Lévaluation des interfaces utilisateurs

• N.B. Dans ces diapos,  BGBG  réfère à la 2e
  édition du livre  Human-Computer Interaction
  de Baecker, Grudin, Buxton et Greenberg (1995)

2
Formative vs Summative Evaluation

• Formative evaluation (Évaluation formative)
• Happens throughout the design process
• Can evaluate scenarios, sketches, models,
  prototypes
• Summative evaluation (Évaluation
  sommative/récapitulative)
• Typically happens at the end
• Assesses system andinterface design
  quality,i.e., how well have we done?

3
Analytic vs Empirical Evaluations (BGBG pp.
228-229)

• Analytic Evaluations (Évaluations analytiques)
• Do not involve actual users
• Focus is on why things happen the way they
  do,and on the components of the system
• Produce interpretations and suggestions, not
  solid facts
• Better for formative evaluation than summative
  evaluation
• Can be used early in design process,before any
  high-fidelity prototype exists
• Examples heuristic evaluation, walkthrough,
  claims analysis
• Empirical Evaluations (Évaluations empiriques)
• Involve actual users
• Focus is on what actually happens in practice
• Produce factual measurements and observations
• Good for summative evaluation,but may not
  clearly point to what changes to make
• Can produce a lot of data that is laborious to
  analyze
• Examples experiments, usability testing, field
  studies

4
Empirical EvaluationNaturalistic Observation vs
True Experiments(Example Ray and Ravizza 1985)
Naturalistic observation(watching, recording) True experiments(manipulating, measuring)
Noninterference with phenomena Manipulation, control
Observations of patternsand invariants Measurements of observed patterns
High level, big picture insights Low level, detailed results
Qualitative, descriptive Quantitative
5
Empirical Evaluation User Testing

• Design and implement scenario or prototype
• Record user behaviour
• Typical usage, or critical incidents
• Keystroke and mouse event recording
• Thinking aloud protocols
• Audio or video recording
• Collect subjective impressions(questionnaire,
  interview)
• Analyze recordings of user behaviour

6
Typical Steps in User Testing (Gomoll, in Laurel,
85-90)

• Set up the observation
• Describe the purpose of the study, and how the
  data collected will be used
• Tell the user (verbally and on paper) that it's
  OK to quit at any time
• Ask participant if they are willing to sign form
  to give their permission to begin
• Pre-questionnaire (name, age, handedness,
  background, education, experience with computers,
  etc.)
• Talk about and demonstrate the equipment
• Explain how to think aloud
• Explain that you will not provide help
• Describe the task and introduce the system
• Ask if there are questions before you start then
  begin observation
• Post-questionnaire and/or interview to solicit
  opinions, impressions, etc.
• Conclude the observation and debrief participants
• Transcribe, tabulate the data and results
• Analyze, interpret the results

7
User Testing (BGBG, Fig. 2.8, p. 85, adapted from
Neilsen, 1992)

• Practical study design
• Reflect on the participants backgrounds and how
  they might affect the study
• Be aware of problems that arise when
  experimenters know the users personally
• Prepare for the study carefully (avoid last
  minute panic)
• Select the tasks carefully to be representative
  and to fit the allotted time
• In general, start with an easier (but not
  frivolous) task
• Write down features of system not being tested as
  well as those that are!
• Define the start-up state for the study precisely
• Define precise rules for when and how users can
  be helped during the study
• Plan timing and cut-off procedure (if subject
  gets stuck) for each part of study
• Include provisions for data collection (e.g.,
  audio, video, or keystroke capture)
• Plan data analysis techniques in advance
• Carry out an initial pilot study to test your
  protocol
• Written materials
• Participant release (permission) form
• Pre-questionnaire covering prior experience etc.
• Introduction to the study for users, including
  scenario of use,and description of tasks
• Checklist for experimenters, and paper for
  note-taking
• Post-questionnaire or survey

