Machine Learning

1
11/16
2
Learning
Improving the performance of the agent -w.r.t.
the external performance measure
Dimensions What can be learned? --Any of
the boxes representing the agents
knowledge --action description, effect
probabilities, causal relations in the
world (and the probabilities of
causation), utility models (sort of through
credit assignment), sensor data
interpretation models What feedback is
available? --Supervised, unsupervised,
reinforcement learning --Credit
assignment problem What prior knowledge is
available? -- Tabularasa (agents head is
a blank slate) or pre-existing knowledge
3
Dimensions of Learning

• Representation of the knowledge
• Degree of Guidance
• Supervised
• Teacher provides training examples solutions
• E.g. Classification
• Unsupervised
• No assistance from teacher
• E.g. Clustering Inducing hidden variables
• In-between
• Either feedback is given only for some of the
  examples
• Semi-supervised Learning
• Or feedback is provided after a sequence of
  decision are made
• Reinforcement Learning

• Degree of Background Knowledge
• Tabula Rasa
• No background knowledge other than the training
  examples
• Knowledge-based learning
• Examples are interpreted in the context of
  existing knowledge
• Inductive vs. deductive learning
• If you do have background knowledge, then a
  question is whether the learned knowledge is
  entailed by the background knowledge or not
• (Entailment can be logical or probabilistic)
• If it is entailed, then it is called deductive
  learning
• If it is not entailed, then it is called
  inductive learning

4
(No Transcript)
5
Inductive Learning(Classification Learning)

• Given a set of labeled training examples
• Find the rule that underlies the labeling
• (so you can use it to predict future unlabeled
  examples)
• Tabula Rasa, fully supervised
• Qns
• How do we test a learner?
• Can learning ever work?
• How do we compare learners?

--similar to predicting credit card fraud,
predicting who are likely to respond to junk
mail predicting what items you are likely to
buy
Closely related to Function learning
or curve-fitting (regression)
6
K-Nearest Neighbor

• An unseen instances class is determined by its
  nearest neighbor
• Or the majority label of its nearest k neighbors
• Real Issue Getting the right distance metric to
  decide who are the neighbors
• One of the most obvious classification algorithms
• Skips the middle stage and lets the examples be
  their own pattern
• A variation is to cluster the training examples
  and remember the prototypes for each cluster
  (reduces the number of things remembered)

7
Inductive Learning(Classification Learning)

• How are learners tested?
• Performance on the test data (not the training
  data)
• Performance measured in terms of positive
• (when) Can learning work?
• Training and test examples the same?
• Training and test examples have no connection?
• Training and Test examples from the same
  distribution

8
A good hypothesis will have fewest false
positives (Fh) and fewest false negatives
(Fh-) Ideally, we want them to be zero Rank(h)
f(Fh, Fh-) --f depends on the domain
by default fSum but can give different
weights to different errors (Cost-based
learning)
False ve The learner classifies the example
as ve, but it is actually -ve
Ranking hypotheses
Medical domain --Higher cost for F- --But
also high cost for F Spam Mailer --Very low
cost for F --higher cost for
F- Terrorist/Criminal Identification --High
cost for F (for the individual) --High cost
for F- (for the society)
H1 Russell waits only in italian restaurants
false ves X10, false ves
X1,X3,X4,X8,X12 H2 Russell waits only in cheap
french restaurants False ves False
ves X1,X3,X4,X6,X8,X12
9
What is a reasonable goal in designing a learner?

• (Idea) Learner must classify all new instances
  (test cases) correctly always
• Always?
• May be the training samples are not completely
  representative of the test samples
• So, we go with probably
• Correctly?
• May be impossible if the training data has noise
  (the teacher may make mistakes too)
• So, we go with approximately

• The goal of a learner then is to produce a
  probably approximately correct (PAC) hypothesis,
  for a given approximation (error rate) e and
  probability d.
• When is a learner A better than learner B?
• For the same e,d bounds, A needs fewer trailing
  samples than B to reach PAC.

Complexity measured in number of Samples
required to PAC-learn
10
Sample Complexity
H
e
f
Hbad
11
Inductive Learning(Classification Learning)

• Given a set of labeled examples, and a space of
  hypotheses
• Find the rule that underlies the labeling
• (so you can use it to predict future unlabeled
  examples)
• Tabularasa, fully supervised
• Idea
• Loop through all hypotheses
• Rank each hypothesis in terms of its match to
  data
• Pick the best hypothesis

• Main variations
• Bias the sort of rule are you looking for?
• If you are looking for only conjunctive
  hypotheses, there are just 3n
• Search
• Greedy search
• Decision tree learner
• Systematic search
• Version space learner
• Iterative search
• Neural net learner

It can be shown that sample complexity of PAC
learning is proportional to 1/e, 1/d AND log H
The main problem is that the space of
hypotheses is too large Given examples described
in terms of n boolean variables There are 2
different hypotheses For 6 features, there are
18,446,744,073,709,551,616 hypotheses
2n
12
ThanksandGiving
11/21
It's the mark of a truly educated man to be
deeply moved by statistics. -Oscar Wilde

