Overview of Parallel Architecture and
Programming Models
2
What is a Parallel Computer?

• A collection of processing elements that
  cooperate to solve large problems fast
• Some broad issues that distinguish parallel
  computers
• Resource Allocation
• how large a collection?
• how powerful are the elements?
• how much memory?
• Data access, Communication and Synchronization
• how do the elements cooperate and communicate?
• how are data transmitted between processors?
• what are the abstractions and primitives for
  cooperation?
• Performance and Scalability
• how does it all translate into performance?
• how does it scale?

3
Why Parallelism?

• Provides alternative to faster clock for
  performance
• Assuming a doubling of effective per-node
  performance every 2 years, 1024-CPU system can
  get you the performance that it would take 20
  years for a single-CPU system to deliver
• Applies at all levels of system design
• Is increasingly central in information processing
• Scientific computing simulation, data analysis,
  data storage and management, etc.
• Commercial computing Transaction processing,
  databases
• Internet applications Search Google operates
  at least 50,000 CPUs, many as part of large
  parallel systems

4
How to Study Parallel Systems

• History diverse and innovative organizational
  structures, often tied to novel programming
  models
• Rapidly matured under strong technological
  constraints
• The microprocessor is ubiquitous
• Laptops and supercomputers are fundamentally
  similar!
• Technological trends cause diverse approaches to
  converge
• Technological trends make parallel computing
  inevitable
• In the mainstream
• Need to understand fundamental principles and
  design tradeoffs, not just taxonomies
• Naming, Ordering, Replication, Communication
  performance

5
Outline

• Drivers of Parallel Computing
• Trends in Supercomputers for Scientific
  Computing
• Evolution and Convergence of Parallel
  Architectures
• Fundamental Issues in Programming Models and
  Architecture

6
Drivers of Parallel Computing

• Application Needs Our insatiable need for
  computing cycles
• Scientific computing CFD, Biology, Chemistry,
  Physics, ...
• General-purpose computing Video, Graphics, CAD,
  Databases, TP...
• Internet applications Search, e-Commerce,
  Clustering ...
• Technology Trends
• Architecture Trends
• Economics
• Current trends
• All microprocessors have support for external
  multiprocessing
• Servers and workstations are MP Sun, SGI, Dell,
  COMPAQ...
• Microprocessors are multiprocessors. Multicore
  SMP on a chip

7
Application Trends

• Demand for cycles fuels advances in hardware, and
  vice-versa
• Cycle drives exponential increase in
  microprocessor performance
• Drives parallel architecture harder most
  demanding applications
• Range of performance demands
• Need range of system performance with
  progressively increasing cost
• Platform pyramid
• Goal of applications in using parallel machines
  Speedup
• Speedup (p processors)
• For a fixed problem size (input data set),
  performance 1/time
• Speedup fixed problem (p processors)

Time (1 processor)
Time (p processors)
8
Scientific Computing Demand

• Ever increasing demand due to need for more
  accuracy, higher-level modeling and knowledge,
  and analysis of exploding amounts of data
• Example area 1 Climate and Ecological Modeling
  goals
• By 2010 or so
• Simply resolution, simulated time, and improved
  physics leads to increased requirement by factors
  of 104 to 107. Then
• Reliable global warming, natural disaster and
  weather prediction
• By 2015 or so
• Predictive models of rainforest destruction,
  forest sustainability, effects of climate change
  on ecoystems and on foodwebs, global health
  trends
• By 2020 or so
• Verifiable global ecosystem and epidemic models
• Integration of macro-effects with localized and
  then micro-effects
• Predictive effects of human activities on earths
  life support systems
• Understanding earths life support systems

9
Scientific Computing Demand

• Example area 2 Biology goals
• By 2010 or so
• Ex vivo and then in vivo molecular-computer
  diagnosis
• By 2015 or so
• Modeling based vaccines
• Individualized medicine
• Comprehensive biological data integration (most
  data co-analyzable)
• Full model of a single cell
• By 2020 or so
• Full model of a multi-cellular tissue/organism
• Purely in-silico developed drugs personalized
  smart drugs
• Understanding complex biological systems cells
  and organisms to ecosystems
• Verifiable predictive models of biological
  systems

10
Engineering Computing Demand

• Large parallel machines a mainstay in many
  industries
• Petroleum (reservoir analysis)
• Automotive (crash simulation, drag analysis,
  combustion efficiency),
• Aeronautics (airflow analysis, engine efficiency,
  structural mechanics, electromagnetism),
• Computer-aided design
• Pharmaceuticals (molecular modeling)
• Visualization
• in all of the above
• entertainment (movies), architecture
  (walk-throughs, rendering)
• Financial modeling (yield and derivative
  analysis)
• etc.

