Title: MAKING SIMPLE DECISIONS


1
MAKING SIMPLE DECISIONS
Russell Norvig
  • Reetal Pai
  • April 9, 2002

2
Ideas
  • Utility Functions
  • Utility functions that depend on several
    quantities
  • Decision Theoretic Agent
  • Decision Networks / Influence Diagrams
  • Information Theory

3
Utility Functions
  • Utility functions an agents preference
    between world states. Assigns a single number to
    express the desirability of a state.
  • States are complete snapshots of the world.
  • U(S) utility of a state S according to the
    agent making the decisions.

Result1(A)
Action A
Result2(A)
Evidence available to the agent
Non- deterministic
Result3(A)
P(Resulti(A)/Do(A), E)
4
Maximum Expected Utility ( MEU)
  • Expected Utility
  • EU (A/E) ?i P(Resulti(A) /Do
    (A), E) U(Resulti(A))
  • Principle of MEU A rational agent should choose
    an action that maximizes its EU.
  • Problems with MEU -
  • Computationally prohibitive.
  • Difficult to formulate any problem completely.
  • Knowing the initial state of the world requires
    perception, inference, knowledge
    representation and learning.
  • Computing P(Resulti(A) /Do (A), E) requires a
    complete causal model of the entire world.
  • Computing U(Resulti(A)) requires search and
    planning. An agent does not know the goodness of
    a state until it gets to it.

5
Utility Functions
  • If an agent maximizes a utility function that
    correctly reflects the performance measure by
    which its behavior is being judged, then it will
    achieve the highest possible performance score,
    if we average over the possible environments in
    which the agent could be placed.
  • Single / one-shot decisions as opposed to
    sequential decisions.

6
Utility Theory
  • Complex scenarios are called Lotteries.
  • Different outcomes are like prizes and they are
    determined by chance.
  • L p, A 1-p , B
  • Multiple outcomes. Outcomes can be atomic or
    other lotteries.
  • Preferences between lotteries defined as
  • A gt B A is preferred to B
  • A B Agent is indifferent between A B
  • A gt B Agent prefers A to B or is indifferent
    between them.

7
Axioms of Utility Theory
  • Orderability An agent should know what it
    wants.
  • (A gt B) ? (B gt A) ? (A B)
  • Transitivity Preferences are transitive.
  • (A gt B) (B gt C) gt (A gt C)
  • Continuity For some state B which lies between
    A and C in preference,
  • A gt B gt C gt ? p p, A 1-p, C B
  • Substitutability
  • A B gt p, A 1-p, C p, B 1-p, C
  • Monotonicity
  • A gt B p ? q gt p, A 1-p, B gt q, A 1-q,
    B
  • Decomposability An agent should not prefer a
    lottery just because it has more choices than
    another.
  • p, A 1-p, q, B 1-q, C p, A (1-p)q, B
    (1-p)(1-q), C

8
Utility Principle
  • Utility axioms refer only to preferences
    basic property of rational agents.
  • Utility Principle If the agents preferences
    obey the axioms of utility, then there is a real
    valued function U that operates on states A B
    such that
  • U(A) gt U(B) iff A gt B
  • U(A) U(B) iff A B
  • MEU Principle
  • Utility of a lottery ? (Probability of each
    outcome) (Utility of that outcome)
  • U(p1, s1 , pn, sn ) ?i pi U(si)

9
Choice of Utility Function
  • Utility theory has its roots in economics.
  • Money is an obvious candidate for utility
    measure.
  • Agent has a monotonic preference for money.
  • Money behaves as an ordinal utility measure gt
    agent prefers more money to less when considering
    definite amounts.

10
Definitions of agent behavior
  • Risk averse agents For a lottery L, the utility
    of being faced with the lottery lt utility of
    being handed the expected monetary value of the
    lottery as a sure thing.
  • U(SL) lt U(SEMV(L))
  • Risk seeking
  • U(SL) gt U(SEMV(L))
  • Certainty Equivalent of the lottery Value an
    agent will accept in lieu of lottery.
  • Insurance premium difference between EMV of a
    lottery and its certainty equivalent.
  • Risk Neutral An agent with a linear curve
    (Utility versus money) .

11
Assess Utilities
  • Establish a scale with a best possible prize and
    the worst possible catastrophe.
  • U(S) u U(S) u ?
  • Normalized utilities
  • U(S) u 1 U(S) u ? 0
  • Utilities of intermediate outcomes are assessed
    by asking the agent to indicate a preference
    between outcome state S and a standard lottery
    p, u (1-p) u ? .

