National Science Foundation Stevens Center for Wireless Network Security

1
National Science FoundationStevens Center for
Wireless Network Security
Energy Issues in Secure and Reliable Wireless
Multimedia Sensor Networking
Chetan NanjundaSatish BapatlaR.ChandramouliStev
en Institute of Technology
N. VijaykrishnanM.J. IrwinPenn State University
2
Contents

• Energy Awareness
• Sensor Networks
• Security
• Error Control
• Optimizations
• Experimental results

3
Energy Awareness

• Energy Sources
• Battery
• Solar (time variant)
• Energy consumption
• Computation
• Transmission
• Power consumption varies over time in wireless
  sensor networks
• Energy awareness spans several layers

4

• SENSOR NETWORKS

5
Constraints in Sensor Networks

• By design, sensors should be inexpensive
• Sensors are powered by a small battery, hence
  limited power will be available
• Battery replacement is an expensive process.
• sometimes not possible!!!
• The two basic resource constraints in a sensor
  are
• Memory
• Power

6
Constraints in Sensor Networks

• Memory
• Operating system code space
• The network protocols requires the intervention
  of operating system
• Available code space
• Data processing, Security algorithms and Error
  control should be run in this available code space

• Power
• Power consumption is in three domains
• Sensing
• Data processing
• Communication

7

• SECURITY

Information
8
Avalanche Effect

• The bits in the ciphertext change with a
  probability of one half whenever a single input
  bit is complemented before encryption
• This is one of the important criterion for
  designing cryptographically good S-boxes

Example For a 128 bit AES encryption p1 ? AES ?
c1 p2 ? AES ? c2
if d(p1,p2) 1 ? d(c1,c2) 64
9
Effect of Bit Errors

• Error Propagation Caused because of Avalanche
  effect

if d(c1,c2) 1 ? d(p1,p2) 64
i.e if one bit in the ciphertext gets corrupted
the whole message is lost!!

• This triggers several retransmissions
• Energy inefficient
• Error control strategies are important

10

• ERROR CONTROL

11
Optimizations in Error Control

• Adaptive Error Control.
• Feedback loop allows the transmitter to adapt the
  error coding according to the error rate observed
  at the receiver
• Example RCPC codes

12
Optimizations in Error Control

• Viterbi Vs. List Viterbi
• Viterbi decoder
• Maximum likelihood decoder for convolution codes
• Has three basic parts
• Branch metric computation
• Path metric computation
• Trace back unit
• Probability of successful decoding is very high
  for random bit error rates lt 10-2 (average
  transmissions are below 1.1 at such BER)

13
Optimizations in Error Control

• List Viterbi decoder
• Decodes M paths with ascending order of path
  metric
• The ith best path is the path with the ith least
  minimal metric
• This approach greatly reduces the number of
  retransmissions for error rates 10-2 , 10-1
• Power asymmetry in sensor networks can be
  exploited by list viterbi
• One of the important design criteria is to
  evaluate the tradeoff between computation and
  communication

14
Data Dependent Optimizations

• Layered Multimedia Encoding
• Different layers have different level of
  priorities
• Layered multimedia can be integrated with the
  retransmission strategy to optimize transmission
  power
• The varying level of priority in these layers can
  be exploited to provide varying levels of
  security to optimize computational power

15
Experimental Results

• Security
• AES (avalanche effect)
• Error Control
• List Viterbi (Distribution of Path search success
  for different error rates)
• Power Consumption
• Different Rounds of DES
• DES Vs. RC4
• Different Key Lengths of RC4
• Comparison of DES, IDEA, GOST

16
Avalanche Effect
d(p1,p2) 1
P1-1
P2-1
Encryption
Encryption
A E S
P2-2
P1-2
A E S
P2-9
P1-9
one bit of plaintext was flipped at a random
position and the bit differences between original
cipher and the encrypted cipher was observed at
intermediate rounds
17
Avalanche Effect In AES
one bit of plaintext was flipped at a random
position and the bit differences between original
cipher and the encrypted cipher was observed at
intermediate rounds
18
Error Propagation
d(c1,c2) 1
C1-1
C2-1
Decryption
Decryption
A E S
A E S
C2-2
C1-2
C2-9
C1-9

• One bit in the cipher text was flipped in random
  position and the bit differences between the
  recovered plaintext and the ideal plaintext was
  observed at intermediate rounds

19
Error Propagation Caused by Avalanche

• One bit in the cipher text was flipped in random
  position and the bit differences between the
  recovered plaintext and the ideal plaintext was
  observed at intermediate rounds

20
Error Control Setup
DATA
CRC
RCPC
AES Enc
Puncturing matrix
Wireless Channel with Random Bit Error
Channel condition
List Viterbi
Received DATA
AES Dec

• CRC

• Packet Size 200bits
• 16bit CRC

• Convolution mother code rate 1/2

21
Distribution of Successful Decoding Over Path
Search Depth
10-2 BER
22
Distribution of Successful Decoding Over Path
Search Depth
(0.2) 10-1 BER
23
Distribution of Successful Decoding Over Path
Search Depth
(0.4) 10-1 BER
24
Distribution of Successful Decoding Over Path
Search Depth
(0.6) 10-1 BER
25
Distribution of Successful Decoding Over Path
Search Depth
(0.8) 10-1 BER
26
Distribution of Successful Decoding Over Path
Search Depth

• 10-1 BER

27
Schematic Of H/W Setup
Read Voltage Current by GPIB
Labview
Vcc I cc
Power Supply
28
DES Power Requirement for Different Rounds
power
(watts)
Number of Rounds
29
Power Requirement for Different Key Lengths of RC4
power
(watts)
Key Length
30
DES Vs. RC4 for Random Data
? DES
power
(watts)
? RC4
Random DATA
31
Power Consumption Per Round
power
? IDEA
? DES
(watts)
?Gost
Key Length
32
Overall Power Consumption
power
?Gost
? IDEA
(watts)
? DES
Key Length
33
Questions??
