Concepts of Multimedia Processing and Transmission

1
Concepts of Multimedia Processing and Transmission

• IT 481, Lecture 7
• Dennis McCaughey, Ph.D.
• 19 March, 2007

2
Direct Video Broadcast (DVB) Systems
Slide Courtesy, Hung Nguyen
3
Processing of The Streams in The Set-Top Box (STB)
Slide Courtesy, Hung Nguyen
4
Multimedia CommunicationsStandards and
Applications
Slide Courtesy, Hung Nguyen
5
Video Coding Standards

• ITU H.261 for Video Teleconference (VTC)
• ITU H.263 for VTC over POTS
• ITU H.262 for VTC over ATM/broadband and digital
  TV networks
• ISO MPEG-1 for movies on CDROM (VCD)
• 1.2 Mbps for video coding and 256 Kbps for audio
  coding
• ISO MPEG-2 for broadcast quality video on DVD
• 2-15 Mbps allocated for audio and video coding
• Low-bit rate telephony over POTS
• 10 Kbps for video and 5.3 Kbps for audio
• Internet and mobile communication MPEG-4
• Very Low Bit Rate (VLBR) code to be compatible
  with H.263
• Multimedia content description interface MPEG-7
• Description schemes and description definition
  language for integrated multimedia search engine

Slide Courtesy, Hung Nguyen
6
History

• H.261
• First video coding standard, targeted for video
  conferencing over ISDN. Uses block-based hybrid
  coding framework with integer-pixel MC
• H.263
• Improved quality at lower bit rate, to enable
  video conferencing/telephony below 54 kbps
  (modems, desktop conferencing)
• Half-pixel MC and other improvement
• MPEG-1 video
• Video on CD and video on the Internet (good
  quality at 1.5 mbps)
• Half-pixel MC and bidirectional MC
• MPEG-2 video
• SDTV/HDTV/DVD (4-15 mbps)
• Extended from MPEG-1, considering interlaced video

Slide Courtesy, Hung Nguyen
7
H.261 Video Coding Standard

• For video-conferencing/video phone
• Video coding standard in H.320 (VTC over switched
  phone network) which is an umbrella
  recommendation
• Low delay (real-time, interactive)
• Slow motion in general
• For transmission over ISDN
• Fixed bandwidth px64 Kbps, p1,2,,30
• Video Format
• CIF (352x288, above 128 Kbps) - Common Interface
  Format
• QCIF (176x144, 64-128 Kbps) - Quarter CIF
• 420 color format, progressive scan
• Published in 1990
• Each macroblock can be coded in intra- or
  inter-mode
• Periodic insertion of intra-mode to eliminate
  error propagation due to network impairments
• Integer-pixel accuracy motion estimation in
  inter-mode

Slide Courtesy, Hung Nguyen
8
H.261 Encoder

• F Loop filter P motion estimation and
  compensation
• Loop filter apply low-pass filter to smooth the
  quantization noise in previously reconstructed
  frames before motion estimation and compensation

Slide Courtesy, Hung Nguyen
9
Picture Frames - Overview

• Three frame types I-Picture (Intra-frame
  picture), P-Picture (Inter-frame predicted
  picture) and B-Picture (Bi-directional predicted-
  interpolated pictures)
• I-Picture is being coded by intra-frame coding.
  When encoding I-Picture, we only reduce the
  spatial redundancy in the picture without
  referencing other pictures. The coding process is
  much similar to JPEG Standard. So encoding
  I-Picture is less complex than P-frame and B-frame

The basic coding unit is a 8 by 8 matrix block. A
macroblock is consists of six block 4 block of
luminance (Y) , one block of Cb chrominance, and
one block of Cr chrominance
Slide Courtesy, Hung Nguyen
10
Frame Types

• Intracoded Frames -gt I-Frames
• Level of compression is relatively small 101 to
  201
• Present at regular intervals to limit extent of
  errors
• Number of frames between I-frames is known as the
  Group of pictures (GOP)
• 101 to 201 compression ratio
• Intercoded Frames
• Predicted Frames-gt P-Frames
• Significant compression level achieved here
• Errors are propagated
• 201 to 301 compression ratio
• Bidirectional Frames -gt B-Frames
• Highest levels of compression achieved
• B-frames are not used for prediction, thus errors
  are not propagated
• 301 to 501 compression ratio

