Introduction to Smoothing Splines

1
Introduction to Smoothing Splines

• Tongtong Wu
• Feb 29, 2004

2
Outline

• Introduction
• Linear and polynomial regression, and
  interpolation
• Roughness penalties
• Interpolating and Smoothing splines
• Cubic splines
• Interpolating splines
• Smoothing splines
• Natural cubic splines
• Choosing the smoothing parameter
• Available software

3
Key Words

• roughness penalty
• penalized sum of squares
• natural cubic splines

4
Motivation
5
Motivation
6
Motivation
7
Motivation
Spline(y18)
8
Introduction

• Linear and polynomial regression
• Global influence
• Increasing of polynomial degrees happens in
  discrete steps and can not be controlled
  continuously
• Interpolation
• Unsatisfactory as explanations of the given data

9
Roughness penalty approach

• A method for relaxing the model assumptions in
  classical linear regression along lines a little
  different from polynomial regression.

10
Roughness penalty approach

• Aims of curving fitting
• A good fit to the data
• To obtain a curve estimate that does not display
  too much rapid fluctuation
• Basic idea making a necessary compromise between
  the two rather different aims in curve estimation

11
Roughness penalty approach

• Quantifying the roughness of a curve
• An intuitive way
• (g a twice-differentiable curve)
• Motivation from a formalization of a mechanical
  device if a thin piece of flexible wood, called
  a spline, is bent to the shape of the graph g,
  then the leading term in the strain energy is
  proportional to

12
Roughness penalty approach

• Penalized sum of squares
• g any twice-differentiable function on a,b
• smoothing parameter (rate of exchange
  between residual error and local variation)
• Penalized least squares estimator

13
Roughness penalty approach

• Curve for a large value of

14
Roughness penalty approach

• Curve for a small value of

15
Interpolating and Smoothing Splines

• Cubic splines
• Interpolating splines
• Smoothing splines
• Choosing the smoothing parameter

16
Cubic Splines

• Given altt1ltt2ltlttnltb, a function g is a cubic
  spline if
• On each interval (a,t1), (t1,t2), , (tn,b), g is
  a cubic polynomial
• The polynomial pieces fit together at points ti
  (called knots) s.t. g itself and its first and
  second derivatives are continuous at each ti, and
  hence on the whole a,b

17
Cubic Splines

• How to specify a cubic spline
• Natural cubic spline (NCS) if its second and
  third derivatives are zero at a and b, which
  implies d0c0dncn0, so that g is linear on the
  two extreme intervals a,t1 and tn,b.

18
Natural Cubic Splines

• Value-second derivative representation
• We can specify a NCS by giving its value and
  second derivative at each knot ti.
• Define
• which specify the curve g completely.
• However, not all possible vectors represent a
  natural spline!

19
Natural Cubic Splines

• Value-second derivative representation
• Theorem 2.1
• The vector and specify a natural spline g
  if and only if
• Then the roughness penalty will satisfy

20
Natural Cubic Splines

• Value-second derivative representation

21
Natural Cubic Splines

• Value-second derivative representation
• R is strictly diagonal dominant, i.e.
• ? R is positive definite, so we can define

22
Interpolating Splines

• To find a smooth curve that interpolate (ti,zi),
  i.e. g(ti)zi for all i.
• Theorem 2.2
• Suppose and t1ltlttn. Given any values
  z1,,zn, there is a unique natural cubic spline g
  with knots ti satisfying

23
Interpolating Splines

• The natural cubic spline interpolant is the
  unique minimizer of over S2a,b that
  interpolate the data.
• Theorem 2.3
• Suppose g is the interpolant natural cubic
  spline,
• then

24
Smoothing Splines

• Penalized sum of squares
• g any twice-differentiable function on a,b
• smoothing parameter (rate of exchange
  between residual error and local variation)
• Penalized least squares estimator

25
Smoothing Splines

• 1. The curve estimator is necessarily a
  natural cubic spline with knots at ti, for
  i1,,n.
• Proof suppose g is the NCS

26
Smoothing Splines

• 2. Existence and uniqueness
• Let then
• since be precisely the vector of .
  Express ,

27
Smoothing Splines

• 2. Theorem 2.4
• Let be the natural cubic spline with knots
  at ti for which . Then for
  any in S2a,b

28
Smoothing Splines

• 3. The Reinsch algorithm
• The matrix has bandwidth 5 and is
  symmetric and strictly positive-definite,
  therefore it has a Cholesky decomposition

29
Smoothing Splines

• 3. The Reinsch algorithm for spline smoothing
• Step 1 Evaluate the vector .
• Step 2 Find the non-zero diagonals of
• and hence the Cholesky decomposition
  factors L and D.
• Step 3 Solve
• for by forward and back substitution.
• Step 4 Find g by .

30
Smoothing Splines

• 4. Some concluding remarks
• Minimizing curve essentially does not depend
  on a and b, as long as all the data points lie
  between a and b.
• If n2, for any , setting to be the
  straight line through the two points (t1,Y1) and
  (t2,Y2) will reduce S(g) to zero.
• If n1, the minimizer is no longer unique, since
  any straight line through (t1,Y1) will yield a
  zero value S(g).

31
Choosing the Smoothing Parameter

• Two different philosophical approaches
• Subjective choice
• Automatic method chosen by data
• Cross-validation
• Generalized cross-validation

32
Choosing the Smoothing Parameter

• Cross-validation
• Generalized cross-validation

33
Available Software

• smooth.spline in R
• Description
• Fits a cubic smoothing spline to the supplied
  data.
• Usage
• plot(speed, dist)
• cars.spl lt- smooth.spline(speed, dist)
• cars.spl2 lt- smooth.spline(speed, dist, df10)
• lines(cars.spl, col "blue")
• lines(cars.spl2, lty2, col "red")

34
Available Software

• Example 1
• library(modreg)
• y18 lt- c(13,5,4,73,2(25),rep(10,4))
• xx lt- seq(1,length(y18), len201)
• (s2 lt- smooth.spline(y18)) GCV
• (s02 lt- smooth.spline(y18, spar 0.2))
• plot(y18, maindeparse(s2call), col.main2)

• lines(s2, col "blue")
• lines(s02, col "orange")
• lines(predict(s2, xx), col 2)
• lines(predict(s02, xx), col 3)
• mtext(deparse(s02call), col 3)

35
Available Software

• Example 1

36
Available Software

• Example 2
• data(cars) N50, n ( of distinct x) 19
• attach(cars)
• plot(speed, dist, main "data(cars)
  smoothing splines")
• cars.spl lt- smooth.spline(speed, dist)
• cars.spl2 lt- smooth.spline(speed, dist,
  df10)
• lines(cars.spl, col "blue")
• lines(cars.spl2, lty2, col "red")
• lines(smooth.spline(cars, spar0.1))
• spar smoothing parameter (alpha) in (0,1
• legend(5,120,c(paste("default C.V. gt df
  ",round(cars.spldf,1)), "s( , df 10)"), col
  c("blue","red"), lty 12, bg'bisque')
• detach()

37
Available Software

• Example 2

38
Extensions of Roughness penalty approach

• Semiparametric modeling a simple application to
  multiple regression
• Generalized linear models (GLM)
• To allow all the explanatory variables to be
  nonlinear
• Additive model approach

39
Reference

• P.J. Green and B.W. Silverman (1994)
  Nonparametric Regression and Generalized Linear
  Models. London Chapman Hall
