Advanced Memory Management

1
Advanced Memory Management
2
Advanced Topics

• Distributed Shared Memory
• Application Controlled Memory Management
• TLB Issues

3
Distributed Shared Memory
on hardware
on opearting system
in user space
4
Distributed Shared Memory

• a way to facilitate the programming of
  distributed systems
• DSM
• message passing
• provides a uniform single address space view
• easy to use
• separate the memory view from threads
• each node can access all the memories even though
  machines do not physically share memory
• software layer allow application software to
  access shared data not resident at a node
• integrated with OS (IVY, Clouds, ..)
• runs on top of the OS (NOW)

5
Issues in the design of DSM

• Virtual memory and DSM
• find where is the physical page frame
• make it coherent if duplicated
• memory model and coherence protocol
• what is guaranteed when a data is accessed in
  parallel
• how to make shared pages coherent
• synchronization
• will be used frequently in parallel programs on
  DSM
• hardware support
• speed network, CPU
• functionality TLB, message processing

6
Distributed Shared Memory

• Virtual Memory Mechanism
• 1. CPU generates a virtual address
• 2. if the page is in local memory, keep going
• else send a request for the page to ???
• needs information who has it or
• needs information who knows where the page is
• 3. the node who has the page replies with the
  page
• with write privilege if it is a write request
  invalidating its own copy
• with read-only privilege keeping the ownership
• when a page has to be replaced either
• swap it to disk or
• send it to network DRAM

7
Consistency Protocol

• similar to those of distributed file system and
  SMP caches
• defines actions on a write to a shared page
• invalidate (a page)
• update (a page or a word or cache line or ,,,,)
• the length of write run decides which one is
  better
• defines state of a page
• shared or exclusive
• write or read
• ownership, if any
• defines the information about
• how to find the owner
• how to find replicated copies

8
Memory Model

• defines result of series of memory operations
• restricts the implementation of shared memory
• may disallow cacheing
• may allow out of order processing of memory
  operations
• sequential consistency (Lamport)
• most strong model
• result should be the same as serializable
  operations
• restrict any out of order accesses to memory
• release consistency
• based on a synchronization
• acquire
• release
• guarantee consistency only at the end of release
  operation
• allows buffering memory accesses inside a
  critical section

9
GLUnix

• DSM that runs on top of OS
• minimizes OS modification
• fast prototyping
• most applications can be run without modification
• modifications needed
• network protocol that is suited for page handling
• use network RAM as a secondary storage
• page fault handler
• page tables

10
GLUnix(2)

• Virtual OS layer
• captures DSM-related interrupts and syscalls
  generated from running application programs
• how to capture external interrupts?
• software fault isolation
• insert a code to check before the instruction
  that may cause interrupt
• Issues
• load balancing
• parallel computation finishes when the slowest
  component finishes
• communicating processes
• lots of small messages

11
IVY

• First DSM
• invalidation-based
• ownership based
• test three algorithms to find an owner
• centralized server
• fixed distributed manager
• each node has the ownership for predetermined
  pages
• dynamic distributed manager
• page table of each node has the possible owner of
  each page
• if it is not the true owner, it should know where
  to look for further search

12
IVY(2)

• Process Migration
• needed for load balancing
• sends PCB to destination
• send pages containing stack to destination with
  write privilege
• why? those pages will be transferred anyway as
  the stack is accessed in the destination node
• Good performance
• runs only those good for DSM
• some applications show even super-linear speedup

13
Munin

• DSMized the V kernel
• Software Release Consistency
• Multiple Consistency Protocols
• performance of a consistency protocol is
  sensitive to
• structure of parallel programs
• sharing pattern inside a program
• a protocol is defined on each shared object
• an annotation is needed for each object to define
  the protocol
• if it is missing, default protocol works

14
Munin Annotation

• what is defined in an annotation?
• invalidate vs update
• replication allowed?
• delayed operation allowed?
• fixed owner?
• multiple writes allowed?
• static sharing pattern
• the object is accessed by a single thread by a
  static pattern, updates are sent to the same node
  even before the node requests them
• flush changes to owner?
• writable?

15
Munin Release Consistency

• thread-A thread-B
• lock(A) lock(B)
• X X1 Y Y1 X and Y are in the
• unlock(A) unlock(B) same page
• when updated pages are flushed to owner, how to
  update the home page?
• introduces twin page
• if there is no twin no problem
• else, difference of each twin page are updated
• where to keep the twin pages?