12
Multi-attribute Utility Function
  • If an option has attributes X1, X2,. Xn with
    values x1, x2, xn then the utility function is
  • U(x1, x2, xn ) f f1(x1),.fn(xn)
  • Strict dominance If an option has higher values
    on all attributes than another option.
  • Cumulative Distribution Measures the
    probability that the cost ? any given amount. It
    integrates the original distribution.
  • Stochastic Dominance Action A1 dominates A2 on
    X if
  • ? x p1(x) dx ? p2(x) dx
  • In this case we now have n attributes with m
    possible values. gt Possible outcomes of size mn.
    Therefore we need simplified decision procedures.

13
Mutual Preferential Independence
  • 2 attributes X1 X2 are preferentially
    independent of a third attribute X3 if the
    preference between outcomes (x1, x2, x3) (x1,
    x2, x3) does not depend on a particular value x3
    for X3.
  • MPI gt Each attribute may be independent, but it
    does not affect the way in which one trades off
    the other attributes against each other.
  • If attributes are MPI then the agents preference
    behavior can be described as maximizing the
    function
  • V(S) ?i Vi(Xi(S))

14
Decision Networks
  • Combine belief networks with additional node
    types for actions and utilities.
  • It represents information about the agents
    current state, its possible actions, the state
    resulting from the agents action and the utility
    of that state.

Airport Site
Air Traffic
Deaths
U
Litigation
Noise
Construction
Cost
15
Evaluating Decision Networks
  • Algorithm for evaluating decision networks
  • Set the evidence variables for the current state.
  • For each possible value of the decision node
  • Set the decision node to that value.
  • Calculate the posterior probabilities for the
    parent nodes of the utility node.
  • Calculate the resulting utility for the action.
  • Return the action with the highest utility.

16
Information Theory
  • Important part of decision making is knowing
    which questions to ask.
  • Value of the current best action ? be
  • EU(?/E) max ?i P(Resulti(A) /Do (A), E)
    U(Resulti(A))
  • Value of the best action after new evidence Ej is
    obtained
  • EU(?/E, Ej) max ?i P(Resulti(A) /Do (A), E, Ej)
    U(Resulti(A))
  • Value of discovering Ej is defined as
  • VPI(Ej ) ?k P(Ej ejk/E) EU(? ejk/E, Ej ejk
    ) - EU(?/E)
  • Myopic or a greedy search agent

17
Modular Utility Representation For Decision
Theoretic Planning
Michael P. Wellman Jon Doyle
18
Decision Theoretic Planning
  • Design planning systems to design constructs that
    can be represented in terms of probabilities and
    utilities.
  • Support computationally tractable inference about
    plans and partial plans.
  • Goals do not provide any means to resolve
    tradeoffs among competing tradeoffs or to
    express partial satisfaction.
  • Ad hoc measures to account for this include
    augmenting goals with numeric achievement values
    to individual goals.
  • Problem measures lack any precise meaning.

19
Decision Theoretic Planning
  • Using decision theoretic preferences allows
    designers to
  • Judge coherence of objectives
  • Judge effectiveness of the planning system
  • 2 options in using decision theory
  • Specify a utility function over the entire domain
    and ranking the plan results by desirability.
  • Modular representations that separately specify
    preference information so as to allow dynamic
    combination of relevant factors.

20
Modularity
  • Modularity in knowledge representation
    specification of flexibly composable model
    elements.
  • Synthesis of a composite plan involves looking at
    the overall effects of the plan as a modular
    combination of the effects of its constituent
    actions.
  • Specify utility functions over individual
    features or small groups of features and
    combining these in decision problems involving
    sets of features.

21
Utility Functions
Utility Functions
  • In planning, outcome state resulting from
    execution of a plan.
  • Outcomes are ranked by comparing the numeric
    values of the utility function applied.
  • If u(?) ?? u(?) then ?(u(?)) ?? ?(u(?)) , if ?
    is a monotonically increasing function.
  • Both the functions represent the same preference
    order and so sanction identical decisions.
  • Therefore u and ? ? u are strategically
    equivalent.

22
Multi-attribute Outcomes
  • Attributes preference relevant features of an
    outcome.
  • In order to separate overall preference into a
    preference for individual attributes, a structure
    is imposed on the outcome space.
  • Framing defines a multi-attribute representation
    of the outcome space.
  • Each outcome ? is represented as a vector ? ?1 ,
    ?2 , ?n?. Each outcome attribute is drawn from
    an attribute space Ai.