11
Learning Curve for Parallel Applications

• AMBER molecular dynamics simulation program
• Starting point was vector code for Cray-1
• 145 MFLOP on Cray90, 406 for final version on
  128-processor Paragon, 891 on 128-processor Cray
  T3D

12
Commercial Computing

• Also relies on parallelism for high end
• Scale not so large, but use much more wide-spread
• Computational power determines scale of business
  that can be handled
• Databases, online-transaction processing,
  decision support, data mining, data warehousing
  ...
• TPC benchmarks (TPC-C order entry, TPC-D decision
  support)
• Explicit scaling criteria provided size of
  enterprise scales with system
• Problem size no longer fixed as p increases, so
  throughput is used as a performance measure
  (transactions per minute or tpm)
• E-commerce, search and other scalable internet
  services
• Parallel applications running on clusters
• Developing new parallel software models and
  primitives
• Insight from automated analysis of large
  disparate data

13
TPC-C Results for Wintel Systems
6-way Unisys AQ HS6 Pentium Pro 200 MHz 12,026
tpmC 39.38/tpmC Avail 11-30-97 TPC-C
v3.3 (withdrawn)
4-way Cpq PL 5000 Pentium Pro 200 MHz 6,751
tpmC 89.62/tpmC Avail 12-1-96 TPC-C
v3.2 (withdrawn)
4-way IBM NF 7000 PII Xeon 400 MHz 18,893
tpmC 29.09/tpmC Avail 12-29-98 TPC-C
v3.3 (withdrawn)
8-way Cpq PL 8500 PIII Xeon 550 MHz 40,369
tpmC 18.46/tpmC Avail 12-31-99 TPC-C
v3.5 (withdrawn)
8-way Dell PE 8450 PIII Xeon 700 MHz 57,015
tpmC 14.99/tpmC Avail 1-15-01 TPC-C
v3.5 (withdrawn)
32-way Unisys ES7000 PIII Xeon 900 MHz 165,218
tpmC 21.33/tpmC Avail 3-10-02 TPC-C v5.0
32-way NEC Express5800 Itanium2 1GHz 342,746
tpmC 12.86/tpmC Avail 3-31-03 TPC-C v5.0
32-way Unisys ES7000 Xeon MP 2 GHz 234,325
tpmC 11.59/tpmC Avail 3-31-03 TPC-C v5.0

• Parallelism is pervasive
• Small to moderate scale parallelism very
  important
• Difficult to obtain snapshot to compare across
  vendor platforms

14
Summary of Application Trends

• Transition to parallel computing has occurred for
  scientific and engineering computing
• Also occurred commercial computing
• Database and transactions as well as financial
• Scalable internet services (at least
  coarse-grained parallelism)
• Desktop also uses multithreaded programs, which
  are a lot like parallel programs
• Demand for improving throughput on sequential
  workloads
• Greatest use of small-scale multiprocessors
• Solid application demand, keeps increasing with
  time
• Key challenge throughout is making parallel
  programming easier
• Taking advantage of pervasive parallelism with
  multi-core systems

15
Drivers of Parallel Computing

• Application Needs
• Technology Trends
• Architecture Trends
• Economics

16
Technology Trends Rise of the Micro
The natural building block for multiprocessors is
now also about the fastest!
17
General Technology Trends

• Microprocessor performance increases 50 - 100
  per year
• Clock frequency doubles every 3 years
• Transistor count quadruples every 3 years
• Moores law xtors per chip 1.59year-1959
  (originally 2year-1959)
• Huge investment per generation is carried by huge
  commodity market
• With every feature size scaling of n
• we get O(n2) transistors
• we get O(n) increase in possible clock frequency
• We should get O(n3) increase in processor
  performance.
• Do we?
• See architecture trends