8
User Testing (BGBG, Fig. 2.8, p. 85, adapted from
Neilsen, 1992)

• Carrying out the study
• Let users know that complete anonymity will be
  preserved
• Let them know that they may quit at any time
• Stress that the system is being tested, not the
  participant
• Note participant is the more modern term for
  subjet
• Indicate that you are only interested in their
  thoughts relevant to the system
• Demonstrate the thinking-aloud method by acting
  it out for a simple task, e.g., figuring out how
  to load a stapler
• Hand out instructions for each part of the study
  individually, not all at once
• Maintain a relaxed environment free of
  interruptions
• Occasionally encourage users to talk if they grow
  silent
• If users ask questions, try to get them to talk
  (e.g., What do you think is going on? and
  follow predefined rules on when to help or
  interrupt to help.
• Debrief each user after the experiment

9
Thinking Aloud

• Attempt to elicit thought processes of
  participant, thereby yielding valuable insights
  (although process is slowed down and may be
  changed)
• Participant talking while they are doing
• Problems they are having
• Solutions they are considering
• Why they are having trouble
• Insights that they have
• Wishes that they have
• Co-Discovery Pairs of participants conversing
  (Co-Discovery Learning, Kennedy paper in BGBG,
  pp. 182-185)

10
Data Capture and Analysis

• Keystrokemouse logging
• Record precise user behaviour
• Record times to carry out actions
• Record user errors
• Observation and note taking by observers,especial
  ly of user problems and critical incidents
• Best if note taking done by a 2nd observer
• Audio and video recordings
• Can't observe and record all behaviour in
  real-time
• Preserve behaviour for review (even non-verbal
  behaviour)
• Can produce a lot of data ?

11
Asking Users in Addition to Observing Them

• Methods
• (Post-) Questionnaire design
• Formulating asking questions, analyzing
  answers
• Hard to avoid bias in the phrasing of questions
• Therefore requires pre-testing (pilot testing)
• Surveys (Sondages) (possibly large-scale)
  administration of questionnaires to appropriate
  samples of individuals chosen from a population
• Administration of questions through interviews

12
Ethical Issues

• Basic principles
• Do no harm
• Voluntary participation
• Informed consent
• Right to privacy
• Use of research protocols and consent forms
• Explanation of study and purpose
• Anonymity
• Ability to withdraw at any time
• For example, see p. 256 of Rosson Carroll

13
Une taxonomie de plusieurs techniques
dévaluation
14
Taxonomie de McGrath
(discret)
(intrus, dérangeant)
15
Quadrant 1 Field Strategies

• Study systems in real use on real tasks in real
  work environments, i.e., observe under settings
  with conditions as natural as possible
• Field studies Study systems in situ, disturbing
  as little as possible, e.g., with ethnography,
  contextual inquiry
• Field experiments Observe impact of changing
  (ideally) one aspect of a work environment, e.g.,
  in beta testing, studies of technological change
  and new technology introduction

16
Quadrant 2 Experimental Strategies

• Study systems in a lab under controlled
  conditions, i.e., conditions concocted for
  research purposes
• Laboratory experiments Carry out controlled
  experiments studying impacts of (ideally) one (or
  two) interface parameter(s)
• Experimental simulations Create in lab for
  experimental purposes a real system that is used
  by real users on (usually) artificially
  simplified tasks, e.g., user testing, usability
  engineering

17
Quadrant 3 Respondent Strategies

• Ask informants to tell us something about
  themselves and/or their work or about an
  interface, i.e., where the setting in which
  questions are asked plays no role
• Judgment studies Ask respondents about an
  interface, e.g., in a demonstration, or with
  usability inspection
• Sample surveys Ask respondents about themselves
  and/or their work, e.g., with questionnaires,
  surveys, interviews

18
Usability Inspection (a Respodant strategy)

• Methods
• Heuristic evaluation Judgments by a panel of
  evaluators (e.g, 3 to 5) of the degree to which
  an interface satisfies a set of usability
  guidelines, followed by discussion and analysis
• Cognitive walkthroughs
• Roles
• Evaluation without users (contrast to usability
  tests, etc.)
• Elicit expert opinions about the users model,
  functionality, look feel, etc.

