Title: An Introduction to Functional Data Analysis


1
An Introduction to Functional Data Analysis
  • Jim Ramsay
  • McGill University

2
Overview
  • Well use three case studies to see what is meant
    by functional data, and to consider some
    important issues in the analysis of functional
    data
  • Human growth data
  • US nondurable goods manufacturing index
  • Thirty years of Montreal weather

3
Human Growth From data to functions
4
  • We need repeated and regular access to subjects
    for up to 20 years.
  • Height changes over the day, and must be measured
    at a fixed time.
  • Height is measured in supine position in infancy,
    followed by standing height. The change involves
    an adjustment of about 1 cm.
  • Measurement error is about 0.5 cm in later years,
    but is rather larger in infancy.
  • Measurements are not taken at equally spaced
    points in time.

5
Challenges to functional modeling
  • We want smooth curves that fit the data as well
    as is reasonable.
  • We will want to look at velocity and
    acceleration, so we want to differentiate twice
    and still be smooth.
  • In principle the curves should be monotone i.
    e., have a positive derivative.

6
The monotonicity problem
  • The tibia of a newborn measured daily shows us
    that over the short term growth takes places in
    spurts.
  • This babys tibia grows as fast as 2 mm/day!
  • How can we fit a smooth monotone function?

7
Weighted sums of basis functions
  • We need a flexible method for constructing curves
    to fit the data.
  • We begin with a set of basic functional building
    blocks fk(t), called basis functions.
  • Our fitting function x(t) is a weighted sum of
    these

8
B-splines for growth data
  • Order 4 splines look smooth, but their second
    derivatives are rough.
  • We use order 6 B-splines because we want to
    differentiate the result at least twice.
  • We place a knot at each of the 31 ages.
  • The total number of basis functions order
    number of interior knots. 35 in this case.

9
Isnt using 35 basis functions to fit 31
observations a problem?
  • Yes. We will fit each observation exactly.
  • This will ignore the fact that the measurement
    error is typically about 0.5 cm.
  • But well fix this up later, when we look at
    roughness penalties.

10
Okay, lets see what happens
  • These two Matlab commands define the basis and
    fit the data
  • hgtbasis
  • create_bspline_basis(1,18, 35, 6, age)
  • hgtfd
  • data2fd(hgtfmat, age, hgtbasis)

11
Why we need to smooth
  • Noise in the data has a huge impact on derivative
    estimates.

12
Please let me smooth the data!
  • This command sets up 12 B-spline basis functions
    defined by equally spaced knots. This gives us
    about the right amount of fitting power given the
    error level.
  • hgtbasis
  • create_bspline_basis(1,18, 12, 6)

13
  • These are velocities are much better.
  • They go negative on the right, though.

14
Lets see some accelerations
  • These acceleration curves are too unstable at the
    ends.
  • We need something better.

15
A measure of roughness
  • What do we mean by smooth?
  • A function that is smooth has limited curvature.
  • Curvature depends on the second derivative. A
    straight line is completely smooth.

16
Total curvature
  • We can measure the roughness of a function x(t)
    by integrating its squared second derivative.
  • The second derivative notation is D2x(t).

17
Total curvature of acceleration
  • Since we want acceleration to be smooth, we
    measure roughness at the level of acceleration

18
The penalized least squares criterion
  • We strike a compromise between fitting the data
    and keeping the fit smooth.

19
How does this control roughness?
  • Smoothing parameter ? controls roughness.
  • When ? 0, only fitting the data matters.
  • But as ? increases, we place more and more
    emphasis on penalizing roughness.
  • As ? ? 8, only roughness matters, and functions
    having zero roughness are used.