11
Macro Blocks Color Sub-sampling Schemes
A macroblock consists of 4 8x8 pixel blocks
Slide Courtesy, Hung Nguyen
12
Sub-sampling of Chrominance Information

• Transforming (R,G,B)-gt(Y,Cb,Cr) provides two
  advantages
• 1)The human visual system (HVS) is more sensitive
  to Y component than the Cb or Cr components.
• 2) Cb and Cr are far less correlated with Y than
  R with G, R with Blue and Blue with G, thus
  reducing TV transmission bandwidths.
• Cb and Cr both require far less bandwidth and can
  be sampled more coarsely (Shannon).
• By doing so we can reduce data without affecting
  visual quality from a personal view.

Slide Courtesy, Hung Nguyen
13
Color Space Conversion

• In general , each pixel in a picture consists of
  three components R (Red), G (Green), B (Blue).
  (R,G,B) must be converted to (Y,Cb,Cr) in MPEG-1
  before processing
• We can view the color value of each pixel from
  RGB color space , or YCbCr color space
• Because (Y,Cb,Cr) is less correlated than
  (R,G,B), coding using (Y,Cb,Cr) components is
  more efficient.
• (Y,U,V) can also be used to denote (Y,Cb,Cr),
  however it most appropriately represents the
  analog TV equivalent

Slide Courtesy, Hung Nguyen
14
RGB Image
15
Compressed Image (QSF24)
16
Luminance Plane (Y)
17
Blue Chrominance Plane (Cb)
18
Red Chrominance Plane (Cr)
19
Red
20
Green
21
Blue
22
DCT (discrete cosine transform)

• DCT is used to convert data from the spatial
  domain to data in frequency domain. The higher
  frequency coefficients can be more coarsely
  quantized without a perceived loss of image
  quality due to the fact that the HVS is less
  sensitive to the higher frequencies and they
  contain less energy.
• The DCT coefficient at location (0,0) is called
  DC coefficient and the other values we call them
  AC coefficients. In general, we use large
  quantization step in quantizing the higher AC
  coefficients. Higher precision is required for
  the DC term in order to avoid blocking in the
  reconstructed image.
• In MPEG-1, we use 88 DCT. By using this
  transform we can convert a 8 by 8 pixel block to
  another 8 by 8 block. In general most of the
  energy(value) is concentrated to the top-left
  corner.
• After quantizing the transformed matrix, most
  data in this matrix may be zero, then using
  zig-zag order scan and run length coding can
  achieve a high compression ratio.

Slide Courtesy, Hung Nguyen
23
Transform Coding (TC)

• Pack the signal energy into as few transform
  coefficients as possible
• The DCT yields nearly optimal energy
  concentration
• A 2-dimensional DCT with block size of 8x8 pixels
  is commonly used in todays image coder
• Transform is followed by quantization and entropy
  coding

Slide Courtesy, Hung Nguyen
24
2D DCT and IDCT
u, v, x, y 0, 1,2, .,7
Slide Courtesy, Hung Nguyen
25
DCT Scan Modes

• The zigzag scan used in MPEG-1 is suitable for
  progressive images where frequency components
  have equal importance in each horizontal and
  vertical direction. (Frame pictures only)
• In MPEG-2, an alternate scan is introduced
  because interlaced images tend to have higher
  frequency components in the vertical direction.
  Thus, the scanning order weighs more on the
  higher vertical frequencies than the same
  horizontal frequencies. Selection between these
  two zigzag scan orders can be made on a picture
  basis. (Frame and field pictures allowed)

Slide Courtesy, Hung Nguyen
26
Motion Compensation

• Try to match each block in the actual picture to
  content in the previous picture. Matching is made
  by shifting each of the 8 x 8 blocks of the two
  successive pictures pixel by pixel each direction
  -gt Motion vector
• Subtract the two blocks -gt Difference block
• Transmit the motion vector and the difference
  block