18
Die and Feature Size Scaling

• Die Size growing at 7 per year feature size
  shrinking 25-30

19
Clock Frequency Growth Rate (Intel family)

• 30 per year

20
Transistor Count Growth Rate (Intel family)

• Transistor count grows much faster than clock
  rate
• - 40 per year, order of magnitude more
  contribution in 2 decades
• Width/space has greater potential than per-unit
  speed

21
How to Use More Transistors

• Improve single threaded performance via
  architecture
• Not keeping up with potential given by technology
  (next)
• Use transistors for memory structures to improve
  data locality
• Doesnt give as high returns (2x for 4x cache
  size, to a point)
• Use parallelism
• Instruction-level
• Thread level
• Bottom line Not that single-threaded performance
  has plateaued, but that parallelism is natural
  way to stay on a better curve

22
Microprocessor Performance
23
Similar Story for Storage (Transistor Count)
24
Similar Story for Storage (DRAM Capacity)
25
Similar Story for Storage

• Divergence between memory capacity and speed more
  pronounced
• Capacity increased by 1000x from 1980-95, and
  increases 50 per yr
• Latency reduces only 3 per year (only 2x from
  1980-95)
• Bandwidth per memory chip increases 2x as fast as
  latency reduces

• Larger memories are slower, while processors get
  faster
• Need to transfer more data in parallel
• Need deeper cache hierarchies
• How to organize caches?

26
Similar Story for Storage

• Parallelism increases effective size of each
  level of hierarchy, without increasing access
  time
• Parallelism and locality within memory systems
  too
• New designs fetch many bits within memory chip
  follow with fast pipelined transfer across
  narrower interface
• Buffer caches most recently accessed data
• Disks too Parallel disks plus caching
• Overall, dramatic growth of processor speed,
  storage capacity and bandwidths relative to
  latency (especially) and clock speed point toward
  parallelism as the desirable architectural
  direction

27
Drivers of Parallel Computing

• Application Needs
• Technology Trends
• Architecture Trends
• Economics

28
Architectural Trends

• Architecture translates technologys gifts to
  performance and capability
• Resolves the tradeoff between parallelism and
  locality
• Recent microprocessors 1/3 compute, 1/3 cache,
  1/3 off-chip connect
• Tradeoffs may change with scale and technology
  advances
• Four generations of architectural history tube,
  transistor, IC, VLSI
• Here focus only on VLSI generation
• Greatest delineation in VLSI has been in scale
  and type of parallelism exploited

29
Architectural Trends in Parallelism

• Up to 1985 bit level parallelism 4-bit -gt 8 bit
  -gt 16-bit
• slows after 32 bit
• adoption of 64-bit well under way, 128-bit is far
  (not performance issue)
• great inflection point when 32-bit micro and
  cache fit on a chip
• Basic pipelining, hardware support for complex
  operations like FP multiply etc. led to O(N3)
  growth in performance.
• Intel 4004 to 386

30
Architectural Trends in Parallelism

• Mid 80s to mid 90s instruction level parallelism
• Pipelining and simple instruction sets,
  compiler advances (RISC)
• Larger on-chip caches
• But only halve miss rate on quadrupling cache
  size
• More functional units gt superscalar execution
• But limited performance scaling
• N2 growth in performance
• Intel 486 to Pentium III/IV

31
Architectural Trends in Parallelism

• After mid-90s
• Greater sophistication out of order execution,
  speculation, prediction
• to deal with control transfer and latency
  problems
• Very wide issue processors
• Dont help many applications very much
• Need multiple threads (SMT) to exploit
• Increased complexity and size leads to slowdown
• Long global wires
• Increased access times to data
• Time to market
• Next step thread level parallelism

32
Can Instruction-Level get us there?

• Reported speedups for superscalar processors
• Horst, Harris, and Jardine 1990
  ...................... 1.37
• Wang and Wu 1988 .............................
  ............. 1.70
• Smith, Johnson, and Horowitz 1989
  .............. 2.30
• Murakami et al. 1989 .........................
  ............... 2.55
• Chang et al. 1991 ............................
  ................. 2.90
• Jouppi and Wall 1989 .........................
  ............. 3.20
• Lee, Kwok, and Briggs 1991 ...................
  ........ 3.50
• Wall 1991 ....................................
  ...................... 5
• Melvin and Patt 1991 .........................
  .............. 8
• Butler et al. 1991 ...........................
  .................. 17
• Large variance due to difference in
• application domain investigated (numerical versus
  non-numerical)
• capabilities of processor modeled

