The IEEE CS Task Force on Cluster Computing (TFCC)

1
The IEEE CS Task Force on Cluster Computing (TFCC)
William GroppMathematics and Computer
ScienceArgonne National Labwww.mcs.anl.gov/grop
p
Thanks to Mark BakerUniversity of Portsmouth,
UKhttp//www.dcs.port.ac.uk/mab
2
A Little History

• In 1998 there was obvious huge interest in
  clusters, so it seemed natural to set up a
  focused group in this area.
• A Cluster Computing Task Force was proposed to
  the IEEE CS.
• The TFCC was approved and started operating in
  February 1999 been going just over 2 years.

3
Proposed Activities

• Act as an international forum to promote cluster
  computing research and education, and participate
  in setting up technical standards in this area.
• Be involved with issues related to the design,
  analysis and development of cluster systems as
  well as the applications that use them.
• Sponsor professional meetings, produce
  publications, set guidelines for educational
  programs, and help co-ordinate academic, funding
  agency, and industry activities.
• Organize events and hold a number of workshops
  that would span the range of activities sponsored
  by the Task Force.
• Publish a bi-annual newsletter to help the
  community keep abreast of activities in field.

4
IEEE CS Task Forces

• A TF is expected to have a finite term of
  existence, normally a period of 2-3 years -
  continued existence beyond that point is
  generally not appropriate.
• A TF is expected to either increase their scope
  of activities such that establishment of a
  Technical Committee (TC) is warranted, or the
  task force will be merged into existing TCs.
• TFCC will submit an application to the CS become
  a TC later this year.

5
Why a separate TFCC!

• It brings together all the activities/technologies
  used with Cluster Computing into one area - so
  instead of tracking four or five IEEE TCs there
  is one...
• Cluster Computing is NOT just Parallel,
  Distributed, OSs, or the Internet, it is a mix of
  them all, and consequently different.
• The TFCC is an appropriate body for focusing
  activities and publications associated with
  Cluster Computing.

6
http//www.ieeetfcc.org
7
TFCC Mailing Lists

• Currently three emails lists have been set up
• tfcc-l_at_bucknell.edu a discussion list open to
  anyone interested in the TFCC - see TFCC page for
  info. on how to subscribe.
• tfcc-exe_at_port.ac.uk a closed executive
  committee mailing reflector.
• tfcc-adv_at_port.ac.uk a closed advisory
  committee mailing reflector.

8
Annual Conference ClusterXY

• 1st IEEE International Workshop on Cluster
  Computing (Cluster 1999), Melbourne, Australia,
  December 1999, about 105 attendees from 16
  countries.
• http//www.clustercomp.org
• 2nd IEEE International Conference on Cluster
  Computing (Cluster 2000), Chemnitz, Germany,
  November, 2000, anticipate 160 attendees.
• http//www.tu-chemnitz.de/cluster2000
• 3rd IEEE International Conference on Cluster
  Computing (Cluster 2001), Newport Beach,
  California, October 8-11, 2001, expect 250-300
  attendees.
• http//andy.usc.edu/cluster2001

9
Associated Events - GRIDXY

• 1st IEEE/ACM International Workshop on Grid
  Computing (Grid2000), Bangalore, India, December
  17, 2000 (attendees from 15 countries).
• http//www.gridcomputing.org
• 2nd IEEE/ACM International Workshop on Grid
  Computing (Grid2001), at SC2001, November 2001

10
Supercomputing

• Birds of A Feather at SC99 and SC2000.
• Aims of meetings are to gather together
  interested parties and bring them up to date, but
  also put together a bunch of short talks and
  start a discussion on a variety of topics
• Probably be another at SC01 depending on the
  community interest.

11
Other Activities

• Book donation program
• Cluster Computing Archive
• www.ieeetfcc.org/ClusterArchive.html
• TopClusters Project
• www.TopClusters.org
• TFCC Whitepaper
• www.dcs.port.ac.uk/mab/tfcc/WhitePaper
• TFCC Newsletter
• www.eg.bucknell.edu/hyde/tfcc

12
TopClusters Project

• http//www.TopClusters.org
• TFCC collaboration with Top500 project.
• Numeric, I/O, Web, Database, and Application
  level benchmarking of clusters.
• Joint BOF with Top500 at SC2000 on Cluster-based
  benchmarking.
• Ongoing effort

13
TFCC Whitepaper

• A Whitepaper on Cluster Computing, submitted to
  the International Journal of High-Performance
  Applications and Supercomputing, November 2000
• Snap-shot of the state-of-the-art of Cluster
  Computing.
• Preprint, www.dcs.port.ac.uk/mab/tfcc/WhitePaper/

14
TFCC Membership

• Over 300 registered members
• Free membership open to all, but few benefits may
  be restricted - (reduced registration fee for
  IEEE members)
• Over 450 on the TFCC mailing list
  lttfcc-l_at_bucknell.edugt

15
Future Plans

• We plan to submit an application to the IEEE CS
  Technical Activities Board (TAB) to attain full
  Technical Committee status.
• The TAB see the TFCC as a success and we hope
  that our application will be successful.
• Obviously if we achieve TC status, we will need
  the continuing assistance and help of the TFCCs
  current volunteers plus encourage a bunch of new
  ones

16
Summary

• Successful conference series has been started,
  with commercial sponsorship.
• Promoting Cluster-based technologies through TFCC
  sponsorship.
• Helping the community with our book donation
  program.
• Engendering debate and discussion through mailing
  forum.
• Keeping the community informed with our
  information rich TFCC Web site.