Slide Courtesy, Hung Nguyen
27
Quantization

• In MPEG-1, a matrix called the quantizer ( Qi,j
  ) defines the quantization step. If ( Xi,j ) is
  the DCT matrix with the same size as Qi,j,
  Xi,j is divided by Qi,jQSF to obtain the
  quantized value matrix Xqi,j . QSF is the
  Quantization Scale Factor
• Quantization Equation
• Xqi,j Round( Xi,j/(Qi,j QSF))
• Inverse Quantization (dequantize) is to
  reconstruct original value.
• Inverse Quantization Equation
• X'i,jQSFXqi,jQi,j
• The difference between actual value and
  reconstructed value from quantized value is
  called the quantization error. In general if we
  carefully design Qi,j, visual quality will not
  be affected.

Slide Courtesy, Hung Nguyen
28
Quantization (contd)
Slide Courtesy, Hung Nguyen
29
Average Distribution of AC Coefficients
30
MPEG (Moving Picture Expert Group)

• Established in January 1988
• Operated in the framework of the Joint ISO/IEC
  Technical Committee
• ISO International Organization for
  Standardization
• IEC International Electro-technical Commission
• First meeting was in May 1988 with 25 experts
  participated
• Grown to 350 experts from 200 companies in some
  20 countries
• As a rule, MPEG meets in March, July and November
  could be more often as needed

Slide Courtesy, Hung Nguyen
31
MPEG-1 Coding of Moving Pictures and Associated
Audio

• Request for Proposal (RFP) July 1989
• Adopted in 1993
• Coding of audiovisual signal at 1.5 Mbps
• Audio coding is separate from speech at 256
  Kbps/per channel PCM
• Five parts systems, video, audio, conformance
  testing and software simulation

Slide Courtesy, Hung Nguyen
32
MPEG-1 Overview

• In MPEG-1, video is represented as a sequence of
  pictures, and each picture is treated as a
  two-dimensional array of pixels (pixels)
• The color of each pixel is consists of three
  components Y (luminance), Cb and Cr (two
  chrominance components)
• Composite video, aka baseband video or RCA video,
  is the analog waveform that conveys the image
  data in a conventional National Television
  Standards Committee (NTSC) television signal
• Composite video contains chrominance (hue and
  saturation) and luminance (brightness)
  information, along with synchronization and
  blanking pulses
• In order to achieve high compression ratio,
  MPEG-1 must use hybrid coding techniques to
  reduce both spatial redundancy and temporal
  redundancy

Slide Courtesy, Hung Nguyen
33
MPEG-1 Overview

• Audio/video on CD-ROM (1.5 Mbps, CIF 352x240)
• Maximum 1.856 mbps, 768x576 pixels
• Start late 1988, test in 10/89, Committee Draft
  9/90
• ISO/IEC 11172-15 (Systems, video, audio,
  compliance, software).
• Prompted explosion of digital video applications
  MPEG1 video CD and downloadable video over
  Internet
• Software only decoding, made possible by the
  introduction of Pentium chips, key to the success
  in the commercial market
• MPEG-1 Audio
• Offers 3 coding options (3 layers), higher layer
  have higher coding efficiency with more
  computations
• MP3 MPEG1 layer 3 audio

Slide Courtesy, Hung Nguyen
34
MPEG-2 vs. MPEG-1

• MPEG-2 is a superset of MPEG-1.
• Generally, MPEG-1 is used for CD-ROM or Video CD
  (VCD) and MPEG-2 is used for broadcast or DVD.
• One current difference between MPEG-1 and MPEG-2
  is that MPEG-2 has implemented variable bit rate.

• MPEG-2 also is whats known as a closed format,
  meaning that a license fee must be paid to use
  the decoding algorithms, where MPEG-1 can be
  implemented free of charge.

