Week 14: Activity Diagram

1
Week 14 Activity Diagram Interaction Diagrams
IFS 410 Advanced Analysis and Design
2
UML Techniques for OO Design

• Activity Diagram
• Communication (Collaboration) Diagram
• Sequence Diagram
• Package, Component, Deployment Diagrams

3
Activity Diagrams

• Shows the conditional logic for the sequence of
  system activities needed to accomplish a business
  process
• Clearly shows parallel and alternative behaviors
• Can be used to show the logic of a use case

4
Activity Diagram

• Focus on system behavior
• Model an objects workflow during program
  execution
• Model the actions the object will perform and in
  what order
• UML representation
• Action state ( rectangle with its left and right
  sides replaced by arcs curving outwards)
• Action order ( arrow with a stick arrowhead)
• Initial state (solid circle)
• Final state (solid circle enclosed in an open
  circle)

5
Components of Activity Diagram
6
Fig. 5.30 Activity diagram for a BalanceInquiry
object.
7
Fig. 5.31 Activity diagram for a withdrawal
transaction.
8
When to Use Activity Diagrams

• Activity diagrams are useful when you want to
  describe a behavior which is parallel, or when
  you want to show how behaviors in several
  use-cases interact.
• Use Communication diagrams when you want to show
  how objects collaborate to implement an activity
  diagram. Use a state (chart) diagram to show how
  one object (attribute) changes during its
  lifetime.

9
Interaction Diagrams

• Model interactions use UML
• Communication diagrams
• Also called collaboration diagrams
• Emphasize which objects participate in
  collaborations
• Sequence diagrams
• Emphasize when messages are sent between objects

10
A communication diagram
Fig. 7.26 Communication diagram of the ATM
executing a balance inquiry.
11
Sequence diagrams

• Help model the timing of collaborations
• Lifeline
• Dotted line extending down from an objects
  rectangle
• Represents the progression of time
• Activation
• Thin vertical rectangle
• Indicates that an object is executing

12
A Sequence Diagram
Fig. 7.28 Sequence diagram that models a
Withdrawal executing.
13
Elements in Sequence Diagrams
14
Creating a Sequence Diagram
