Sequence Learning

1
Sequence Learning

• Sudeshna Sarkar
• 14 Aug 2008

2
Alternative graphical models for part of speech
tagging
3
Different Models for POS tagging

• HMM
• Maximum Entropy Markov Models
• Conditional Random Fields

4
Hidden Markov Model (HMM) Generative Modeling
Source Model P(Y)
Noisy Channel P(XY)
y
x
5
Dependency (1st order)
6
Disadvantage of HMMs (1)

• No Rich Feature Information
• Rich information are required
• When xk is complex
• When data of xk is sparse
• Example POS Tagging
• How to evaluate P(wktk) for unknown words wk ?
• Useful features
• Suffix, e.g., -ed, -tion, -ing, etc.
• Capitalization
• Generative Model
• Parameter estimation maximize the joint
  likelihood of training examples

7
Generative Models

• Hidden Markov models (HMMs) and stochastic
  grammars
• Assign a joint probability to paired observation
  and label sequences
• The parameters typically trained to maximize the
  joint likelihood of train examples

8
Generative Models (contd)

• Difficulties and disadvantages
• Need to enumerate all possible observation
  sequences
• Not practical to represent multiple interacting
  features or long-range dependencies of the
  observations
• Very strict independence assumptions on the
  observations

9
Making use of rich domain features

• A learning algorithm is as good as its features.
• There are many useful features to include in a
  model
• Most of them arent independent of each other

• Identity of word
• Ends in -shire
• Is capitalized
• Is head of noun phrase
• Is in a list of city names
• Is under node X in WordNet

• Word to left is verb
• Word to left is lowercase
• Is in bold font
• Is in hyperlink anchor
• Other occurrences in doc

10
Problems with Richer Representationand a
Generative Model

• These arbitrary features are not independent
• Overlapping and long-distance dependences
• Multiple levels of granularity (words,
  characters)
• Multiple modalities (words, formatting, layout)
• Observations from past and future
• HMMs are generative models of the text
• Generative models do not easily handle these
  non-independent features. Two choices
• Model the dependencies. Each state would have
  its own Bayes Net. But we are already starved
  for training data!
• Ignore the dependencies. This causes
  over-counting of evidence (ala naïve Bayes).
  Big problem when combining evidence, as in
  Viterbi!

11
Discriminative Models

• We would prefer a conditional modelP(yx)
  instead of P(y,x)
• Can examine features, but not responsible for
  generating them.
• Dont have to explicitly model their
  dependencies.
• Dont waste modeling effort trying to generate
  what we are given at test time anyway.
• Provide the ability to handle many arbitrary
  features.

12
Locally Normalized Conditional Sequence Model
Maximum Entropy Markov Models McCallum, Freitag
Pereira, 2000 MaxEnt POS Tagger Ratnaparkhi,
1996 SNoW-based Markov Model Punyakanok Roth,
2000
Conditional
Generative (traditional HMM)
S
S
S
S
S
S
transitions
t
-
1
t
t1
transitions
t
-
1
t
t1
...
...
...
...
observations
observations
...
...
O
O
O
O
O
O
t
t
1
-
t
1
t
t
1
-
t
1
Standard belief propagation forward-backward
procedure. Viterbi and Baum-Welch follow
naturally.
13
Locally Normalized Conditional Sequence Model
Maximum Entropy Markov Models McCallum, Freitag
Pereira, 2000 MaxEnt POS Tagger Ratnaparkhi,
1996 SNoW-based Markov Model Punyakanok Roth,
2000
Or, more generally
Conditional
Generative (traditional HMM)
S
S
S
S
S
S
transitions
t
-
1
t
t1
transitions
t
-
1
t
t1
...
...
...
...
...
...
observations
...
entire observation sequence
O
O
O
O
t
t
t
1
-
t
1
Standard belief propagation forward-backward
procedure. Viterbi and Baum-Welch follow
naturally.
14
Exponential Form for Next State Function
st-1
Black-box classifier
weight
feature
Overall Recipe - Labeled data is assigned to
transitions. - Train each states exponential
model by maximum likelihood (iterative scaling
or conjugate gradient).
15
Principle of Maximum Entropy

• The correct distribution P(s,o) is that which
  maximizes entropy, or uncertainty subject to
  constraints
• Constraints represent evidence
• Given k features, constraints have the form,
  i.e. the models
  expectation for each feature should match the
  observed expectation
• Philosophy Making inferences on the basis of
  partial information without biasing the
  assignment would amount to arbitrary assumptions
  of information that we do not have