Slide Courtesy, Hung Nguyen
35
MPEG2 vs. MPEG1 (contd)

• MPEG1 only handles progressive sequences
  specified by Source Input Format (SIF).
• MPEG2 is targeted primarily at interlaced, as
  opposed to progressive for MPEG-1, sequences and
  at higher resolution.
• Different DCT modes and scanning methods are
  developed for interlaced sequences.
• More sophisticated motion estimation methods
  (frame/field prediction mode) are developed to
  improve estimation accuracy for interlaced
  sequences.
• MPEG2 has various scalability modes.
• MPEG2 has various profiles and levels, each
  combination targeted for a different application

Slide Courtesy, Hung Nguyen
36
MPEG Encoding

• Frame Types
• I Intra Encode complete image, similar to JPEG
• P Forward Predicted Motion relative to previous
  I and Ps
• B Backward Predicted Motion relative to previous
  future Is Ps

Slide Courtesy, Hung Nguyen
37
Frame Reconstruction (I P Frames Only)

• I frame complete image
• P frames provide series of updates to most recent
  I frame

Slide Courtesy, Hung Nguyen
38
Using Forward-Backward Prediction

• If only forward prediction is used, there are
  uncovered areas (such as block behind car in
  Frame N) for which we may not be able to find a
  good match from the previous reference picture
  (Frame N-1).
• On the other hand, backward prediction can
  properly predict these uncovered areas since they
  are available in the future reference picture,
  i.e. frame N1 in this example.
• New objects such as an airplane moving into the
  picture, cannot be predicted from the previous
  picture, but can be predicted from the future
  picture.

Backward Prediction
Forward Prediction
Slide Courtesy, Hung Nguyen
39
Frame Reconstruction (contd)

• B frames interpolate between frames represented
  by Is Ps

Slide Courtesy, Hung Nguyen
40
Transmission Order of the Frames
Slide Courtesy, Hung Nguyen
41
Intra-frame Encoding Process

• Decomposing image to three components in RGB
  space
• Converting RGB to YCbCr
• Dividing image into several macroblocks (each
  macroblock has 6 blocks , 4 for Y, 1 for Cb, 1
  for Cr)
• DCT transformation for each block
• After DCT transform , Quantizing each coefficient

• Then use zig-zag scan to gather AC value Use
  DPCM to encode the DC value, then use VLC to
  encode it
• Use RLE to encode the AC value, then use VLC to
  encode it

42
I-Picture Encoding Flow Chart
Slide Courtesy, Hung Nguyen
43
(No Transcript)
44
Inter-frame Coding

• The kind of pictures that are using the
  intra-frame coding technique are P pictures and B
  pictures
• Coding of the P pictures is more complex than for
  I pictures, since motion-compensated macroblocks
  may be constructed
• The difference between the motion compensated
  macroblock and the current macroblock is
  transformed with a 2-dimensional DCT giving an
  array of 8 by 8 transform coefficients.
• The coefficients are quantized to produce a set
  of quantized coefficients. The quantized
  coefficients are then encoded using a run-length
  value technique.

Slide Courtesy, Hung Nguyen
45
Inter-frame Encoding Process

• Decomposing image to three components in RGB
  space
• Converting RGB to YCbCr
• Perform motion estimation to record the
  difference between the encoding frame and the
  reference frame stored within the frame buffer
• Dividing image into several macroblocks (each
  macroblock has 6 blocks , 4 for Y, 1 for Cb, 1
  for Cr)
• DCT transformation for each block
• Quantizing each coefficient
• Use zig-zag scan to gather AC value
• Reconstruct the frame and store it to the frame
  buffer if necessary
• DPCM is applied to encode the DC value, then use
  VLC to encode it
• Use RLE to encode the AC value, then use VLC to
  encode it

Slide Courtesy, Hung Nguyen
46
Predictive Coding

• Predictive coding is a technique to reduce
  statistical redundancy. That is based on the
  current value to predict next value and code
  their difference (called prediction error). If we
  predict next value more precisely, then the
  prediction error will be small.
• So we can use less bits to encode prediction
  error than actual value. In MPEG-1, we use DPCM
  (Difference Pulse Coded Modulation) techniques
  which is a kind of predictive coding. And it is
  only used in DC coefficient

Slide Courtesy, Hung Nguyen
47
Motion Compensation (MC) And Motion Estimation
(ME)

• Motion Estimation is to predict a block of
  pixels' value in next picture using a block in
  current picture. The location difference between
  these blocks is called Motion Vector. And the
  difference between two blocks is called
  prediction error.
• In MPEG-1, encoder must calculate the motion
  vector and prediction error. When decoder obtain
  these information , it can use this information
  and current picture to reconstruct the next
  picture.
• We usually call this process as Motion
  Compensation. In general, motion compensation is
  the inverse process of motion Estimation