• Suppose you randomly reshuffled the world, and
  you have 100 people on your street (randomly
  sampled from the entire world).
• On your street, there will be 5 people from US.
  Suppose they are a family. This family
• Will own 2 of the 8 cars on the entire street
• Will own 60 of the wealth of the whole street
• Of the 100 people on the street, you (and you
  alone) will have had a college education
• and of your neighbors
• Nearly half (50) of your neighbors would suffer
  from malnutrition.
• About 13 of the people would be chronically
  hungry.
• One in 12 of the children on your street would
  die of some mostly preventable disease by the age
  of 5 from measles, malaria, or diarrhea. One in
  12.
• If we came face to face with these inequities
  every day, I believe we would already be doing
  something more about them.
•
  --William H. Gates

http//www.pbs.org/now/transcript/transcript_gates
.html
13
Administrative

• Homework 4 is gathering mass
• (insert ominous sound effects here)
• Project 4 will be the last coding project
• You can submit until tomorrow (make-up class)
  without penalty and with 3p penalty until
  Monday
• Make-up class tomorrow BYENG 210
• Note This is the second floor of Brickyard bldg
  (near the instructional labs and on the same
  floor as advising office)

14
We defined inductive learning problem

• So, lets get started learning already..

15
More expressive the bias, larger the
hypothesis space ?Slower the learning --Line
fitting is faster than curve fitting --Line
fitting may miss non-line patterns
Gavagai example. -The whole object bias
in language learning. Brazilians
BIAS
16
Uses different biases in predicting Russels
waiting habbits
Decision Trees --Examples are used to --Learn
topology --Order of questions
K-nearest neighbors
If patronsfull and dayFriday then wait
(0.3/0.7) If waitgt60 and Reservationno then
wait (0.4/0.9)
Association rules --Examples are used to
--Learn support and confidence of
association rules
SVMs
Neural Nets --Examples are used to --Learn
topology --Learn edge weights
Naïve bayes (bayesnet learning) --Examples are
used to --Learn topology --Learn CPTs
17
The Many Splendors of Bias
The Space of Hypotheses
Training Examples (labelled)
Bias filter
Pick the best hypothesis that fits the examples
Bias is any knowledge other than the training
examples that is used to restrict the space of
hypotheses considered Can be domain independent
or domain-specific
Use the hypothesis to predict new instances
18
Biases

• Domain-indepdendent bias
• Syntactic bias
• Look for lines
• Look for naïve bayes nets
• Whole object bias
• Gavagai problem
• Preference bias
• Look for small decision trees

• Domain-specific bias
• ALL domain knowledge is bias!
• Background theories Explanations
• The relevant features of the data point are those
  that take part in explaining why the data point
  has that label
• Weak domain theories/Determinations
• Nationality determines language
• Color of the skin determines degree of sunburn
• Relevant features
• I know that certain phrases are relevant for
  spam/non-spam classification

19
Bias Learning cost

• Strong Bias ? smaller filtered hypothesis space
• Lower learning cost! (because you need fewer
  examples to rank the hypotheses!)
• Suppose I have decided that hair length
  determines pass/fail grade in the class, then I
  can learn the concept with a _single_ example!
• Cuts down the concepts you can learn accurately
• Strong Bias? fewer parameters for describing the
  hypthesis
• Lower learning cost!!
• For discrete variable learning cases, the sample
  complexity can be shown to be proportional to
  log(H) where H is the hypothesis space

20
PAC learning
Note This result only holds for finite
hypothesis spaces (e.g. not valid for the space
of line hypotheses!)
21
Bias Learning Accuracy

• Having weak bias (large hypothesis space)
• Allows us to capture more concepts
• ..increases learning cost
• May lead to over-fitting

22
Tastes Great/Less Filling

• Biases are essential for survival of an agent!
• You must need biases to just make learning
  tractable
• Whole object bias used by kids in language
  acquisition
• Biases put blinders on the learnerfiltering away
  (possibly more accurate) hypotheses
• God doesnt play dice with the universe
  (Einstein)
• Color of Skin relevant to predicting crime
  (Billy BennettFormer Education Secretary)

