Programming for Geographical Information Analysis: Core Skills

1
Programming for Geographical Information
AnalysisCore Skills

• Lecture 9Core Packages
• Images and Drawing

2
This lecture

• Colour
• Images
• Drawing
• IDEs

3
Background

• You can change the background colour of any
  container with
• someObject.setBackground(someColor)
• Here someColor is a object of type
  java.awt.Color.
• Note the US spelling.

4
Color

• Comes with static types you can use
• setBackground(Color.RED)
• Or you can set them up with RGB (red, green,
  blue) values between 0 and 255
• Color red new Color(255,0,0)
• setBackground(red)
• Theres actually also a transparency (alpha
  RGBA) level you can set, but anything other than
  0 (clear) and 255 (opaque) is poorly supported.
• Color red new Color(255,0,0,255)
• There are also options for using hue, saturation,
  brightness (HSB) instead.

5
Common colours

• new Color (255,0,0) Red
• new Color (0,255,0) Green
• new Color (0,0,255) Blue
• new Color (0,0,0) Black
• new Color (127,127,127) Medium grey
• new Color (255,255,255) White
• Note that whenever the values are the same, you
  get greyscale.

6
Color methods

• If we get a Color object, e.g. from an image, we
  can find out the RGB values thus
• int r ourColor.getRed()
• int g ourColor.getGreen()
• int b ourColor.getBlue()

7
This lecture

• Colour
• Images
• Drawing
• IDEs

8
Images

• Images are stored in java.awt.Image objects.
• Read them from files using a javax.imageio.ImageIO
  .
• Make them yourself.

9
Images

• Main way of making them from scratch is with a
  java.awt.image.MemoryImageSource object.
• A MemoryImageSource object takes in an int
  array and turns it into an image in memory
• MemoryImageSource(int width, int height,
• int pixel, int arrayStart, int scanLineWidth)

10
Making Images from data

• We can create the pixel array ourselves. Pixels
  are made up of RGBA data. Again, each is 0 to
  255.
• The array is 1D as this is more efficient to
  dynamically process.
• However, why is it just one array, not four?
• With a bit of clever computing, we can squeeze
  all four RGBA values into one super-efficient
  array.

11
Packed ints

• If we take four int values of up to 255
• 00000000 00000000 00000000 00000001 int 1
• 00000000 00000000 00000000 11111111 int 255
• 00000000 00000000 00000000 01111111 int 127
• 00000000 00000000 00000000 11111111 int 255
• All this space is wasted.
• What we really need to do is this
• 00000001 int 1
• 00000000 11111111 int 255
• 00000000 00000000 01111111 int 127
• 00000000 00000000 00000000 11111111 int 255
• 00000001 11111111 01111111 11111111 compressed
  weirdness

12
Making pixels the hard way

• So thats what we do.
• You can do this very efficiently, using a series
  of bitwise operators Java has for interacting
  with bits.
• This is about as much fun as being continually
  kicked in the groin by a battery of mules.

13
Making pixels the easy way

• The Color class has methods to help change 0?255
  r, g, and b values into a packed int
• Color color new Color(r,g,b)
• int packedInt color.getRGB()
• You can also make a Color object using a packed
  int
• Color color new Color(packedInt)

14

• int width 16
• int height 16
• int pixels new intwidth height
• for (int h 0 h lt height h)
• for (int w 0 w lt width w)
• int value 0
• Color pixel new Color(value,value,value)
• pixels(hwidth) w pixel.getRGB()

15

• int width 16
• int height 16
• int pixels new intwidth height
• for (int h 0 h lt height h)
• for (int w 0 w lt width w)
• int value (w h gt 255) ? 255 w h
• Color pixel new Color(value,value,value)
• pixels(hwidth) w pixel.getRGB()

16

• int width 16
• int height 16
• int pixels new intwidth height
• for (int h 0 h lt height h)
• for (int w 0 w lt width w)
• int value datahw
• Color pixel new Color(value,value,value)
• pixels(hwidth) w pixel.getRGB()
• Must re-range our data between 0 and 255 if below
  or above this.

