Object Oriented Programming

1
Object Oriented Programming
Universitatea de Vest din Timisoara
Facultatea de Matematica si Informatica

• Lect. Dr. Daniel POP

2
Course 13 Agenda

• Object-Oriented Design
• Overview and concepts
• OOD principles
• Error handling in OO systems
• Case study (continued)

3
Object-oriented design

• DEFINITION Object-oriented design OOD is the
  discipline of defining the objects and their
  interactions to solve a business problem that was
  identified and documented during object oriented
  analysis.
• Covers software architecture activities of
  software development process.
• Inputs of OOD step
• Deliverables of OOA step (conceptual model, use
  cases, UI documentation, other documents)
• Deliverables (output) of OOD step
• Class diagram static structure diagram that
  describes the structure of a system by showing
  the system's classes, their attributes, and the
  relationships between the classes
• Sequence diagram shows different processes or
  objects that live simultaneously, and the
  messages exchanged between them, in the order in
  which they occur.

4
OOD concepts
WHAT DO WE DO IN OOD STEP?

• Define objects identify attributes, behavior
  and services exposed by objects.
• Create class diagram from conceptual diagram.
• Define application framework (if applicable)
  Application framework is a term usually used to
  refer to a set of libraries or classes that are
  used to implement the standard structure of an
  application for a specific operating system. By
  bundling a large amount of reusable code into a
  framework, much time is saved for the developer,
  since he/she is saved the task of rewriting large
  amounts of standard code for each new application
  that is developed.
• Identify persisted objects/data (if
  applicable) Identify objects that have to be
  persisted. If relational database is used design
  the object relation mapping (data layout and
  database services).
• Identify, define remote objects (if
  applicable).
• Evaluate existing OO programming language and
  choose the most appropriate one
• Evaluate the OO design
• Define the testing strategy unit testing,
  non-regression testing, integration testing etc.

HOW DO WE DO IT?

• Base on experience, common-sense, using OOD
  principles and design patterns.

5
Structuring objects

• Generalization-specialization hierarchies
  (is-a) use inheritance to factor-out common
  attributes and behavior of discovered objects
• does the union of all specializations cover the
  set described by generalization?
• are the specializations mutually exclusive?
• Example Shape, Ellipse, Point
• Multiple inheritance
• tend to complicate the hierarchy
• conflicts may appear between similar
  attributes/behavior inherited from the two
  distinct base classes
• should be used with caution
• Java-like approach extend a single
  representation and implement many behaviors
• Multiple inheritance is like a parachute you
  dont always need it, but when you do, youre
  really happy to have it at hand., G. Booch
• Whole-part hierarchies (has-a)
• Example Person has 1 Body, 0 or 2 Arms, 1 Head
  etc. A Polyline has 2..N Points.
• the whole does not inherit behavior from parts
  gt inheritance is not applicable here.
• usually, whole-part relationships are identified
  after gen-spec
• Note Attributes and behavior are added in
  later steps.

6
Object attributes

• Discovering attributes
• use a first-person perspective
  (personification)
• analyze the problem, interview the customer
• Placing attributes in a class hierarchy which
  class in a hierarchy is the most appropriate
  place-holder for an attribute?
• Define attribute domain, i.e. what are the
  legal values the attribute can take.
• The relationships between objects are
  implemented as attributes as well, but these
  attributes arent explicitly presented as
  normal objects attributes, though they are
  part of the objects state
• During this phase, the class hierarchy is
  revised
• Examples a Point has 2 coordinates, denoted X,
  Y that can only take positive values.

7
Object behavior

• DEFINITION Behavior, Service A behavior
  describes an activity of an object. A service
  defines the relationship to other model
  components.
• Represented using UMLs behavior and
  interaction diagrams (e.g. Activity, State
  Machine etc.)
• Identify possible objects states and then
  explore meaningful connections (state changes).
• Have all states been defined? Are all the
  states reachable? In each state, does the object
  respond properly to all possible conditions?
• Involve interactions with other objects that
  will be detailed in object services.
• Example Add Department

• Add Department - this diagram shows how new
  departments are added to the system. The process
  starts by the user pressing the Add Department
  button on the University window. This brings up a
  small dialog where the name of the new department
  can be entered. When the user presses OK, a
  create message is sent to create the new
  Department. This message contains a single
  attribute the name of the new Department.

8
Object services (I)

• Discovering required services ( member
  functions) based on their types
• implicit services create a new instance
  (constructor), destructor, get/set value of
  attributes (getter/setter) etc. (usually not
  shown in diagrams)
• services associated with message connections
  identify the messages sent to that objects in
  previous steps and add services to handle them
  can be suggested by behavior diagram(s)
• services associated with object relationships
  establish/disconnect the relationships between
  objects (relationships have been identified in
  OOA phase) (e.g. Polyshape has Points gt
  add/remove/change points to polyshape object)
• services associated with attributes protect
  some attributes, modify an attribute only
  together with other attribute, synchronization in
  real-time systems etc.