Slide Courtesy, Hung Nguyen
48
Motion Estimation (ME)
Slide Courtesy, Hung Nguyen
49
Motion Compensation (MC)
Slide Courtesy, Hung Nguyen
50
P-Frame Encoding Macroblock Structure
51
P-Frame Encoding Encoding Procedure
52
Example Frame Sequences
I and P Frames Only
I,P and B Frames
53
Coding of P Pictures

• As in I pictures, the encoder needs to store the
  decoded P pictures since this may be used as the
  starting point for motion compensation.
  Therefore, the encoder will reconstruct the image
  from the quantized coefficients.
• In coding P pictures, the encoder has more
  decisions to make than in the case of I pictures
• Selection of Macroblock Type There are 8 types
  of macroblock in P pictures.
• Motion Compensation Decision The encoder has an
  option on whether to transmit motion vectors or
  not for predictive-coded macroblocks.
• Intra/Non-intra Coding Decision Coded/Not Coded
  DecisionAfter quantization, if all the
  coefficients in a block is zero then the block is
  not coded.
• Quantizer/No Quantizer Decision Quantizer scale
  can be altered which will affect the picture
  quality.

Slide Courtesy, Hung Nguyen
54
The Inter-frame Encoding Flow Chart
Slide Courtesy, Hung Nguyen
55
Coding of P Pictures (contd)
Slide Courtesy, Hung Nguyen
56
Coding of B Pictures

• B pictures are divided into slices in the same
  way as I and P pictures. Since B pictures are not
  used as a reference for motion compensation,
  errors in B pictures are slightly less important
  than in I or P pictures. Consequently, it might
  be appropriate to use fewer slices for B pictures

57
Decisions to be made when coding the B pictures

• Selection of Macroblock Type There are 12 types
  of macroblock in B pictures. Compare with P
  pictures, there are extra types due to the
  introduction of the backward motion vector. If
  both the backward and backward motion vectors are
  present, then motion-compensated macroblocks are
  constructed from both previous and future
  pictures, and the result is averaged to form the
  "interpolated" motion-compensated macroblock.
• Selecting Motion Compensation Mode
• Intra/Non-Intra Coding
• Coded/Not Coded Decision

Slide Courtesy, Hung Nguyen
58
Coding of B-Pictures
59
Variable Length Coding (VLC)

• In MPEG-1, the last of all encoding processes is
  to use a Huffman Code to reduce data redundancy
  and the first step in decoding process is to
  decode VLC to reconstruct image data
• Encoding and decoding processes with a Huffman
  Code must refer to a code table having two
  entries
• The original data and the corresponding codeword.

• In MPEG-1 standard , multiple code tables are
  defined in MPEG-1 Standard 2-ANNEX C. The use of
  multiple code tables improves the compression
  ratio.

Slide Courtesy, Hung Nguyen
60
MPEG-2 vs. MPEG-1

• MPEG-2 is a superset of MPEG-1.
• Generally, MPEG-1 is used for CD-ROM or Video CD
  (VCD) and MPEG-2 is used for broadcast or DVD.
• One current difference between MPEG-1 and MPEG-2
  is that MPEG-2 has implemented variable bit rate.

• MPEG-2 also is whats known as a closed format,
  meaning that a license fee must be paid to use
  the decoding algorithms, where MPEG-1 can be
  implemented free of charge.

Slide Courtesy, Hung Nguyen
61
MPEG2 vs. MPEG1 (contd)

• MPEG1 only handles progressive sequences
  specified by Source Input Format (SIF).
• MPEG2 is targeted primarily at interlaced, as
  opposed to progressive for MPEG-1, sequences and
  at higher resolution.
• Different DCT modes and scanning methods are
  developed for interlaced sequences.
• More sophisticated motion estimation methods
  (frame/field prediction mode) are developed to
  improve estimation accuracy for interlaced
  sequences.
• MPEG2 has various scalability modes.
• MPEG2 has various profiles and levels, each
  combination targeted for a different application