17
Using MemoryImageSource

• With the array of pixels we can build the
  java.awt.image.MemoryImageSource.
• Encapsulates an image in the computers memory.
• Computers can have multiple output devices on
  which an image is displayed, so this doesnt
  represent a displayed image. To do this, we need
  to use a Component to convert it. They know about
  the display.
• MemoryImageSource memImage
• new MemoryImageSource(16,16,pixels,0,16)
• Panel panel new Panel()
• Image image panel.createImage(memImage)
• Well see how to draw the image in a bit.

18
Sequence

• Get an image array.
• Create a MemoryImageSource object.
• Create an Image object.

19
Making Images PixelGrabbers

• If we have an Image and we want the pixels, we
  can use a java.awt.image.PixelGrabber.
• The PixelGrabber object does the exact opposite
  of MemoryImageSource.
• PixelGrabber(Image img, int left, int top, int
  width, int height, int pixels, int startArray,
  int scanLineWidth)
• int pixels new int 100
• PixelGrabber pg
• new PixelGrabber(image,0,0, 16,16,
  pixels,0,16)
• pg.grabPixels()

20
Putting it all together

• We now have all the methods we need to build a
  small image processor
• First we get an image.
• Then we use a pixelGrabber to pull the pixels
  into an array.
• We then expand the pixels into their alpha, red,
  green and blue values.
• We manipulate the values for example filtering
  the data.

21
Putting it all together

• We then recode the values into the int array.
• We use a MemoryImageSource to put the pixels back
  in an Image.
• We draw the image on the screen.
• We then run to the pub and drink ourselves
  unconscious to celebrate being geek
  gods/goddesses unfettered by the mere trifling
  difficulties of everyday human beings.

22
This lecture

• Colour
• Images
• Drawing
• IDEs

23
Drawing on components

• All containers have a graphics context which is
  encapsulated in a Graphics class object.
• We can get the Graphics object and use its
  methods to draw
• Frame f new Frame()
• Graphics g f.getGraphics()
• g.drawline(0,0,300,200) // x1, y1, x2, y2
• g.dispose()
• or, if were in the frame class...
• Graphics g getGraphics()
• g.drawline(0,0,300,200)
• g.dispose()
• All graphics are relative to the upper left
  corner (0, 0).
• If drawings stray outside the Components size,
  theyre clipped automatically (i.e. theyre
  stopped at the edges).

24
Displaying an Image

• We can then use a Graphics objects drawImage
  method to draw the image to the screen.
• drawImage(Image im, int left, int top,
  ImageObserver imob)
• g frame.getGraphics()
• g.drawImage(image,0,0,panel)
• All components implement ImageObserver. This
  interface has one method imageUpdate, which
  returns whether an image has finished loading.

25
Vector drawing methods

• drawLine(int startx, int starty, int endX, int
  endY)
• drawOval(int topLeftX, int topLeftY, width,
  height)
• drawRect(int topLeftX,topLeftY,lowRightX,lowRightY
  )
• drawPolygon(int xs, int ys, int
  numberOfPoints)
• drawPolygon closes polygons automatically.
• drawString(String str, int x, int y)
• To set the font you need a java.awt.Font class
  object.
• To get the line height etc. so you know where to
  start the next line you need a java.awt.FontMetric
  s class object.

26
Drawing on Frames

• Note that setSize() sets the total size, so you
  lose some space under the menu, side borders etc.
• You can find these insets. The following
  wouldnt be unusual
• Insets insets getInsets()
• setSize(300 insets.left insets.right,
• 300 insets.top insets.bottom)
• Or
• g.drawString(Top left text",
• getInsets().left, getFontMetrics(getFont()).getHe
  ight() getInsets().top
• )

This gets the default line height drawString
draws from y bottom of the line.
27
Colour revisited

• Note the Graphics object has a set colour
  encapsulated in a java.awt.Color object all
  lines are drawn in this.
• Background set in Components not their Graphics
  objects
• setBackground(Color colorObject)
• Graphics setXORMode(Color) - swaps present colour
  for Color if the background drawn over is the
  present colour.