33
ILP Ideal Potential

• Infinite resources and fetch bandwidth, perfect
  branch prediction and renaming
• real caches and non-zero miss latencies

34
Results of ILP Studies

• Concentrate on parallelism for 4-issue machines

• Realistic studies show only 2-fold speedup
• More recent work examines ILP that looks across
  threads for parallelism

35
Architectural Trends Bus-based MPs

• Micro on a chip makes it natural to connect many
  to shared memory
• dominates server and enterprise market, moving
  down to desktop
• Faster processors began to saturate bus, then
  bus technology advanced
• today, range of sizes for bus-based systems,
  desktop to large servers

No. of processors in fully configured commercial
shared-memory systems
36
Bus Bandwidth
37
Bus Bandwith Intel Systems
38
Do Buses Scale?

• Buses are a convenient way to extend architecture
  to parallelism, but they do not scale
• bandwidth doesnt grow as CPUs are added
• Scalable systems use physically distributed memory

39
Drivers of Parallel Computing

• Application Needs
• Technology Trends
• Architecture Trends
• Economics

40
Finally, Economics

• Fabrication cost roughly O(1/feature-size)
• 90nm fabs cost about 1-2 billion dollars
• So fabrication of processors is expensive
• Number of designers also O(1/feature-size)
• 10 micron 4004 processor had 3 designers
• Recent 90 nm processors had 300
• New designs very expensive
• Push toward consolidation of processor types
• Processor complexity increasingly expensive
• Cores reused, but tweaks expensive too

41
Design Complexity and Productivity

• Design complexity outstrips human productivity

42
Economics

• Commodity microprocessors not only fast but CHEAP
• Development cost is tens of millions of dollars
• BUT, many more are sold compared to
  supercomputers
• Crucial to take advantage of the investment, and
  use the commodity building block
• Exotic parallel architectures no more than
  special-purpose
• Multiprocessors being pushed by software vendors
  (e.g. database) as well as hardware vendors
• Standardization by Intel makes small, bus-based
  SMPs commodity
• What about on-chip processor design?

43
Whats on a processing chip?

• Recap
• Number of transistors growing fast
• Methods to use for single-thread performance
  running out of steam
• Memory issues argue for parallelism too
• Instruction-level parallelism limited, need
  thread-level
• Consolidation is a powerful force
• All seems to point to many simpler cores rather
  than single bigger complex core
• Additional key arguments wires, power, cost

44
Wire Delay

• Gate delay shrinks, global interconnect delay
  grows short local wires

45
Power

• Power dissipation in Intel processors over time

46
Power and Performance
47
Power

• Power grows with number of transistors and clock
  frequency
• Power grows with voltage P CV2f
• Going from 12V to 1.1V reduced power consumption
  by 120x in 20 yr
• Voltage projected to go down to 0.7V in 2018, so
  only another 2.5x
• Power per chip peaking in designs
• - Itanium II was 130W, Montecito 100W
• - Power is first-class design constraint
• Circuit-level power techniques quite far along
• - clock gating, multiple thresholds, sleeper
  transistors

48
Power versus Clock Frequency

• Two processor generations two feature sizes

49
Architectural Implication of Power

• Fewer transistors per core a lot more power
  efficient
• Narrower issue, shorter pipelines, smaller OOO
  window
• Get per-processor performance back on O(n3) curve
• But lower single thread performance.
• What complexity to eliminate?
• Speculation, multithreading, ?
• All good for some things, but need to be careful
  about power/benefit

50
ITRS Projections
51
ITRS Projections (contd.)

• Procs on chip will outstrip individual processor
  performance

52
Cost of Chip Development

• Non-recurring engineering costs increasing
  greatly as complexity outstrips productivity

53
Recurring Costs Per Die (1994)
54
Summary Whats on a Chip

• Beyond arguments for parallelism based on
  commodity processors in general
• Wire delay, power and economics all argue for
  multiple simpler cores on a chip rather than
  increasingly complex single cores
• Challenge SOFTWARE. How to program parallel
  machines

