Title: Continuity Equations: Analytical Monitoring of Business Processes in Continuous Auditing
1Continuity Equations Analytical Monitoring of
Business Processes in Continuous Auditing
- Michael G. Alles
- Alexander Kogan
- Miklos A. Vasarhelyi
- Jia Wu
- 12th World Continuous Auditing Symposium
- Nov 3-4, 2006
2IT-enabled Business Processes (BPs)
- A business organization consists of a variety of
business processes. - A business process is a set of logically related
tasks performed to achieve a defined business
outcome, Davenport and Short (1990). - Modern information technology makes it possible
to measure and monitor business processes at the
unprecedented level of detail (disaggregation) on
the real-time basis. But currently there is a
lack of BP control monitoring. - Continuous auditing (CA) methodology can utilize
the IT capability to capture BP data at the
source and in the disaggregated and unfiltered
form to achieve more efficient, effective and
timely audit.
3Comparison between Conventional Analytical
Procedures and CA Analytical Monitoring
- CA Analytical Monitoring
- Focus on business processes data
- Audit data are unfiltered and disaggregated.
- Analytical modeling based on the relationship
between business processes - Continuity equation models
- Conventional Analytical Procedure
- Focus on financial data
- Audit data are summarized and aggregated.
- Analytical modeling based on the relationships
between financial accounts - Ratio Analysis, trend analysis, reasonableness
tests
4Reengineering of Substantive Testing in CA
- AP can be used in the planning, substantive
testing, and reviewing stages of an audit. We
focus on AP in substantive testing. - Conventional auditing
- First, apply analytical procedures to identify
potential problems. - Then, focus detailed transaction testing on the
identified problem areas. - CA the sequence is reversed
- First, apply automated general transaction tests
to all the transactions and screen out identified
exceptions for resolution. - Then, apply automated analytical procedures to
the transaction stream to identify unforeseen
problems. - Finally, alarm humans to investigate anomalies.
(Targeted transaction tests)
5Data-oriented Continuous Auditing System
Automatic Analytical Monitoring Continuity
Equations
Automatic Transaction Verification
Exception Alarms
Anomaly Alarms
Responsible Enterprise Personnel
Business Data Warehouse
Enterprise System Landscape
Materials Management
Sales
Ordering
Accounts Receivable
Accounts Payable
Human Resources
6Data-oriented CA Automation of Substantive
Testing
- Automation of Transaction Testing
- Formalization of BP rules as transaction
integrity and validity constraints. - Verification of transaction integrity and
validity ? detection of exceptions ? generation
of alarms. - Automation of Analytical Procedures
- Selection of critical BP metrics and development
of stable business flow (continuity) equations. - Monitoring of continuity equation residuals ?
detection of anomalies ? generation of alarms. - This presentation focuses on the automation of
APs.
7Advanced Analytics in CA BP Modeling Using
Continuity Equations
- Continuity equations
- Statistical models capturing relationships
between various business processes rather than
financial accounts. - Can be used as expectation models in the
analytical procedures of continuous auditing. - Originated in physical sciences (various
conservation laws e.g. mass, momentum, charge). - Continuity equations are developed using
statistical methodologies of - Linear regression modeling (LRM)
- Simultaneous equation modeling (SEM)
- Multivariate time series modeling (MTSM) Vector
Autoregressive Model (VAR), Subset-VAR,
Bayesian-VAR (BVAR).
8Basic Procurement Cycle
t2-t1
P.O.(t1)
Receive(t2)
t3-t2
Voucher(t3)
9Inferred Analytical Model (Subset-VAR) of
Procurement
- P.O.(t) 0.24P.O.(t-4) 0.25P.O.(t-14)
0.56Receive(t-15) ePO - Receive(t) 0.26P.O.(t-4) 0.21P.O.(t-6)
0.60Voucher(t-10) eR - Voucher(t)0.54Receive(t-1) - 0.17P.O.(t-9)
0.22P.O.(t-17) 0.24Receive(t-17) eV
10Steps of Analytical Modeling and Monitoring Using
Continuity Equations
- Choose essential business processes to model
(purchasing, payments, etc.). - Define (physical, financial, etc.) metrics to
represent each process e.g., Amount of
purchase orders, quantity of items received,
number of payment vouchers processed. - Choose the levels of aggregation of metrics
- By time (hourly, daily, weekly), by business
unit, by customer or vendor, by type of products
or services, etc.
