Identity Management and Biometrics in the Government of Canada

1
Identity Management and Biometricsin the
Government of Canada
Public Forum University of Toronto June 15, 2006

• Alice Sturgeon
• Senior Director,
• Accessibility, Identity Management and Security
• Information Privacy and Security Policies
  Division
• CIO Branch

2
Why is identity management important?

• Program integrity and program costs
• Identity theft and identity fraud impact on the
  economy
• Privacy
• Private sector support and guidance
• Client Satisfaction
• Avoid collecting the same or similar information
  more than once
• Service Transformation
• Opportunities for service improvement
• Opportunities for cost savings
• Support to PSAT agenda
• GC-wide framework permits extension to the
  enterprise of initiatives such as MyAccounts

3
Context

• Growth of government services need for proof of
  entitlement
• Proof of entitlement proof of identity
• Foundation documents for identity birth
  certificate (provincial/territorial) and
  immigration documents (federal)
• Secondary documents issued based on foundation
  documents
• Result over time secondary documents used as
  foundation documents
• Outcome House of Cards

4
Identity and Government Three key roles
Authenticating Identity
Providing Identification
Establishing Identity

• Numerous organizationsinvolved at all levels
  ofgovernment, for example
• Federally issued..
• Social Insurance Number (SIN)
• Passport
• Issued by Provinces/ Territories
• Birth registration
• Birth certificate
• Health card
• Drivers license
• Most organizations require a similar base of
  information to provide identification
• Some additional needs specific to the
  organization

• Shared jurisdiction
• Federal rolefor those arrivingin Canada
• Provincial / Territorial role with Vital
  Statistics for those born in Canada
• Based on relativelystandard set of
  coreattributes including
• Name
• Place of Birth
• Date of Birth
• Gender
• Citizenship

• Separate stand-alone processes by department or
  program for authentication
• E-Pass
• Health Infoway
• Service Canada
• Etc.
• Common function provide
• verification of clients identity
• Enabling technologies
• PKI
• Biometrics
• Tokens

5
What is identity for individuals?

• Identity the concept of self
• Set of attributes that make up the identity of a
  single, specific individual
• Foundation of our social system
• Categories
• Attribute identity
• Physiological/Biometric identity
• Biographical identity

6
What is identity? 2

• Business
• Do governments share identification information
  for registered businesses, ie. federally,
  provincially or territorially-registered
  businesses?
• Which identifier(s) can be used Federal
  Business Number?

• GC Employees
• What privacy rights apply?
• Does shared authentication methodology extend to
  other jurisdictions through governance provided
  by Public Sector CIO Council?
• Do the same principles apply for both GC
  employees and other Canadians?

At what level is separation of direction and
guidance required for each set of clients?
7
Guiding Principles

• Government responsibility
• Protection of privacy
• Joint accountability
• Equity of access
• Universality
• Quality of service
• Security commensurate with risk
• Uniformity of standards and compatibility of
  systems
• Acceptability to the public

Source F/P/T Council on Identity Identity
Strategic Framework, November 2002
8
Complementary Objectives

• Citizen-centric service transformation and
  service delivery based on a single, comprehensive
  concept of identity, encompassing all government
  clients
• External clients citizens, residents, taxpayers,
  vendors
• Canadian businesses
• GC employees and contractors
• Strong verification of identity for
  authentication, to address security concerns of
  anti-terrorism, identity theft, and similar
  threats of todays global electronic environment.

9
Security and Service Delivery
SERVICES
SECURITY
Privacy
Identity Proving
IDENTITY
International Requirements
Common and Shared Services
Service Transformation
PKI
Authentication
Multi-Jurisdictional services
Biometrics
Document Integrity
Standards
National Security Policy and Government Security
Policy
Unique Identifiers
10
Biometrics Backgrounder

• Many Types of Biometrics
• Physiological
• Iris
• Fingerprint (including nail)
• Hand (including knuckle, palm, vascular)
• Face
• Voice
• Retina
• DNA
• Even Odour, Earlobe, Sweat pore, Lips
• Behavioural
• Signature
• Keystroke
• Voice
• Gait
• and more to come

Purpose of Biometrics To prove an individual who
they claim to be

• Supporting Many Business Purposes
• Security
• Financial Services
• Health Care
• Service Delivery
• Fraud Reduction
• Physical Access Control

Definition of Biometrics Automated recognition of
individuals based on their behavioural and
biological characteristics
11
Facial Recognition

• Maps facial characteristics of an individual
• Distance between the persons eyes
• Angle of jaw
• Length of nose, etc.
• Advantages less intrusive, fewer privacy
  concerns
• Disadvantages most susceptible to failed or
  false match caused by changes to physical
  appearance, angling differences least static
  characteristic dataset increases correlate to
  decrease in accurate match

12
Fingerprint

• Matching ridges, whorls and patterns
• Finger minutiae and finger-pattern techniques
• Advantages
• More accurate than facial recognition
• Least expensive and most readily available
• Disadavantages
• Interoperability of automated fingerprint
  identification systems (AFIS) readers and
  template software
• Operator error
• Spoofing/liveness unsuitable for unattended
  systems (e.g., CANPass)
• Acceptability hygiene concerns criminal
  connotation

13
Iris Scan

• Advantages
• Iris patterns are static
• Exception eye diseases and artificial changes
• High accuracy
• Size of database does not affect accuracy rates
• Impossible to spoof
• Disadvantages
• Acceptability highly intrusive
• More expensive and difficult to implement

