Title: Performance Engineering


1
Performance Engineering
  • Bob Dugan, Ph.D.
  • Computer Science Department
  • Rensselaer Polytechnic Institute
  • Troy, New York 12180

2
The Nightmare Scenario
  • Product pre-sold by marketing as carrier scalable
  • Demos are flashy, fast and successful
  • Product is supposed to ship to big name customers
    like GM, Fidelity, and ATT a week after QA
  • During QA product is performance tested
  • Performance tests uncover serious scalability
    problems
  • Analysis shows a fundamental architecture flaw
  • Months of redesign and testing necessary to fix

3
Overview
  • Background
  • Methodology
  • Resources

Incorporate performance into softwares entire
life cycle to achieve performance goals.
4
Background
What is software performance?
5
Background
Response Time
Resource Utilization
Throughput
6
Background Response Time
  • How long does it take for a request to execute?
  • Example
  • Web page takes 100ms to return to browser after
  • request.
  • Interactive applications require 2000ms or less.
  • Tells us a lot about how system is performing.
  • Response time has big impact on the holy grail
  • of performance THROUGHPUT.

7
Background Throughput
  • How many requests per second can be processed?
  • Example
  • A server has throughput of 30 requests/sec
  • Supports roughly 1 million requests/10 hour day
  • Assume average user makes 10 requests/day
  • Server will support approximately 100,000 users
  • Inverse of response time on lightly loaded
    system.
  • Combined with user model, can be used for
  • performance requirements, capacity planning,
  • sales, and marketing.

8
Background Resource Utilization
  • Resources consumed by code processing request.
  • Examples CPU, memory, network, disk
  • In a closed system, as load increases
  • Throughput rises linearly
  • Resources are consumed
  • Response time remains near constant
  • When a resource is completely consumed
  • Throughput remains constant
  • Resource utilization remains near constant
  • Response time rises linearly with load

9
Background Resource Utilization
Virtual Users Response Time Throughput CPU Utilization
1 100ms 10 req/sec 25
2 110ms 19 req/sec 53
4 130ms 38 req/sec 96
8 300ms 37 req/sec 98
16 640ms 39 req/sec 99
  • Resource utilization is critical to determining
    throughput/response time relationships.
  • During performance testing, resource utilization
    helps identify the cause of a performance
    problem.

10
Performance Engineering Methodology
  • Incorporate performance into softwares entire
    life cycle to achieve performance goals.

11
Software Life Cycle
Requirements
Specification
Design
Implementation
Integration
Test
Release
Maintenance
12
Requirements
  • Functional requirements identified.
  • What are the performance requirements?
  • Do any functional requirements interfere with
    performance requirements?

13
Performance Requirements
  • What is the capacity planning guide for the
    system?
  • How much is a customer willing to pay for
    performance and scalability?
  • Hardware
  • Software licensing (e.g. OS, Oracle, etc.)
  • System Administration

14
Example Internet Bank
  • View accounts
  • Search for specific transaction
  • Transfer money between accounts
  • Export account to Quicken
  • 10 million potential users

15
Performance Model
  • Make some assumptions (refine later)
  • Three tier system browser, web farm, database
    server
  • Database updated nightly with days transactions
    (e.g. read mostly)
  • User logs in once per 5 day work week, between
    8AM-6PM EST
  • Logins evenly distributed
  • Typical user does 3 things, then logs off
  • About 20 of customers will actually use online
    banking

16
Performance Model
10,000,000 users x 20 adoption rate 2,000,000
users/week 2,000,000 x 3 requests per user
6,000,000 requests/week 6,000,000 / 5 day work
week 1,200,000 requests/day 1,200,000 / 10
hour day 120,000 requests/hour 120,000 / 60
minutes per hour 2000 requests / minute 2000
/ 60 seconds per hour
33 requests per second
17
Performance Model
18
Performance Requirements
  • The customer wants to pay as little as possible
    for the system hardware.
  • Your company wants the system to perform well,
    but theres a development cost.
  • YOU must find the balance.
  • What are reasonable service times and throughput
    for web and database servers?

19
Performance Requirements
Description Time Throughput
Web/App Service Time lt 1000 ms 1 req/sec per processor
Database Service Time lt 100 ms 10 req/sec per processor
Total Response Time lt 1100 ms 33 req/sec
20
Requirements
Goal Identify/eliminate performance problems
before they get into Functional/Design/UI
specifications.
21
Functional/Design/UI
Goal Eliminate performance problems before
writing a line of code. Example Requirements
say that users should be able to search on
account activity using any combination of
activity fields (e.g. date, payee, amount,
check). Functional/Design specification
describes an ad-hoc query mechanism with
pseudocode that allows users to conduct this
search using a single database query. Performance
analysis of prototype ad-hoc query shows a
throughput of 2 req/sec with 100 CPU utilization
on a two processor database server.
22
Prototyping
  • Great time to play
  • Investigate competing architectures
  • Dont forget performance!
  • Example HTML Tag Processing Engine for Internet
    Bank
  • Initial performance analysis showed 5 tags/sec.
    Web server CPU 100. Dependency on size of page.
  • Second iteration improved to 20 tags/sec. Still
    too slow! Service time allotted completely
    consumed by tag processing.
  • Third iteration at 60 tags/sec. No page size
    dependency.

