequency, correlated with
  error feedback

6
The Cerebellum

• Deep nuclei
• Dendate
• Emboliform
• Globose
• Fastigial
• Non-human primates
• Interpositus
• Emboliform
• Globose
• Output
• Spinal nuclei
• Thalamus

7
The Cerebellum

• Cortical Zones
• Spinocerebellum
• Intermediate Hemisphere
• Lateral Hemisphere

8
The Cerebellum

• Spinocerebellum

9
The Cerebellum

• Intermediate Cerebellum

10
The Cerebellum

• Cerebrocerebellum

11
The cerebro-cerebellar system

• Regions of cerebral cortex that give rise to
  corticopontine tract and corticorubral tract
• Regions of cerebellum that give rise to
  dentato-thalamic tract
• Closed loop architecture

12
Long-term Depression (of synapses)

• Coincidence of simple spikes and complex spikes
• Decrease efficacy of parallel fiber purkinje
  cell synapses
• NO as neurotransmitter

13
Two sensory-motor adaptation paradigms
Target-shift Adaptation
Prism Adaptation
Late
Early
Late
Early
Reaching movements Saccadic eye movements
Reaching movements
14
Typical adaptation curves
Prism Adaptation
Target Shift Adaptation
15
Short-term and long-term sensory-motor adaptation
Short-term
Long-term
Once acquired persists for years
16
The acquired sensory-motor mapping is triggered
by context
Prism glasses that shift in the opposite
direction
17
pl-Cerebellar Lesions

• Motor ataxia is the clinical hallmark of
  cerebellar lesions
• pl-cerebellum lesions little or no ataxia
  compared to anterior lobe lesions
• Impair sensory-motor adaptation

18
Electrophysiology in the cerebellum
Dorsal view of cerebellar cortex
19
Visually guided reach adaptation task
Target Appearance
Movement Start
Target Re-appearance
Screen Touched
Hand Returned
Random initial target location Targets were
shifted in eight directions Variable delay in
target reappearance (50, 75, or 150ms)
20
Simple spikes were correlated with ipsi-lateral
and contra-lateral limb reaching
Increasing Firing Rate
Decreasing Firing Rate
Monkey 1
Monkey 2
21
Simple spike population data for ipsi and contra
lateral limb reaching

• Contrasts with simple spikes in the anterior lobe
  being correlated only with ispilateral limb
  movement

22
Simple spikes correlated with movement parameters
irrespective of limb
All findings in pl-cerebellum were present
irrespective of limb used for movement
23
Simple spike firing was different on success
versus failure trials
Touch Location on Screen
Success-failure signal
Not correlated with distance
Touch Location Relative to Target
24
Success-failure signal appeared approximately
200ms after screen touch
Receiver operating characteristic (ROC)
analysis Gamma probability that an ideal
observer could discriminate two signals
25
Complex spike peaks on target appearance (T1)
De-adaptation
Adaptation
Pre-adaptation
26
Complex spike peaks on target reappearance (T2)
Adaptation
De-adaptation
Pre-adaptation
Complex spike firing rate constant throughout
adaptation
Norris, Greger, Hathaway, Thach 2004
27
T1 and T2 complex spike peaks time locked to
visual stimuli not reach
28
T1 complex spike peak related to target location
on screen
Pre-adaptation Trials
Touch relative to target
Target on screen
Touch on screen
ni number of locations with T1 CS in quadrant i
N total number of location with CS mi
number of locations in quadrant i M total
number of locations
29
T2 complex spike peak related to target shift
direction
Adaptation Trials
Touch relative to target
Target on screen
Touch on screen
30
Direction tuning of T1 and T2 complex spike peaks
correlated
Retinotopic encoding of off-gaze visual targets
31
Complex spikes influence simple spike firing rates

• Adaptation SS and CS

• Pre-adaptation SS and CS

32
Cerebro-cerebellar interactions
Cerebral plasticity
Cerebellar plasticity
