Advanced Operating Systems

1
Advanced Operating Systems
Lecture 7 Concurrency

• University of Tehran
• Dept. of EE and Computer Engineering
• By
• Dr. Nasser Yazdani

2
How to use shared resource

• Some general problem and solutions.
• References
• Fast Mutual Exclusion for Uniprocessors
• On Optimistic Methods for Concurrency Control

3
Outline

• Introduction
• Motivation
• Implementing mutual exclusion
• Implementing restartable atomic sequence
• Kernel design considerations
• The performance of three software techniques
• Conclusions

4
Why Coordinate?

• Critical section
• Must execute atomically, without interruption.
• Atomicity usually only w.r.t. other operations on
  the same data structures.
• What are sources of interruption?
• Hardware interrupts, UNIX signals.
• Thread pre-emption.
• Interleaving of multiple CPUs.

5
Spooling Example Correct
Shared memory
Process 1
Process 2
int next_free
int next_free

out
next_free in
1
abc
4
Stores F1 into next_free
Prog.c
5
2
Prog.n
6
innext_free1
in
3
F1
7
next_free in
4
F2
Stores F2 into next_free
5

innext_free1
6
6
Spooling Example Races
Shared memory
Process 1
Process 2
int next_free
int next_free

out
next_free in
1
abc
4
Prog.c
next_free in / value 7 /
5
2
Stores F1 into next_free
Prog.n
6
3
in
F1
7
F2
innext_free1
4
Stores F2 into next_free
5

innext_free1
6
7
Critical Section Problem

• N threads all competing to use the same shared
  data
• It might eventuate to Race condition
• Each thread has a code segment, called a critical
  section, in which share data is accessed
• We need to ensure that when one thread is
  executing in its critical section, no other
  thread is allowed to execute in its critical
  section

8
Critical Region (Critical Section)

• Process
• while (true)
• ENTER CRITICAL SECTION
• Access shared variables // Critical Section
  LEAVE CRITICAL SECTION
• Do other work

9
Critical Region Requirement

• Mutual Exclusion
• one process must execute within the critical.
• Progress
• If no Waiting process in its critical section,
  any process entry to its critical section cannot
  be postponed indefinitely.
• No process running outside its critical region
  may block other processes
• Bounded Wait
• A process requesting entry to a critical section
  should only have to wait for a bounded number of
  other processes to enter and leave the critical
  section.
• No process should have to wait forever to enter
  its critical region
• Speed and Number of CPUs
• No assumption may be made about speeds or number
  of CPUs.

10
Critical Regions (2)

• Mutual exclusion using critical regions

11
Synchronization approaches

• Disabling Interrupts
• Lock Variables
• Strict Alternation
• Petersons solution
• TSL
• Sleep and Wakeup
• Message sending

12
Disabling Interrupts

• How does it work?
• Disable all interrupts just after entering a
  critical section and re-enable them just before
  leaving it.
• Why does it work?
• With interrupts disabled, no clock interrupts and
  switch can occur.
• Problems
• What if the process forgets to enable the
  interrupts?
• Multiprocessor? (disabling interrupts only
  affects one CPU)
• Only used inside OS

13
Lock Variables

• Int lock
• lock0
• While (lock)
• lock 1
• EnterCriticalSection
• access shared variable
• LeaveCriticalSection
• lock 0
• Does the above code work?

14
Strict Alternation

• Thread Me / For two threads /
• while (true)
• while ( turn ! my_thread_id)
• Access shared variables // Critical
  Section
• turn other_thread_id
• Do other work
• Satisfies mutual exclusion but not progress.
• Why?
• Notes
• While turn ! my_thread_id / busy
  waiting/
• A lock (turn variable) that uses busy waiting is
  called a spin lock

15
Using Flags

• int flag2 false, false
• Thread Me
• while (true)
• flagmy_thread_id true
• while (flagother_thread_id )
• Access shared variables // Critical
  Section
• flagmy_thread_id false
• Do other work
• Can block indefinitely
• Why? (You go ahead!)

16
Test Set (TSL)

• Requires hardware support
• Does test and set atomically
• char Test_and_Set ( char target)
• \\ All done atomically
• char temp target
• target true
• return(temp)

17
Problems with TSL

• Operates at motherboard speeds, not CPU.
• Much slower than cached load or store.
• Prevents other use of the memory system.
• Interferes with other CPUs and DMA.
• Silly to spin in TSL on a uniprocessor.
• Add a thread_yield() after every TSL.