23
Implementation
Goal Identify and eliminate performance
problems before they are discovered in QA.
  • Long duration
  • Break into drops
  • Performance assessment of drops
  • Track progress
  • A maturing system increases in complexity and
    jeopardizes performance
  • Use instrumentation!

24
Instrumentation
  • Code must be instrumented by development
  • Allows self-tuning
  • Provides execution trace for debugging
  • Aids performance analysis in lab
  • Useful for monitoring application in production

25
Example Instrumentation
Sample code
sub unitTest eCalMetrics-gtnew()-gtpunchIn()
my tableName my result
tableSelect("users") print result."\n"
eCalMetrics-gtnew()-gtpunchOut()
Activating instrumentation
eCalMetrics-gtnew()-gtsetEnabled("true") eCalMe
trics-gtnew()-gtsetShowExecutionTrace("true") unitT
est
Sample instrumentation output
PUNCHIN eCalMetricsTableStatisticsDBunitTest
PUNCHIN eCalMetricsTableStatisticsDBtab
leSelect PUNCHIN eCalOracleprepare
PUNCHOUT eCalOracleprepare
131.973028182983 msecs PUNCHOUT
eCalMetricsTableStatisticsDBtableSelect
642.809987068176 msecs PUNCHOUT
eCalMetricsTableStatisticsDBunitTest
643.355011940002 msecs
26
Testing
Goal Identify and eliminate performance
problems before they get into production.
  • Performance testing and analysis must occur
    throughput development!!!
  • In late cycle QA, should be a formality with no
    surprises.
  • A surprise at this point will delay product
    release or potentially kill a product.

27
Maintenance
Goal Identify and eliminate performance
problems before they are detected by users.
  • Management console for resource monitoring
  • Metrics pages
  • Instrumentation

28
Conclusion
Incorporate performance into softwares entire
life cycle to achieve performance goals.
29
Resources Books
  • Smith/Williams, Software Performance
    Engineering
  • Jain, The Art of Computer Systems Performance
    Analysis
  • Tannenbaum, Modern Operating Systems
  • Elmasri/Navathe, Fundamentals of Database
    Systems
  • Baase, Computer Algorithms An Introduction to
    Design and Analysis

30
Resources Software
  • Resource Monitoring
  • Task Manager, Perfmon
  • Sar/iostat/netstat/stdprocess, SE Toolkit
  • BMC Best/1, HP OpenView, Precise Insight
  • Load Generation
  • LoadRunner, SilkPerformer
  • Webload
  • Automated Instrumentation
  • Numega True Time, Jprobe
  • Tkprof, Explain Plan, Precise In Depth for Oracle

31
Resources Literature/Web
  • www.perfeng.com - Dr. Connie Smiths Website
  • www.spec.org - Benchmarks for computer hardware
  • www.tpc.org - Benchmarks for databases
  • Computer Management Group annual conference in
    December.
  • Workshop on Software Performance semi-annual
    conference in late summer/early fall
  • ACM SIGMETRICs annual conference in early
    summer.
  • ACM SIGSOFT/SIGMETRICS publications
    periodically feature papers on performance
    engineering.

32
Case Studies
33
Case Study Microsoft VBScript
  • Website uses IIS, Microsoft ASP, VBScript
  • Critical page takes 3000 ms, CPU bound
  • Instrumentation shows 2500 ms in a single
    subroutine
  • Subroutine executed just before html returned to
    browser
  • Approximate size of HTML page is 64K
  • resp resp ltulgt
  • I0
  • while (IltMAX)
  • resp resp ltligt List Element I
    oneKString
  • resp resp lt/ulgt

34
Case Study Microsoft VBScript
MAX Response Time Average Time per Iteration
10 10ms 1ms
100 800ms 8ms
1000 50000ms 50ms
10000 2,000,000ms 200ms
  • The more the loop iterates, the longer each
    iteration takes.
  • VBScript does not support string concatenation
  • Each string operation results in a malloc(),
    copy, and free which is dependent on the current
    size of the html string
  • Why is that so bad?

35
Case Study Microsoft VBScript
?
n
oneK string malloc()
cost of malloc()
I 1
Sn 1 2 (n-1) n Sn n
(n-1) 2 1 2Sn (n1) (n1)
(n1) (n1) Sn n(n1)/2
36
Case Study Microsoft VBScript
Solutions?
