Exclusive Meson Production with EIC
Tanja Horn (JLab) Antje Bruell (JLab) Garth Huber
(University of Regina) Christian Weiss (JLab)

• EIC Collaboration Meeting, Hampton University,
• 19-23 May 2008

2
Outline

• Exclusive processes physics motivation
• Cross section parameterization
• Monte Carlo simulations input for detector
  design
• L/T separations and the pion form factor

3
Exclusive Processes Physics motivation

• Study of high-Q2 exclusive processes essential
  part of physics program for ep collider
• Reaction mechanism QCD factorization
• Information about GPDs, meson wave functions
  (baryon/meson structure)

• Experimental challenge
• Small cross sections, s(mesonN) 1/Q8
• Detection of the recoil nucleon
• Differential measurements in x, Q2, t
• cf. GPD White Paper for NSAC Long-Range Plan,
  presented at Rutgers Town Meeting Jan-07

4
Exclusive Processes Collider Energies
5
Exclusive Processes EIC Potential and Simulations
6
1H(e,ep)n at EIC Cross Section Parameterization
7
MC Simulations

• Rate predictions including simulations of the
  detector restrictions
• Input for detector design
• Momentum and angular distributions for various
  particles
• Case studies
• H(e,ep)n
• H(e,ep)p
• H(e,eK) ?

8
Exclusive MC Generator

• Exclusive EIC Monte Carlo
• Based on HERMES GMC
• New event generator using standard cernlib
  functions
• Includes cross section model by Ch. Weiss model
  for p production
• Can be easily extended to other channels, e.g.
  p, K? etc.

• MC agrees with fixed target data from Jlab

9
1H(e,ep)n Momentum and Angular Distributions
neutrons
electrons
p

• Kinematically, electrons and pions are separated

Q2gt1 GeV2

• The neutron is the highest energy particle and is
  emitted in the direction of the proton beam

p
n
10
1H(e,ep)n Scattered Electron

• Most electrons scatter at angles lt25
• BUT access to the high Q2 region of interest for
  GPD studies requires larger electron angles

11
1H(e,ep)n Scattered Neutron

• Low t neutrons are emitted at very small angles
  with respect to the beam line, outside the main
  detector acceptance
• A separate detector placed tangent to the proton
  beam line away from the intersection region is
  required

12
1H(e,ep)n Scattered Pion
Q2 (GeV2)
P (GeV)
Pion Lab Angle (deg)
Pion Lab Angle (deg)

• The pion cross section is peaked in the direction
  of the proton
• At larger Q2 pion angles and momenta are smaller
• within the capability of the detector (pp and Q2
  are uncorrelated)
• provide good missing mass resolution

13
Event Topologies

• The most straightforward way to assure
  exclusivity of the 1H(e,ep)n reaction is by
  detecting the recoil neutron
• The neutron acceptance is limited to lt0.27 by a
  magnet aperture close to the interaction point

• Alternatively, the neutron can be reconstructed
  from missing momentum
• Missing mass resolution has to be good enough to
  exclude additional pions

14
Rates and coverage in different Event Topologies
Assume 100 days, Luminosity10E34
Detect the neutron
Missing mass reconstruction
10ltQ2lt15
10ltQ2lt15
15ltQ2lt20
15ltQ2lt20
35ltQ2lt40
35ltQ2lt40
G ds/dt (ub/GeV2)
G ds/dt (ub/GeV2)
0.02ltxlt0.05
0.05ltxlt0.1
0.01ltxlt0.02
0.05ltxlt0.1
-t (GeV2)
-t (GeV2)

• Neutron acceptance limits the t-coverage
• The missing mass method gives full t-coverage for
  xlt0.2

Assume dp/p1 (pplt5 GeV)
15

• At higher energies, the missing mass resolution
  deteriorates, so need to detect the neutron
• At lower energies, the missing mass
  reconstruction works well, but neutron detection
  is more difficult
• With Ee5 GeV and Ep 50 GeV can ensure
  exclusivity over the full region in (x,-t, Q2)
  using a combination of the two methods
• Overlap region between the two methods allows for
  cross checks

