Title: Autonomic System Design

Autonomic System Design
  • Visa Holopainen,

Enabling autonomic behavior in systems software
with hot swapping, J. Appavoo et al. 2003
  • Focus on object-oriented systems software
  • By hot swapping, new algorithms and monitoring
    code can be added to a running system without
  • Hot swapping is accomplished either by
    interpositioning of code, or by replacement of
  • Interpositioning involves inserting a new
    component between two existing ones. This enables
    more detailed monitoring when problems occur,
    while minimizing run-time costs when the system
    is performing acceptably
  • Replacement allows an active component to be
    switched with a different implementation of that
    component while the system is running
  • Triggering hot swapping
  • In many cases an object is expected to trigger a
    replacement itself (autonomously).
  • For example, if an object is designed to support
    small files and it registers an increase in file
    size, then the object can trigger a hot swap with
    an object that supports large files
  • In other cases, the system infrastructure is
    expected to determine the need for an object
    replacement through a hot swap. Monitoring is
    required for this purpose.

Adaptive code vs. hot swapping
  • Among other features, hot swapping allows systems
    software to react to changes in environment
  • More traditional approach towards handling
    varying environments is to use adaptive code
  • In a system using adaptive code, all possible
    configurations must be built to the system
  • Adaptive code has many problematic features
    (presented below)

Illustration of adaptive code vs. hot swapping
  • An adaptive code implementation (A) vs a
    hot-swapping implementation (B) of the same
  • The adaptive code approach is monolithic and
    includes monitoring code that collects the data
    needed by the adaptive algorithm to choose a
    particular code path
  • With hot swapping, each algorithm is implemented
    independently (resulting in reduced complexity
    per component), and is hot swapped in when needed

Benefits of hot swapping
  • Hot swapping can be beneficial at least in the
    following respects
  • Optimizing for the (non) common case
  • Dynamic replacement allows efficient
    implementations of common paths to be used when
    suitable, and less-efficient, less-common
    implementations to be switched in when necessary
  • Optimizing for a wide range of file attribute
  • For example, although the vast majority of files
    accessed are small (lt 4 KB), OSs must also
    support large files
  • Access patterns
  • Researchers have shown up to 30 percent fewer
    cache misses by using the appropriate cache
    management policy
  • Multiprocessor optimizations
  • Some applications perform better when distributed
    to many processors while others perform better
    when run on a single processor
  • Enabling client-specific customization
  • Exporting system structure information
  • Always gathering the necessary profiling
    information increases overhead

Testing system
  • A research operating system (K42) has been
    developed to test the hot swapping approach
  • Runs on PowerPC and MIPS architectures (soon
    available for x86 also)
  • K42 scales well to multiprocessor systems
  • Performance advantages of hot swapping have been
    demonstrated in K42
  • K42 is available at http//

Adding Autonomic Functionality to object-oriented
applications, M. Schanne, W. Tichy, T.
Gelhausen, 2003
  • The goal is to separate autonomic functionality
    from applications (similar to hot swapping)
  • This is accomplished by creating a system based
    on class renaming and proxy/wrapper generation
  • A list of the proxy objects is kept in registry
  • Proxy objects has always a pointer to the latest
    version of the actual object and access to its
    member functions
  • This is accomplished by ByteCode Engineering
    Library (BCEL)
  • Wrapper functions ensure synchronization of
  • The design ensures that there is no need for the
    user to adapt his source code in any way or even
    to restart the program
  • The supported environment the likes of Java 2

Usable Autonomic Computing Systems the
Administrators Pers- pective, R. Barrett, P.
Maglio, E. Kandogan, J. Bailey, 2004
  • Autonomic computing seeks to solve the problem of
    increasingly complex configurations through
    increased automation
  • However, the AC strategy of managing complexity
    through automation runs the risk of making
    management harder (more powerful commands)
  • This is why autonomic systems should
  • Provide facilities that make rehearsing and
    planning easy
  • Be designed to allow administrators to quickly
    undo changes, making operations (whether on
    production systems or test systems) less risky
    and therefore easier
  • Inform the administrator if undoing a command
    will not be possible (easily)
  • Have enhanced capabilities for testing complex
    end-to-end systems so that administrators will be
    confident that their changes are not having
    unintended consequences
  • Provide access to arbitrary levels of
    configuration detail if need be
  • Autonomic system should also
  • Contain a command line interface (in addition to