19
Usability Inspection (contd)

• Advantages
• Structured method of using accumulated wisdom of
  experts
• Disadvantages
• Doesnt take advantage of real insights from real
  users
• Example Heuristic evaluation with 10 usability
  guidelines (Nielsen, BGBG, Fig. 2.7, p. 83)
• Visibility of system status
• Match between system and the real world
• User control and freedom
• Consistency and standards
• Error prevention
• Recognition rather than recall
• Flexibility and efficiency of ue
• Aesthetic and minimalist design
• Help users recognize, diagnose, and recover from
  errors
• Help and documentation

20
Demonstrations (a Respodant strategy)

• Demonstrate system to
• Any random person
• Management, potential investors, journalists
• Potential customers
• Potential users
• Potential business partners
• Take detailed notes
• Elicit reactions to user's model, functionality,
  interface
• Advantages
• Get feedback early in prototype or system
  construction
• You're going to have to give demos anyway why
  not learn from them?
• Disadvantages
• System still rough, which introduces noise into
  process

21
Quadrant 4 Theoretical Strategies

• Ask a theory to tell us something about people's
  work and/or about an interface, i.e., no
  observation of behaviour, experiments, or
  questions are required
• Formal theory Use a qualitative theory or some
  equations, e.g., behavioural theory, such as
  colour vision or Fitts Law
• Computer simulation Use and run a computer
  model, e.g., human information processing theory

22
Résumé des techniques dévaluation

• Stratégies sur le terrain (Field Strategies)
• Études sur le terrain (Field Studies)
• Observer processus in situ, en changeant le
  système le moins possible
• Exemples études ethnographiques, enquêtes
  contextuelles (contextual inquiry) (BGBG pages
  42, 46) (pas nécessaire à
  savoir pour lexamen)
• Expérimentations sur le terrain (Field
  Experiments)
• Changer un aspect de lenvironnement et observer
  les effets
• Stratégies expérimentales (Experimental
  Strategies)
• Expérimentations de laboratoire (Laboratory
  Experiments / Controlled Experiments)
• Varier ou manipuler, de façon précise, une ou
  plusieurs variables indépendentes
• Mesurer de façon précise, une ou plusieurs
  variables dépendentes
• Essayer de contrôler soigneusement les conditions
• Simulation expérimentale
• Créer un système réel, dans un laboratoire, pour
  des utilisateurs réels
• Exemples
• Tests dutilisabilité / tests dutilisateurs
• Emploi souvent un protocole de penser à haute
  voix et/ou une phase de découverte où
  lutilisateur explore linterface emploi souvent
  aussi des questionnaires et/ou entrevues
• Génie dutilisabilité (Usability engineering)
• Plus formel que les tests dutilisabilité
• Mesures quantitatives de performance (métriques)

23
Résume des techniques dévaluation (2)

• Stratégies de répondants (Respondant Strategies)
• Études de jugement
• Exemple inspection dutilisabilité (usability
  inspection) ou expert review
• Fait par des experts ou concepteurs, sans
  utilisateurs
• Exemples évaluation heuristique (heuristic
  evaluation)
• Utilise un ensemble de directives de conceptions
  ou de règles (heuristiques) (exemple les
  heuristique de Nielsen)
• Exemple cognitive walkthrough
• Exemple démonstrations
• Sondages (Surveys)
• Exemples questionnaires, entrevues
• Stratégies théoriques (Theoretical Strategies)
• Théories formelles
• Involves a model of the user, the system, and
  interaction between the two
• Exemples loi de Fitts, loi de Hick-Hyman, KLM,
  GOMS, etc.
• Simulations à lordinateur
• Simuler un modèle

24
Compromis (Tradeoffs)
A Généralizable (validité externe)B Précis
(validité interne (?))C Réaliste (validité
écologique)
25
Controlled Experiments
26
Controlled Experiments

