MSc Business Improvement Knowledge Management

1

Introduction to XML Part 2
2
Related Standards

• XML documents and DTDs provide foundation for an
  Internet document paradigm do not provide all
  necessary features!
• Need for XML standards (some of which are still
  under development)

3
Standard Efforts
4
XML Namespaces -

• XML is based on elements, each is distinguished
  by unique element name
• Applications process a document they associate
  element content with corresponding element name
• Naming collisions are problematic for example
  both Accounting and Fullfillment applications use
  term status to signify different meanings
• Using XML Namespaces developers can qualify the
  use of status element in reconciliation document

5
XML Namespaces - Example

• ltacctcustomer xmlnsaccthttp//www.foocompany.c
  om/names/acct-REV10gt
• ltacctnamegtBar Corporationlt/acctnamegt
• ltacctaddresseegtAccounts Payable Bar
  Corporationlt/acctaddresseegt
• ltacctorder acctreference5566-1010gt
• ltacctstatusgtinvoicelt/acctstatusgt
• lt/acctordergt
• lt/acctcustomergt
• ltfulcustomer xmlnsfulhttp//www.foocompany.com
  /names/ful-REV10gt
• ltfulnamegtBar Corporationlt/fulnamegt
• ltfuladdresseegtLoading Docklt/fuladdresseegt
• ltfulorder fulreferenceA98755656gt
• ltfulstatusgtshippedlt/fulstatusgt
• lt/fulordergt
• lt/fulcustomergt

6

• Namespaces attached to element/attribute with
  colon
• First time use namespace, associate namespace
  prefix with namespace name use reserved XML
  attribute xmlns
• xmlnsacct
• xmlnsful
• Repetition?

7
Default Namespace

• ltcustomer xmlnshttp//www.foocompany.com/names/a
  cct-REV10gt
• ltnamegtBar Corporationlt/namegt
• ltaddresseegtAccounts Payable Bar
  Corporationltaddresseegt
• ltorder reference5566-1010gt
• ltstatusgtinvoicelt/statusgt
• lt/ordergt
• lt/customergt
• ltcustomer xmlnshttp//www.foocompany.com/names/f
  ul-REV10gt
• ltnamegtBar Corporationlt/namegt
• ltaddresseegtLoading Docklt/addresseegt
• ltorder referenceA98755656gt
• ltstatusgtshippedlt/statusgt
• lt/ordergt
• lt/customergt

8
XML Linking Language - XLink

• Similar to HTML linking but XLink enables people
  to specify links with multiple target documents
  by using XLink namespaces
• Two forms simple and extended

9
Simple XLink

• ltBarCorpLink
• xlinkformsimple
• xlinkinlinetrue
• xlinkrefhttp//www.foocompany.com/customers/bar
  corp.xml
• xlinkrolelink record
• xlinktitleBar Corporation
• xlinkshownew
• xlinkactuateuser
• xlinkcontent-rolelink BarCorp record
• xlinkcontent-titleLink to Bar Corporation
  Customer RecordgtBar Corporation
• lt/BarCorpLinkgt

10
Extended XLink

• ltBarCorpOrderTrackingLink
• xlinkformextended
• xlinkinlinefalse
• xlinkroletrack order
• xlinkcontent-roletrack BarCorpgt
• ltInvoice
• xlinkformlocator
• xlinkhrefBarCorpInvoice.xml
• xlinktitleBar Corporation Invoice
• xlinkactuateuser/gt
• ltShipment
• xlinkformlocator
• xlinkhrefBarCorpShipment.xml
• xlinktitleBar Corporation Shipment
• xlinkactuateuser/gt
• lt/BarCorpOrderTrackingLinkgt

11
Extensible Stylesheet Language - XSL

• Used for formatting document display
• Three primary requirements for solution
• Apply formatting rules to elements
• Usable with different display technologies
• Document consumer may control application of
  stylesheets
• Define formatting templates that apply to an
  element and its subelements
• Select particular elements by using xsl
  namespace
• Instructions for formatting use fo namespace
• Common practice is to use XSL template syntax but
  directly insert HTML tags XSL is used simply as
  transformation language (source doc HTML)