16
Maximum Entropy Classifier

• Conditional model p(yx)
• Does not try to model p(x)
• Can work with complicated input features since we
  do not need to model dependencies between them.
• Principle of maximum entropy
• We want a classifier
• Matching feature constraints from training data
• Predictions maximize entropy
• There is a unique exponential family distribution
  that meets these criteria.
• Maximum Entropy Classifier
• p(yx?) inference and learning

17
Indicator Features

• Feature functions f(x,y)
• f1(w,y) word is Sarani y Location
• f2(w,y) previous tag Per-begin, current word
  suffix an, y Per-end

18
Problems with MaxEnt classifier

• It makes decisions at each point independently

19
MEMM

• Use a series of maximum entropy classifiers that
  know the previous label
• Define a Viterbi model of inference
• P(yx) ?t Pyt-1 (ytx)
• Finding the most likely label sequence given an
  input sequence and learning
• Combines the advantages of HMM and maximum
  entropy.
• But there is a problem.

20
Maximum Entropy Markov Model
Label bias problem the probability transitions
leaving any given state must sum to one
21

• In some state space configurations, MEMMs
  essentially completely ignore the inputs
• Example of label bias problem
• This is not a problem for HMMs, because the input
  is generated by the model.

22
Label Bias Example
P0.75
P0.25

• Given rib 3 times, rob 1 times
• Training p(10, r)0.75, p(40, r)0.25
• Inference

23
Conditional Markov Models (CMMs) aka MEMMs aka
Maxent Taggers vs HMMS
St-1
St
St1
...
Ot
Ot1
Ot-1
St-1
St
St1
...
Ot
Ot1
Ot-1
24
Random Field
25
CRF

• CRFs have all the advantages of MEMMs without
  label bias problem
• MEMM uses per-state exponential model for the
  conditional probabilities of next states given
  the current state
• CRF has a single exponential model for the joint
  probability of the entire sequence of labels
  given the observation sequence
• Undirected acyclic graph
• Allow some transitions vote more strongly than
  others depending on the corresponding observations

26
Graphical comparison among HMMs, MEMMs and CRFs
HMM MEMM CRF
27
Machine Learning a Panacea?

• A machine learning method is as good as the
  feature set it uses
• Shift focus from linguistic processing to feature
  set design

28
Features to use in IE

• Features are task dependent
• Good feature identification needs a good
  knowledge of the domain combined with automatic
  methods of feature selection.

29
Feature Examples

• Extraction of protein and their interactions from
  biomedical literature (Mooney)
• For each token, they take the following as
  features
• Current token
• Last 2 tokens and next 2 tokens
• Output of dictionary-based tagger for these 5
  tokens
• Suffix for each of the 5 tokens (last 1, 2, and 3
  characters)
• Class labels for last 2 tokens

Two potentially oncogenic cyclins , cyclin A and
cyclin D1 , share common properties of subunit
configuration , tyrosine phosphorylation and
physical association with the Rb protein
30
More Feature Examples

• line, sentence, or paragraph features
• length
• is centered in page
• percent of non-alphabetics
• white-space aligns with next line
• containing sentence has two verbs
• grammatically contains a question
• contains links to authoritative pages
• emissions that are uncountable
• features at multiple levels of granularity

• Example word features
• identity of word
• is in all caps
• ends in -ski
• is part of a noun phrase
• is in a list of city names
• is under node X in WordNet or Cyc
• is in bold font
• is in hyperlink anchor
• features of past future
• last person name was female
• next two words are and Associates

31
Indicator Features

• Theyre a little different from the typical
  supervised ML approach
• Limited to binary values
• Think of a feature as being on or off rather than
  as a feature with a value
• Feature values are relative to an object/class
  pair rather than being a function of the object
  alone.
• Typically have lots and lots of features (100s of
  1000s of features is quite common.)

32
Feature Templates

• Next word
• A feature template gives rise to VxT binary
  features
• Curse of Dimensionality
• Overfitting

33
Feature Selection vs Extraction

• Feature selection Choosing kltd important
  features, ignoring the remaining d k
• Subset selection algorithms
• Feature extraction Project the
• original xi , i 1,...,d dimensions to
• new kltd dimensions, zj , j 1,...,k
• Principal components analysis (PCA), linear
  discriminant analysis (LDA), factor analysis (FA)

34
Feature Reduction

• Example domain NER in Hindi (Sujan Saha)
• Feature Value Selection
• Feature Value Clustering