An Architectural Approach to Autonomic Computing,
S. White, J. Hanson, I. Whalley, D. Chess, J.
Kephart, 2004
  • An autonomic system can be decomposed to 1)
    interfaces, 2) interactions and 3) design
  • A bit RFC-style paper with MUST and SHOULD
    statements about Autonomic Elements (AE)
  • MUST Examples
  • An AE MUST be self-managing
  • An AE MUST handle problems locally whenever
  • An AE MUST be capable of establishing and
    maintaining relationships with other autonomic
  • SHOULD Examples
  • An AE SHOULD ask for a realistic set of
    requirements when requesting a service from
    another element
  • An AE SHOULD offer a range of performace,
    reliability, availability and security associated
    with its service
  • An AE SHOULD protect itself against inappropriate
    service requests and responses

Use of policies
  • The use of policies is essential for autonomic
  • Three (3) policy levels presented
  • Action policies (IF condition THEN action)
  • An AE employing action policies MUST measure
    and/or synthesize the quantities stated in the
  • Goal policies (Response time must not exceed 2
  • AEs employing goal policies MUST possess
    sufficient modeling or planning capabilities to
    translate goals into actions
  • Utility function policies (automatically
    determine the most valuable goal in any
  • AEs employing utility funtion policies MUST have
    sophisticated modeling and optimization
    capabilities to translate utility functions into

  • Making a system autonomic requires additional
    interfaces to be added to the system
  • Monitoring and test interfaces
  • Enable an element to be monitored by any other
    element that has established the appropriate
    administrative relationships with it
  • Lifecycle interfaces
  • Enable administrative elements to determine the
    lifecycle state of an element (e.g. starting,
    paused), to cause a state change, and to
    determine the lifecycle model that applies to the
    element, and to determine the lifecycle model
    that applies to the element
  • Policy interfaces
  • Enable administrative elements to send new
    policies to an element, and to determine the
    policies currently in use by the element
  • Negotiation and binding interfaces
  • Permit an element to request a service from other
    elements, or to request to provide a service

  • When an AE has agreed to provide service to
    another AE, then those two elements have a
  • Relationships are typically formed at run-time
  • Autonomic systems are built by relationships
  • Request-response paradigm used to form

From autonomic elements to autonomic systems
  • Assembling an autonomic system requires
  • A collection of AEs that implement the desired
  • Additional autonomic elements to implement system
    functions that enable the needed system-level
    behaviors (infrastructure elements)
  • Design patterns for system self-management
  • Infrastructure element can be
  • Registry (provides mechanisms for elements to
    find one another)
  • Sentinel (provides monitoring services to other
  • Aggregator (combines two or more existing
    elements and uses them to provide improved
  • Broker (facilitates interaction)
  • Negotiator (assists elements with complex

Towards Requirements-Driven Autonomic
Systems Design, A. Lapouchnian, S. Liaskos, J.
Mylopoulos, Y. Yu, 2005
  • There are three basic ways to make a system
  • Design the system to support a space of possible
  • Equip system with planning and social
    capabilities so that it can delegate tasks to
    external software components (agents)
  • Build the system so that it has evolutionary
    capabilities (like biological systems)
  • The first approach was studied in the paper
  • Requirements engineering
  • Development of a framework for capturing and
    analyzing stakeholder intentions to generate
    functional and non-functional requirements

Illustration of requirements engineering goal
  • Top-level hard goal
  • Schedule meeting
  • AND-composed of lower level hard goals
  • 4 top-level softgoals
  • Good quality schedule, Minimal effort, Minimal
    disturbances, Accurate constraints
  • Lower level softgoals can be related to higher
    levels by help (), hurt (-), make () or break
    (--) relationships
  • 6 alternative ways to fulfill the goal Schedule
  • An autonomic system should address all different
    ways of fulfilling the top-level goals

Goal model -gt Feature model -gtComponent Connector
Goal model is integrated into the knowledge of an
autonomic element
Architectural Design of a Distributed Application
with Autonomic Quality Requirements, D. Weyns, K.
Schelfthout and T. Holvoet, 2005
  • A reference architecture for situated multi-agent
    systems (situated MAS) was developed
  • This reference architecture was applied to a
    real-world software system
  • The architecture
  • A situated MAS consists of an environment
    populated with agents (autonomous entities)
  • Intelligence in a situated MAS originates from
    the interaction between agents, rather than from
    their individual capabilities
  • The architecture holds three abstractions
    agents, ongoing activities and the environment