16
Munin Directory Structure

• hash function directs an address to an entry in
  the table
• the entry contains object description
• start address and size
• protocol defined
• state valid, writable, modified, replicated
• copyset bitmap? linked-list?
• synchq pointer to the synch object that governs
  this object
• probable owner best guess
• home node for book keeping
• access control semaphore

17
Munin(3)

• Merging Sync with Data Transfer
• a message transfer is expensive in DSM
• most sync operations are used to control shared
  data
• then let's merge them in a single message
• how do we know which sync object governs which
  object?
• programmer knows it
• can be defined at variable declaration
• when a lock is released to a node
• the data governed is sent together

18
Shasta

• Motivations
• fine-grain sharing will reduce false sharing
• run binary executables
• most commercial softwares are distributed in this
  way
• insert checks in application executables (like
  Blizzard-S) at loads and stores
• ordinary overhead 50150
• support SMP as a node
• Virtual address space
• conventional space is private
• code, static data, stack
• shared space is dynamically allocated (followed
  the convention of SPLASH)

19
Shasta Coherence Protocol

• three states
• invalid, shared, exclusive
• directory-based invalidation
• home node is assigned for each virtual page
• owner node is the last node that updates the page
• directory contains
• a pointer to the owner
• full map bit-vector for all sharers
• coherence unit and coherence information
• block (multiple of lines) by directory
  information
• lines (64128 bytes) by state table

20
Shasta(2)

• Polling instead of interrupt for coherence
  actions
• polling is much more efficient (only 3
  instructions)
• simplifies concurrency problem handling a miss
• while a miss is being check, messages related to
  this miss can arrive
• places to insert polling code
• when the protocol waits for a message
• depends on desired response time
• at every function call
• at every loop backedge

21
Shasta Shared Miss Check

• Each load and store should be checked if it is a
  miss instructions that need not be checked
• private, stack accesses
• addresses calculated from the above addresses
• check if they use registers used for private data
• normal operations
• 1. checks if the target address is in shared
  region
• 2. if so, check out the state from the state
  table
• 3. if needed, call miss handling routine

22
Inserted Code for Store Check
1. lda rx, offset(base) 2. srl rx, 39, ry 3.
beq ry, nomiss 4. srl rx, 6, rx 5. ldq_u ry,
0(rx) 6. extbl ry, rx, ry 7. beq ry, nomiss 8.
call miss handler check for a store
shared region
state table
static data text stack
23
Inserted Code for Store Check(2)

• no register save/restore
• use unused ones
• if cannot find unused ones, insert a code to
  secure two registers
• instruction 2 and 6 requires smart address space
  allocation
• shared region
• state table
• operations
• 1. calculate effective address of the target
• 2. 3. check if the target address is within the
  shared region
• 4. calculate the (byte) address in the state
  table for the target address
• 5.6. extract the state information
• 7. if it is 0 (exclusive) go to nomiss

24
Shasta Optimization

• code rescheduling
• shift instruction needs 2 cycles to generate the
  result
• branch delay slots can be filled with the above
  code
• rx, and ry are unused registers no dependency
• load checks
• when a line becomes invalid, store a fixed value
  to each long word in the line
• for a load check, compare the value of a long
  word with the flag value
• if equal, call miss handling routine
• else, continue
• the flag value should not be the one that used
  frequently in normal computing
• not zero, not a small positive integer
• 253 was chosen in Shasta

25
Shasta Optimization(2)

• store check
• separate exclusive bit(1 bit) for each line is
  prepared
• a table of such bits will occupy a small space in
  the data cache reduce cache misses for looking
  up the state table
• batching miss checks
• if several instructions touch the same line, one
  check is enough for all of them
• multiple granularity
• allow applications to define the block size at
  malloc() system call

26
Alpha LL and SC

• synchronization primitives of Alpha
• lock_flag and lock_address per processor
• operations
• LL sets the lock_flag and the lock_address
• the lock_flag will be reset if another processor
  writes in its own cache at the lock_address
• SC succeeds if the lock_flag is still set
• exact implementation would be expensive
  (inefficient) for shasta
• Alpha programming recommendation
• for an SC there is a unique LL
• no store or load between SC and LL
• SC and LL are in the same line

27
Shasta Approach to LL and SC

• before LL
• save the state of the line in a register
• get the latest copy if the state is invalid
• before SC
• if the saved state is exclusive, OK
• if invalid return fail
• if shared, send a special message to the home
• at the home node
• if the requester is still a sharer, send OK
• else send failure

28
Memory Barrier

• fence operation to make all the pending
  operations of the processor to be globally
  performed
• inefficient due to blind performing at MB
• Shasta at MB
• finishes all the pending operations
• the hardware also executes MB operation for SMP

29
System Calls

• validating arguments
• what if arguments are in shared region?
• copy the arguments from shared region to local
  memory
• expensive operations
• validate arguments using a wrapper
• make sure the arguments are in proper states
• support multiple cluster
• replace all related calls with Shastas calls
• process managements
• shared memory management
• threads that share an address space
• need inline checking even for the accesses to
  private and stack expensive
• page based protocol can be used for stack
• access to remote file
• distributed file system is needed

30
Process Handling

• Processes are created/terminated dynamically
• Issues
• data and states information owned by a terminated
  process
• more processes than processors
• inactive ones may cause delays for servicing
  requests from other processes
• solution
• a daemon process per processor while the
  application is running
• it shares all the data with processes allocated
  to the same processor
• it runs at a low priority and handles messages
  arrived for peer processes

31
Code modification

• when?
• load time
• it may slow down the loading time
• you have only binaries
• cacheing will reduce the number of modifications
  of frequently-used code
• caveat program that generates code