18
Other Similar Hardware Instruction

• Swap TSL
• void Swap (char x, y)
• \\ All done atomically
• char temp x
• x y
• y temp

19
Petersons Solution

• int flag2false, false
• int turn
• Thread Me
• while (true)
• flagmy_thread_id true
• turn other_thread_id
• while (flagother_thread_id
• and turn other_thread_id )
• Access shared variables // Critical
  Section
• flagmy_thread_id false
• Do other work
• It works!!!
• Why?

20
Sleep and Wakeup

• Problem with previous solutions
• Busy waiting
• Wasting CPU
• Priority Inversion
• a high priority waits for a low priority to leave
  the critical section
• the low priority can never execute since the high
  priority is not blocked.
• Solution sleep and wakeup
• When blocked, go to sleep
• Wakeup when it is OK to retry entering the
  critical section
• Semaphore operation that executes sleep and wakeup

21
Semaphores

• A semaphore count represents count number of
  abstract resources.
• New variable having 2 operations
• The Down (P) operation is used to acquire a
  resource and decrements count.
• The Up (V) operation is used to release a
  resource and increments count.
• Any semaphore operation is indivisible (atomic)
• Semaphores solve the problem of the wakeup-bit

22
Whats Up? Whats Down?

• Definitions of P and V
• Down(S)
• while (S lt 0) // no-op
• S S-1
• Up(S)
• S
• Counting semaphores 0..N
• Binary semaphores 0,1

23
Possible Deadlocks with Semaphores

• Example
• P0 P1
• share two semaphores S and Q
• S 1 Q1
• Down(S) // S0 ------------gt Down(Q) //Q0
• Down(Q) // Q -1 lt--------
• --------------------gt Down(S) //
  S-1
• // P0 blocked // P1 blocked
• DEADLOCK
• Up(S) Up(Q)
• Up(Q) Up(S)

24
Monitor

• A simpler way to synchronize
• A set of programmer defined operators
• monitor monitor-name
• // variable declaration
• public entry P1(..)
• ...
• ......
• public entry Pn(..)
• ...
• begin
• initialization code
• end

25
Monitor Properties

• The internal implementation of a monitor type
  cannot be accessed directly by the various
  threads.
• The encapsulation provided by the monitor type
  limits access to the local variables only by the
  local procedures.
• Monitor construct does not allow concurrent
  access to all procedures defined within the
  monitor.
• Only one thread/process can be active within the
  monitor at a time.
• Synchronization is built in.

26
Cooperating Processors via Message Passing

• IPC is best provided by a messaging system
• Messaging system and shared memory system are not
  mutually exclusive, they can be used
  simultaneously within a single OS or single
  process
• Two basic operations
• Send (destination, message)
• Receive (source, message)
• Message size Fixed or Variable size.
• Real life analogy conversation

27
Message Passing
28
Direct Communication

• Binds the algorithm to Process name
• Sender explicitly names the received or receiver
  explicitly names the sender
• Send(P,message)
• Receive(Q,message)
• Link is established automatically between every
  pair of processes that want to communicate
• Processes must know about each other identity
• One link per pair of processes

29
Indirect Communication

• send(A,message) / send a message to mailbox A
  /
• receive(A,message) / receive a message from
  mailbox A /
• Mailbox is an abstract object into which a
  message can be placed to or removed from.
• Mailbox is owned either by a process or by the
  system

30
Fast Mutual Exclusion for Uniprocessors

• Describe restartable atomic sequences (an
  optimistic mechanism for implementing atomic
  operations on a uniprocessor)
• Assumes that short, atomic sequences are rarely
  interrupted.
• Rely on a recovery mechanisms.
• Performance improvements.

31
Motivation of efficient mutual-exclusion

• Modern applications use multiple threads
• As a program structuring device
• As a mechanism for portability to multiprocessors
• As a way to manage I/O and server concurrency
• Many OSs are build on top of a microkernel
• Many services are implemented as multithreaded
  user-level applications
• Even single threaded programs rely on basic OS
  services that are implemented outside the kernel

32
Implementing mutual exclusion on a uniprocessor

• Pessimistic methods
• Memory-interlocked instruction
• Software reservation
• Kernel emulation
• Restartable atomic sequences

33
Memory-interlocked instruction

• Implicitly delays interrupts until the
  instruction completes.
• Require special hardware support from the
  processor and bus.
• The cycle time for an interlocked access is
  several times greater than that for a
  non-interlocked access.