23
Uses different biases in predicting Russels
waiting habbits
Decision Trees --Examples are used to --Learn
topology --Order of questions
If patronsfull and dayFriday then wait
(0.3/0.7) If waitgt60 and Reservationno then
wait (0.4/0.9)
Association rules --Examples are used to
--Learn support and confidence of
association rules
Neural Nets --Examples are used to --Learn
topology --Learn edge weights
Naïve bayes (bayesnet learning) --Examples are
used to --Learn topology --Learn CPTs
24
Mirror, Mirror, on the wall Which learning
bias is the best of all?
Well, there is no such thing, silly! --Each
bias makes it easier to learn some patterns and
harder (or impossible) to learn others -A
line-fitter can fit the best line to the data
very fast but wont know what to do if the data
doesnt fall on a line --A curve fitter can
fit lines as well as curves but takes longer
time to fit lines than a line fitter. --
Different types of bias classes (Decision trees,
NNs etc) provide different ways of naturally
carving up the space of all possible
hypotheses So a more reasonable question is --
What is the bias class that has a specialization
corresponding to the type of patterns that
underlie my data? ?Bias can be seen as a
sneaky way of letting background knowledge
in.. -- In this bias class, what is the most
restrictive bias that still can capture the true
pattern in the data?
--Decision trees can capture all boolean
functions --but are faster at capturing
conjunctive boolean functions --Neural nets can
capture all boolean or real-valued functions
--but are faster at capturing linearly separable
functions --Bayesian learning can capture all
probabilistic dependencies But are faster at
capturing single level dependencies (naïve bayes
classifier)
25
Fitting test cases vs. predicting future
cases The BIG TENSION.
Review
2
1
3
Why not the 3rd?
26
(No Transcript)
27
A classification learning example Predicting when
Rusell will wait for a table
--similar to book preferences, predicting credit
card fraud, predicting when people are likely
to respond to junk mail
28
Learning Decision Trees---How?
Basic Idea --Pick an attribute --Split
examples in terms of that attribute
--If all examples are ve label Yes.
Terminate --If all examples are ve
label No. Terminate --If some are ve, some
are ve continue splitting recursively
20 Questions AI Style
29
Decision Trees Sample Complexity

• Decision Trees can Represent any boolean function
• ..So PAC-learning decision trees should be
  exponentially hard (since there are 22n
  hypotheses)
• ..however, decision tree learning algorithms use
  greedy approaches for learning a good (rather
  than the optimal) decision tree
• Thus, using greedy rather than exhaustive search
  of hypotheses space is another way of keeping
  complexity low (at the expense of losing PAC
  guarantees)

30
Depending on the order we pick, we can get
smaller or bigger trees
Which tree is better? Why do you think so??
31
Basic Idea --Pick an attribute --Split
examples in terms of that attribute
--If all examples are ve label Yes.
Terminate --If all examples are ve
label No. Terminate --If some are ve, some
are ve continue splitting recursively
--if no attributes left to split?
(label with majority element)
32
The Information Gain Computation
P N /(NN-) P- N- /(NN-) I(P ,, P-)
-P log(P) - P- log(P- )
The difference is the information gain So, pick
the feature with the largest Info Gain I.e.
smallest residual info
Given k mutually exclusive and exhaustive events
E1.Ek whose probabilities are p1.pk The
information content (entropy) is defined as
S i -pi log2 pi A split is good if it
reduces the entropy..
33
11/22 (Make-up for 11/28)
34
The Information Gain Computation
P N /(NN-) P- N- /(NN-) I(P ,, P-)
-P log(P) - P- log(P- )
The difference is the information gain So, pick
the feature with the largest Info Gain I.e.
smallest residual info
Given k mutually exclusive and exhaustive events
E1.Ek whose probabilities are p1.pk The
information content (entropy) is defined as
S i -pi log2 pi A split is good if it
reduces the entropy..
35
I(1/2,1/2) -1/2 log 1/2 -1/2 log 1/2
1/2 1/2 1 I(1,0) 1log 1 0
log 0 0
A simple example
V(M) 2/4 I(1/2,1/2) 2/4 I(1/2,1/2)
1 V(A) 2/4 I(1,0) 2/4 I(0,1)
0 V(N) 2/4 I(1/2,1/2) 2/4
I(1/2,1/2) 1
So Anxious is the best attribute to split on Once
you split on Anxious, the problem is solved
36
(No Transcript)
37
Lesson Every bias makes something easier to
learn and others harder to learn
Evaluating the Decision Trees
Learning curves Given N examples, partition
them into Ntr the training set and Ntest the test
instances Loop for i1 to Ntr Loop for
Ns in subsets of Ntr of size I Train the
learner over Ns Test the learned
pattern over Ntest and compute the accuracy
(correct)
Can also consider different Ntr and Ntest
partitions
38
Decision Stumps
This was used in the class but the next one is
the correct replacement

• Decision stumps are decision trees where the leaf
  nodes do not necessarily have all ve or all ve
  training examples
• In general, with each leaf node, we can associate
  a probability p that if we reach that leaf node,
  the example is classified ve
• When you reach that node, you toss a biased coin
  (whose probability of heads is p and output ve
  if the coin comes heads)
• In normal decision trees, p is 0 or 1
• In decision stumps, 0 lt p lt 1

Splitting on feature fk
P N1 / N1N1-
Majority vote is better than tossing coin
Sometimes, the best decision tree for a problem
could be a decision stump (see coin toss example
next)
39
Decision Stumps

• Decision stumps are decision trees where the leaf
  nodes do not necessarily have all ve or all ve
  training examples
• Could happen either because examples are noisy
  and mis-classified or because you want to stop
  before reaching pure leafs
• When you reach that node, you return the majority
  label as the decision.
• (We can associate a confidence with that decision
  using the P and P-)

Splitting on feature fk
P N1 / N1N1-
Sometimes, the best decision tree for a problem
could be a decision stump (see coin toss example
next)
40
Problems with Info. Gain. Heuristics

