Learning Causality

1
Learning Causality
Some slides are from Judea Pearls class
lecture http//bayes.cs.ucla.edu/BOOK-2K/viewgraph
s.html
2
A causal model Example

• Statement rain causes mud implies an asymmetric
  relationship the rain will create mud, but the
  mud will not create rain.
• Use ? when refer such causal relationship
• There is no arrow between rain and other
  causes of mud means that there is no direct
  causal relationship between them

3
Directed (causal) Graphs

• A and B are causally independent
• C, D, E, and F are causally dependent on A and B
• A and B are direct causes C
• A and B are indirect causes D, E and F
• If C is prevented from changing with A and B,
  then A and B will no longer cause changes in D, E
  and F.

4
Conditional Independence
5
Conditional Independence
6
Conditional Independence (Notation)
7
Causal Structure
8
Causal Structure (contd)

• A Causal Structure serves as a blueprint for
  forming a casual model a precise
  specification of how each variable is influenced
  by its parents in the DAG.
• We assume that Nature is at liberty to impose
  arbitrary functional relationships between each
  effect and its causes and then to perturb these
  relationships by introducing arbitrary
  disturbance
• These disturbances reflect hidden or
  unmeasurable conditions.

9
Causal Model
10
Causal Model (Contd)

• Once a causal model M is formed, it defines a
  joint probability distribution P(M) over the
  variables in the system
• This distribution reflects some features of the
  causal structure
• Each variable must be independent of its
  grandparents, given the values of its parents
• We may allowed to inspect a select subset O?V of
  observed variables to ask questions about Po,
  the probability distribution over the
  observations
• We may recover the topology D of the DAG, from
  features of the probability distribution Po.

11
Inferred Causation
12
Latent Structure
13
Structure Preference
14
Structure Preference (Contd)

• The set of independencies entailed by a causal
  structure imposes limits on its power to mimic
  other structure
• L1 cannot be preferred to L2 if there is even one
  observable dependency that is permitted by L1 and
  forbidden by L2
• L1 is preferred to L2 if L2 has subset of L1s
  independence
• Thus, test for preference and equivalence can
  sometimes be reduced to test dependencies, which
  can be determined by topology of the DAGs without
  concerning parameters.

15
Minimality
16
Consistency
17
Inferred Causation
18
Examples

• a,b,c,d reveal two independencies
• a is independent of b
• d is independent of a,b given c
• Assume further that the data reveals no other
  independencies
• a having a cold
• b having hay fever
• c having to sneeze
• d having to wipe ones nose.

19
Example (Contd)

• a,b,c,d reveal two independencies
• a is independent of b
• d is independent of a,b given c

Not minimal fails to impose conditional
Independence between d and a,b
Not consistent with data impose
marginal independence between d and a,b
20
Stability
The stability condition states that, as we vary
the parmeters from ? to ??, no indpendence in P
can be destroyed. In other words, if the
independency exists, it will always exists.
21
Stable distribution

• A probability distribution P is a faithful/stable
  distribution if there exist a directed acyclic
  graph (DAG) D such that the conditional
  independence relationship in P is also shown in
  the D, and vice versa.

22
IC algorithm (Inductive Causation)

• IC algorithm (Pearl)
• Based on variable dependencies
• Find all pairs of variables that are dependent of
  each other (applying standard statistical method
  on the database)
• Eliminate (as much as possible) indirect
  dependencies
• Determine directions of dependencies

23
Comparing abduction, deduction and induction
A gt B A --------- B

• Deduction major premise All balls in the
  box are black
• minor premise
  These balls are from the box
• conclusion
  These balls are black
• Abduction rule All balls
  in the box are black
• observation
  These balls are black
• explanation These balls
  are from the box
• Induction case These
  balls are from the box
• observation
  These balls are black
• hypothesized rule All
  ball in the box are black

A gt B B ------------- Possibly A
Whenever A then B but not vice versa -------------
Possibly A gt B
Induction from specific cases to general
rules Abduction and deduction both from
part of a specific case to other part of
the case using general rules (in different ways)
Source from httpwww.csee.umbc.edu/ypeng/F02671/le
cture-notes/Ch15.ppt
24
IC Algorithm (Contd)

• Input
• P a stable distribution on a set V of
  variables
• Output
• A pattern H(P) compatible with P
• Patten is a partially directed DAG
• some edges are directed and
• some edges are undirected

25
IC Algorithm Step 1

• For each pair of variables a and b in V, search
  for a set Sab such that (a-b Sab) holds in P
  in other words, a and b should be independent in
  P, conditioned on Sab .
• Construct an undirected graph G such that
  vertices a and b are connected with an edge if
  and only if no set Sab can be found.

26
IC Algorithm Step 2

• For each pair of nonadjacent variables a and b
  with a common neighbor c, check if c? Sab.
• If it is, then continue
• Else add arrowheads at c
• i.e a? c ? b

27
Example
28
IC Algorithm Step 3

• In the partially directed graph that results,
  orient as many of the undirected edges as
  possible subject to two conditions
• The orientation should not create a new
  v-structure
• The orientation should not create a directed
  cycle

29
Rules required to obtaining a maximally oriented
pattern

• R1 Orient b c into b?c whenever there is an
  arrow a?b such that a and c are non adjacent

30
Rules required to obtaining a maximally oriented
pattern

• R2 Orient a b into a?b whenever there is a
  chain a?c?b

31
Rules required to obtaining a maximally oriented
pattern

• R3 Orient a b into a?b whenever there are two
  chains ac?b and ad?b such that c and d are
  nonadjacent

32
Rules required to obtaining a maximally oriented
pattern

• R4 Orient a b into a?b whenever there are two
  chains ac?d and c?d?b such that c and b are
  nonadjacent

c
a
d
d
c
b
33
IC Algorithm

• Input
• P, a sampled distribution
• Output
• core(P), a marked pattern

34
Marked PatternFour types of edges
35
IC Algorithm Step 1

• For each pair of variables a and b, search for a
  set Sab such that a and b are independent in P,
  conditioned on Sab. If there is no such Sab,
  place an undirected link between the two
  variables, a b.

36
IC Algorithm Step 2

• For each pair of nonadjacent variables a and b
  with a common neighbor c, check if c?Sab
• If it is, then continue
• If it is not, then add arrow heads pointing at c
  (i.e. a ? c ? b).
• In the partially directed graph that results, add
  (recursively) as many arrowheads as possible, and
  mark as many edges as possible, according to the
  following two rules

37
IC Algorithm Rule 1

• R1 For each pair of non-adjacent nodes a and b
  with a common neighbor c, if the link between a
  and c has an arrow head into c and if the link
  between c and b has no arrowhead into c, then add
  an arrow head on the link between c and b
  pointing at b and mark that link to obtain c ?
  b

38
IC Algorithm Rule 2

• R2 If a and b are adjacent and there is a
  directed path (composed strictly of marked links)
  from a to b, then add an arrowhead pointing
  toward b on the link between a and b