32
Page Table for 64 bit OS

• Motivations
• page table is huge for 64-bit address space
• inverted page table is not a solution due to
  increased physical memory size
• most programs use the address space sparsely
• Multi-level page tables
• PTEs are structured into an n-ary tree
• reduces significantly PTEs for unused address
  space
• when the height of the tree is large
• too many memory reference to find a PTE
• when it is too small
• lose the benefit of multi-level

33
Page Table for 64 bit OS

• Hashed page tables
• hash function maps a VPN to a bucket
• a bucket is a linked list of elements which
  consist of
• PTE (PPN, attribute, valid bit,..)
• VPN (almost 8 bytes)
• next pointer (8 bytes)
• space overhead 16 bytes per PTE
• next pointer can be eliminated by allocating a
  fixed number of elements for each bucket
• overflow problem remains

34
Page Table for 64 bit OS

• Clustered page table
• each element of the linked list maps multiple
  pages
• VPN
• next pointer
• n PTEs
• a memory object (in virtual address) usually
  occupies multiple pages
• space overhead of the hashed page table is
  amortized
• more efficient than linear table for sparse space

35
Clustered Page Table

• Operations
• adding a PTE
• hash table memory allocation list insertion
  PTE initialization per each new PTE
• clustered
• mem alloc list insertion per n PTEs
• initialization for each PTE
• modifying a PTE
• modification is done for a memory object not for
  a page, so cluster scheme is more efficient
• synchronization
• many threads use the page table concurrently
• cluster lock for a group of pages
• reduces concurrency
• less blocking overhead
• can support finer granularity with some overhead

36
TLB Issues

• Can this scheme support new TLB technologies such
  as superpage and subblocking?
• Superpage
• a superpage is 2n of base page size
• each TLB entry must has the size field
• why not segmentation
• complex because its size is arbitrary and it
  starts at an arbitrary location
• reduce TLB misses since each entry maps wider
  region
• good for frame buffer, kernel data, DB buffer
  pool
• how about file cache?

37
TLB Issues(2)

• Subblocking
• put multiple PPNs in a TLB entry
• it may waste TLB space
• partial subblocking
• physical memory is aligned, so
• one PPN in a TLB entry
• multiple valid bits needed
• Clustered page table
• just need a field to indicate if this list
  element is for a normal cluster or
  partial-subblock or superpage
• mechanism for operation is naturally similar

38
Application Controlled MM

• why user-controlled something?
• computing usages are too diverse
• multimedia data
• real time
• personal computing
• large scientific application (usually parallel
  computing)
• a general OS cannot satisfy the needs that come
  from such diversity
• User-controlled what?
• almost any part of OS scheduling, memory
  management, file system, network protocol,
  security,

39
Application Controlled MM

• Mechanisms for User Control
• microkernel approach
• parts of OS that need to be customized are
  prepared as user processes or
• they are prepared as library functions that can
  be binded into applications (ExoKernel)
• modular but inefficient
• binary loadable into the OS
• needs dynamic linking method inside the OS
• efficient but insecure

40
External Pager

• Motivations applications doesnt know and cant
  control
• the amount of memory available to it
• some programs can use as much memory as it is
  given
• what parts of it are kept in the memory
• some data accesses are predictable
• Some solutions
• allow applications to pin pages in memory
• disable OS ability to shared memory
• hard to know how much to pin
• allow application to advise VM system
• madvise() system call
• very primitive and complex mechanism

41
External Pager

• segment manager
• user level pager
• reclaims page frames
• writeback page frames
• on page fault
• kernel forwards this event to the segment manager
• via signal or interrupt
• the manager reclaims a page frame
• may writeback a page
• need to maintain a list of free pages

42
External Pager

• system call
• SetSegmentManager(seg, manager)
• specify the manager of a segment
• MigratePages(srcSeg, dstSeg, flags)
• move pages from a segment to another
• ModifyPageFlags(seg, flags)
• set/clear dirty bit, protection
• GetPageAttribute(seg, pages)
• determine the flags and mapping of pages
• the manager can be a part of the application
• recursive page faults may occur
• a manger pins its stack into memory

43
External Pager

• how a manager gets a free page
• from a free-page segment that it manages
• reclaim a page from another segment it manages
• request an additional page from the kernel
• System page cache manager
• the controller of the machines global memory
  pool
• segment managers get segments from this
• it may approve, deny, or partially fulfill
  requests

44
Memory Market Model

• until now, scheduling is for the time a program
  uses
• with multiprocessors memory will be more
  contended than CPU
• charges each process for space_used x time
• an application requests an amount of dram
  initially
• the kernel allocates dram according to system
  status and user request
• applications choose if they want large memory to
  be executed fast OR
• small memory since it is not very urgent
• questions remain
• interactions with CPU scheduling

45
Summary

• external pager is a trend
• OS should provide abstractions of the hardware
  complete in
• functionality (dont hide useful functionality)
• performance (dont hide performance)
• other user-controlled approaches
• gang scheduling on parallel machine
• scheduler activation
• user-level devices and file system
