CSC 172 DATA STRUCTURES
2
SETS and HASHING

• Unadvertised in-store special SETS!
• in JAVA, see Weiss 4.8
• Simple Idea Characteristic Vector
• HASHING...The main event.

3
Representation of Sets

• List
• Simple O(n) dictionary operations
• Binary Search Trees
• O(log n) average time
• Range queries, sorting
• Characteristic Vector
• O(1) dictionary ops, but limited to small sets
• Hash Table
• O(1) average for dictionary ops
• Tricky to expand, no range queries

4
Characteristic Vectors

• Boolean Strings whose position corresponds to the
  members of some fixed universal set
• A 1 in a location means that the element is in
  the set
• A 0 means that it is not

5
MUSIC THEORY

• A chord is a set of notes played at the same
  time.
• Represented by a 12 bit vector called a pitch
  class
• B,A,A,G,G,F,F,E,D,D,C,C
• 000010010001 represents C major
• 000010001001 represents C minor
• Rotation is transposition
• Bit reversal is inversion

6
UNIX file privileges

• user, group, others x read, write, execute
• 9 possible privileges
• Type ls l on UNIX
• total 142
• -rw-rw-r-- 1 pawlicki none 76 Jun 20
  2000 PKG416.desc
• -rw-rw-r-- 1 pawlicki none 28906 Jun 20
  2000 PKG416.pdf
• -rw-rw-r-- 1 pawlicki none 1849 Jun 20
  2000 let.1
• -rw-rw-r-- 1 pawlicki none 0 Apr 2
  1303 out
• -rw-rw-r-- 1 pawlicki none 39891 Jun 20
  2000 stapp.uu

7
UNIX files

• The order is rwx for each of user (owner), group,
  and others
• So, a protection mode of 110100000 means that the
  owner may read and write (but not execute), the
  group can read only and others cannot even read

8
GAMBLING

• A deck has 52 cards
• 2C,2H,2S,2D,3C, .... KD,AC,AH,AS,AD
• Represent a hand as a vector of 52 bits
• 00000000000000000000000000000000000000000000000001
  01 is a pair of aces
• In Texas Hold'em everyone gets two hole cards
  and 5 board cards
• We can use bitwise to find hands

9
CV advantages

• If the universal set is small, sets can be
  represented by bits packed 32 to a word
• Insert, delete, and lookup are O(1) on the proper
  bit
• Union, intersection, difference are implemented
  on a word-by-word basis
• O(m) where m is the size of the set
• Small constant factor (1/32)
• Fast, machine operations

10
Hashing

• A cool way to get from an element x to the place
  where x can be found
• An array 0..B-1 of buckets
• Bucket contains a list of set elements
• B number of buckets
• A hash function that takes potential set elements
  and quickly produces a random integer 0..B-1

11
Example

• If the set elements are integers then the
  simplest/best hash function is usually h(x) x
  B or h(x) x - (xB), (never 0).
• Suppose B 6 and we wish to store the integers
• 70, 53, 99, 94, 83, 76, 64, 30
• They belong in the buckets 4, 5, 3, 4, 5, 4, 4,
  and 0
• Note If B 7 0,4,1,3,6,6,1,2

12
Pitfalls of Hash Function Selection

• We want to get a uniform distribution of elements
  into buckets
• Beware of data patterns that cause non-uniform
  distribution

13
Example

• If integers were all even, then B 6 would cause
  only buckets 0,2, and 4 to fill
• If we hashed words in the UNIX dictionary into 10
  buckets by length of word then 20 go into bucket
  7

14
Dictionary Operations

• Lookup
• Go to head of bucket h(x)
• Search for bucket list. If x is in the bucket
• Insertion append if not found
• Delete list deletion from bucket list

15
Analysis

• If we pick B to be new N, the number of elements
  in the set, then the average list is O(1) long
• Thus, dictionary ops take O(1) time
• Worst case all elements go into one bucket
• O(n)

16
Managing Hash Table Size

• If n gets as high as 2B, create a new hash table
  with 2B buckets
• Rehash every element into the new table
• O(n) time total
• There were at least n inserts since the last
  rehash
• All these inserts took time O(n)
• Thus, we amortize the cost of rehashing over
  the inserts since the last rehash
• Constant factor, at worst
• So, even with rehashing we get O(1) time ops