55
Summary Why Parallel Architecture?

• Increasingly attractive
• Economics, technology, architecture, application
  demand
• Increasingly central and mainstream
• Parallelism exploited at many levels
• Instruction-level parallelism
• Thread level parallelism and On-chip
  multiprocessing
• Multiprocessor servers
• Large-scale multiprocessors (MPPs)
• Focus of this class multiprocessor level of
  parallelism
• Same story from memory (and storage) system
  perspective
• Increase bandwidth, reduce average latency with
  many local memories
• Wide range of parallel architectures make sense
• Different cost, performance and scalability

56
Outline

• Drivers of Parallel Computing
• Trends in Supercomputers for Scientific
  Computing
• Evolution and Convergence of Parallel
  Architectures
• Fundamental Issues in Programming Models and
  Architecture

57
Scientific Supercomputing

• Proving ground and driver for innovative
  architecture and techniques
• Market smaller relative to commercial as MPs
  become mainstream
• Dominated by vector machines starting in 70s
• Microprocessors have made huge gains in
  floating-point performance
• high clock rates
• pipelined floating point units (e.g. mult-add)
• instruction-level parallelism
• effective use of caches
• Plus economics
• Large-scale multiprocessors replace vector
  supercomputers

58
Raw Uniprocessor Performance LINPACK
59
Raw Parallel Performance LINPACK

• Even vector Crays became parallel X-MP (2-4)
  Y-MP (8), C-90 (16), T94 (32)
• Since 1993, Cray produces MPPs too (T3D, T3E)

60
Another View
61
Top 10 Fastest Computers (Linpack)

• Rank Site Computer Processors Year Rmax
• DOE/NNSA/LLNL USA IBM BlueGene 131072 2005 28060
  0
• NNSA/Sandia Labs, USA Cray Red Storm, Opteron
  26544 2006 101400
• IBM Research, USA, IBM Blue Gene Solution
  40960 2005 91290
• DOE/NNSA/LLNL, USA ASCI Purple - IBM eServer p5
  12208 2006 75760
• Barcelona Center, Spain IBM JS21 Cluster, PPC
  970 10240 2006 62630
• NNSA/Sandia Labs, USA Dell Thunderbird Cluster
  9024 2006 53000
• CEA, France Bull Tera-10 Itanium2 Cluster
  9968 2006 52840
• NASA/Ames, USA SGI Altix 1.5 GHz, Infiniband
  10160 2004 51870
• GSIC Center, Japan NEC/Sun Grid Cluster
  (Opteron) 11088 2006 47380

• NEC Earth Simulator (top for 5 lists) moves
  down to 14
• 10 system has doubled in performance since
  last year

62
Top 500 Architectural Styles
63
Top 500 Processor Type
64
Top 500 Installation Type
65
Top 500 as of Nov 2006 Highlights

• NEC Earth Simulator (top for 5 lists) moves down
  to 14
• 10 system has doubled in performance since last
  year
• 359 six months ago was 500 in this list
• Total performance of top 500 up from 2.3 Pflops a
  year ago to 3.5 Pflops
• Clusters are dominant at this scale 359 of top
  500 labeled as clusters
• Dual core processors growing in popularity 75
  use Opteron dual core, and 31 Intel Woodcrest
• IBM is top vendor with almost 50 of systems, HP
  is second
• IBM and HP have 237 out of the 244 commercial and
  industrial installations
• US has 360 of the top 500 installations, UK 32,
  Japan 30,Germany 19, China 18

66
Top 500 Linpack Performance over Time
67
Another View of Performance Growth
68
Another View of Performance Growth
69
Another View of Performance Growth
70
Another View of Performance Growth
71
Processor Types in Top 500 (2002)
72
Parallel and Distributed Systems
73
Outline

• Drivers of Parallel Computing
• Trends in Supercomputers for Scientific
  Computing
• Evolution and Convergence of Parallel
  Architectures
• Fundamental Issues in Programming Models and
  Architecture

74
History

• Historically, parallel architectures tied to
  programming models
• Divergent architectures, with no predictable
  pattern of growth.

