Transactional Memory An Overview of Hardware Alternatives

1
Transactional MemoryAn Overview of Hardware
Alternatives

• David A. Wood
• University of Wisconsin
• Transactional Memory Workshop
• April 8th, 2005

2
Whats database got to do with it?

• Atomicity
• All updates, or none
• Consistency
• Correct at begin and end
• Isolation
• Partial work not visible
• Inputs stay stable
• Durability
• Survive system failures

All (or some) memory ops, not just database
objects
Despite increasing awareness of failures
3
801 Database Storage

• Lock bits on virtual memory
• 128 byte granularity
• Added to pagetable and TLB
• Caches users lock state
• Trap on lock conflict
• No h/w for logging, abort, etc.
• Only uniprocessors
• 801 and RS/6000

Memory
TLB
Tid
Was this transactional memory?
4
SQL/801

• The development of SQL/801 was greatly
  simplified because, with minor exceptions, it
  considers only a single user. It achieves
  multiuser concurrency on a uniprocessor by
  running in multiple processes using the shared
  database storage. Chang and Mergen, 88
• Largest transactional memory application
• Only real hardware transactional memory
  implementation
• No one seems to be looking at what they learned

5
Basic Transactional Mechanisms

• Isolation
• Detect when transactions conflict
• Track read and write sets
• Version management
• Record new and old values
• Atomicity
• Commit new values
• Abort back to old values

6
H/W Transactional Memory Systems

• Knights Lisp Work
• Transactional Memory
• Oklahoma Update
• SLE/TLR
• Transactional Coherence and Consistency
• Unbounded TM
• Virtual TM
• Thread-level TM

7
Knights Lisp Work 86

• Parallel execution of sequential code
• Break program into transaction blocks
• Multiple loads in a transaction
• Exactly one store ends the transaction
• No register state passed between transactions
• Execute transactions in parallel
• Track dependences (i.e., read set)
• Abort and restart on conflicting write
• Transactions commit in sequential order
• Broadcast writes on commit

8
Knights Hardware

• Two caches
• Dependency cache
• Tracks read set
• Bus monitor detects conflicts
• Confirm cache
• Holds write set
• Supports multiple writes
• Commits
• Check dep. cache
• Broadcast writes
• Fast aborts
• Invalidate Confirm cache
• Use old values in Dep. Cache
• Immediately restart execution

Memory
Confirm Cache
Dependency Cache
Spawned two threads TLS TM
9
HMs Transactional Memory 93

• Targets explicitly parallel (non-functional)
  codes
• Motivated by lock-free data structures
• Transactions
• Read and write multiple locations
• Commit in arbitrary order
• Implicit begin, explicit commit operations
• Abort affects memory, not registers
• Software manages restarting execution
• Validate instruction detects pending abort
• Implementation extends cache coherence
• Read/Write locks correspond to MOESI states
• Add orthogonal transaction states

10
HMs Transactional Memory

• Adds Transaction Cache
• Stores all data accessed by transactions
• 2 copies of each line
• Before and after image
• Even for read-only data
• Small, fully associative
• Abort on all conflicts
• NACK conflicting requests
• Abort NACKed transaction
• Fast commit and abort
• Change trans. cache state

Memory
Cache
Transaction Cache
11
SLE/TLR

• Hardware exploits speculative processors
• Read sets tracked by coherence protocol
• Write set maintained in store queue
• Abort restarts execution, including register
  state
• Speculative lock elision (SLE)
• Elide locks from the dynamic execution stream
• Convert critical sections to optimistic
  transactions
• Concurrently execute non-conflicting transactions
• Fall back on explicit locks if conflicts
• Transactional Lock Removal (TLR)
• Resolve conflicts using priority ordering
  (timestamps)
• Delay lower priority transactions
• Deadlock and starvation free

12
Transactional Coherence and Consistency 04

• TCC unifies coherence, memory consistency, and
  transaction support
• All transactions, all the time
• Transaction ordering
• Ordered, Unordered, Partially Ordered
• Supports thread-level speculation
• Optimistic concurrency model
• Unordered transactions serialize at commit
• Conflicts detected at commit

13
TCC
On-Chip Interconnect Broadcast updates at commit
Write buffer 4 kB, holds new values until commit
Shadow register file checkpoints architectural
registers
L2 Cache Logically Shared
CPU
L1 D
L1 cache tracks read set, bit per line
SRF
14
TCC

• Commits are sequential
• Broadcasts addresses of all updates
• Supports large transactions
• Serialize all other transactions
• Grabs and holds the commit bus
• Cannot abort large transactions
• Updates affect L2/Mem no undo
• Extensions forthcoming
• talk to Kunle and Christos

15
Unbounded Transactional Memory (UTM)

• Unbounded transactions
• Arbitrary size
• Not limited by write buffer, cache, or memory
• Arbitrary duration
• Not limited by interrupts, context switch, etc.
• Complex implementation
• Not justified by performance
• Settle for nearly unbounded transactions
• Much simpler hardware

16
Transactional Linux
Log-log scale

• Almost all of the transactions require lt 100
  cache lines
• 99.9 need fewer than 54 cache lines
• There are, however, some very large transactions!
• gt500k-byte fully-associative cache required

17
Large Transaction Memory (LTM)

• Register checkpoints
• Snapshot of rename maps
• Cache tracks read and write sets
• T-bits mark transactional blocks
• Cache holds new data values in place
• O-bit indicates overflow to in-memory hashtable
• Memory holds committed state
• Abort invalidates all modified blocks
• Miss on re-execution
• Transactional writes force memory updates
• Repeated writes (e.g., to local data) are written
  through

18
Virtual Transactional Memory (VTM)

• Only an overflow mechanism
• No overhead on common in-cache case
• Check shared overflow counter on cache miss
• Low overhead when no conflict
• Shared Bloom Filter rules out conflicts
• Filter resides in virtual memory
• Higher overhead on possible conflict
• Hardware table walk to detect actual conflict
• Table resides in virtual memory
• Only incurred by large transactions with likely
  conflict
• Supports context switches and paging

19
801 revisited

• Why didnt 801 database storage succeed?
• Lock bits helped performance and simplified
  software
• Answer 1
• Changing lock bits requires TLB shootdown
• Too complicated for the benefits?
• ? Not a current problem transaction h/w is easy
• Answer 2
• Not universally available
• DB2 was (is) multiplatform
• Cant rely on feature only available in one
  architecture
• ?Still a relevant concern

20
Need Standard Transaction Interface

• Abstract away resource requirements
• Support large, long transactions
• Virtualize transactional memory
• Transaction semantics between threads
• NOT a hardware property
• Permit range of implementations
• Hardware, software, and combinations

21
Thread-level Transactional Memory

• Abstract mechanisms
• Version management
• Update memory in place
• Log before images to thread level VM
• Isolation
• Logically extend memory words with read and write
  bits
• Implementations can be conservative (e.g.,
  blocks)
• Atomicity
• Commits easy due to in place updates
• Aborts trap to user-level software
• Hardware can accelerate common case

22
Conclusions

• Make the common case fast
• 99 of transactions fit in hardware
• Lots of alternatives
• Make both commits and aborts fast
• Handle the uncommon case
• Large transactions will occur, deal with em
• Shouldnt be limited by hardware
• Agree on a common abstraction
• Success requires multi-platform support
• Let vendors compete on price-performance