28
Repaint

• The JVM calls components repaint() method when
  it feels like it (when maximized, uncovered).
• Repaint calls two methods
• update() paints the background.
• paint(Graphics g) paints the foreground.
• If we dont overwrite paint, each repaint the
  component will lose any graphics weve added as
  it repaints the default look.
• Even if you overwrite paint, call repaint() so
  update() runs.

29
Example Frame with constant text
Note that a Graphics object is passed in for you.

• import java.awt.
• public class TitlePanel extends Frame
• public void paint (Graphics g)
• g.drawString(Hello World", 100, 100)

30
This lecture

• Colour
• Images
• Drawing
• IDEs

31
Tooling Up

• When you do real programming, its unlikely
  youll do it with Notepad and the command line
  compiler.
• Youll probably use an Integrated Development
  Environment (IDE).
• These make your life easier.
• They take a little time to learn to use, but are
  worth the investment.

32
What do IDEs do?

• Usually have Syntax colouring (e.g. will colour
  keywords, strings, method names etc.) and line
  numbers, like Notepad.
• Push-button formatting.
• Usually have one-push compiling and running.
• Usually have run-time debugging stops when your
  code breaks, shows you where, and tells you the
  problem. Usually have a facility for stepping
  through code one line at a time, and watching how
  variables change. Some will highlight errors as
  you type.
• Often have auto-complete drop down lists you
  type an Objects name, and they give drop-down
  lists of the potential methods.
• Linking to other peoples code.

33
Other Functions

• Rapid Application Development (RAD)
• The software lets you draw user interfaces and
  writes the code for you. It may or may not then
  let you alter that code.
• Computer Aided Software Engineering (CASE) Tools
• CASE tools help structure the development
  process. They may contain facilities for
  generating UML, converting UML into code, and for
  seeing which classes are dependent on each other.
• UML a way of drawing code well come back to
  this.
• Profilers/Refactoring tools
• Show unused code and speed bottlenecks.
• Allow quick altering of multiple files.

34
Other Functions

• Build scripting
• Software that reads scripts that compile your
  code into different forms.
• Version and repository control
• Links to online repositories that store code and
  maintain different versions you can roll-back to.
• Native compilation
• Compilation to executables that dont rely on the
  JVM, or wrappers for code to install and run the
  JVM when appropriate.

35
Popular Java IDEs

• Free
• Netbeans (Oracle)
• http//netbeans.org/
• Eclipse (IBM)
• http//www.eclipse.org/
• JDeveloper (Oracle originally based on JBuilder
  specifically for Enterprise development)
• http//www.oracle.com/technetwork/developer- tool
  s/jdev/overview/index.html
• BlueJ (Kent Uni Basic beginners IDE)
• http//www.bluej.org/
• Commercial
• IntelliJ IDEA (JetBrains there is a free
  version)
• http//www.jetbrains.com/idea/
• JBuilder (Was Borland, now Embarcadero)
• http//www.embarcadero.co.uk/products/jbuilder

36
Netbeans
Big advantage of being built by Oracle,
therefore well tied to Java. Written in Java, so
developers can use it as the foundation for other
software and build plugins for it in Java.
37
Eclipse

• Lots of plugins for major pieces of software
  (e.g. ArcGIS).

38
Conclusions

• Find what best suits your practice.
• But have a go at both Netbeans and Eclipse so you
  can operate in both.
• Dont forget the command line and Notepad for
  quick jobs / lowest common denominator backtrack
  and old skool retro fun.

39
Practical

• Images

Next lecture
Network communications