20
  • We can either smooth at the data fitting step, or
    smooth a rough function.
  • This Matlab command smooths the fit to the data
    obtained using knots at ages. The roughness of
    the fourth derivative is controlled.
  • lambda 0.01
  • hgtfd smooth_fd(hgtfd, lambda, 4)

21
Accelerations using a roughness penalty
  • These accelerations are much less variable at the
    extremes.

22
The corresponding velocities look good, too
23
How did you choose ??
  • We smooth just enough to obtain tolerable
    roughness in the estimated curves (accelerations
    in this case), but not so much as to lose
    interesting variation.
  • There are data-driven methods for choosing ?, but
    they offer only a reasonable place to begin
    exploring.
  • But this is inevitably involves judgment.

24
What about monotonicity?
  • The growth curves should be monotonic.
  • The velocities should be non-negative.
  • Its hard to prevent linear combinations of
    anything from breaking rules like monotonicity.
  • We need an indirect approach to constructing a
    monotonic model.

25
A differential equation for monotonicity
  • Any strictly monotonic function x(t) must satisfy
    a simple linear differential equation

The reason is simple Because of strict
monotonicity, the first derivative Dx(t) will
never be 0, and function w(t) is therefore
simply D2x(t)/Dx(t).
26
The solution of the differential equation
  • Consequently, any strictly monotonic function
    x(t) must be expressible in the form

This suggests that we transform the monotone
smoothing problem into one of estimating function
w(t), and constants ß0 and ß1.
27
What we have learned from the growth data
  • We can control smoothness by either using a
    restricted number of basis functions, or by
    imposing a roughness penalty.
  • Roughness penalty methods generally work better
    than simple basis expansions.
  • Differential equations can play a useful role in
    defining constrained functions.

28
Phase-Plane Plotting the Nondurable Goods Index
29
  • Nondurable goods last less than two years Food,
    clothing, cigarettes, alcohol, but not personal
    computers!!
  • The nondurable goods manufacturing index is an
    indicator of the economics of everyday life.
  • The index has been published monthly by the US
    Federal Reserve Board since 1919.
  • It complements the durable goods manufacturing
    index.

30
What we want to do
  • Look at important events.
  • Examine the overall trend in the index.
  • Have a look at the annual or seasonal behavior of
    the index.
  • Understand how the seasonal behavior changes over
    the years and with specific events.

31
The log nondurable goods index
32
Events and Trends
  • Short term
  • 1929 stock market crash
  • 1937 restriction of money supply
  • 1974 end of Vietnam war, OPEC oil crisis
  • Medium term
  • Depression
  • World War II
  • Unusually rapid growth 1960-1974
  • Unusually slow growth 1990 to present
  • Long term increase of 1.5 per year

33
The evolution of seasonal trend
  • We focus on the years 1948 to 1999
  • We estimate long- and medium-term trend by spline
    smoothing, but with knots too far apart to
    capture seasonal trend
  • We subtract this smooth trend to leave only
    seasonal trend

34
Smoothing the data
We want to represent the data yj by a smooth
curve x(t). The curve should have at least two
smooth derivatives. We use spline smoothing,
penalizing the size of the 4th derivative.
A function Pspline in S-PLUS is available by ftp
from ego.psych.mcgill.ca/pub/ramsay/FDAfuns
35
Three years of typical trend 1964-1966
36
Seasonal Trend
  • Typically three peaks per year
  • The largest is in the fall, peaking at the
    beginning of October
  • The low point is mid-December

37
Non-seasonal trend is in red
38
Seasonal trend data nonseasonal trend
39
Phase-Plane Plots
  • Looking at seasonal trend itself does not reveal
    as much as looking at the interplay between
  • Velocity or its first derivative, reflecting
    kinetic energy in the system.
  • Acceleration or its second derivative, reflecting
    potential energy.
  • The phase-plane diagram plots acceleration
    against velocity.
  • For purely sinusoidal trend, the plot would be an
    ellipse.

