Design Patterns: Supporting Task Design by Scaffolding the Assessment Argument

1
Design Patterns Supporting Task Design by
Scaffolding the Assessment Argument
Robert J. Mislevy University of Maryland Geneva
Haertel Britte Haugan Cheng SRI International
DR K-12 grant 0733172, Application of
Evidence-Centered Design to State Large-Scale
Science Assessment. NSF Discovery Research K-12
PI meeting, November 10, Washington D.C. This
material is based upon work supported by the
National Science Foundation under Grant No. DRL-
0733172. Any opinions, findings, and conclusions
or recommendations expressed in this material are
those of the authors and do not necessarily
reflect the views of the National Science
Foundation.
2
Overview

• Design patterns
• Background
• Evidence-Centered Design
• Main idea
• Layers
• Assessment Arguments
• Attributes of Design Patterns
• How they inform task design

3
Design Patterns

• Design Patterns in Architecture
• Design Patterns in Software Engineering
• Poltis Thirty-Six Dramatic
• Situations

4
Messicks Guiding Questions

• What complex of knowledge, skills, or other
  attributes should be assessed?
• What behaviors or performances should reveal
  those constructs?
• What tasks or situations should elicit those
  behaviors?
• Messick, S. (1994). The interplay of evidence
  and consequences in the validation of performance
  assessments. Educational Researcher, 23(2), 13-23.

5
Evidence-Centered Assessment Design

• Organizing formally around Messick quote
• Principled framework for designing, producing,
  and delivering assessments
• Conceptual model, object model, design tools
• Connections among design, inference, and
  processes to create and deliver assessments.
• Particularly useful for new / complex
  assessments.
• Useful to think in terms of layers

6
Domain Analysis
What is important about this domain? What work
and situations are central in this domain? What
KRs are central to this domain?
Domain Modeling
How do we represent key aspects of the domain in
terms of assessment argument. Conceptualization.
Conceptual Assessment Framework
Design structures Student, evidence, and task
models. Generativity.
Manufacturing nuts bolts authoring tasks,
automated scoring details, statistical models.
Reusability.
Assessment Implementation
Assessment Delivery
Students interact with tasks, performances
evaluated, feedback created. Four-process
delivery architecture.
Layers in the assessment enterprise

• From Mislevy Riconscente, in press

7
Domain Analysis
What is important about this domain? What work
and situations are central in this domain? What
KRs are central to this domain?
Domain Modeling
How do we represent key aspects of the domain in
terms of assessment argument. Conceptualization.
Conceptual Assessment Framework
Design structures Student, evidence, and task
models. Generativity.
Manufacturing nuts bolts authoring tasks,
automated scoring details, statistical models.
Reusability.
Assessment Implementation
Assessment Delivery
Students interact with tasks, performances
evaluated, feedback created. Four-process
delivery architecture.

• From Mislevy Riconscente, in press

8
Domain Analysis
What is important about this domain? What work
and situations are central in this domain? What
KRs are central to this domain?
Domain Modeling
How do we represent key aspects of the domain in
terms of assessment argument. Conceptualization.
Conceptual Assessment Framework
Design structures Student, evidence, and task
models. Generativity.

• Assessment argument structures
• Design Patterns

Manufacturing nuts bolts authoring tasks,
automated scoring details, statistical models.
Reusability.
Assessment Implementation
Assessment Delivery
Students interact with tasks, performances
evaluated, feedback created. Four-process
delivery architecture.

• From Mislevy Riconscente, in press

9
Domain Analysis
What is important about this domain? What work
and situations are central in this domain? What
KRs are central to this domain?
Domain Modeling
How do we represent key aspects of the domain in
terms of assessment argument. Conceptualization.
Conceptual Assessment Framework
Design structures Student, evidence, and task
models. Generativity.
Manufacturing nuts bolts authoring tasks,
automated scoring details, statistical models.
Reusability.
Assessment Implementation

• Psychometric models
• Automated scoring
• Task templates
• Object models
• Simulation environments

Assessment Delivery
Students interact with tasks, performances
evaluated, feedback created. Four-process
delivery architecture.

• From Mislevy Riconscente, in press

10
Domain Analysis
What is important about this domain? What work
and situations are central in this domain? What
KRs are central to this domain?

• Authoring interfaces
• Simulation environments
• Re-usable platforms elements

Domain Modeling
How do we represent key aspects of the domain in
terms of assessment argument. Conceptualization.
Conceptual Assessment Framework
Design structures Student, evidence, and task
models. Generativity.
Manufacturing nuts bolts authoring tasks,
automated scoring details, statistical models.
Reusability.
Assessment Implementation
Assessment Delivery
Students interact with tasks, performances
evaluated, feedback created. Four-process
delivery architecture.