Slide Courtesy, Hung Nguyen
62
MPEG2 Overview

• A/V broadcast (TV, HDTV, Terrestrial, Cable,
  Satellite, High Speed Inter/Intranet) as well as
  DVD video
• 48 Mbps for TV quality, 10-15 Mbps for better
  quality at SDTV resolutions (BT.601)
• 18-45 Mbps for HDTV applications
• MPEG-2 video high profile at high level is the
  video coding standard used in HDTV
• Test in 11/91, Committee Draft 11/93
• ISO/IEC 13818-16 (Systems, video, audio,
  compliance, software, DSM-CC)
• Consist of various profiles and levels
• Backward compatible with MPEG1
• MPEG-2 Audio
• Support 5.1 channel
• MPEG2 AAC (Advanced Audio Coding) requires 30
  fewer bits than, and not backward compatible
  with, MPEG1 layer 3 or MP3

Slide Courtesy, Hung Nguyen
63
Features Supported by the MPEG-2 Algorithm

• Different chrominance sampling formats (i.e.,
  420, 422, and 444) can be represented
• Video in both the progressive and interlaced scan
  formats can be encoded
• The decoder can use 32 pull down to represent a
  24 fps film as 30 fps video
• The displayed video can be selected by a movable
  pan-scan window within a larger raster
• A wide range for picture qualities can be used
• Both constant an variable bit rate channels are
  supported
• ISO/IEC 11172-2 bit streams are decodable
• Bit streams for high and low (hardware)
  complexity decoders can be generated
• Editing of encoded video is supported
• The encoded bit stream is resilient to errors

Slide Courtesy, Hung Nguyen
64
MPEG-2 Slice and Macro-block Structure
Slide Courtesy, Hung Nguyen
65
MPEG-2 Bit Stream Syntax
GOF Group of Frames
Slide Courtesy, Hung Nguyen
66
Progressive vs. Interlaced Scanning

• In the Interlaced video, each displayed frame
  consists of two interlaced fields, with the
  scanning lines in Field 1 located between the
  lines of Field 2.
• On the contrary, the Progressive video has all
  the lines of a picture displayed in one frame.
  Thus, progressive video requires a higher picture
  rate than the frame-rate of an Interlaced video,
  to avoid a flickering display.

(a) Progressive Scan (b) Interlaced Scan
Slide Courtesy, Hung Nguyen
67
Disadvantage of Interlaced Scanning

• A moving object may appear distorted when two
  fields are merged into a frame.
• Since a moving ball will be at different
  locations in the two fields in the Interlaced
  Format, the ball will look distorted when two
  fields are put into a frame
• Interlaced video also tends to cause horizontal
  picture details to dither thus introduces more
  high frequency noises

(a) Progressive Scan (b) Interlaced Scan
Slide Courtesy, Hung Nguyen
68
Field vs. Frame DCT

• Frame-based DCT Suitable for the blocks in the
  background or in a still image having little
  motion because these blocks have high correlation
  between pixel values from adjacent scan lines.
• Field-based DCT Suitable for blocks having
  motion because motion causes distortion and may
  introduce high-frequency noises into the
  interlaced frame.

Slide Courtesy, Hung Nguyen
69
HDTV Standards
Standard Samples/Line Number of Lines Aspect Ratio
Advanced television (ATV) 1280 720 16/9
Digital Video Broadcast (DVB) 1440 1152 4/3
Multiple Sub-Nyquist Sampling Encoding (MUSE) 1920 1035 16/9
ITU-R HDTV 1920 1152 16/9
70
Summary

• H.261
• First video coding standard, targeted for video
  conferencing over ISDN. Uses block-based hybrid
  coding framework with integer-pixel MC
• H.263
• Improved quality at lower bit rate, to enable
  video conferencing/telephony below 54 bkps
  (modems, desktop conferencing)
• Half-pixel MC and other improvement
• MPEG-1 video
• Video on CD and video on the Internet (good
  quality at 1.5 mbps)
• Half-pixel MC and bidirectional MC
• MPEG-2 video
• SDTV/HDTV/DVD (4-15 mbps)
• Extended from MPEG-1, considering interlaced video

Slide Courtesy, Hung Nguyen
