CSC 2720Building Web Applications

• Improving Web Application Performance

2
Outline

• Introduction
• Locating the bottleneck
• Improvement Methods

3
Introduction

• To improve the performance of a web application
  could mean
• To reduce latency
• i.e., to reduce the time delay between sending a
  request and receiving the corresponding response,
  or between sending a request and receiving all
  the page components, such as images, that are
  needed to render the page.
• To serve as many concurrent requests as possible
  without failing or exceeding a response time
  limit
• Response time the time a server takes to serve
  a request

4
PHP Performance Optimization

• Obtaining good performance is not merely writing
  fast PHP scripts. High performance PHP requires a
  good understanding of the underlying hardware,
  the operating system and supporting software such
  as the web server and database.
• Source http//phplens.com/lens/php-book/optimizin
  g-debugging-php.php
• Often involves trade-off among CPU, storage,
  bandwidth and other resource requirements

5
Factors that affect the performance

• Running out of resources
• Processors
• Memory
• Storage
• Network bandwidth
• of the maximum database connections
• Poorly designed database schema and queries
• Poorly written PHP code
• Too much disk access

6
Locating the Bottlenecks Profiling

• To measure the behavior of a server-side script
  as it executes, particularly frequency and
  duration of function calls (Ref Wikipedia)
• Help you detect which parts of your code are
  worth your attention (e.g., functions that are
  called the most, functions that take a long time
  to run)
• Can be used to analyze the performance of a
  database indirectly by measuring the functions
  that interact with the database (e.g., The
  mysqli_ functions)
• e.g. of Profiling Tools
• XDebug http//www.xdebug.org/

7
Locating the Bottlenecks Stress Tests

• Tests a web application for its robustness,
  availability, and error handling capabilities
  under a heavy load, particularly to ensure the
  software doesn't crash in conditions of
  insufficient computational resources (such as
  memory or disk space), unusually high
  concurrency, or denial of service attacks. (Ref
  Wikipedia)
• Use in conjunction with other tools to find out
• The maximum of requests/users a server can
  handle before failing or slowing down
  significantly
• The bottleneck (i.e., which resource run out
  first?)
• The average time a page and its components to
  fully load.

8
Locating the Bottlenecks Stress Tests

• Microsoft Web Application Stress Tool
• Can emulate HTTP requests (with parameters) from
  clients
• Can generate large number of requests within a
  short period of time (stress test)
• Can help you gather info such as the average and
  the highest latency experienced from accessing a
  URL

9
Locating the Bottlenecks System Info

• Show the usage and availability of various system
  resources (e.g., CPU, memory, virtual memory,
  I/O). The usage can be the overall usage or usage
  by individual processes.
• Use in conjunction with stress tests tools to
  locate the bottleneck of a server
• e.g. of tools
• "Task Manager" on Windows OS
• The command "tops" on most Unix/Linux OS

10
Improvement Methods

• Small changes that could make a big difference.
• PHP accelerators
• (Opcode compiler Opcode cache)
• Content caching
• Utilizing client's and proxy's cache
• Cache output
• Server-Side web proxy
• Compression
• Connection pooling

11
Improvement Methods

• Fine tuning your web applications, servers, and
  OS
• Reducing number of HTTP requests
• Query optimization
• Optimizing PHP code
• Additional methods that make a page loads faster
• Tuning the Server (Apache)

12
1. PHP Accelerators

• Typically made up of an opcode compiler and an
  opcode cache
• Opcode compiler compiles PHP code into opcode
• Opcode cache keeps frequently used compiled PHP
  scripts in memory
• A PHP accelerator can help reducing the response
  time of PHP scripts significantly because
• Interpreting opcode is faster than interpreting
  PHP code
• Loading opcode from memory is faster than loading
  PHP scripts from disk
• List of PHP accelerators
• http//en.wikipedia.org/wiki/PHP_accelerator

13
1.1 How PHP Accelerators Work
Source http//phplens.com/lens/php-book/optimizin
g-debugging-php.php
14
2.1 Content Caching Utilizing Client and Proxy
Caches

• Request clients/proxies to cache reusable
  components (e.g., images, scripts and
  stylesheets) in order to avoid retransmitting the
  same components

• To illustrate, suppose
• Clients A and B share a proxy server.
• The HTML page generated by index.php needs x.jpg
  and y.css.
• Only x.jpg and y.css are cacheable.