High-level model view of the architecture
  • The Perception module maps the local state of the
    environment onto a percept for the agent
  • The Consuption module handles the effects of
    encironment changes that affect the agent
  • The Decision module is responsible for action

The application
  • A system in which robots transport loads from one
    place to another within a warehouse and recharge
    themselves whenever needed
  • Old system centralized server controlled robots
  • Main problem inflexibility robots cant adapt
    to changing situations
  • Improvement Robots are agents acting in a MAS
  • Drawback more complicated system

Module view of the application
  • Two kinds of agents trasport agents and AGV
  • Transport agents are managers they determine
    the priority of the transport, assign transports
    to AGVs and ensure that the transport succeeds
  • AGV agents are responsible for executing the
    assigned transport

Architecture of the environment
  • To cope with the complexity of the environment,
    it is presented through a layered architecture
  • Virtual environment uses a middleware layer that
    enbles agents to communicate with each other
  • Virtual environment enbles agent routing and
    prevents collisions
  • The agent observer a 3-5 meter circle from the
    virtual environment at a time
  • In this circle the agent marks the path it is
    going to use and removes this path when leaving
    the circle
  • This way collisions can be avoided
  • Transport agents use the virtual environment to
    locate AGV agents

A Control Theory Foundation for Self-Managing
Computing Systems, Y. Diao, J. Hellerstein, S.
Parekh, R. Griffith, G. Kaiser, D. Phung, 2005
  • Control theory used as a way to identify a number
    of requirements for and challenges in building
    self-managing systems
  • What does control theory bring to table in terms
    of self-management?
  • Autonomic computing and control theory have
    slightly different points of focus autonomic
    computing focuses on the specification and
    construction of management components that
    interoperate well, while the focus of control
    theory is on analyzing and/or developing
    components and algorithms so that the resulting
    system achieves the control objectives
  • For example, control theory provides design
    techniques for determining the values of
    parameters in commonly used control algorithms so
    that the resulting control system is stable and
    settles quickly in response to disturbances

Feedback Control Theory
  • Reference Input (I/P) Desired Output (O/P) (as
    specified by the human)
  • Control Error (Reference I/P Measured O/P)
  • Control Input Parameters which affect behavior
    of the system
  • Disturbance I/P affects Control I/P
  • Controller Change Control I/P to achieve
    Reference I/P
  • Measured O/P Measurable feature of the system
  • Noise I/P affects Measured O/P
  • Transducer Transforms measured O/P to compare
    with Reference I/P

Properties of Control Systems
  • SASO
  • Stable
  • Bounded Input produces bounded output
  • Unstable systems not usable in mission critical
  • Accurate
  • Measure Output converges to Reference (Desired)
  • Short Settling Times
  • Converges to the Stable Value quickly
  • No Overshoot
  • Achieves objectives in a steady manner

Control Analysis and Design
  • Transfer function and Z-transformation used to
    control and model response times and settling

Example control theory approach to web server
  • Objective CPU Utilization lt 50
  • Measured Output CPU utilization
  • Control Input MaxClients
  • During the first 300 s, the system operates
    without feedback control. When the controller is
    turned on, a reference input of 0.5 is used. At
    this point, the system begins to oscillate and
    the amplitude of the oscillations increases. This
    is a result of a controller design that
    overreacts to the stochastics in the CPU
    utilization measurement.

ltusernamegt, I Need You!Initiative and
Interaction in Autonomic Systems, P. Kaminski, P.
Agrawal, H. Kienle, H. Müller, 2005
  • Autonomic job requirements
  • If I hired a person instead, what qualities would
    I look for?
  • attention to detail, strong communication skills,
    initiative, tempered by job boundaries,
    self-knowledge and willingness to seek help
  • Treat users as partners, not masters
  • Basic idea
  • The system has an optimization engine that
    decides if the preferred mode of action in some
    situation is to 1) connect a human or 2) try to
    repair the system
  • Decision based on 1) explicit instructions and 2)
  • Balance match, bother, rush, risk
  • The system learns from human actions and becomes
    more competent in solving problems on its own
  • Balance initiative and interaction
  • Send messages via e-mail, instant messenger, etc.

Human (operator) is added to the traditional
autonomic computing cycle
Write a Comment
User Comments (0)