• Feature correlation We are splitting on one
  feature at a time
• The Costanza party problem
• No obvious easy solution
• Overfitting We may look too hard for patterns
  where there are none
• E.g. Coin tosses classified by the day of the
  week, the shirt I was wearing, the time of the
  day etc.
• Solution Dont consider splitting if the
  information gain given by the best feature is
  below a minimum threshold
• Can use the c2 test for statistical significance
• Will also help when we have noisy samples
• We may prefer features with very high branching
• e.g. Branch on the universal time string for
  Russell restaurant example
• Branch on social security number to look
  for patterns on who will get A
• Solution gain ratio --ratio of information
  gain with the attribute A to the information
  content of answering the question What is the
  value of A?
• The denominator is smaller for attributes with
  smaller domains.

41
(No Transcript)
42
Neural Network Learning

• Idea Since classification is really a question
  of finding a surface to separate the ve examples
  from the -ve examples, why not directly search in
  the space of possible surfaces?
• Mathematically, a surface is a function
• Need a way of learning functions
• Threshold units

43
Neural Net is a collection of with
interconnections
threshold units
differentiable
44
The Brain Connection
A Threshold Unit
Threshold Functions
differentiable
is sort of like a neuron
45
Perceptron Networks
What happened to the Threshold? --Can model
as an extra weight with static input

46
Can Perceptrons Learn All Boolean Functions?
--Are all boolean functions linearly separable?
47
Perceptron Learning

• Perceptron learning algorithm
• Loop through training examples
• If the activation level of the output unit is 1
  when it should be 0, reduce the weight on the
  link to the jth input unit by aIj, where Li is
  the ith input value and r a learning rate
• If the activation level of the output unit is 0
  when it should be 1, increase the weight on the
  link to the ith input unit by aIj
• Otherwise, do nothing
• Until convergence

Iterative search! --node -gt network weights
--goodness -gt error Actually a gradient
descent search
A nice applet at
http//neuron.eng.wayne.edu/java/Perceptron/New38.
html
48
Perceptron Learning as Gradient Descent Search in
the Space of Weights
Often a constant learning rate parameter is
used instead
Ij
I
49
Perceptron Training in Action
A nice applet at
http//neuron.eng.wayne.edu/java/Perceptron/New38.
html
50
Comparing Perceptrons and Decision Trees in
Majority Function and Russell Domain
Decision Trees
Perceptron
Decision Trees
Perceptron
Majority function
Russell Domain
Majority function is linearly seperable..
Russell domain is apparently not....
Encoding one input unit per attribute. The unit
takes as many distinct real values as the size
of attribute domain
51
Max-Margin Classification Support Vector
Machines
This slide was shown in the class but the next
one is a better replacement

• Any line that separates the ve ve examples
  is a solution
• And perceptron learning finds one of them
• But could we have a preference among these?
• may want to get the line that provides maximum
  margin (equidistant from the nearest ve/-ve)
• The nereast ve and ve holding up the line are
  called support vectors
• This changes the problem into an optimization
  one
• Quadratic Programming can be used to directly
  find such a line

Learning is Optimization after all!
52
Max-Margin Classification Support Vector
Machines

• Any line that separates the ve ve examples
  is a solution
• And perceptron learning finds one of them
• But could we have a preference among these?
• may want to get the line that provides maximum
  margin (equidistant from the nearest ve/-ve)
• The nereast ve and ve holding up the line are
  called support vectors
• This changes the problem into an optimization
  one
• Quadratic Programming can be used to directly
  find such a line

Learning is Optimization after all!
53
Lagrangian Dual
54
Linear Separability in High Dimensions
Kernels allow us to consider separating
surfaces in high-D without first converting
all points to high-D
55
11/30

• ?Next class Conclusion Interactive review
• ?Today Statistical Learning

56
Kernelized Support Vector Machines

• Turns out that it is not always necessary to
  first map the data into high-D, and then do
  linear separation
• The quadratic programming formulation for SVM
  winds up using only the pair-wise dot product of
  training vectors
• Dot product is a form of similarity metric
  between points
• If you replace that dot product by any non-linear
  function, you will, in essence, be tranforming
  data into some high-dimensional space and then
  finding the max-margin linear classifier in that
  space
• Which will correspond to some wiggly surface in
  the original dimension
• The trick is to find the RIGHT similarity
  function
• Which is a form of prior knowledge

57
Kernelized Support Vector Machines

• Turns out that it is not always necessary to
  first map the data into high-D, and then do
  linear separation
• The quadratic programming formulation for SVM
  winds up using only the pair-wise dot product of
  training vectors
• Dot product is a form of similarity metric
  between points
• If you replace that dot product by any non-linear
  function, you will, in essence, be tranforming
  data into some high-dimensional space and then
  finding the max-margin linear classifier in that
  space
• Which will correspond to some wiggly surface in
  the original dimension
• The trick is to find the RIGHT similarity
  function
• Which is a form of prior knowledge

58
Domain-knowledge Learning
Those who ignore easily available domain
knowledge are doomed to re-learn it
Santayanas brother

• Classification learning is a problem addressed by
  both people from AI (machine learning) and
  Statistics
• Statistics folks tend to distrust
  domain-specific bias.
• Let the data speak for itself
• ..but this is often futile. The very act of
  describing the data points introduces bias (in
  terms of the features you decided to use to
  describe them..)
• but much human learning occurs because of strong
  domain-specific bias..
• Machine learning is torn by these competing
  influences..
• In most current state of the art algorithms,
  domain knowledge is allowed to influence
  learning only through relatively narrow
  avenues/formats (E.g. through kernels)
• Okay in domains where there is very little (if
  any) prior knowledge (e.g. what part of proteins
  are doing what cellular function)
• ..restrictive in domains where there already
  exists human expertise..