34
Software reservation

• Explicitly guards against arbitrary interleaving.
• A thread must register its intent to perform an
  atomic operation, and then wait.
• Examples
• Dekkers algorithm
• Lamports algorithm
• Petersons algorithm

35
Kernel emulation

• A strictly uniprocessor solution
• Explicitly disables interrupts during operations
  that must execute atomically.
• Although requires no special hardware, its
  runtime cost is high.
• The kernel must be invoked on every
  synchronization operation

36
Restartable atomic sequence

• Instead of using a mechanism that guards against
  interrupts, we can instead recognize when an
  interrupt occurs and recover.
• The recovery process restart the sequence.
• Are attractive because
• Do not require hardware support.
• Have a short code path with one load and store
  per atomic read-modify-write.
• Do not involve the kernel on every atomic
  operation.

37
Implementing restartable atomic sequences

• Require kernel support to ensure that a suspended
  thread is resumed at the beginning of the
  sequence.
• Strategies for implementing kernel
• Explicit registration in Mach
• Designated sequences in Taos

38
Explicit registration in Mach

• The kernel keeps track of each address spaces
  restartable atomic sequence.
• An application registers the starting address and
  length of the sequence with kernel.
• In response to the failure
• Replace restartable atomic sequence with
  conventional mechanisms code.

39
Costs of explicit registration

• Cost of subroutine linkage
• Because the kernel identifies restartable atomic
  sequences by a single PC range per address space,
  They cannot be inlined.
• Cost of checking return PC
• Kernel must check the return PC, whenever a
  thread is suspended.
• Make additional scheduling overhead worthwhile.

40
Designated sequences in Taos

• The kernel must recognize every interrupted
  sequence.
• Uses two-stage check to recognize atomic
  sequences.
• 1st rejects most interrupted code sequences that
  are not restartable.
• (the opcode of the suspended instruction is
  used as an index into a hash table containing
  instructions eligible to appear in a restartable
  atomic sequence)
• 2nd uses another table (indexed by opcode)

41
Kernel design considerations

• Cost of the two-stage check on every thread
  switch
• Placement of the PC check
• Mutual exclusion in the kernel

42
Placement of the PC check

• When should the kernel check/adjust the PC of a
  suspended thread?
• When it is first suspended.
• When it is about to be resumed.
• Detection at user level
• Whenever a suspended thread is resumed by the
  kernel, it returns to a fixed user-level
  sequence.
• Determine if the thread was suspended within a
  restartable atomic sequence.
• (complexity and overhead -- save return address
  to user-level stack at each suspension)

43
Mutual exclusion in the kernel

• The kernel is itself a client of thread
  management facilities.
• Two events, can trigger a thread switching
• Page fault
• Thread preemption
• Careless ordering of the PC check could lead to
  mutual recursion between the thread scheduler and
  the virtual memory system.

44
The performance

• R.A.S. via Kernel Emulation via Software
  reservation
• Discuss performance at three levels
• Basic overhead of various mechanisms.
• Effect on the performance of common thread
  management operations.
• Effect of mutual exclusion overhead on the
  performance of several application.

45
Microbenchmarks

• The performance is with test which enters
  critical section (TSL) in a loop for 1M
• Two version of Lamprot algorith (fast and meta)

46
Thread management overhead

• Different thread management packages

Two thread using mutex and condition variable
alternatively
47
Application performance

• afs-bench file sys intensive like cp
• Parthenon-n theorem prover with n threads
• Procon-64 producer-consumer
• Thread suspensions for R.A.S of time to check

48
Conclusions

• R.A.S. represent a common case approach to
  mutual exclusion on a uniprocessor.
• R.A.S. are appropriate for uniprocessors that do
  not support memory-interlocked atomic
  instructions.
• Also on processors that do have hardware support
  for synchronization, better performance may be
  possible.

49
Next Lecture

• Distributed systems
• References
• Read the first chapter of the book
• Read The Anatomy of the Grid Enabling Scalable
  virtual Organizations