17
Collisions

• A collision occurs when two values in the set
  hash to the same value
• There are several ways to deal with this
• Chaining (using a linked list or some secondary
  structure)
• Open Addressing
• Double hashing
• Linear Probing

18
Chaining
Very efficient Time Wise
Other approaches Use less space
?
19
Open Addressing

• When a collision occurs,
• if the table is not full find an available space
• Linear Probing
• Quadratic Probing
• Double Hashing

20
Linear Probing

• If the current location is occupied, try the next
  table location
• LinearProbingInsert(K)
• if (table is full) error
• probe h(K)
• while (tableprobe is occupied)
• probe probe M
• tableprobe K
• Walk along table until an empty spot is found
• Uses less memory than chaining (no links)
• Takes more time than chaining (long walks)
• Deleting is a pain (mark a slot as having been
  deleted)

21
Linear Probing
h(K) K 13
Insert 18, 41, 22, 59, 32, 31, 73
h(K) 5,
22
Linear Probing
h(K) K 13
Insert 18, 41, 22, 59, 32, 31, 73
h(K) 5, 2,
23
Linear Probing
h(K) K 13
Insert 18, 41, 22, 59, 32, 31, 73
h(K) 5, 2, 9,
24
Linear Probing
h(K) K 13
Insert 18, 41, 22, 59, 32, 31, 73
h(K) 5, 2, 9, 7,
25
Linear Probing
h(K) K 13
Insert 18, 41, 22, 59, 32, 31, 73
h(K) 5, 2, 9, 7, 6,
26
Linear Probing
h(K) K 13
Insert 18, 41, 22, 59, 32, 31, 73
h(K) 5, 2, 9, 7, 6, 5,
27
Linear Probing
h(K) K 13
Insert 18, 41, 22, 59, 32, 31, 73
h(K) 5, 2, 9, 7, 6, 5,
28
Linear Probing
h(K) K 13
Insert 18, 41, 22, 59, 32, 31, 73
h(K) 5, 2, 9, 7, 6, 5,
29
Linear Probing
h(K) K 13
Insert 18, 41, 22, 59, 32, 31, 73
h(K) 5, 2, 9, 7, 6, 5,
30
Linear Probing
h(K) K 13
Insert 18, 41, 22, 59, 32, 31, 73
h(K) 5, 2, 9, 7, 6, 5,
8
31
Linear Probing
h(K) K 13
Insert 18, 41, 22, 59, 32, 31, 73
h(K) 5, 2, 9, 7, 6, 5,
8
73
32
Double Hashing

• If the current location is occupied, try another
  table location
• Use two hash functions
• If M is prime, eventually will examine every
  location
• DoubleHashInsert(K)
• if (table is full) error
• probe h1(K)
• offset h2(K)
• while (tableprobe is occupied)
• probe (probeoffset) M
• tableprobe K
• Many of the same (dis)advantages as linear
  probing
• Distributes keys more evenly than linear probing

33
Quadratic Probing

• Don't step by 1 each time. Add i2 to the h(x)
  hashed location (mod B of course) for i 1,2,...

34
Double Hashing
h1(K) K 13 h1(K) 8 - K 8
Insert 18, 41, 22, 59, 32, 31, 73
h1(K) 5, 2, 9, 7, 6, 5,
8
h2(K) 6, 7, 2, 5, 8, 1,
7
35
Double Hashing
h1(K) K 13 h1(K) 8 - K 8
Insert 18, 41, 22, 59, 32, 31, 73
h1(K) 5, 2, 9, 7, 6, 5,
8
h2(K) 6, 7, 2, 5, 8, 1,
7
31
36
Double Hashing
h1(K) K 13 h1(K) 8 - K 8
Insert 18, 41, 22, 59, 32, 31, 73
h1(K) 5, 2, 9, 7, 6, 5,
8
h2(K) 6, 7, 2, 5, 8, 1,
7
31
73
37
Theoretical Results
38
Expected Probes
1.0
0.5
1.0
