Literature%20Review

1
Literature Review

• Single-Slice Rebinning Method for
• Helical Cone-Beam CT
• Frédéric Noo, Michel Defrise, Rolf Clackdoyle
• Physics in Medicine and Biology
• Vol 44, 1999

Henry Chen May 13, 2011
2
Background

• Computed Tomography

3
Tomography

• Basis for CAT scan, MRI, PET, SPECT, etc.
• Greek tomos part or section
• Cross-sectional imagingtechnique using
  transmissionor reflection data frommultiple
  angles

4
Computed Tomography (CT)

• A form of tomographic reconstruction on computers
• Usually refers to X-ray CT
• Positron (PET)
• Gamma rays (SPECT)

5
Cross-Sections by X-Ray Projections

• Project X-ray through biological tissuemeasure
  total absorption of ray by tissue
• Projection P?(t) is the Radontransform of object
  functionf(x,y)
• Total set of projections calledsinogram

6
X-Ray Projection Example
7
Phantom and Sinogram
Shepp-Logan Phantom
8
CT Reconstruction

• Restore image from projection data
• Inverse Radon transform
• Most common algorithm is filtered backprojection
• Smear each projection over image plane

9
Fourier Slice Theorem

• Fourier transform of a 2-D object projected onto
  a line is equal to a slice of a 2-D Fourier
  transform of the object
• Allows image reconstruction from projection data
• Overlay FT of projections in 2-D Fourier domain
• If carried out in space domain, becomes
  backprojection procedure

10
(No Transcript)
11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
Backprojection Result

• Need filtering (high-pass), interpolation

20
FBP Algorithm

• Input sinogram sino(?, n)
• Output image img(x,y)
• for each ?
• filter sino(?,)
• for each x
• for each y
• n x cos ? y sin ?
• img(x,y) sino(?, n) img(x,y)
• O(n3) algorithm
• But highly parallelizable, given sufficient
  memory bandwidth not computationally intensive

21

• Single-Slice Rebinning Methodfor Helical
  Cone-Beam CT

22
3-D Tomography

• Construct 3-D image using sequence ofcross
  sectional images
• Requires many passes of ionizing x-ray radiation

23
Helical Cone-Beam Scanner

• Helical traversal reduces total number of passes
  increases scanning speed and reduces x-ray
  exposure
• However, need to convertcone-beam data into
  stackof fan-beam slice images

24
Rebinning

• Maps projection data into fan-beam slices
• Virtual fan source mapped to surface of cone
  source
• Each slice requires CB projections from 1
  revolution centered on that slice (/- 0.5P)

25
Rebinning

• Fan-beam projection estimated from value of
  cone-beam projection in same vertical plane
• Use closest cone-beam source directly above or
  below virtual fan-beam source
• Use oblique ray passing through M

26
Rebinning Geometry
27
Rebinning Equation

• Each fan-beam value is just weighted version of
  cone-beam projection data

fan-beam projection length
fan sino
CB sino
cone-beam projection length
28
Simulation Comparisons

• A Single detector row (no oblique rays), 5mm
  pitch CSH-HS algorithm
• B Seven detector rows, 25mm pitch CB-SSRB
  algorithm
• C Seven detector rows, 100mm pitch Full 3-D
  backprojection algorithm
• D Seven detector rows, 100mm pitch CB-SSRB
  algorithm

29
Simulation Comparisons
30
Simulation Comparisons
31
Performance Comparison

• Runtime for (C) 276s CPU, using 27 ray-sums
• Runtime for (D) 1310s CPU, using 57 ray-sum
• Runtimes for (A) and (B) about equal

32
Conclusions

• Like all CT, CB-SSRB is not exact reconstruction
  artifacts can affect image quality
• However, good performance for large-pitch helixes
• 5x larger pitch 5x fewer projection
  measurements
• Selection of oblique rays integral to performance
• Need multiple detector rows (7 vs. 1)

33
References

• http//en.wikipedia.org/wiki/Tomography
• http//en.wikipedia.org/wiki/Computed_tomography
• Kak, A. C., Slaney, M., Principles of
  Computerized Tomographic Imaging, IEEE Press, 1988