Client A
Proxy
Server
index.php
Client B
y.css
15
Client A
Proxy
Server
index.php
Client B
y.css
The 1st time client A requests index.php from the
server, all three files need to be transferred
from the server.
Client A
Proxy
Server
index.php
Client B
y.css
After the request, x.jpg and y.css are chached in
the client A's and proxy's cache.
16
Client A
Proxy
Server
index.php
Client B
y.css
In subsequent requests, client A only needs to
download the HTML page generated by index.php.
Client A
Proxy
Server
index.php
Client B
y.css
If client B accesses index.php after client A has
accessed the same file, then client B could load
the page faster because the proxy server only
needs to retrieve the HTML content from the
server. In practice, there could be more than
one proxy servers between the clients and the
server.
17
2.1 Content Caching Utilizing Client and Proxy
Caches

• Use the Expires or Cache-Control header fields to
  tell the clients and proxies how a component
  should be cached
• e.g.,
• When should the component be considered as
  expired?
• Is the component cacheable?
• Recommendations
• For static components implement a "Never expire"
  policy by setting far future Expires header.
• For dynamic components use an appropriate
  Cache-Control header to help clients with
  conditional requests.

18
2.1 Content Caching Utilizing Client and Proxy
Caches

• For examples
• To indicate that a component expires on a fixed
  time and date
• Expires Sat, 11 Apr 2009 200000 GMT
• To indicate that a component expires in one hour
  (relative to the access time) and the client must
  revalidate the content with the server when the
  component becomes stale
• Cache-Control max-age3600, must-revalidate
• To set caching policy for static components, you
  can configure the web server.
• To set up expiration policy for different files
  with Apache, see module mod_expires or these
  examples.
• To set up default header values for different
  files with Apache, see module mod_headers or
  these examples.

19
2.1 Content Caching Utilizing Client and Proxy
Caches

• References and Reading Materials
• Caching Tutorial
• Contains specific info about how (and how not) to
  cache
• http//www.mnot.net/cache_docs/
• Working with cached pages in PHP
• http//www.badpenguin.org/docs/php-cache.html
• HTTP conditional requests in PHP
• http//alexandre.alapetite.net/doc-alex/php-http-3
  04/index.en.html
• Use Server Cache Control to Improve Performance
• http//www.websiteoptimization.com/speed/tweak/cac
  he/

20
2.2. Content Caching Reusing Generated Output

• If a script only generates new content
  periodically, cache the generated output to avoid
  executing code and querying database for every
  request.
• Examples of cacheable output
• List of high scores for an online game
• List of products on an e-commerce website in
  which the products are updated daily
• PHP examples about output caching
• Caching output in PHP
• http//www.addedbytes.com/php/caching-output-in-ph
  p/
• Output Caching with PHP
• http//www.devshed.com/c/a/PHP/Output-Caching-with
  -PHP/

21
3. Server-Side Web Proxy

• Use a web proxy at the server side to relieve the
  web server from serving frequently requested
  static files
• An example of web proxy Squid
• http//www.squid-cache.org/

22
4. Compression

• Reduce the data size before transmitting
• (Online) Use HTTP Compression Compress textual
  data on the fly before sending them to a client
• Can typically reduce the size of textual data by
  70
• (Offline) Use compression tools to reduce the
  file size of JavaScript, CSS, Images, Video, etc.
• The compression tools must not change the file
  format or the content of these files. Otherwise
  the files cannot be referred from HTML files.
• e.g., use optipng for PNGs, gifsicle for GIFs and
  jpegoptim for JPGs

23
4.1. Compression HTTP Compression

• A publicly defined way to compress textual
  content transferred from web servers to browsers
• Compression is done at the server.
• Built into HTTP 1.1 and is supported by most
  browsers
• Drawback Takes time and CPU cycles to compress
• Ref http//www.websiteoptimization.com/speed/twea
  k/compress/
• Using HTTP Compression in PHP
• Configure php.ini to enable automatic HTTP
  compression
• zlib runtime configuration (http//hk2.php.net/man
  ual/en/zlib.configuration.php)
• Perform HTTP compression in PHP scripts
  programmatically
• Examples of using ob_gzhandler (http//hk2.php.net
  /ob_gzhandler)

24
5. Connection Pooling (Why?)

• A database connection incurs overhead it
  requires resources to create the connection,
  authenticate it, maintain it, and then release it
  when it is no longer required.
• The overhead is particularly high for Web-based
  applications.
• A server-side script typically opens a
  connection, performs few queries, and then close
  the connection.
• Often, more effort is spent connecting and
  disconnecting than is spent during the
  interactions themselves.
• Ref IBM WebSphere App. Server What is
  Connection Pooling?

25
5. Connection Pooling

• A connection pool is a cache of opened database
  connections.
• When a script needs to establish a connection to
  the database, a connection is selected from the
  pool if one is available. Otherwise a new
  connection is created.
• When a script closes the connection, the
  connection is not actually closed but returned to
  the pool so that the connection can be reused by
  other scripts.
• Note Implementing a connection pool is not easy.
  Usually we just use it if it is available.