Application Software
System Software
Systolic Arrays
SIMD
Architecture
Message Passing
Dataflow
Shared Memory

• Uncertainty of direction paralyzed parallel
  software development!

75
Today

• Extension of computer architecture to support
  communication and cooperation
• OLD Instruction Set Architecture
• NEW Communication Architecture
• Defines
• Critical abstractions, boundaries, and primitives
  (interfaces)
• Organizational structures that implement
  interfaces (hw or sw)
• Compilers, libraries and OS are important bridges
  between application and architecture today

76
Modern Layered Framework
77
Parallel Programming Model

• What the programmer uses in writing applications
• Specifies communication and synchronization
• Examples
• Multiprogramming no communication or synch. at
  program level
• Shared address space like bulletin board
• Message passing like letters or phone calls,
  explicit point to point
• Data parallel more regimented, global actions on
  data
• Implemented with shared address space or message
  passing

78
Communication Abstraction

• User level communication primitives provided by
  system
• Realizes the programming model
• Mapping exists between language primitives of
  programming model and these primitives
• Supported directly by hw, or via OS, or via user
  sw
• Lot of debate about what to support in sw and gap
  between layers
• Today
• Hw/sw interface tends to be flat, i.e. complexity
  roughly uniform
• Compilers and software play important roles as
  bridges today
• Technology trends exert strong influence
• Result is convergence in organizational structure
• Relatively simple, general purpose communication
  primitives

79
Communication Architecture

• User/System Interface Implementation
• User/System Interface
• Comm. primitives exposed to user-level by hw and
  system-level sw
• (May be additional user-level software between
  this and prog model)
• Implementation
• Organizational structures that implement the
  primitives hw or OS
• How optimized are they? How integrated into
  processing node?
• Structure of network
• Goals
• Performance
• Broad applicability
• Programmability
• Scalability
• Low Cost

80
Evolution of Architectural Models

• Historically, machines were tailored to
  programming models
• Programming model, communication abstraction, and
  machine organization lumped together as the
  architecture
• Understanding their evolution helps understand
  convergence
• Identify core concepts
• Evolution of Architectural Models
• Shared Address Space (SAS)
• Message Passing
• Data Parallel
• Others (wont discuss) Dataflow, Systolic Arrays
• Examine programming model, motivation, and
  convergence

81
Shared Address Space Architectures

• Any processor can directly reference any memory
  location
• Communication occurs implicitly as result of
  loads and stores
• Convenient
• Location transparency
• Similar programming model to time-sharing on
  uniprocessors
• Except processes run on different processors
• Good throughput on multiprogrammed workloads
• Naturally provided on wide range of platforms
• History dates at least to precursors of
  mainframes in early 60s
• Wide range of scale few to hundreds of
  processors
• Popularly known as shared memory machines or
  model
• Ambiguous memory may be physically distributed
  among processors

82
Shared Address Space Model

• Process virtual address space plus one or more
  threads of control
• Portions of address spaces of processes are shared

• Writes to shared address visible to other
  threads (in other processes too)
• Natural extension of uniprocessor model
  conventional memory operations for comm. special
  atomic operations for synchronization
• OS uses shared memory to coordinate processes

83
Communication Hardware for SAS

• Also natural extension of uniprocessor
• Already have processor, one or more memory
  modules and I/O controllers connected by hardware
  interconnect of some sort
• Memory capacity increased by adding modules, I/O
  by controllers

Add processors for processing!
84
History of SAS Architecture

• Mainframe approach
• Motivated by multiprogramming
• Extends crossbar used for mem bw and I/O
• Originally processor cost limited to small
• later, cost of crossbar
• Bandwidth scales with p
• High incremental cost use multistage instead

• Minicomputer approach
• Almost all microprocessor systems have bus
• Motivated by multiprogramming, TP
• Used heavily for parallel computing
• Called symmetric multiprocessor (SMP)
• Latency larger than for uniprocessor
• Bus is bandwidth bottleneck
• caching is key coherence problem
• Low incremental cost

85
Example Intel Pentium Pro Quad

• All coherence and multiprocessing glue integrated
  in processor module
• Highly integrated, targeted at high volume
• Low latency and bandwidth

86
Example SUN Enterprise

• Memory on processor cards themselves
• 16 cards of either type processors memory, or
  I/O
• But all memory accessed over bus, so symmetric
• Higher bandwidth, higher latency bus

87
Scaling Up

• Problem is interconnect cost (crossbar) or
  bandwidth (bus)
• Dance-hall bandwidth still scalable, but lower
  cost than crossbar
• latencies to memory uniform, but uniformly large
• Distributed memory or non-uniform memory access
  (NUMA)
• Construct shared address space out of simple
  message transactions across a general-purpose
  network (e.g. read-request, read-response)
• Caching shared (particularly nonlocal) data?

