Outline Lecture 1

1
EE459 Neural NetworksHow to design a good
performance NN?
Kasin Prakobwaitayakit Department of Electrical
Engineering Chiangmai University
2
Glossary

• Pattern a complete set of data inputs and
  outputs that provide a snapshot of the system
  being modelled
• also called examples, cases
• Feature an identifying characteristic in the
  data that the model will ideally capture
• Domain a set of boundaries that define the range
  of expected / observed data for a particular
  model or problem

3
Backpropagation Modelling Heuristics

• Selection of model inputs and outputs
• Defining the model domain
• Data pre-processing
• Selection of training/testing cases
• Data scaling
• Number of hidden layers
• Number of neurons
• Activation function selection
• Initial weight values
• Learning rate and momentum
• Presentation of patterns
• Stopping criteria for training
• Improving model performance

4
Selection of Model Inputs and Outputs

• Start with a set of inputs that are KNOWN to
  affect the process
• then add other inputs that are suspected of
  having a relationship in the process one at a
  time
• Eliminate input variables that are redundant
  (high covariance)
• Eliminate data patterns that do not contribute to
  training (no new information)
• Identify / eliminate data patterns with the same
  inputs that have different outputs

5
Defining the Model Domain

• ANNs should be confined to a limited domain
• develop separate models for contradictory areas
  of the domain
• Build models that predict a single output
• link multiple models together, if required

6
Data Pre-processing

• Any time the dynamic range of an input is over a
  few orders of magnitude, a logarithmic
  transformation should be applied
• Transformations may also be useful in
  reconditioning input data when an ANN has
  trouble converging
• Non-numerical inputs need to be codified

7
Selection of Training/Testing Cases

• Training cases should be representative of the
  problem domain
• For good generalization capacity, the training
  set must be complete
• important variable must be measured
• Data set is randomly divided into training and
  testing sets
• in a 7030 ratio, for example

8

• Rules of thumb
• The number of training patterns should be at
  least 5 times the number of nodes in the network
• The number of training cases should be roughly
  the number of weightsthe inverse of the accuracy
  parameter (e, e0.9 means 90 accuracy of
  prediction is required)

9
Data Scaling

• Output variables should be scaled in the 0.1 to
  0.9 range
• avoids operating in the saturation range of the
  sigmoid function

10
Number of Hidden Layers

• Increasing the number of hidden layers increases
  both the time and number of patterns (examples)
  required for training
• For most problems, one hidden layer will suffice
• problems can always be solved with two
• Multiple slabs (Ward Nets) supposedly increase
  processing power
• each slab (group of neurons) acts as a detector
  for one or more input features

11
Number of Neurons

• One neuron in the input layer for each input
• One neuron in the output layer for each output
• Proper number of hidden neurons is often
  determined experimentally
• too few poor ability to capture features
• too many poor ability to generalize (ANN simply
  memorizes training data)
• Various rules of thumb have been reported
• 0.75N
• 2N 1

N number of inputs
12

• In general, more weights introduce more local
  minima to the error surface
• Flat regions in the error surface can mislead
  gradient-based error minimization methods
  (backpropagation)
• Start with a small network and then add
  connections as needed
• avoids convergence problems as the networks get
  too large
• The optimum ratio of hidden neurons in the first
  to second hidden layer is 31

13
Activation Function Selection

• Sigmoidal (logistic) activation functions are the
  most widely used
• Thresholding functions are only useful for
  categorical outputs

14
Initial Weight Values

• Weights need to be randomized initially
• if all weights are set to the same number, the
  GDR would never be able to leave the starting
  point
• The backpropagation algorithm may also have
  difficulty if the connection weights are
  prematurely saturated (gt0.9)

15
Learning Rate and Momentum

• Learning rate (?) affects the speed of
  convergence.
• If it is large (gt0.5), the weights will be
  changed more drastically, but this may cause the
  optimum to be overshot
• If it is small (lt0.2) the weights will be changed
  in smaller increments, thus causing the system to
  converge more slowly with little oscillation
• The best training occurs when the learning rate
  is as large as possible without leading to
  oscillation

16

• The learning rate can be increased as learning
  progresses, or a momentum term added to improve
  network learning speed
• The momentum factor (?) has the ability to dampen
  out oscillations caused by increasing the
  learning rate
• a momentum of 0.9 allows higher learning rates

17
Presenting Patterns to the ANN

• Present patterns in a random fashion
• If input patterns can be easily classified, do
  not train the ANN on all patterns in a class in
  succession
• the ANN will forget information as it moves from
  class to class
• Shaping can be used to improve network training
• involves starting off on a very small cohesive
  data set and then adding more patterns that have
  greater deviations from variable means as
  training progresses

