Estimating Flood Limits in Large Riverine Systems Using Unsteady-State Hydraulic Modeling (HEC-RAS)

1
Estimating Flood Limits in Large Riverine Systems
Using Unsteady-State Hydraulic Modeling (HEC-RAS)

• Brian Greathouse, P.E.
• Malcolm Pirnie, Inc.

2
(No Transcript)
3
METHODOLOGIES

• US ARMY CORP OF ENGINEERS HEC-RAS RIVER ANALYSIS
  SYSTEM
• STEADY STATE ANALYSIS
• UNSTEADY STATE ANALYSIS

4
HEC-RAS OVERVIEW

• MODEL COMPONENTS
• GEOMETRY DATA
• FLOW DATA
• BOUNDARY CONDITIONS

5
GEOMETRY DATA

• CROSS SECTION DATA
• DEVELOPED FROM TOPOGRAPHIC DATA
• SURVEY DATA
• COMBINATION OF BOTH
• LAND COVER DATA MANINGS N VALUE
• DEFINED FOR THE CHANNEL AND OVERBANK PORTION OF
  THE CROSS SECTION
• STRUCTURE DATA
• BRIDGES, CULVERTS, WEIRS

6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
FLOW DATA

• STEADY STATE UNIFORM FLOW
• UNSTEADY STATE NON-UNIFORM FLOW FLOW HYDROGRAPH

10
STEADY-STATE MODELING

• APPLICATION OF A UNIFORM FLOW THROUGHOUT THE
  RIVER SYSTEM
• TYPICALLY A PEAK FLOW TAKEN FROM THE FLOW
  HYDROGRAPH
• COMMON APPLICATION IS FEMA FLOOD MAPPING

11
UNSTEADY STATE MODELING

• NON-UNIFORM FLOW
• APPLICATION OF A FLOW HYDROGRAPH
• BETTER REPRESENTATION OF THE HYDRAULIC
  CHARATERISTICS OF A RIVER SYSTEM

12
CASE STUDY TALLAPOOSA RIVER MODEL

• MODELED FROM THURLOW DAM TO THE DEAD RIVER AREA

13
(No Transcript)
14
FLOW DATA

• APPLIED ACTUAL DAM RELEASE RATES TO THE MODEL
• APPLIED HYPOTHETICAL RELEASE RATES WERE APPLIED

15
MODEL CALIBRATION

• STREAM GAGE DATA USED FOR MODEL CALIBRATION
• COMPARE FLOW AND STAGE (MODELED vs GAGE DATA)
• APPLY A UNIFORM DISTRIBUTED FLOW
• CALIBRATION COMPENSATES FOR FLOW ENTERING SYSTEM
  DOWNSTREAM FROM DAM AND OFFLINE STORAGE

16
Model Flow vs. Gage Flow
17
Model Flow vs. Gage Height
18
Model Flow vs. Gage Height
19
(No Transcript)
20
FLOOD LIMITS

• MODEL PRODUCES WATER SURFACE ELEVATIONS AT EACH
  CROSS SECTION
• WATER SURFACE ELEVATIONS ARE APPLIED TO
  TOPOGRPAHICAL DATA AND THE FLOOD LIMITS ARE
  DETRMINED.

21
QUESTIONS????????