40
Position of a swinging pendulum
41
Phase-plane plot for pendulum
42
Phase-plane plot for 1964
  • There are three large loops separated by two
    small loops or cusps
  • Spring cycle mid-January into April
  • Summer cycle May through August
  • Fall cycle October through December

43
A look at the years 1929-1931.
44
(No Transcript)
45
(No Transcript)
46
(No Transcript)
47
1929 through 1931
  • The stock market crash shows up as a large
    negative surge in velocity.
  • Subsequent years nearly lose the fall production
    cycle, as people tighten their belts and spend
    less at Christmas.

48
What happened in 1937-1938?
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
1937 and 1938
  • The Treasury Board, fearing that the economy was
    becoming overheated again, clamped down on the
    money supply. The effect was catastrophic, and
    nearly wiped out the fall cycle.
  • This new crash was even more dramatic than that
    of 1929, but was forgotten because of the
    outbreak of World War II.

53
What about World War II?
54
(No Transcript)
55
  • During World War II, the seasonal cycle became
    very small, since the war, and the production
    that fed it, lasted all year long.
  • Now look at three pivotal years, 1974 to 1976,
    when the Vietnam War ended and the OPEC oil
    crisis happened. Watch the shrinking of the fall
    cycle.

56
(No Transcript)
57
(No Transcript)
58
(No Transcript)
59
What about today?
60
(No Transcript)
61
These days
  • Over the last ten years the size of all three
    cycles have become much smaller.
  • Why?
  • Is variation now smoothed out by information
    technology?
  • Are the aging baby boomers spending less?
  • Are personal computers, video games, and other
    electronic goods really durable?
  • Has manufacturing now moved off shore?

62
Conclusions
  • We can separate long- and medium-term trends from
    seasonal trends by smoothing.
  • Phase-plane plots are great ways to inspect
    seasonality.
  • Derivatives were used in two ways to penalize
    roughness, and to reflect the dynamics of
    manufacturing.

63
Trends in Seasonality
  • We see by inspection that seasonal trends change
    systematically over time, and can also change
    abruptly.
  • We first estimate the principal components of
    seasonal variation, using a version of principal
    components analysis adapted to functional data,
    and sensitive only to effects periodic over one
    year.

64
(No Transcript)
65
(No Transcript)
66
(No Transcript)
67
The Components
  1. Relative sizes of spring and summer cycles (53)
  2. Joint size of spring and summer cycles (25)
  3. Size of fall cycle (11)

68
Plotting Component Scores
  • We can compute scores at each year for these
    three principal components, sometimes called
    empirical orthogonal functions.
  • Plotting the evolution of these scores over the
    51 years shows some interesting structural
    changes in the economics of everyday life.

69
(No Transcript)
70
(No Transcript)
71
Wrap-up
  • Phase-plane plots are good for inspecting
    seasonal quasi-harmonic trends
  • Principal components analysis reveals main
    components of variation in seasonal trend.
  • Plotting component scores shows how trend has
    evolved.

72
  • This was joint with work with James B. Ramsey,
    Dept. of Economics, New York University, and is
    reported in
  • Ramsay, J. O. and Ramsey, J. B. (2001) Functional
    data analysis of the dynamics of the monthly
    index of non-durable goods production. Journal
    of Econometrics, 107, 327-344.

73
Phase and Amplitude Variation in Montreal Weather
  • 34 years of daily temperatures, 1961-1994
    inclusive
  • Values are averages of daily maximum and minimum
  • 12410 observations in tenths of a degree Celsius
  • Available for Montreal and 34 other Canadian
    weather stations

74
(No Transcript)
75
  • We know that there are two kinds of variation in
    these data
  • Amplitude variation day-to-day and year-to-year
    variation in temperature at events such as the
    depth of winter.
  • Phase variation the timing of these events --
    the seasons arrive early in some years, and late
    in others.

76
Goals
  • Separate phase variation from amplitude variation
    by registering the series to its strictly
    periodic image.
  • Estimate components of variation due to amplitude
    and phase variation.