16
Systematic uncertainty on the rate estimate
Assume 100 days, Luminosity10E34
10ltQ2lt15
15ltQ2lt20
35ltQ2lt40

• Data rates obtained using two different
  approaches are in reasonable agreement
• Ch. Weiss Regge model
• T. Horn p empirical parameterization

0.02ltxlt0.05
0.05ltxlt0.1
0.01ltxlt0.02
17
Statistical uncertainty in the measurement
Assume 100 days
Luminosity 1031
G ds/dt (ub/GeV2)

• High luminosity is essential to achieve the
  experimental goals

18
1H(e,ep)p Momentum and Angular Distributions
Photon from p decay
electrons
p
protons

• Similar to p, but additional complication due to
  photons from p decay

Q2gt1 GeV2

• p decay photon opening angle places a constraint
  on the calorimetry

p
2? opening angle
tlt1GeV2
19
1H(e,ep)p p Decay Photons
1 ? 35mm / 2m

• Opening angle is small and requires fine
  calorimeter granularity
• JLab/BigCal 38x38mm, H1 forward calorimeter
  35x35mm
• High energy photons at large angles can be
  detected
• At high momentum, charged particles are difficult
  to measure

20
1H(e,eK)? Momentum and Angle Distributions
Assume 100 days, Luminosity10E34

• Kinematics overall similar to the pion case
• Some p- from ? decay might be detected in an
  outbending toroidal field

?
21
Rate estimate for K?
15ltQ2lt20
10ltQ2lt15
35ltQ2lt40

• Using an empirical fit to kaon electroproduction
  data from DESY and JLab

0.01ltxlt0.02
0.02ltxlt0.05
0.05ltxlt0.1
22
1H(e,ep)n L/T Separation Experiments

• Pion Form Factor, Fp(Q2)
• Excellent opportunity for studying the QCD
  transition from effective degrees of freedom to
  quarks and gluons.
• i.e. from the strong QCD regime to the hard QCD
  regime.
• 2. Longitudinal Photon, Transverse Nucleon
  Single-Spin Asymmetry, A-p
• Especially sensitive to spin-flip GPD which
  can only be probed via hard exclusive
  pseudoscalar meson production.
• 3. QCD and GPD scaling tests
• Scan vs Q2 at fixed xB to test Hard QCD scaling
  predictions
• sL1/Q6, sT1/Q8
• Scan sL vs xB at fixed Q2 to distinguish pole and
  axial contributions in GPD framework.

23
Determination of F? via Pion Electroproduction
At low Q2lt0.3 GeV2, the ? form factor can be
measured exactly using high energy ? scattering
from atomic electrons. ? F? determined by the
pion charge radius 0.6570.012 fm.

• To access higher Q2, one must employ the
  p(e,e?)n reaction.
• the t-channel process dominates ?L at
• small tlt0.02 GeV2.

In the actual analysis, a model incorporating the
? production mechanism and the spectator
nucleon is used to extract F? from ?L.
24
L/T separations in exclusive p production

• Cross Section Extraction
• Determine sT e sL for high and low e
• Isolate sL, by varying photon polarization, e

Ee3 GeV Ep5 GeV
e0.64
e0.40
Ee5 GeV Ep2 GeV

• L/T separations require sufficiently large ?e to
  avoid magnification of the systematic uncertainty
  in the separation

• Requires special low energies for at least one e
  point and cannot be done with the standard EIC

25
Different accelerator mode

• The ability to use 5-15 GeV protons will allow
  many high priority L/T-separation experiments
  which are otherwise not possible.
• The proton accelerator needs a mode where the
  injector is not run to its full energy.
• This beam is injected into the main proton
  accelerator, which is used as a storage ring.
• The costs to implement this low energy mode will
  be reduced if this flexibility is included at the
  planning stage.
• Achieving the high luminosity required for this
  experiment may not be possible

26
Recoil Polarization Technique

• In parallel kinematics can relate sL/sT to recoil
  polarization observables

• From R and the simultaneous measurement of s0 one
  can obtain sL

• Requires only one epsilon setting
• Polarized proton beam
• Additional model assumptions needed in general if
  the reaction is not elastic

27
Kinematic Reach (Pion Form Factor)

• Assumptions
• High e 5(e-) on 50(p).
• Low e proton energies as noted.
• ?e0.22.
• Scattered electron detection over 4p.
• Recoil neutrons detected at ?lt0.35o with high
  efficiency.
• Statistical unc ?sL/sL5
• Systematic unc 6/?e.
• Approximately one year at L1034.