18
Stopping Criteria for Training

• Training should be stopped when one of the
  following conditions is met
• the testing error is sufficiently small
• the testing error begins to increase
• a set number of iterations has passed

19
Improving Model Performance

• Re-initialize network weights to a new set of
  random values
• re-train the model
• Adjust learning rate and momentum
• Modify stopping criteria
• Prune network weights
• Use genetic algorithms to adjust network topology
• Add noise to training cases to decrease the
  chance of memorization

20
ANN Modelling Approach
21
Needs and Suitability Assessment

• What are the modelling needs ?
• Is the ANN technique suitable to meet these needs
  ?
• Can the following be met ?
• data requirements
• software requirements
• hardware requirements
• personnel requirements

22
Data Collection and Analysis

• Successful models require careful attention to
  data details
• Recall relevant historical data is a key
  requirement
• For data collection, investigate
• data availability
• parameters, time-frame, frequency, format
• QA/QC protocols
• data reliability
• process changes

23

• Data requirements and guidelines
• data for each of the parameters must be available
• at least one full cycle of data must be available
• appropriate QA/QC protocols must be in place
• data collected prior to major process changes
  should generally not be used
• Data analysis involves
• data characterization
• a complete statistical analysis

24

• Data characterization for each parameter
• qualitative assessment of hourly, daily, seasonal
  trends (graphical examination of data)
• time-series analyses may be warranted
• Statistical analysis for each parameter
• measures of central tendency
• mean, median, mode
• measures of variability
• standard deviation, variance
• percentile analyses
• identification of outliers, erroneous entries,
  non-entries

25
Application of a Model-Building Protocol

• There is no accepted best method of developing
  ANN models
• An infinite number of distinct architectures are
  possible
• A protocol is to reduce the number of
  architectures that are evaluated

26

• A sample five-step protocol

27

• Selection of model inputs and outputs
• Why its important
• ANN models are based on process inputs and
  outputs
• How its done
• first, select the model output
• best models only have one output parameter
• next, select model inputs from available input
  parameters
• selection is based on data availability,
  literature, expert knowledge

28

• Selection and organization of data patterns
• Why its important
• ANN models are only as good as the data used
• separate independent data sets are required to
  test and validate the model
• How its done
• examine each data pattern for erroneous entries,
  outliers, blank entries
• delete questionable data patterns
• sort and divide data into training, testing, and
  production sets
• perform a statistical analysis on each of the
  three data sets

29

• Determination of architecture characteristics
• Why its important
• each modeling scenario will have an optimal
  architecture
• How its done
• initially, hold many factors at software defaults
  or at pre-determined values
• use modelling heuristics from literature along
  with expert knowledge
• determine the number of hidden layer neurons
• compare results for different runs

30

• Evaluation of model stability
• Why its important
• ensure that model results are independent of the
  method of data sorting
• How its done
• build new training, testing, and production sets
  from the original database
• re-train models on the new data sets
• compare results with initial runs

31

• Model fine tuning
• Why its important
• some models require minor improvements in order
  to meet process operating criteria
• How its done
• modeling parameters previously held constant can
  be varied to improve model results
• the model fine-tuning methodology is typically
  researcher-specific

32
Evaluating Model Performance

• In many situations, more than one good model can
  be developed
• The best model is the one that both
• meets the modelling needs initially identified
• offers the smallest prediction errors
• Therefore need to be able to evaluate model
  performance

33

• Prediction errors can be assessed
• graphically
• visual representation of missed predictions

34

• using statistics
• absolute measures of error
• mean absolute error (MAE)
• maximum absolute error
• relative measures of error
• mean absolute percent error (MAPE)
• coefficients of correlation
• coefficient of correlation (r)
• coefficient of multiple correlation (R)
• coefficients of determination
• coefficient of determination (r2)
• coefficient of multiple determination (R2)

35

• Model residuals should also be studied
• residual prediction error
• residuals should be
• Normally distributed
• plot a histogram of the residuals
• have a mean 0
• independent
• plot the residuals (in time order if applicable)
• plot should be free of obvious trends
• have constant variance
• plot the residuals against the predicted values
• plot should not show spreading, converging, or
  other trends

36
Model Evaluation Using Real-time Data

• Need to consider
• changes in the frequency of data collection
• changes in the methodology of data collection
• existence of QA/QC protocols to detect erroneous
  data
• The evaluation can take the form of
• simulated real-time testing on a stand-alone PC
• online testing in real-time

37

• Methodology
• select the time frame of the test
• the data is ported to the developed models
• process each data pattern and record the results
• the model predicted values are compared to the
  actual values
• prediction errors are determined