11Steps of Analytical Modeling and Monitoring Using
Continuity Equations-II
- Identify and estimate stable statistical
relationships between business process metrics
Continuity Equations (CEs). - Define acceptable thresholds of variance from the
expected relationships. - If the variances (residuals) exceed the
acceptable levels, alarm human auditors to
investigate the anomaly (i.e., the relevant
sub-population of transactions).
12How Do We Evaluate CE Models?
- Linear Regression Model is the classical
benchmark for comparison. - Models are compared on two aspects
- Prediction Accuracy, and
- Anomaly Detection Capability.
13Prediction Accuracy Comparison Results Analysis
- Mean Absolute Percentage Error (MAPE) is used to
measure prediction accuracy. - Prediction accuracy comparison results
- Multivariate Time Series (best).
- Linear regression (middle).
- Simultaneous Equations (worst).
- Difference is small (lt2).
- Noise in our data sets may pollute the results.
- Prediction accuracy is relatively good for all
continuity equation models - There are studies in which MAPE exceeds 100.
14Simulating Error Stream The Ultimate Test of CA
Analytics
- Seed errors of various magnitude into randomly
chosen subset of the holdout sample. - Identify anomalies as those observations in the
holdout sample for which the variance exceeds the
acceptable threshold of variance. - Test whether anomalies are the observations with
seeded errors, and count the number of false
positives (Type I ERR) and false negatives (Type
II ERR). - Repeat this simulation several times by choosing
different random subsets to seed errors into.
15Measuring Anomaly Detection
- False positive error (false alarm, Type I error)
A non-anomaly mistakenly detected by the model as
an anomaly. Decreases efficiency. - False negative error (Type II error) An anomaly
failed to be detected by the model. Decreases
effectiveness. - A good analytical model is expected to have good
anomaly detection capability low false negative
error rate and low false positive error rate.
16Simulated Real-time Error Correction
- CA makes it possible to investigate a detected
anomaly in (nearly) real-time. - Anomaly investigation can likely correct a
detected problem in (nearly) real-time. - Real-time problem correction results in utilizing
the actual (not erroneous) values in analytical
BP models for future predictions. - Real-time error correction is likely to make
subsequent anomaly detection more accurate, and
the magnitude of this benefit can be evaluated
using simulation.
17(No Transcript)
18(No Transcript)
19Error Detection Aggregated Data vs.
Disaggregated Data
- In CA the disaggregated data are available. Can
the disaggregated data boost anomaly detection
performance? - Dimensions for aggregation and disaggregation
- temporal and geographic.
- A comparative simulation study of error detection
vs. BP metric aggregation has to examine
different aggregation patterns of seeded errors - Best case aggregated error (e.g., total weekly
error seeded in a single day) - Worst case disaggregated error (e.g., total
weekly error is equally partitioned between every
day of the week) - Intermediate case somewhat disaggregated error
20(No Transcript)
21(No Transcript)
22Results and Conclusions from Simulation Studies
- Various statistical methods can be used to derive
expectation models of acceptable quality - Linear regression is often OK
- Multivariate time series methodology can provide
somewhat more accurate models. - Real-time error correction significantly improves
error detection capabilities of all models. - More disaggregated models are not always better
weekly data can be more stable than the daily
one. - Alarms have to be managed trade-off between
Type I and Type II errors.
23Concluding Remarks
- New CA-enabled analytical audit methodology
simultaneous relationships between highly
disaggregated BP metrics. - How to automate the inference and estimation of
numerous CE models? - How to identify and remove outliers from the
historical data to estimate statistically valid
CEs (step-wise re-estimation of CEs)? - How to choose the confidence level for generating
alarms (trade-off between Type I and Type II
errors efficiency vs. effectiveness)? - How to make it worthwhile (is it worth the cost)?