12
XSL Example

• ltxsltemplate matchaddress
• ltfoblockgt
• fofont-sizelarge
• fofont-weightbold
• fofont-familyArial
• foline-height2
• ltxslappy-templates/gt
• lt/foblockgt
• lt/xsltemplategt
• ltxsltemplate matchaddress_at_ADDTYPEshipgt
• ltfoblockgt
• fofont-sizesmall
• fofont-weightnormal
• fofont-familyTimesl
• foline-height1
• ltxslappy-templates/gt
• lt/foblockgt
• lt/xsltemplategt

13
XSL Transformations - XSLT

• XSLT is used to transform data from one format to
  another
• Used when two companies want to exchange same
  information but apply own internal DTD
• Provides mechanism to support customised data
  flow delivers data to each application in
  format it desires

14
XSLT Example

• Ex 1
• ltorder currencyUSDgt
• lt/ordergt
• Ex 2
• ltordergt
• ltcurrencygtUSDlt/currencygt
• lt/ordergt

15
XSLT code

• ltxsltemplate match/gt
• ltxslfor-each selectorder
• ltordergt
• ltcurrencygt
• ltxslvalue-of select_at_currency/gt
• lt/currencygt
• lt/ordergt
• lt/xslfor-eachgt
• lt/xsltemplategt

16
XML Schema

• Using XML Schema instead of DTDs to specify the
  content of XML documents offers advantages of
  using XML syntax and enforcing datatype
  restrictions on element content and attribute
  values
• Additional features to DTD, such as ability to
  define recurring blocks of elements or attributes
  once and then reuse definition many times

17
XML Tools
Applications
Content Management Tools
Authoring Tools
Web Infrastructure
Development Tools
Fundamental Components
Relationship of Major Tools
18
Fundamental Components

• Determining factor of XMLs success is
  availability of fundamental software components
  that provide processing documents and related
  standards
• XML parsers typically embedded in applications.
  It reads in physical files associated with a
  document and converts the document text into
  programming constructs accessible to application
  logic
• Tree Based
• Event Based

19
Tree-based Parser
XML DTD
Document Tree
Uses App Prog Interface (API)
Tree-Based Parser
Application Logic
Valid
XML Document

• Effective for apps that need random access to doc
  element
• However, building a complete tree for every doc
  is expensive in
• terms of memory
• Event-based parsers avoid this as they do not
  create data structure
• for entire document

20
Event-based Parsers
XML DTD
Parsing event
Event-Based Parser
Application Logic
Valid
Data Request
XML Document

• Event-based parsers send parsing events directly
  to application logic
• (beg and end of element but not its attributes)
• If application logic interested in element it
  requests additional data from
• parser
• Effective when application needs only sequential
  access to certain kinds of
• elements

21
Web Browsers

• Internet Explorer
• Netscape Navigator
• Modzilla Firefox
• W3C Amaya Web browser derived for testing XML
  documents
• Download for FREE
• http//www.w3c.org/Amaya

22
XML Editor

• Windows Notepad or WordPad
• Microsoft XML Notepad
• http//msdn.microsoft.com/xml/notepad/intro.asp
• XML writer available from Wattle Software
• http//www.xmlwriter.com/
• Macintosh Emile editor
• http//www.in-progress.com/emile/

23
Special XML characteristics

• Less than symbol (lt) - lt
• Greater than symbol (gt) - gt
• Quote symbol () - quot
• Apostrophe symbol () - apos
• Ampersand symbol () - amp

24
Real world XML

• P3P Web privacy policies
• RELML real estate listings
• HRMML human resource infomration (resumes,
  etc.)
• VoxML voice response scripts (Press 1 for this,
  Press 2 for that, etc.)
• VML vector graphics
• SVG vector graphics
• SMIL multimedia presentations
• 3DML three-dimensional virtual worlds

• WML Web pages for mobile devices
• XMLNews news stories
• CDF Web channels
• OSD descriptions of software
• OFX financial information (EFT, etc.)
• RDF descriptions of info in web pages (helps to
  aid search engines)
• MathML mathematical equations

25
Application Areas

• Information accessibility and sharing
• Information distribution capabilities
• Document life cycle and content management
• Accumulating knowledge from employees (tacit and
  explicit)
• Searching knowledge repositories, such as
  database systems and the Internet
• Knowledge categorisation systems and limitations
  of classifications
• Workflow systems and integration barriers
• Application integration
• System architecture standardisation and
  compatibility
• Customized publishing
• File configuration and logging
• Electronic commerce