77
Smoothing
  • The registration process requires that we smooth
    the data two ways
  • With an unconstrained smooth that removes the
    day-to-day variation, but leaves longer-term
    variation unchanged.
  • With a strictly periodic smooth that eliminates
    all but strictly periodic trend.

78
Unconstrained smooth
  • Raw data are represented by a B-spline expansion
    using 500 basis functions of order 6.
  • Knot about every 25 days.
  • The standard deviation of the raw data about this
    smooth, adjusted for degrees of freedom, is 1.52
    degrees Celsius.

79
(No Transcript)
80
Periodic smooth
  • The basis is Fourier, with 9 basis functions
    judged to be enough to capture most of the
    strictly periodic trend for a period of one year.
  • The standard deviation of the raw about data
    about this smooth is 2.18 deg C.
  • Compare this to 2.07 deg C. for the unconstrained
    smooth.

81
(No Transcript)
82
  • Plotting the unconstrained B-spline smooth minus
    the constrained Fourier smooth reveals some
    striking discrepancies.
  • We focus on Christmas, 1989. The Ramsays spent
    the holidays in a chalet in the Townships, and
    awoke to 37 deg C. No skiing, car dead,
    marooned!
  • This temperature would still be cold in
    mid-January, but less unusual.

83
(No Transcript)
84
Registration
  • Let the unconstrained smooth be x(t) and the
    strictly periodic smooth be x0(t).
  • We need to estimate a nonlinear strictly
    increasing smooth transformation of time h(t),
    called a warping function, such that a fitting
    criterion is minimized.

85
Fitting criterion
The fitting criterion was the smallest eigenvalue
of the matrix
This criterion measures the extent to which a
plot of xh(t) against x0(t) is linear, and thus
whether the two curves are in phase.
86
The warping function h(t)
  • Every smooth strictly monotone function h(t) such
    that h(0) 0 can be represented as

We represent unconstrained function w(v) by a
B-spline expansion. Constant C is determined by
constraint h(T) T.
87
The deformation u(t) h(t) - t
  • Plotting this allows us to see when the seasons
    come early (negative deformation) or late
    (positive deformation).

88
(No Transcript)
89
  • Mid-winter for 1989-1990 arrived about 25 days
    early.
  • The next step is to register the temperature data
    by computing x(t) xh(t). The registered
    curve x(t) contains only amplitude variation.
  • Registration was done by Matlab function
    registerfd, available by ftp from
  • ego.psych.mcgill.ca/pub/ramsay/FDAfuns

90
(No Transcript)
91
Amplitude variation
  • The standard deviation of the difference between
    the unconstrained smooth and the strictly
    periodic smooth is 2.15 C.
  • The standard deviation of the difference between
    the registered smooth and the period smooth is
    1.73 C.
  • (2.152 1.732)/2.152 .35, the proportion of
    the variation due to phase.

92
  • The standard deviation of the raw data around the
    registered smooth is 2.13 C, compared with 2.07 C
    for the unregistered smooth.
  • About 10 of the total variation is due to phase.

93
Conclusions
  • Phase variation is an important part of weather
    behavior.
  • Statisticians seldom think about phase variation,
    and classical time series methods ignore it
    completely.
  • Phase variation needs more attention, and
    registration is an essential tool.

94
Unique Aspects of Functional Data Analysis
  • The data are smooth, so we can use derivatives in
    various ways.
  • Differential equations can play a big role.
  • Events in functional data occur over different
    time scales.
  • Time itself may be an elastic medium, and vary
    over functional observations.

95
Finding out More
  • Ramsay, J. O. and Silverman, B. W. (1997, 2004)
    Functional Data Analysis. Springer.
  • Ramsay, J. O. and Silverman, B. W.
  • (2002) Applied Functional Data Analysis. Springer
  • Visit the FDA website www.psych.mcgill.ca/misc/fd
    a/
  • Software in Matlab, R and S-PLUS available at
    ego.psych.mcgill.ca/pub/ramsay
Write a Comment
User Comments (0)
About PowerShow.com