88
Example Cray T3E

• Scale up to 1024 processors, 480MB/s links
• Memory controller generates comm. request for
  nonlocal references
• Communication architecture tightly integrated
  into node
• No hardware mechanism for coherence (SGI Origin
  etc. provide this)

89
Caches and Cache Coherence

• Caches play key role in all cases
• Reduce average data access time
• Reduce bandwidth demands placed on shared
  interconnect
• But private processor caches create a problem
• Copies of a variable can be present in multiple
  caches
• A write by one processor may not become visible
  to others
• Theyll keep accessing stale value in their
  caches
• Cache coherence problem
• Need to take actions to ensure visibility

90
Example Cache Coherence Problem

• Processors see different values for u after event
  3
• With write back caches, value written back to
  memory depends on happenstance of which cache
  flushes or writes back value when
• Processes accessing main memory may see very
  stale value
• Unacceptable to programs, and frequent!

91
Cache Coherence

• Reading a location should return latest value
  written (by any process)
• Easy in uniprocessors
• Except for I/O coherence between I/O devices and
  processors
• But infrequent, so software solutions work
• Would like same to hold when processes run on
  different processors
• E.g. as if the processes were interleaved on a
  uniprocessor
• But coherence problem much more critical in
  multiprocessors
• Pervasive and performance-critical
• A very basic design issue in supporting the prog.
  model effectively
• Its worse than that what is the latest value
  with indept. processes?
• Memory consistency models

92
SGI Origin2000

• Hub chip provides memory control, communication
  and cache coherence support
• Plus I/O communication etc

93
Shared Address Space Machines Today

• Bus-based, cache coherent at small scale
• Distributed memory, cache-coherent at larger
  scale
• Without cache coherence, are essentially (fast)
  message passing systems
• Clusters of these at even larger scale

94
Message-Passing Programming Model

• Send specifies data buffer to be transmitted and
  receiving process
• Recv specifies sending process and application
  storage to receive into
• Optional tag on send and matching rule on receive
• Memory to memory copy, but need to name processes
• User process names only local data and entities
  in process/tag space
• In simplest form, the send/recv match achieves
  pairwise synch event
• Other variants too
• Many overheads copying, buffer management,
  protection

95
Message Passing Architectures

• Complete computer as building block, including
  I/O
• Communication via explicit I/O operations
• Programming model directly access only private
  address space (local memory), comm. via explicit
  messages (send/receive)
• High-level block diagram similar to
  distributed-memory SAS
• But comm. neednt be integrated into memory
  system, only I/O
• History of tighter integration, evolving to
  spectrum incl. clusters
• Easier to build than scalable SAS
• Can use clusters of PCs or SMPs on a LAN
• Programming model more removed from basic
  hardware operations
• Library or OS intervention

96
Evolution of Message-Passing Machines

• Early machines FIFO on each link
• Hw close to prog. Model synchronous ops
• Replaced by DMA, enabling non-blocking ops
• Buffered by system at destination until recv
• Diminishing role of topology
• Storeforward routing topology important
• Introduction of pipelined routing made it less so
• Cost is in node-network interface
• Simplifies programming

97
Example IBM SP-2

• Made out of essentially complete RS6000
  workstations
• Network interface integrated in I/O bus (bw
  limited by I/O bus)
• Doesnt need to see memory references