• Method
• Manipulate independent variables, system
  characteristics
• Control for other variables (hold them constant)
• Measure dependent variables, user behaviour
• Roles
• Understanding factors influencing interface
  quality
• Determining which conditions or which interface
  is best

27
Controlled Experiments

• Advantages
• Strong statements about causality (good internal
  validity)
• Many experimental designs suitable for varying
  situations
• Disadvantages
• Requires time, planning, may be expensive
• Complex designs (more than 3 or 4 independent
  variables) are often difficult to interpret
• Often lack external validity and especially
  ecological validity

28
Examples

• Of 3 interfaces, A, B, C, which enables fastest
  performance at a given task?
• Does prozac have an effect on performance at
  tying shoe laces?
• How does frequency of advertisements on
  television affect voting behaivour?
• Can casting a spell on a pair of dice affect what
  numbers appear on them?

29
Elements of an Experiment

• Population
• Set of all possible subjects / observations
• Sample
• Subset of the population chosen for study a set
  of subjects / observations
• Subjects
• People/users under study. The more politically
  correct term within HCI is participants.
• Observations / Dependent variable(s)
• Individual data points that are
  measured/collected/recorded
• E.g. time to complete a task, errors, etc.
• Condition / Treatment / Independent variables(s)
• Something done to the samples that distinguishes
  them(e.g. giving a drug vs placebo, or using
  interface A vs B)
• Goal of experiment is often to determine whether
  the conditions have an effect on observations,
  and what the effect is

30
Tasks to Design and Run an Experiment

• Design
• Choose independent variables
• Choose dependent variables
• Develop hypothesis
• Choose design paradigm (plan expérimental croisé
  ou emboîté)
• Choose control procedures
• Choose a sample size
• Pilot experiment
• Often more exploratory, varying a greater number
  of variables to get a feel for where the
  effect(s) might be
• Run experiment
• Focuses in on the suspected effect tries to
  gather lots of data under key or optimal
  conditions to result in a strong conclusion
• Analyze data
• Using statistical tests such as ANOVA
• Interpret results

31
The Problem Effectiveness of New Method of
Source Code Presentation

• Source code appearance makes inadequate use of
  capabilities of digital typography
• Potential to make code more readable, more
  comprehensible with new and enhanced
  presentation format
• See book by Baecker and Marcus, Human Factors and
  Typography for More Readable Programs,
  Addison-Wesley, 1990
• On following slides, bullet points that refer to
  an experimental study of our new presentation
  format indicated by

32
Conventional Presentation
33
New Presentation
34
Independent Variables

• The variable manipulated by the experimenter
• Also known as factor or treatment
• Experiment may involve one or many independent
  variables
• Each independent variable
• Has 2 or more levels (i.e. values)
• May be metric (continuous, like the length of a
  menu) or categorical (discrete, like mouse vs.
  trackball, or a Likert scale)
• In our example just one independent variable,
  with two levels new typesetting format or
  traditional presentation format

35
Dependent Variables

• Definition
• Variable measured by experimenter
• Variable which may depend on the independent
  variables
• Relationship is not necessarily causal e.g. may
  only be correlated
• Examples
• Accuracy, or number of errors
• Number of subtasks completed in a given time
  period
• Time to complete each task
• In our example, ability to comprehend program
  as measured by of questions answered in given
  time

36
Hypotheses

• Statement, to be tested, of relationship between
  independent and dependent variables
• The null hypothesis is that the independent
  variables have no effect on the dependent
  variables
• Hypothesis in our example reading
  comprehension as defined above is improved by new
  method of source code presentation

37
Experimental Design Paradigms

• Between subjects or within subjects
  manipulation(entre participants vs à travers
  tous les participants)
• Example designs with one independent variable
• Between subjects (randomized group) design
  (emboîté)
• One independent variable with 2 or more levels
• Subjects randomly assigned to groups
• Each subject tested under only 1 condition
• Within subject (repeated measures) design
  (croisé)
• One independent variable with 2 or more levels
• Each subject tested under all conditions
• Order of conditions randomized or counterbalanced
  (why?)
• In our example, within subjects chosen with two
  conditions, i.e., two sample programs