• From Mislevy Riconscente, in press

11
Domain Analysis
What is important about this domain? What work
and situations are central in this domain? What
KRs are central to this domain?
Domain Modeling
How do we represent key aspects of the domain in
terms of assessment argument. Conceptualization.

• Interoperable elements
• IMS/QTI, SCORM
• Feedback / instruction / reporting

Conceptual Assessment Framework
Design structures Student, evidence, and task
models. Generativity.
Manufacturing nuts bolts authoring tasks,
automated scoring details, statistical models.
Reusability.
Assessment Implementation
Assessment Delivery
Students interact with tasks, performances
evaluated, feedback created. Four-process
delivery architecture.

• From Mislevy Riconscente, in press

12
Toulmins Argument Structure
Claim
unless
Alternative explanation
since
Warrant
so
Backing
Data
13
Assessment Argument Structure
Data concerning performance
14
Assessment Argument Structure
Claim about student
unless
Alternative explanations
Warrant for assessment argument
since
so
Data concerning performance
15
Assessment Argument Structure
Claim about student
unless
Alternative explanations
Warrant for assessment argument
since
so
Data concerning situation
Data concerning performance
Student acting in assessment situation
16
Assessment Argument Structure
Claim about student
unless
Alternative explanations
Warrant for assessment argument
since
e.g., near or far transfer, familiarity with
tools, assessment format, representational forms,
evaluation standards, task content context.
so
Data concerning situation
Data concerning performance
Not in measurement models, but crucial to
inference.
Other information concerning student vis a vis
assessment situation
Warrant for scoring
Warrant for task design
since
since
Student acting in assessment situation
17
PADI Design Patterns

• Structured around assessment arguments
• Substance based on recurring principles, ways of
  thinking, inquiry, etc.
• E.g., NSES on inquiry, unifying themes
• Science ed. cog psych research

18
Some PADI Design Patterns

• Model-Based Reasoning
• Model Formation Evaluation Revision Use
• Model-Based Inquiry
• Design under Constraints
• Generate Scientific Explanations
• Troubleshooting (with Cisco)
• Assessing Epistemic Frames (in progress with
  David Williamson Shaffer)

19
The Structure of Assessment Design Patterns
20
How Design Patterns Support Thinking about the
Assessment Argument
21
How Design Patterns Support Thinking about the
Assessment Argument
Associated with Characteristic Features of Tasks.
22
How Design Patterns Support Thinking about the
Assessment Argument
23
How Design Patterns Support Thinking about the
Assessment Argument
Additional KSAs play multiple roles. You need to
think about which ones you really DO want to
include as targets of inference (validity) and
which ones you really DONT (invalidity).
24
How Design Patterns Support Thinking about the
Assessment Argument
Connected with Variable Features of Tasks.
25
How Design Patterns Support Thinking about the
Assessment Argument
Connected with Variable Features of Tasks Work
Products.
26
How Design Patterns Support Thinking about the
Assessment Argument
The Characteristic Features of Tasks help you
think about critical data concerning the
situation what you need to get evidence about
the Focal KSAs.
27
How Design Patterns Support Thinking about the
Assessment Argument
Variable Features of Tasks also help you think
about data concerning the situation but now to
influence difficulty
28
How Design Patterns Support Thinking about the
Assessment Argument
29
How Design Patterns Support Thinking about the
Assessment Argument
Potential Work Products help you think about what
you want to capture from a performance product,
process, constructed model, written explanation,
etc.
30
How Design Patterns Support Thinking about the
Assessment Argument
31
How Design Patterns Support Thinking about the
Assessment Argument
32
For more information

• PADI Principled Assessment Design for Inquiry
• http//padi.sri.com
• NSF project, collaboration with SRI et al.
• Links to follow-on projects
• Bob Mislevy home page
• http//www.education.umd.edu/EDMS/mislevy/
• Links to papers on ECD
• Cisco applications

33
Now for the Good Stuff

• Examples of design patterns with content
• Different projects
• Different grain sizes
• Different users
• How they evolved to suit needs of users
• Same essential structure
• Representations, language, emphases, and
  affordances tuned to users and needs
• How they are being used