98
Example Intel Paragon

• Network interface integrated in memory bus, for
  performance

99
Toward Architectural Convergence

• Evolution and role of software have blurred
  boundary
• Send/recv supported on SAS machines via buffers
• Can construct global address space on MP using
  hashing
• Software shared memory (e.g. using pages as units
  of comm.)
• Hardware organization converging too
• Tighter NI integration even for MP (low-latency,
  high-bandwidth)
• At lower level, even hardware SAS passes hardware
  messages
• Hw support for fine-grained comm makes software
  MP faster as well
• Even clusters of workstations/SMPs are parallel
  systems
• Fast system area networks (SAN)
• Programming models distinct, but organizations
  converged
• Nodes connected by general network and
  communication assists
• Assists range in degree of integration, all the
  way to clusters

100
Data Parallel Systems

• Programming model
• Operations performed in parallel on each element
  of data structure
• Logically single thread of control, performs
  sequential or parallel steps
• Conceptually, a processor associated with each
  data element
• Architectural model
• Array of many simple, cheap processors with
  little memory each
• Processors dont sequence through instructions
• Attached to a control processor that issues
  instructions
• Specialized and general communication, cheap
  global synchronization

• Original motivations
• Matches simple differential equation solvers
• Centralize high cost of instruction
  fetch/sequencing

101
Application of Data Parallelism

• Each PE contains an employee record with his/her
  salary
• If salary gt 100K then
• salary salary 1.05
• else
• salary salary 1.10
• Logically, the whole operation is a single step
• Some processors enabled for arithmetic operation,
  others disabled
• Other examples
• Finite differences, linear algebra, ...
• Document searching, graphics, image processing,
  ...
• Some recent machines
• Thinking Machines CM-1, CM-2 (and CM-5)
• Maspar MP-1 and MP-2,

102
Evolution and Convergence

• Rigid control structure (SIMD in Flynn taxonomy)
• SISD uniprocessor, MIMD multiprocessor
• Popular when cost savings of centralized
  sequencer high
• 60s when CPU was a cabinet
• Replaced by vectors in mid-70s
• More flexible w.r.t. memory layout and easier to
  manage
• Revived in mid-80s when 32-bit datapath slices
  just fit on chip
• No longer true with modern microprocessors
• Other reasons for demise
• Simple, regular applications have good locality,
  can do well anyway
• Loss of applicability due to hardwiring data
  parallelism
• MIMD machines as effective for data parallelism
  and more general
• Prog. model converges with SPMD (single program
  multiple data)
• Contributes need for fast global synchronization
• Structured global address space, implemented with
  either SAS or MP

103
Convergence Generic Parallel Architecture

• A generic modern multiprocessor

• Node processor(s), memory system, plus
  communication assist
• Network interface and communication controller
• Scalable network
• Communication assist provides primitives with
  perf profile
• Build your programming model on this
• Convergence allows lots of innovation, now within
  framework
• Integration of assist with node, what operations,
  how efficiently...

104
Outline

• Drivers of Parallel Computing
• Trends in Supercomputers for Scientific
  Computing
• Evolution and Convergence of Parallel
  Architectures
• Fundamental Issues in Programming Models and
  Architecture

105
The Model/System Contract

• Model specifies an interface (contract) to the
  programmer
• Naming How are logically shared data and/or
  processes referenced?
• Operations What operations are provided on these
  data
• Ordering How are accesses to data ordered and
  coordinated?
• Replication How are data replicated to reduce
  communication?
• Underlying implementation addresses performance
  issues
• Communication Cost Latency, bandwidth,
  overhead, occupancy
• Well look at the aspects of the contract through
  examples

106
Supporting the Contract

• Given prog. model can be supported in various
  ways at various layers
• In fact, each layer takes a position on all
  issues (naming, ops, performance etc), and any
  set of positions can be mapped to another by
  software
• Key issues for supporting programming models are
• What primitives are provided at comm. abstraction
  layer
• How efficiently are they supported (hw/sw)
• How are programming models mapped to them

107
Recap of Parallel Architecture

• Parallel architecture is important thread in
  evolution of architecture
• At all levels
• Multiple processor level now in mainstream of
  computing
• Exotic designs have contributed much, but given
  way to convergence
• Push of technology, cost and application
  performance
• Basic processor-memory architecture is the same
• Key architectural issue is in communication
  architecture
• How communication is integrated into memory and
  I/O system on node
• Fundamental design issues
• Functional naming, operations, ordering
• Performance organization, replication,
  performance characteristics
• Design decisions driven by workload-driven
  evaluation
• Integral part of the engineering focus