38
Control Procedures

• Goal is to eliminate confound hypothesis, i.e.,
  that there are alternative explanation(s) for the
  observed effect(s)
• To do this Make sure there are no systematic
  differences between conditions other than the
  independent variable
• In our example, ensure that two sample
  programs are identical in length, complexity,
  difficulty

39
What To Control

• Subject characteristics
• Gender, handedness, etc.
• Ability
• Experience
• Task variables
• Instructions
• Materials used
• Environmental variables
• Setting
• Noise, light, etc.
• Order effects
• Practice
• Fatigue

40
How to Control

• Hold constant
• Use males only, or students from same class
  only
• Novices only
• Randomize
• Subjects to groups
• Counterbalance
• Half (chosen randomly) get new presentation
  format first

41
Sample Size Selection

• More subjects --gt more confidence in results.
  i.e., greater statistical significance
• But this can be very expensive
• Many methods to reduce the required number of
  subjects
• Most HCI experiments 4 to 25 subjects per group
• In our example, 44 subjects chosen from an 3rd
  year programming course

42
Designing and Running the Experiment and
Collecting the Data

• Run pilot studies
• Check experimental design
• Test and improve
• Task definition
• Experimental materials (often the most difficult)
• Instructions
• Practice tasks
• Develop experimenter skills
• Identify and deal with special problems
• Run actual experiment
• Record data
• Observe behaviour

43
The Presentation Format Experiment

• Within-subjects design, 44 subjects from 3rd year
  programming course
• Two similar short C programs, roughly 200 lines
  of code, 4 to 5 pages
• 40 minutes to skim first program and attempt to
  answer 18 questions, half in familiar format and
  half in new format
• Then each group given other program in other
  format

44
Data Analysis and Hypothesis Testing

• Describe data
• Descriptive statistics (means, medians, standard
  deviations)
• Graphs and tables
• Perform statistical analysis of results
• Are results due to chance? (That is, with what
  probability)
• In our example, mean percentage of correct
  answers with new format 44, with conventional
  format 35
• Analysis of variance showed that effect of
  presentation format in increasing program
  readability was significant, F(1,42)18.25,
  plt0.0001.

45
ANOVA

• Analysis of Variance
• A statistical test that compares the
  distributions of multiple samples, and determines
  the probability that differences in the
  distributions are due to chance
• In other words, it determines the probability
  that the null hypothesis is correct
• If probability is below 0.05 (i.e. 5 ), then we
  reject the null hypothesis, and we say that we
  have a (statistically) significant result
• Why 0.05 ? Dangers of using this value ?

46
Techniques for Making Experiment more Powerful
(i.e. able to detect effects)

• Reduce noise (i.e. reduce variance)
• Increase sample size
• Control for confounding variables
• E.g. psychologists often use in-bred rats for
  experiments !
• Increase the magnitude of the effect
• E.g. give a larger dosage of the drug

47
Une petite différence entre les moyennes des
échantillons. Est-ce significative, ou
simplement dû au hasard ?
Une plus grande différence entre les moyennes des
échantillons. Est-ce significative, ou
simplement dû au hasard ?
48
et la différence plus grande ici est
significative.
Avec une variance plus petite (que sur le diapo
précedent), on est plus sûr que la très petite
différence ici est dû au hasard
49
Avec une taille déchantillon plus large (que sur
les diapos précedents), on est plus sûr que la
très petite différence ici est dû au hasard
et la différence plus grande ici est
significative.
50
Uses of Controlled Experiments within HCI

• Evaluate or compare existing systems/features/inte
  rfaces
• Discover and test useful scientific principles
• Examples ?
• Establish benchmarks/standards/guidelines
• Examples ?