ACL 2008 Kumar Saha Pabitra Mitra Sudeshna
SarkarWord Clustering and Word Selection Based
Feature Reduction for MaxEnt Based Hindi NER
35
(No Transcript)
36

• Better Approach
• Discriminative model which models P(yx) directly
• Maximize the conditional likelihood of training
  examples

37
Maximum Entropy modeling

• N-gram model probabilities depend on the
  previous few tokens.
• We may identify a more heterogeneous set of
  features which contribute in some way to the
  choice of the current word. (whether it is the
  first word in a story, whether the next word is
  to, whether one of the last 5 words is a
  preposition, etc)
• Maxent combines these features in a probabilistic
  model.
• The given features provide a constraint on the
  model.
• We would like to have a probability distribution
  which, outside of these constraints, is as
  uniform as possible has the maximum entropy
  among all models that satisfy these constraints.

38
Maximum Entropy Markov Model

• Discriminative Sub Models
• Unify two parameters in generative model into one
  conditional model
• Two parameters in generative model,
• parameter in source model
  and parameter in noisy channel
• Unified conditional model
• Employ maximum entropy principle

• Maximum Entropy Markov Model

39
General Maximum Entropy Principle

• Model
• Model distribution P(Y X) with a set of features
  f1, f2, ?, fl defined on X and Y
• Idea
• Collect information of features from training
  data
• Principle
• Model what is known
• Assume nothing else
• ? Flattest distribution
• ? Distribution with the maximum Entropy

40
Example

• (Berger et al., 1996) example
• Model translation of word in from English to
  French
• Need to model P(wordFrench)
• Constraints
• 1 Possible translations dans, en, à, au course
  de, pendant
• 2 dans or en used in 30 of the time
• 3 dans or à in 50 of the time

41
Features

• Features
• 0-1 indicator functions
• 1 if (x, y) satisfies a predefined condition
• 0 if not
• Example POS Tagging

42
Constraints

• Empirical Information
• Statistics from training data T

• Expected Value
• From the distribution P(Y X) we want to model

• Constraints

43
Maximum Entropy Objective

• Entropy

• Maximization Problem

44
Dual Problem

• Dual Problem
• Conditional model
• Maximum likelihood of conditional data

• Solution
• Improved iterative scaling (IIS) (Berger et al.
  1996)
• Generalized iterative scaling (GIS) (McCallum et
  al. 2000)

45
Maximum Entropy Markov Model

• Use Maximum Entropy Approach to Model
• 1st order

• Features
• Basic features (like parameters in HMM)
• Bigram (1st order) or trigram (2nd order) in
  source model
• State-output pair feature (Xk xk, Yk yk)
• Advantage incorporate other advanced features on
  (xk, yk)

46
HMM vs MEMM (1st order)
Maximum Entropy Markov Model (MEMM)
HMM
47
Performance in POS Tagging

• POS Tagging
• Data set WSJ
• Features
• HMM features, spelling features (like ed, -tion,
  -s, -ing, etc.)
• Results (Lafferty et al. 2001)
• 1st order HMM
• 94.31 accuracy, 54.01 OOV accuracy
• 1st order MEMM
• 95.19 accuracy, 73.01 OOV accuracy

48
ME applications

• Part of Speech (POS) Tagging (Ratnaparkhi, 1996)
• P(POS tag context)
• Information sources
• Word window (4)
• Word features (prefix, suffix, capitalization)
• Previous POS tags

49
ME applications

• Abbreviation expansion (Pakhomov, 2002)
• Information sources
• Word window (4)
• Document title
• Word Sense Disambiguation (WSD) (Chao Dyer,
  2002)
• Information sources
• Word window (4)
• Structurally related words (4)
• Sentence Boundary Detection (Reynar
  Ratnaparkhi, 1997)
• Information sources
• Token features (prefix, suffix, capitalization,
  abbreviation)
• Word window (2)

50
Solution

• Global Optimization
• Optimize parameters in a global model
  simultaneously, not in sub models separately
• Alternatives
• Conditional random fields
• Application of perceptron algorithm

51
Why ME?

• Advantages
• Combine multiple knowledge sources
• Local
• Word prefix, suffix, capitalization (POS -
  (Ratnaparkhi, 1996))
• Word POS, POS class, suffix (WSD - (Chao Dyer,
  2002))
• Token prefix, suffix, capitalization,
  abbreviation (Sentence Boundary - (Reynar
  Ratnaparkhi, 1997))
• Global
• N-grams (Rosenfeld, 1997)
• Word window
• Document title (Pakhomov, 2002)
• Structurally related words (Chao Dyer, 2002)
• Sentence length, conventional lexicon (Och Ney,
  2002)
• Combine dependent knowledge sources