59
Multi-layer Neural Nets
How come back-prop doesnt get stuck in local
minima? One answer It is actually hard for
local minimas to form in high-D, as the
trough has to be closed in all dimensions
60
(No Transcript)
61
Multi-Network Learning can learn Russell Domains
Decision Trees
Decision Trees
Multi-layer networks
Perceptron
Russell Domain
but does it slowly
62
Practical Issues in Multi-layer network learning

• For multi-layer networks, we need to learn both
  the weights and the network topology
• Topology is fixed for perceptrons
• If we go with too many layers and connections, we
  can get over-fitting as well as sloooow
  convergence
• Optimal brain damage
• Start with more than needed hidden layers as well
  as connections after a network is learned,
  remove the nodes and connections that have very
  low weights retrain

63
Humans make 0.2 Neumans (postmen) make 2
Other impressive applications --no-hands
across america --learning to speak
K-nearest-neighbor The test examples class is
determined by the class of the majority of
its k nearest neighbors Need to define an
appropriate distance measure --sort of easy
for real valued vectors --harder for
categorical attributes
64
Decision Trees vs. Neural Nets

• Can handle real-valued attributes
• Can learn any non-linear decision surface
• Incremental as new examples arrive, the network
  can adapt.
• Good at handling noise
• Convergence is quite slow
• Faster at learning linear ones
• Learned concept is represented by the weights and
  topology of the network (so hard to understand)
• Consider understanding Einstein by dissecting his
  brain.
• Double edged argumentthere are many learning
  tasks for whion ch we do not know how to
  articulated what we have learned. Eg. Face
  recognition word recognition

• Work well for discrete attributes.
• Converge fast for conjunctive concepts
• Non-incremental (looks at all the examples at
  once)
• Not very good at handling noise
• Generally good at avoiding irrelevant attributes
• Easy to understand the learned concept

Why is it important to understand what is
learned? --The military hidden tank photos
example
65
(No Transcript)
66
(No Transcript)
67
(No Transcript)
68
True hypothesis eventually dominates
probability of indefinitely producing
uncharacteristic data ?0
69
Bayesian prediction is optimal (Given the
hypothesis prior, all other predictions are
less likely)
70
Also, remember the Economist article that shows
that humans have strong priors..
71
..note that the Economist article says humans
are able to learn from few examples only because
of priors..
72
So, BN learning is just probability estimation!
(as long as data is complete!)
73
How Well (and WHY) DOES NBC WORK?

• Naïve bayes classifier is darned easy to
  implement
• Good learning speed, classification speed
• Modest space storage
• Supports incrementality
• It seems to work very well in many scenarios
• Lots of recommender systems (e.g. Amazon books
  recommender) use it
• Peter Norvig, the director of Machine Learning at
  GOOGLE said, when asked about what sort of
  technology they use Naïve bayes
• But WHY?
• NBCs estimate of class probability is quite bad
• BUT classification accuracy is different from
  probability estimate accuracy
• Domingoes/Pazzani 1996 analyze this

74
(No Transcript)
75
(No Transcript)
76
(No Transcript)
77
(No Transcript)
78
Bayes Network Learning

• Bias The relation between the class label and
  class attributes is specified by a Bayes Network.
• Approach
• Guess Topology
• Estimate CPTs
• Simplest case Naïve Bayes
• Topology of the network is class label causes
  all the attribute values independently
• So, all we need to do is estimate CPTs
  P(attribClass)
• In Russell domain, P(Patronswillwait)
• P(Patronsfullwillwaityes)
• training examples where patronsfull and
  will waityes
• training examples where will waityes
• Given a new case, we use bayes rule to compute
  the class label

Class label is the disease attributes are
symptoms
79
Naïve Bayesian Classification

• Problem Classify a given example E into one of
  the classes among C1, C2 ,, Cn
• E has k attributes A1, A2 ,, Ak and each Ai can
  take d different values
• Bayes Classification Assign E to class Ci that
  maximizes P(Ci E)
• P(Ci E) P(E Ci) P(Ci) / P(E)
• P(Ci) and P(E) are a priori knowledge (or can be
  easily extracted from the set of data)
• Estimating P(ECi) is harder
• Requires P(A1v1 A2v2.AkvkCi)
• Assuming d values per attribute, we will need ndk
  probabilities
• Naïve Bayes Assumption Assume all attributes are
  independent P(E Ci) P P(Aivj Ci )
• The assumption is BOGUS, but it seems to WORK
  (and needs only ndk probabilities