Preliminary
Excellent potential to study the QCD transition
nearly over the whole range from the strong QCD
regime to the hard QCD regime.
28
Projected uncertainties for Q-n scaling
EIC Ee5 GeV, Ep50 GeV
Preliminary

• Transition region 5-15 GeV2 well mapped out even
  with narrow fixed x and t
• careful with detector requirements

29
Outlook

• Extend studies to vector mesons
• Resolution studies
• Test additional requirements from e.g. p and K?
• At high energies, calorimeter granularity needs
  to be better than 35x35mm
• Requirements on magnets, e.g. toroidal fields for
  KL

30
Summary

• High Q2 studies of exclusive processes are an
  essential part of the physics program for an ep
  collider
• For beam energy 5 on 50 two methods are available
  to ensure exclusivity over the full range in
  (x,-t,Q2)
• At high energies, need a separate detector
  tangent to proton direction to detect the
  exclusive final state limited acceptance
• At low energies, missing mass reconstruction
  works well
• Overlap in certain kinematic regions allows for
  cross checks between the two methods
• High luminosity (10E34) is essential for these
  studies

31
Other
32
1H(e,ep)n Momentum and Angular Distributions

• Kinematically, electrons and pions are separated

p
neutrons
electrons
Q2gt1 GeV2

• The neutron is the highest energy particle and is
  emitted in the direction of the proton beam

p
n
33
1H(e,ep)p p Decay Photons
6 on 15
Opening Angle (deg)
Opening Angle (deg)
3 on 30
5 on 50
10 on 250
p Lab Angle (deg)

• Separating the p decay photons is getting more
  difficult as the energy increases, but recall
  that pion momenta are low at high Q2

34
Systematic uncertainty on the p rate estimate
10ltQ2lt15
15ltQ2lt20

• Data rates obtained using two different
  approaches are in reasonable agreement
• Ch. Weiss sT from Regge model
• T. Horn sT from p empirical parameterization

35
Missing Mass Resolution
Assume dp/p0.5
36
Longitudinal Photon, Transverse Nucleon
Single-Spin Asymmetry, A-p
where ds is the exclusive p(e,ep)n cross
section using longitudinal photons ß is the angle
between the proton polarization vector and the
reaction plane.

• Measure A-p to access the spin-flip GPD
• Requires a transversely polarized proton beam,
  and an L/T-separation.
• The asymmetry vanishes in parallel kinematics, so
  the p must be detected at ?pqgt0, -t up to 0.2Q2.

A.V.Belitsky, hep-ph/0307256

• A-p vs xB
• LO
• Q24
• Q210

37
QCD Scaling Tests

• To access physics contained in GPDs, one is
  limited to the kinematic regime where hard-soft
  factorization applies
• No single criterion for the applicability, but
  tests of necessary conditions can provide
  evidence that the Q2 scaling regime (partonic
  picture) has been reached

• One of the most stringent tests of factorization
  is the Q2 dependence of the p electroproduction
  cross section
• sL scales to leading order as Q-6
• sT scales as Q-8
• As Q2 becomes large sL gtgt sT

Factorization
Q2 ?

• Factorization theorems for meson
  electroproduction have been proven rigorously
  only for longitudinal photons Collins,
  Frankfurt, Strikman, 1997

38
Low e data from Jlab12?
JLAB Ee12
EIC Ee5 GeV, Ep50 GeV
e0.99
e0.3-0.7

• L/T separations at EIC will benefit from Jlab12
  measurements