34
Use of Design Patterns in STEM Research and
Development Projects

• Britte Haugan Cheng and Geneva Haertel
• DRK-12 PI Meeting, November 2009

35
Current Catalog of Design Patterns

• ECD/PADI related projects have produced over 100
  Design Patterns
• Domains include science inquiry, science
  content, mathematics, economics, model-based
  reasoning
• Design Patterns span grades 3-16
• Organized around themes, models, and processes,
  not surface features or formats of tasks
• Support the design of scenario-based, multiple
  choice, and performance tasks
• The following examples show how projects have
  used and customized Design Patterns in ways that
  suit their needs and users

36
Example 1 DRK-12 ProjectAn Application of ECD
to a State, Large-scale Science Assessment

• Challenge in Minnesota Comprehensive Assessment
  of science
• How to design scenario-based tasks,
  technology-enhanced interactions, grounded in
  standards both EFFICIENTLY and VALIDLY.
• Design Patterns support storyboard writing and
  task authoring
• Designers are committee of MN teachers, supported
  by Pearson
• Project focuses on a small number of Design
  Patterns for hard-to-assess science
  content/inquiry
• Based on Minnesota state science standards and
  benchmarks and the NSES inquiry standards
• Design Patterns are Web-based and interactive

37
Design Pattern Observational Investigation

• Relates science content/processes to components
  of assessment argument
• Higher-level, cross-cutting themes, ways of
  thinking, ways of using science, rather than many
  finer-grained standards
• Related to relevant standards and benchmarks
• Interactive Features
• Examples and details
• Activate pedagogical content knowledge
• Presents exemplar assessment tasks
• Provides selected knowledge representations
• Links among associated assessment argument
  components

38
Design Pattern Observational Investigation
39
Design Pattern Observational Investigation
(cont.)
40
Design Pattern Observational Investigation
(cont.)
41
Interactive Feature Details
42
Interactive FeatureLinking assessment argument
components
43
Design Pattern HighlightsObservational
Investigation

• Relates science content/processes to components
  of assessment argument
• Higher-level, cross-cutting themes, ways of
  thinking, ways of using science, rather than many
  fine-grained standards
• Interactive Features
• Examples and details
• Activates pedagogical content knowledge
• Presents exemplar assessment tasks
• Provides selected knowledge representations
• Relates relevant standards and benchmarks
• Links among associated assessment argument
  components

44
Design Pattern Reasoning about Complex Systems

• Relates science content/processes to components
  of assessment argument
• Across scientific domains and standards
• Convergence among the design of instruction,
  assessment and technology
• Interactive Features
• Explicit support for designing tasks around
  multi-year learning progression

45
Design Pattern Reasoning about Complex Systems
46
Interactive FeatureDetails
47
Interactive FeatureLinking assessment argument
components
48
Design Pattern HighlightsReasoning about Complex
Systems

• Relates science content/processes to components
  of assessment argument
• Across scientific domains and standards
• Convergence among the design of instruction,
  assessment and technology
• Interactive Feature
• Explicit support for designing tasks around
  multi-year learning progression

49
Example 2 Principled Assessment Designs in
InquiryModel-Based Reasoning Suite

• Relates science content/processes to components
  of assessment argument
• A suite of seven related Design Patterns support
  curriculum-based assessment design
• Theoretically and empirically motivated by
  Stewart and Hafner (1994), Research on
  Problem-Solving Genetics. In D. L. Gable (Ed.),
  Handbook of research on science teaching and
  learning. New York MacMillan Publishing.
• Aspects of model-based reasoning including model
  formation, model use, model revision, and
  coordination among aspects of model-based
  reasoning
• Multivariate student model scientific reasoning
  and science content
• Interactive Feature
• Support the design of both
• Independent tasks associated with an aspect of
  model-based reasoning
• Steps in a larger investigation comprised of
  several aspects including model
  conceptualization, model use and model evaluation

50
Design PatternModel Formation
51
Design PatternModel Formation (cont.)
52
Interactive FeatureLinks among Design Patterns
53
Design Pattern HighlightsModel-based Reasoning
Suite

• Relates science content/processes to components
  of assessment argument
• Facilitate the integration of model-based
  reasoning skills into any science content area
• Serve as basis of a learning progression
• Interactive Features
• Support the design of both independent tasks
  associated with an aspect of model-based
  reasoning and steps in a larger investigation
  that is comprised of several aspects including
  conceptualization of a model to its use and
  evaluation
• Explicit supports (links among Design Patterns)
  for designing both investigations and focused
  tasks

54
Example 3Principled Science Assessment Designs
for Students with DisabilitiesDesigning and
Conducting Scientific Investigations Using
Appropriate Methodology