80
NBC in terms of BAYES networks..
NBC assumption
More realistic assumption
81
Estimating the probabilities for NBC

• Given an example E described as A1v1
  A2v2.Akvk we want to compute the class of E
• Calculate P(Ci A1v1 A2v2.Akvk) for all
  classes Ci and say that the class of E is the
  one for which P(.) is maximum
• P(Ci A1v1 A2v2.Akvk)
• P P(vj Ci ) P(Ci) / P(A1v1
  A2v2.Akvk)
• Given a set of training N examples that have
  already been classified into n classes Ci
• Let (Ci) be the number of
  examples that are labeled as Ci
• Let (Ci, Aivi) be the number of
  examples labeled as Ci
• that have attribute Ai
  set to value vj
• P(Ci) (Ci)/N
• P(Aivj Ci) (Ci, Aivi) /
  (Ci)

82
Example
P(willwaityes) 6/12 .5 P(Patronsfullwillw
aityes) 2/60.333 P(Patronssomewillwaityes
) 4/60.666
Similarly we can show that P(Patronsfullwillw
aitno) 0.6666
P(willwaityesPatronsfull) P(patronsfullwill
waityes) P(willwaityes)

--------------------------------------------------
---------
P(Patronsfull)
k
.333.5 P(willwaitnoPatronsfull) k 0.666.5
83
Using M-estimates to improve probablity estimates

• The simple frequency based estimation of
  P(AivjCk) can be inaccurate, especially when
  the true value is close to zero, and the number
  of training examples is small (so the probability
  that your examples dont contain rare cases is
  quite high)
• Solution Use M-estimate
• P(Aivj Ci) (Ci, Aivi)
  mp / (Ci) m
• p is the prior probability of Ai taking the value
  vi
• If we dont have any background information,
  assume uniform probability (that is 1/d if Ai can
  take d values)
• m is a constantcalled equivalent sample size
• If we believe that our sample set is large
  enough, we can keep m small. Otherwise, keep it
  large.
• Essentially we are augmenting the (Ci) normal
  samples with m more virtual samples drawn
  according to the prior probability on how Ai
  takes values
• Popular values p1/V and mV where V is the
  size of the vocabulary

Also, to avoid overflow errors do addition of
logarithms of probabilities (instead of
multiplication of probabilities)
84
How Well (and WHY) DOES NBC WORK?

• Naïve bayes classifier is darned easy to
  implement
• Good learning speed, classification speed
• Modest space storage
• Supports incrementality
• It seems to work very well in many scenarios
• Lots of recommender systems (e.g. Amazon books
  recommender) use it
• Peter Norvig, the director of Machine Learning at
  GOOGLE said, when asked about what sort of
  technology they use Naïve bayes
• But WHY?
• NBCs estimate of class probability is quite bad
• BUT classification accuracy is different from
  probability estimate accuracy
• Domingoes/Pazzani 1996 analyze this

85
Sahami et als Solution for SPAM detection

• use standard Term Vector Space model developed
  by Information Retrieval field (similar to
  AdEater)
• 1 e-mail message ? single fixed-width feature
  vector
• have 1 bit in this vector for each term that
  occurs in some message in E (plus a bunch of
  domain-specific featureseg, when message was
  sent)
• learning algorithm
• use standard Naive Bayes algorithm

86
Feature Selection

• A problem -- too many features -- each vector x
  contains several thousand features.
• Most come from word features -- include a word
  if any e-mail contains it (eg, every x contains
  an opossum feature even though this word occurs
  in only one message).
• Slows down learning and predictoins
• May cause lower performance
• The Naïve Bayes Classifier makes a huge
  assumption -- the independence assumption.
• A good strategy is to have few features, to
  minimize the chance that the assumption is
  violated.
• Ideally, discard all features that violate the
  assumption. (But if we knew these features, we
  wouldnt need to make the naive independence
  assumption!)
• Feature selection a few thousand ? 500
  features

87
Feature-Selection approach

• Lots of ways to perform feature selection
• FEATURE SELECTION DIMENSIONALITY REDUCTION
• One simple strategy mutual information
• Suppose we have two random variables A and B.
• Mutual information MI(A,B) is a numeric measure
  of what we can conclude about A if we know B, and
  vice-versa.
• MI(A,B) Pr(AB) log(Pr(AB)/(Pr(A)Pr(B)))
• Example If A and B are independent, then we
  cant conclude anything MI(A, B) 0
• Note that MI can be calculated without needing
  conditional probabilities.

88
Mutual Information, continued

• Check our intuition independence -gt MI(A,B)0
  MI(A,B) Pr(AB) log(Pr(AB)/(Pr(A)Pr(B)))
  Pr(AB) log(Pr(A)Pr(B)/(Pr(A)Pr(B
  ))) Pr(AB) log 1
  0
• Fully correlated, it becomes the information
  content
• MI(A,A) - Pr(A)log(Pr(A))
• it depends on how uncertain the event is
  notice that the expression becomes maximum (1)
  when Pr(A).5 this makes sense since the most
  uncertain event is one whose probability is .5
  (if it is .3 then we know it is likely not to
  happen if it is .7 we know it is likely to
  happen).