17
Scalable Clusters

• TopCluster.org list
• 26 Clusters with 128 nodes
• 8 with 500 nodes
• 34 with 64-127 nodes
• Most run Linux
• Most dedicated to applications
• Where are scalable tools developed and tested?
• Caveats
• Does not include MPP-like systems (IBM SP, SGI
  Origin, Compaq, Intel TFLOPs, etc.)
• Not a complete list
• Only clusters explicitly contributed to
  topcluster.org

18
What is Scalability?

• Most common definition in use
• Works for n1 nodes if it works for n, for small
  n
• Practical definition
• Operations complete fast enough
• 0.5 to 3 seconds for interactive
• Operations are reliable
• Approach to scalability must not be fragile

19
Issues in Clusters and Scalability

• Developing and Testing Tools
• Requires convenient access to large-scale system
• Can this co-exist with production computing?
• Too many different tools
• Why not adopt Unix philosophy?
• Example solution Scalable Unix Tools
• Following slides thanks to Rusty Lusk and Emil Ong

20
What Are the Scalable Unix Tools?

• Parallel versions of common Unix commands like
  ps, ls, cp, , with appropriate semantics
• A few new commands in the same spirit but without
  a serial counterpart
• Designed for users
• New this spring release of a high-performance
  implementation based on MPI
• One of the original official Ptools projects
• Original definition published
• Proceedings of the Scalable High Performance
  Computing Conference
• http//www.mcs.anl.gov/gropp/papers/1994/shpcc-pa
  per.ps

21
Motivation

• Basic Unix commands (ls, grep, find, ) are
  quintessential tools.
• Simple syntax and semantics (except maybe find
  syntax)
• Have same component interface (lines of text,
  stdin, stdout)
• Unix redirection ( lt, gt, and especially ) allow
  tools to be easily combined into powerful command
  lines
• Old-fashioned no GUI, little interactivity

22
Motivation, continued

• Many parallel machines have Unix and at least
  partially distinct file systems on each node.
• A user needs simple and familiar ways to
• Copy a file to local file space on each node
• Find all processes running on all nodes
• Test for conditions on all nodes
• Avoid getting swamped with output
• On large machines these commands are not useful
  unless they take advantage of parallelism in
  their execution.

23
Design Goals

• Familiar to Unix users
• Similar names (we chose ptltUnix-namegt)
• Same arguments, similar semantics
• Interact well with traditional Unix commands,
  facilitating construction of powerful command
  lines
• Run at interactive speeds (requires scalability
  in parallel process manager startup and handling
  of I/O)

24
Part I Parallel Versions of Traditional Commands

• ptcp
• ptmv
• ptrm
• ptln
• ptmkdir

• ptrmdir
• ptchmod
• ptchgrp
• ptchown
• pttestao

• Select nodes to run on by
• -all
• -m ltfile of hostnamesgt
• -M lthostlistgt
• donner dasher blitzen
• ccnd_at_1-32,42,65-96

25
Part II Traditional Commands Producing Lots of
Output

• ptcat, ptls, ptfind
• Have potential to produce lots of output, and the
  source is also of interest
• With h option ptls M noded_at_1-3 -h
• node1
• myfile1
• node2
• node3
• myfile1
• myfile2

26
Performance of ptcp

• Copying a single 10 MB file
• to 241 nodes in 14 seconds

Time to Copy 10MB file
Total Bandwidth
27
Watching ptcp

• ptcp all bigfile BIGFILE
• X1
• while true do \
• ptexec -all 'echo "hostname ls -s BIGFILE \
• awk \ "print \\"percentage\\" \ (1)/98 \\"
  blue \ red\\"\""' ptdisp -h

28
Percentage of Completion
29
Percentage of Completion
30
Availability

• Open source
• Get from http//www.mcs.anl.gov/sut
• All source, man pages
• Configure, make, on Linux, Solaris, Irix, AIX
• Needs MPI implementation with mpirun
• Developed with Linux, MPICH, MPD, on Chiba City
  at Argonne

31
Chiba City Scalability Testbed

• http//www-unix.mcs.anl.gov/chiba/

32
Some Other Efforts in Scalable Clusters

• Large Programs
• DOE Scientific Discovery through Advanced
  Computing (SciDAC)
• NSF Distributed Terascale Facility (DTF)
• OSCAR
• Goal is a cluster in a box CD
• PVFS (Parallel Virtual File System)
• Many Smaller Efforts
• www.beowulf.org, etc.
• Commercial Efforts
• Scyld, etc.