14
Biometrics Standards

• To support interoperability and data interchange
  among applications and systems
• Includes the following aspects
• Common file frameworks
• Biometric Application Programming Interfaces
  (APIs)
• Biometric Data Interchange Formats
• Evaluation Criteria
• Methodologies for performance testing
• Consideration of cross-jurisdictional and
  societal aspects
• Many standards bodies
• ISO/IEC JTC1/SC37Subcommittee 37 on Biometrics
• ICAO machine readable travel documents
• U.S. NIST and ANSI

15
Biometrics Standards (2)

• ISO/IEC JTC1 SC37 - Biometrics
• Inaugural Plenary December 2002
• Six Working Groups
• WG 1 Harmonized Biometric Vocabulary
• WG 2 Biometric Technical Interfaces
• WG 3 Biometric Data Interchange Formats
• WG 4 Biometric Application Profiles
• WG 5 Biometric Testing and Reporting
• WG 6 Cross-Jurisdictional and Societal Aspects
• 24714 Cross-jurisdiction and societal impacts of
  implementations of biometrics

16
ISO/IEC TR 24714-1

• Cross-Jurisdictional and Societal Aspects of
  Implementation of Biometric Technologies, Part 1
  Guide to the Accessibility, Privacy and Health
  and Safety Issues in the deployment of Biometric
  Systems for Commercial Application
• Objectives
• Enhanced acceptance of systems using biometrics
  by users
• Improved public perception and understanding
• Smoother introduction and operation of these
  systems
• Potential long-term cost reduction (whole life
  costs)
• Establishment of commonly accepted good privacy
  practices and principles

17
Biometrics Architecture
Business and Service Immigration Prison
Visitation Cross-Border Travel Native
Status
Information Citizenship Record of Birth
Record of Employment Medical Records
Biometric Technologies Finger Minutiae
Hand Geometry Iris Scan Facial
Scan
Applications and solutions Border Crossing
Bldg Access Airport Access Data
Access
18
GC Biometric Considerations (1)

• 1. Encourage Adoption of Standards
• Identify requirements that can employ ISO
  standards (e.g. interoperability, data
  interchange, performance measurement, etc.)
• All GC documentation should be consistent with
  standardized vocabulary as per ISO Standards
• Increase overall understanding and application of
  biometrics by using biometrics tutorials
  developed by ISO.
• 2. Promote Industry Compliance
• Procurement of biometric components and standards
  should be compliant to the relevant biometrics
  standards
• The GC should assume leadership role in the
  establishment of biometric certification bodies
• Establishment of performance testing bodies
  (possibly in conjunction with NIST).

19
GC Biometric Considerations (2)

• 3. Participate in Standards Development
• Departments undertaking biometric pilot programs
  should become members of Canadian Advisory
  Council (CAC) to SC 37
• Knowledge gained through biometric
  implementations should be shared with others and
  the biometric standards bodies (ISO, ANSI)
• 4. Increase Knowledge of Standards
• Raise and maintain general awareness of
• Biometrics standards development activities
• Biometrics pilots and implementations currently
  underway in other countries.

20
Relative Nature of Authentication
ISO/IEC 15408 evaluated Certified smart token
Policy control
Certified smart token PIN control No policy
control
Smart token No PIN or policy control
Certified software-based Policy control
Software-based No pswd/PIN or policy control
HIGH
LOW
MEDIUM
Encrypted biometric template
Biometrics with no crypto token or No biometric
Authentication Continuum
21
Some Legislation, Policies Standards
In Canada

• GoC Legislation
• Canadian Charter of Rights and Freedoms
• Privacy Act
• Access to Information Act
• Personal Information Protection and Electronic
  Documents (PIPEDA) Act
• Emergency Preparedness Act (rev.)
• Security of Information Act

• TBS Related Policies
• Privacy Impact Assessment (PIA)
• Privacy and Data Protection
• Personnel Information Management
• Access to Information
• Management of Government Information
• Government Security Policy
• Management of IT Security Standard
• Electronic Authorization and Authentication
  Standard
• PKI Standard
• National Security Policy

• GC Standards
• GSP Security Standards
• TB Information and Technology Standards (TBITS)
• Management of Information and Data Standards
• Other
• IT Security Strategy
• Common Infrastructure and Services
• IT Strategy

In U.S.A.

• Sarbanes-Oxley
• Gramm-Leach-Bliley

• NIST FIPS 201
• NIST SP 800-series

• Clinger-Cohen Act
• USA PATRIOT ACT

22
Inputs Frameworks, Standards, Initiatives
(a representative sampling)

• Canada
• FPT Council on Identity
• Business Transformation Enablement Program
  Mapping Identity Management
• NRS Vital Statistics
• CMC Identity Theft Consultation
• Industry Canada e-authentication principles
• Public Sector Service Delivery Council
• BC Corporate Authentication Project

• UK
• UK Identity Cards Bill
• Information Assurance Advisory Council
• LSE Project

• European Union
• Privacy Enhanced Identity Management for Europe

• US
• OMB M-04-04e-Authentication Guidance for
  Federal Agencies
• General Services Administration
• e-Authentication
• Homeland Security Presidential Directive-12
• Federal Information Processing Standard 201/SP
  800
• National Institute for Standards and
  Technologies
• trust levels
• National Academy of Sciences e-Authentication
  Privacy
• Social Security Administration

• Australia
• Whole-of-Govt ID Framework
• Centrelink Model
• New Zealand
• Evidence of Identity Framework

23
(No Transcript)