23
Separability and Utility Independence
  • Specification of a multi-dimensional function as
    a combination of functions of lower dimension
    depends on the separability of the various
    dimensions.
  • The lower dimensions themselves must also have a
    meaningful interpretation in terms of preferences
    gt subutility functions.
  • Preferences for attribute i must be invariant in
    some sense w.r.t. other attributes.
  • When a utility function is specified for an
    attribute , implies all decisions involving the
    attribute are determined, assuming all the other
    attributes are fixed.
  • The decisions do not depend on the fixed values
    the other attributes take Utility Independence

24
Utility Independence
  • One attribute is UI of the remaining attributes
    if preferences for prospects over this attribute,
    holding the other attribute values fixed, do not
    depend on the fixed values of those attributes.
  • UI is not symmetric.
  • Without UI relationships it is not possible to
    refer to preferences over individual outcome
    features via subutility functions.
  • If A1 is UI of A2 then u(?1, ?2) au(?1, ?2)
    b for a gt 0.
  • a and b may depend on ?2
  • u(?1, ?2) g(?2)u(?1, ?2) h(?2)

25
Multi-linear Decomposition
  • Multi-linear decomposition n-dimensional
    utility function is separable into n-1 subutility
    functions for individual attribute functions.
  • u(?1 , ?2, ?n) f(?1 , u2(?2), , un(?n))
  • Function f is linear in each argument (holding
    the others fixed) except the first.
  • All attributes (except possibly the first) are UI
    of the rest.
  • Disadvantage need to specify O(2n) scaling
    constants in addition to the single attribute
    functions.

26
Multiplicative Decomposition
Multiplicative Decomposition
  • Sum or product of subutility functions, each
    weighed by a scaling constant.
  • Requires only O(n) parameters.
  • Each subset of attributes must be UI of its
    complement.
  • Impossible to specify UI for all subsets.
  • If 2 attribute sets are considered, each UI of
    its complement, with a nonempty intersection, Y.
    Then X, Y, Z, X ? Z, X ? Y ? Z are all UI of
    their respective complements.
  • Unique decomposition hierarchy Utility tree
    corresponding to any set of UI conditions.

27
Example
  • u1, u2,3, u2,4,5,6, u4,5 u7 are the subutility
    functions.

Multilinear
(1) Bulk cargo
(7) Safety
Multiplicative
Multilinear
(3) Tardiness
(2) Expenses
(4) Vehicles
(6) Human Resources
(5) Facilities
28
Rationality and Intelligence
Stuart Russell University of California Berkeley
29
Intelligence
  • Motivation for studying AI create and
    understand intelligence as a general property of
    systems, rather than as a specific attribute of
    humans.
  • Presupposes that there is a productive notion of
    intelligence.
  • Agent based view of AI intelligence is
    strongly related to the capacity for successful
    behavior.
  • Rational agents are agents whose actions make
    sense from the point of view of the information
    they possess and its goals.
  • Rationality is a property of the actions and does
    not specify he process by which the actions are
    selected.

30
Perfect Rationality
Perfect Rationality
  • Perfect rationality Capacity to generate
    maximally successful behavior given the available
    information.
  • fopt argmaxf V(f,E,U) gt Agent does the best
    it can.
  • V(f,E,U) Expected value .
  • Problems
  • Specifying utilities over time
  • Relationship between goals and utility.
  • Perfectly rational agents do not exist.
  • Time lag to process information and select
    actions.

31
Rationality
  • Calculative Rationality - A program that, if
    executed infinitely fast, would result in
    perfectly rational behavior.
  • Systems based on influence diagrams satisfy the
    decision theoretic version of calculative
    rationality.
  • Metalevel Rationality Finding an optimal
    tradeoff between computational costs and decision
    quality.
  • Object level - carries out computations
    concerned with the application domain ( computing
    the utility functions.. etc). These are actions
    with costs and benefits.
  • Metalevel decision making process consisting
    of object level computations . A rational
    metalevel selects computations based on their
    expected utility.

32
Rational Metareasoning
  • Information Value assume that the decision
    theoretic value of acquiring an additional piece
    of information can be calculated.
  • Need to simulate the decision process that would
    be followed given each possible outcome of
    information request .
  • Time or optimality tradeoff has to be made for
    metalevel computations.
  • In some environments most effective agent
    design may simply be a reactive agent, an agent
    that does no metareasoning at all.
  • Bounded Optimality - Capacity to generate
    maximally successful behavior given available
    information and computational resources.
Write a Comment
User Comments (0)
About PowerShow.com