89
MI and Feature Selection

• Back to feature selection Pick features Xi that
  have high mutual information with the junk/legit
  classification C.
• These are exactly the features that are good for
  prediction
• Pick 500 features Xi with highest value MI(Xi, C)
• NOTE NBCs estimate of probabilities is
  actually quite a bit wrong but they still got by
  with those..
• Also, note that this analysis looks at each
  feature in isolation and may thus miss highly
  predictive word groups whose individual words are
  quite non-predictive
• e.g. free and money may have low MI, but
  Free money may have higher MI.
• A way to handle this is to look at MI of not just
  words but subsets of words
• (in the worst case, you will need to compute 2n
  MIs ?)
• So instead, Sahami et. Al. add domain specific
  phrases separately..
• Note Theres no reason that the highest-MI
  features are the ones that least violate the
  independence assumption -- this is just a
  heuristic!

90
MI based feature selection vs. LSI

• Both MI and LSI are dimensionality reduction
  techniques
• MI is looking to reduce dimensions by looking at
  a subset of the original dimensions
• LSI looks instead at a linear combination of the
  subset of the original dimensions (Good Can
  automatically capture sets of dimensions that are
  more predictive. Bad the new features may not
  have any significance to the user)
• MI does feature selection w.r.t. a classification
  task (MI is being computed between a feature and
  a class)
• LSI does dimensionality reduction independent of
  the classes (just looks at data variance)

91
Reinforcement Learning

• Based on slides from Bill Smart
• http//www.cse.wustl.edu/wds/

92
What is RL?

• a way of programming agents by reward and
  punishment without needing to specify how the
  task is to be achieved
• Kaelbling, Littman, Moore, 96

93
Basic RL Model

• Observe state, st
• Decide on an action, at
• Perform action
• Observe new state, st1
• Observe reward, rt1
• Learn from experience
• Repeat
• Goal Find a control policy that will maximize
  the observed rewards over the lifetime of the
  agent

A
S
R
94
An Example Gridworld

• Canonical RL domain
• States are grid cells
• 4 actions N, S, E, W
• Reward for entering top right cell
• -0.01 for every other move
• Minimizing sum of rewards ? Shortest path
• In this instance

1
95
The Promise of Learning
96
The Promise of RL

• Specify what to do, but not how to do it
• Through the reward function
• Learning fills in the details
• Better final solutions
• Based of actual experiences, not programmer
  assumptions
• Less (human) time needed for a good solution

97
Learning Value Functions

• We still want to learn a value function
• Were forced to approximate it iteratively
• Based on direct experience of the world
• Four main algorithms
• Certainty equivalence
• Temporal Difference (TD) learning
• Q-learning
• SARSA

98
Certainty Equivalence

• Collect experience by moving through the world
• s0, a0, r1, s1, a1, r2, s2, a2, r3, s3, a3, r4,
  s4, a4, r5, s5, ...
• Use these to estimate the underlying MDP
• Transition function, T S?A ? S
• Reward function, R S?A?S ? ?
• Compute the optimal value function for this MDP
• And then compute the optimal policy from it

99
Temporal Difference (TD)
Sutton, 88

• TD-learning estimates the value function directly
• Dont try to learn the underlying MDP
• Keep an estimate of Vp(s) in a table
• Update these estimates as we gather more
  experience
• Estimates depend on exploration policy, p
• TD is an on-policy method

100
TD-Learning Algorithm

• Initialize Vp(s) to 0, ?s
• Observe state, s
• Perform action, p(s)
• Observe new state, s, and reward, r
• Vp(s) ? (1-a)Vp(s) a(r gVp(s))
• Go to 2
• 0 a 1 is the learning rate
• How much attention do we pay to new experiences

101
TD-Learning

• Vp(s) is guaranteed to converge to V(s)
• After an infinite number of experiences
• If we decay the learning rate
• will work
• In practice, we often dont need value
  convergence
• Policy convergence generally happens sooner

102
Actor-Critic Methods
Barto, Sutton, Anderson, 83

• TD only evaluates a particular policy
• Does not learn a better policy
• We can change the policy as we learn V
• Policy is the actor
• Value-function estimate is the critic
• Success is generally dependent on the starting
  policy being good enough

Policy (actor)
a
V
Value Function (critic)
r
s
World
103
Q-Learning
Watkins Dayan, 92

• Q-learning iteratively approximates the
  state-action value function, Q
• Again, were not going to estimate the MDP
  directly
• Learns the value function and policy
  simultaneously
• Keep an estimate of Q(s, a) in a table
• Update these estimates as we gather more
  experience
• Estimates do not depend on exploration policy
• Q-learning is an off-policy method