52
Why ME?

• Advantages
• Add additional knowledge sources
• Implicit smoothing
• Disadvantages
• Computational
• Expected value at each iteration
• Normalizing constant
• Overfitting
• Feature selection
• Cutoffs
• Basic Feature Selection (Berger et al., 1996)

53
Conditional Models

• Conditional probability P(label sequence y
  observation sequence x) rather than joint
  probability P(y, x)
• Specify the probability of possible label
  sequences given an observation sequence
• Allow arbitrary, non-independent features on the
  observation sequence X
• The probability of a transition between labels
  may depend on past and future observations
• Relax strong independence assumptions in
  generative models

54
Discriminative ModelsMaximum Entropy Markov
Models (MEMMs)

• Exponential model
• Given training set X with label sequence Y
• Train a model ? that maximizes P(YX, ?)
• For a new data sequence x, the predicted label y
  maximizes P(yx, ?)
• Notice the per-state normalization

55
MEMMs (contd)

• MEMMs have all the advantages of Conditional
  Models
• Per-state normalization all the mass that
  arrives at a state must be distributed among the
  possible successor states (conservation of score
  mass)
• Subject to Label Bias Problem
• Bias toward states with fewer outgoing transitions

56
Label Bias Problem

• Consider this MEMM

• P(1 and 2 ro) P(2 1 and ro)P(1 ro)
  P(2 1 and o)P(1 r)
• P(1 and 2 ri) P(2 1 and ri)P(1 ri)
  P(2 1 and i)P(1 r)
• Since P(2 1 and x) 1 for all x, P(1 and 2
  ro) P(1 and 2 ri)
• In the training data, label value 2 is the only
  label value observed after label value 1
• Therefore P(2 1) 1, so P(2 1 and x) 1 for
  all x
• However, we expect P(1 and 2 ri) to be
  greater than P(1 and 2 ro).
• Per-state normalization does not allow the
  required expectation

57
Solve the Label Bias Problem

• Change the state-transition structure of the
  model
• Not always practical to change the set of states
• Start with a fully-connected model and let the
  training procedure figure out a good structure
• Prelude the use of prior, which is very valuable
  (e.g. in information extraction)

58
Random Field
59
Conditional Random Fields (CRFs)

• CRFs have all the advantages of MEMMs without
  label bias problem
• MEMM uses per-state exponential model for the
  conditional probabilities of next states given
  the current state
• CRF has a single exponential model for the joint
  probability of the entire sequence of labels
  given the observation sequence
• Undirected acyclic graph
• Allow some transitions vote more strongly than
  others depending on the corresponding observations

60
Definition of CRFs
X is a random variable over data sequences to be
labeled Y is a random variable over corresponding
label sequences
61
Example of CRFs
62
Graphical comparison among HMMs, MEMMs and CRFs
HMM MEMM CRF
63
Conditional Distribution
64
Conditional Distribution (contd)

• CRFs use the observation-dependent
  normalization Z(x) for the conditional
  distributions

Z(x) is a normalization over the data sequence x
65
Parameter Estimation for CRFs

• The paper provided iterative scaling algorithms
• It turns out to be very inefficient
• Prof. Dietterichs group applied Gradient
  Descendent Algorithm, which is quite efficient

66
Training of CRFs (From Prof. Dietterich)

• Then, take the derivative of the above equation

• For training, the first 2 items are easy to get.
• For example, for each lk, fk is a sequence of
  Boolean numbers, such as 00101110100111.
• is just the total number of 1s in the
  sequence.

• The hardest thing is how to calculate Z(x)

67
Training of CRFs (From Prof. Dietterich) (contd)

• Maximal cliques

68
POS tagging Experiments
69
POS tagging Experiments (contd)

• Compared HMMs, MEMMs, and CRFs on Penn treebank
  POS tagging
• Each word in a given input sentence must be
  labeled with one of 45 syntactic tags
• Add a small set of orthographic features whether
  a spelling begins with a number or upper case
  letter, whether it contains a hyphen, and if it
  contains one of the following suffixes -ing,
  -ogy, -ed, -s, -ly, -ion, -tion, -ity, -ies
• oov out-of-vocabulary (not observed in the
  training set)

70
Summary

• Discriminative models are prone to the label bias
  problem
• CRFs provide the benefits of discriminative
  models
• CRFs solve the label bias problem well, and
  demonstrate good performance