• Relates science content/processes to components
  of assessment argument
• Guide refinement of science assessment tasks
  across multiple states by identifying and
  reducing sources of construct-irrelevant variance
• Integrate six categories of Universal Design for
  Learning (UDL) into the assessment design
  process
• Perceptual, linguistic, cognitive, motoric,
  executive, affective
• Interactive Feature
• Highlight relationships among Additional KSAs,
  Variable Task Features and Potential Work
  Products to reduce construct-irrelevant variance
  in a systematic manner

55
Design Pattern Designing and Conducting a
Scientific Investigation Using Appropriate
Methodology
56
Design Pattern Designing and Conducting a
Scientific Investigation Using Appropriate
Methodology (cont.)
57
Interactive FeatureLinking Additional KSAs and
Potential Work Products
58
Design Pattern HighlightsDesigning and
Conducting a Scientific Investigation Using
Appropriate Methodology

• Relates science content/processes to components
  of assessment argument
• Integrate UDL in assessment design process rather
  than applying accommodations to an existing task
• Supports the selection of task features that
  reduce construct-irrelevant variance and enhance
  the performance of all test takers
• Particular attention to knowledge representation
  and executive processing demands
• Further customization of Design Patterns to
  develop assessment tasks for students with
  particular disabilities
• Interactive Feature
• Relate the perceptual and expressive capabilities
  required to complete an assessment task to that
  tasks features (Additional KSAs, Variable Task
  Features and Potential Work Products)

59
Example 4Alternate Assessments in Mathematics
Describe, extend, and make generalizations about
geometric and numeric patterns

• Relates math content/processes to components of
  assessment argument
• Standards-based Design Patterns co-designed
  across three states to guide the development of
  statewide assessment tasks for students with
  significant cognitive disabilities
• Integration of six UDL categories into the design
  process
• Interactive Feature
• For logistical reasons, Word document used to
  create Design Patterns
• Attributes visualized in accordance with the
  assessment argument resulting in increased
  efficiency and improved quality of argument
• New arrangement now under development for use in
  online system

60
Design Pattern Describe, extend, and make
generalizations about geometric and numeric
patterns
61
Design Pattern Describe, extend, and make
generalizations about geometric and numeric
patterns (cont.)
62
Design Pattern Describe, extend, and make
generalizations about geometric and numeric
patterns (cont.)
63
Design Pattern Describe, extend, and make
generalizations about geometric and numeric
patterns (cont.)
64
Interactive FeatureHorizontal ViewAligning
Focal KSAs, Potential Observations and Potential
Work Products
65
Interactive Feature Horizontal ViewAligning
Additional KSAs and Variable Task Features
66
Design Pattern HighlightsDescribe, extend, and
make generalizations about geometric and numeric
patterns

• Relates math content/processes to components of
  assessment argument
• Deconstruction of NCTM expectations to identify
  KSAs that are less difficult or tasks that assess
  related cognitive background knowledge
• Supports the principled alignment of task
  difficulty and scope with challenges to
  accessibility
• Interactive Feature
• Use of multiple views of the Design Pattern to
  support understanding of the relationship of
  components of the assessment argument
• Increased efficiency of design and validity of
  assessment argument

67
Summary

• Design Patterns are organized around assessments
  and key ideas in science and math, as opposed to
  surface features of assessment tasks.
• Support designing tasks that move in ways NSES
  and NCTM advocate in ways that build on research
  and experience
• Design Patterns support task design for different
  purposes and different formats (e.g., learning,
  summative, classroom, large-scale, hands-on, PP,
  simulations).
• Especially important for newer forms of
  assessment
• Technology-based, scenario based tasks in
  Minnesota
• Scenario-based learning assessment
  (Foothill-DeAnza project)
• Simulation-based tasks (network troubleshooting,
  with Cisco)
• Games-based assessment (just starting, with
  MacArthur project)

68
Summary

• Design Patterns are eclecticthey are not
  associated with any particular underlying theory
  of learning or cognition all psychological
  perspectives can be represented
• Document design decisions
• Represent hierarchical relationships among Focal
  KSAs, sequential steps required for the
  completion of complex tasks, or superordinate,
  subordinate, and coordinate relations among
  concepts
• Re-usable a family of assessment tasks can be
  produced from a single Design Pattern
• Enhance the integration of UDL with the
  evidence-centered design process
• Technology makes evident the relationships among
  Design Pattern attributes and their role in the
  assessment argument