26
5.1. Connection Pooling in PHP

• PHP's Persistent Connection
• Use mysql_pconnect() to open a persistent
  database connection
• There is no equivalence in MySQLImproved (mysqli)
  extension.
• Must be used with care because changes made to
  the database states, such as setting autocommit
  to "off", will affect the next script that uses
  the connection.
• Other connection pooling solutions
• SQL Relay http//sqlrelay.sourceforge.net/index.h
  tml
• Apache Module mod_dbd http//httpd.apache.org/doc
  s/2.1/mod/mod_dbd.html

27
6. Reducing of HTTP Requests (Why?)

• A large portion of the total response time to
  create a fully rendered page is spent on
  downloading the page components like images,
  stylesheets, JavaScript, etc.
• Some browsers only allow at most two concurrent
  requests per server. That means the page
  components have to take turn to load.
• Ref http//developer.yahoo.com/performance/rules.
  html

28
6. Reducing of HTTP Requests

• Reducing of components ? reducing of HTTP
  requests ? Page loads faster
• Methods to reduce the of page components
• Combine multiple stylesheets into one
• Combine multiple scripts into one
• CSS Sprites Tile multiple images into one image
  and then make use CSS to clip the needed image
  from the combined image.

29
7. Query Optimization

• Tune DB Schema
• First three normal forms ? help ensure data
  integrity
• Denormalization a process that attempts to
  optimize the performance of a database by adding
  redundant data or by grouping data (but makes
  maintaining data integrity difficult).
• Query only what you really need
• e.g., instead of using "SELECT ", select only
  the columns you need and use LIMIT to limit the
  number of rows retrieved from the DB
• Make use of indexes to improve the performance of
  data retrieval
• Take a database course ?
• Ref How to Optimize Queries (Theory an Practice)

• http//www.serverwatch.com/tutorials/article.php/2
  175621

30
8. Optimizing PHP Code

• Make use of output buffer
• See PHP Output Bufering Control
  http//hk2.php.net/ob_start

lt?php ob_start() // Start output buffering
// All the output are kept in memory
instead // of sending to the
client. ?gt lthtmlgt ltheadgtlttitlegtFoolt/titlegtlt/headgt
ltbodygt lt?php echo "Blah Blah Blah"
?gt lt/bodygtlt/htmlgt lt?php ob_end_flush() //
Flush everything in the output buffer
// to the client at once. ?gt
31
8. Optimizing PHP Code

• echo str1, " ", str2, " ", str3
• executes faster than
• echo str1 . " " . str2 . " " . str3
• Note This only works with echo, which is a
  function that can take several strings as
  arguments.
• If you have CPU-intensive tasks to perform,
  consider implement them as C extensions.
• Use the predefined functions (as oppose to
  writing your own functions) whenever possible

32
8. Optimizing PHP Code

• Instead of writing
• for (i0 i lt count(array) i)
• Use a variable to store the array size and
  rewrite the loop as
• array_size count(array)
• for (i0 i lt array_size i)
• More tips about optimizing PHP code can be found
  at http//reinholdweber.com/?p3

33
9. Additional Methods that Make a Page Loads
Faster

• Post-load Components
• Load the less important components on the
  background
• Preload Components
• Anticipating what components are needed in the
  future and pre-load them (i.e., utilizing
  browser's idle time)
• Split Components Across Domains
• Maximize parallel downloads (a browser may only
  issue a few HTTP request in parallel to the same
  sever)
• Make sure you're using not more than 2-4 domains
  because of the DNS lookup penalty.
• Ref Best Practices for Speeding Up Your Web Site
  (http//developer.yahoo.com/performance/rules.html
  )

34
10. Tuning the Server (Apache)

• SendBufferSize Size of output buffer
• MaxClients Maximum of clients
• StartServers The number of child processes to
  create at start up
• MinSpareServers, MaxSpareServers The number of
  idle child processes to keep alive
• Keep-alive tells the server to reuse the same
  socket connection for multiple HTTP requests to
  reduce the overhead of frequent connects
• Source http//phplens.com/lens/php-book/optimizin
  g-debugging-php.php

35
Scaling

• To improve the performance by introducing more
  machines (to host more servers)
• Server Clusters
• Database Replication
• Improve performance or availability of the whole
  database system
• MySQL Replication (http//dev.mysql.com/doc/refman
  /5.0/en/replication.html)

36
References

• Best Practices for Speeding Up Your Web Site
• http//developer.yahoo.com/performance/rules.html
• Performance Research, Part 1 What the 80/20 Rule
  Tells Us about Reducing HTTP Requests
• http//yuiblog.com/blog/2006/11/28/performance-res
  earch-part-1/
• Performance Research, Part 2 Browser Cache Usage
  - Exposed!
• http//yuiblog.com/blog/2007/01/04/performance-res
  earch-part-2/
• Practical PHP Performance
• http//www.developertutorials.com/tutorials/php/pr
  actical-php-performance-8-02-07/page3.html