104
Q-Learning Algorithm

• Initialize Q(s, a) to small random values, ?s, a
• Observe state, s
• Pick an action, a, and do it
• Observe next state, s, and reward, r
• Q(s, a) ? (1 - a)Q(s, a) a(r gmaxaQ(s, a))
• Go to 2
• 0 a 1 is the learning rate
• We need to decay this, just like TD

105
Picking Actions

• We want to pick good actions most of the time,
  but also do some exploration
• Exploring means that we can learn better policies
• But, we want to balance known good actions with
  exploratory ones
• This is called the exploration/exploitation
  problem

106
Picking Actions

• e-greedy
• Pick best (greedy) action with probability e
• Otherwise, pick a random action
• Boltzmann (Soft-Max)
• Pick an action based on its Q-value
• , where t is
  the temperature

107
SARSA

• SARSA iteratively approximates the state-action
  value function, Q
• Like Q-learning, SARSA learns the policy and the
  value function simultaneously
• Keep an estimate of Q(s, a) in a table
• Update these estimates based on experiences
• Estimates depend on the exploration policy
• SARSA is an on-policy method
• Policy is derived from current value estimates

108
SARSA Algorithm

• Initialize Q(s, a) to small random values, ?s, a
• Observe state, s
• Pick an action, a, and do it (just like
  Q-learning)
• Observe next state, s, and reward, r
• Q(s, a) ? (1-a)Q(s, a) a(r gQ(s, p(s)))
• Go to 2
• 0 a 1 is the learning rate
• We need to decay this, just like TD

109
On-Policy vs. Off Policy

• On-policy algorithms
• Final policy is influenced by the exploration
  policy
• Generally, the exploration policy needs to be
  close to the final policy
• Can get stuck in local maxima
• Off-policy algorithms
• Final policy is independent of exploration policy
• Can use arbitrary exploration policies
• Will not get stuck in local maxima

Given enough experience
110
Convergence Guarantees

• The convergence guarantees for RL are in the
  limit
• The word infinite crops up several times
• Dont let this put you off
• Value convergence is different than policy
  convergence
• Were more interested in policy convergence
• If one action is really better than the others,
  policy convergence will happen relatively quickly

111
Rewards

• Rewards measure how well the policy is doing
• Often correspond to events in the world
• Current load on a machine
• Reaching the coffee machine
• Program crashing
• Everything else gets a 0 reward
• Things work better if the rewards are incremental
• For example, distance to goal at each step
• These reward functions are often hard to design

These are sparse rewards
These are dense rewards
112
The Markov Property

• RL needs a set of states that are Markov
• Everything you need to know to make a decision is
  included in the state
• Not allowed to consult the past
• Rule-of-thumb
• If you can calculate the reward
  function from the state without
  any additional information,
  youre OK

K
S
G
113
But, Whats the Catch?

• RL will solve all of your problems, but
• We need lots of experience to train from
• Taking random actions can be dangerous
• It can take a long time to learn
• Not all problems fit into the MDP framework

114
Learning Policies Directly

• An alternative approach to RL is to reward whole
  policies, rather than individual actions
• Run whole policy, then receive a single reward
• Reward measures success of the whole policy
• If there are a small number of policies, we can
  exhaustively try them all
• However, this is not possible in most interesting
  problems

115
Policy Gradient Methods

• Assume that our policy, p, has a set of n
  real-valued parameters, q q1, q2, q3, ... , qn

• Running the policy with a particular q results in
  a reward, rq
• Estimate the reward gradient, , for each
  qi

116
Policy Gradient Methods

• This results in hill-climbing in policy space
• So, its subject to all the problems of
  hill-climbing
• But, we can also use tricks from search, like
  random restarts and momentum terms
• This is a good approach if you have a
  parameterized policy
• Typically faster than value-based methods
• Safe exploration, if you have a good policy
• Learns locally-best parameters for that policy

117
An Example Learning to Walk
Kohl Stone, 04

• RoboCup legged league
• Walking quickly is a big advantage
• Robots have a parameterized gait controller
• 11 parameters
• Controls step length, height, etc.
• Robots walk across soccer pitch and are timed
• Reward is a function of the time taken

118
An Example Learning to Walk

• Basic idea
• Pick an initial q q1, q2, ... , q11
• Generate N testing parameter settings by
  perturbing q
• qj q1 d1, q2 d2, ... , q11 d11, di ?
  -e, 0, e
• Test each setting, and observe rewards
• qj ? rj
• For each qi ? q
• Calculate q1, q10, q1- and set
• Set q ? q, and go to 2

Average reward when qni qi - di
119
An Example Learning to Walk
Initial
Final
Video Nate Kohl Peter Stone, UT Austin
120
Value Function or Policy Gradient?

• When should I use policy gradient?
• When theres a parameterized policy
• When theres a high-dimensional state space
• When we expect the gradient to be smooth
• When should I use a value-based method?
• When there is no parameterized policy
• When we have no idea how to solve the problem

121
Summary for Part I

• Background
• MDPs, and how to solve them
• Solving MDPs with dynamic programming
• How RL is different from DP
• Algorithms
• Certainty equivalence
• TD
• Q-learning
• SARSA
• Policy gradient