9
Object services (II)

• Messages are exchanged between objects in order
  to carry out a service.
• Graphical representation
• as member functions in class diagram
• as message connectors in various interaction
  diagrams (Collaboration/Sequence, Communication,
  Interaction etc.)
• Implemented as public member functions
• Example
• dynamic representation see AddSection in the
  Case Study section
• static representation

10
OOD key principles (I)

•
  Motto
  Imitation is the sincerest form of not being
  stupid.
• DEFINITION Design principle A design
  principle is a basic tool or technique that can
  be applied to designing or writing code to make
  that code more maintainable, flexible, or
  extensible.
• Key principles are
• OCP
• DRY
• SRP
• LSP

11
OOD key principles (II)

• (1) The Open-Closed Principle (OCP). Classes
  should be open for extension and closed for
  modification.
• Allowing change, but without modifying existing
  code.
• Use inheritance to extend/change existing
  working code and dont touch working code.
• Example class Shape, method draw
• It offers flexibility.
• OCP can also be achieved using composition.

12
OOD key principles (III)

• (2) The Dont Repeat Yourself Principle (DRY).
  Avoid duplicate code by abstracting out things
  that are common and placing those things in a
  single location.
• No duplicate code gt ONE requirement in ONE
  place!
• This principle can and should be applied
  everywhere (e.g. in Analysis phase dont
  duplicate requirements or features!)
• Code is easier and safer to maintain because we
  have to change only one place.
• Example (Lab 4, class String, methods
  constructor and set)

StringString(const char pch)
if(pch!NULL) str new
char(szstrlen(pch))1 strcpy(str,
pch) else str NULL
sz 0
void Stringset(const char pch)
if(str!NULL) delete str if(pch!NULL)
str new char(szstrlen(pch))1
strcpy(str, pch) else
str NULL sz 0
WRONG!!
13
OOD key principles (IV)

• Solution corrected String class

/private/ void Stringinit(const char pch)
if(pch!NULL) str new
char(szstrlen(pch))1 strcpy(str,
pch) else str NULL
sz 0
StringString(const char pch)
init(pch) void Stringset(const char pch)
if(str!NULL) delete str
init(pch)
GOOOOD!!
14
OOD key principles (V)

• (3) The Single Responsibility Principle (SRP).
  Every object in your system should have a single
  responsibility, and all the objects services
  should be focused in carrying out that single
  responsibility.
• ONLY one reason to change!
• Code will be simpler and easier to maintain.
• Example Container and Iterator (Container
  stores objects Iterator traverses the container)

• Spotting multiple responsibilities.
• Example Automobile class

Follows SRP. Violates SRP.
The Automobile start itself. The Automobile
stop itself. The Automobile changeTires
itself. The Automobile Drive itself. The
Automobile CheckOil itself. The Automobile
GetOil itself.
Automobile Start() Stop() ChangeTires() Drive
() CheckOil() GetOil()
15
OOD key principles (VI)

• Solution corrected Automobile class

16
OOD key principles (VII)

• (4) The Liskov Substitution Principle (LSP).
  Subtypes must be substitutable for their base
  types.
• Well-designed class hierarchies
• Subtypes must be substitutable for their base
  class without things going wrong.
• Example

void f() Board board new 3DBoard //
ok! board-gtgetTile(1,7) // doesnt make
sense for a 3D board

• All member functions of Board are members of
  3DBoard as well (thats inheritance).
• Member functions of Board class, being defined
  for 2D world, dont make sense in the new context
  (3D world)

WRONG VIOLATES LSP!!
17
OOD key principles (VIII)

• Solution use association instead of inheritance

boards

Remark A 3DBoard stores an array of Board
objects. Member functions of 3DBoard use the
functionality of Board, rather than extend it
(delegate responsibilities).
Tile 3DBoardgetTile(int a, int b, int c)
return boardsa.getTile(b, c)
18
Delegation (design pattern)

• DEFINITION Delegation Delegation is handing
  of a task over another object.
• Alternative to inheritance.
• Advantage over inheritance behavior can be
  changed at run-time
• Example

• Delegation is best used when you want to use
  another classs behavior as is, without changing
  that behavior. Example Board, 3DBoard example

class A public virtual void foo()
printf("Object A doing the job.")
class B A a public virtual
void foo() // delegate the task to
object a a.foo()
class B A pa public B(A aa)
pa(aa) virtual void foo()
// delegate the task to object pa
pa-gtfoo() class AA public A
public virtual void foo() printf("AA at
work.")
void f() // A behavior B b1(new A)
b1.foo() // AA behavior B b2(new
AA) b2.foo()
19
Other OOD principles

• Inheritance
• Classes (implementation, representation) tend
  to couple implementation
• Interfaces (functionality) provide a clean
  and powerful way of expressing concepts (and
  relationships between them) without encumbering
  them with impl. details or run-time overheads
• Program to interfaces
• use interfaces (and classes on top of classes
  hierarchies) for objects
• use creational design patterns to create objects
• Achieve new functionalities by combining
  objects
• Encapsulate what varies

20
Class inheritance vs. object composition
Class inheritance (white-box) Object composition (black-box)
Visibility Reuse
Static (compile time) Dynamic (can change at run-time through instantiation)
Easy to understand (and use) Difficult to understand
Breaks encapsulation principle Doesnt break encapsulation principle
Reusing problems Keeps each class encapsulated and focused on one task
Large class hierarchies fewer objects Small class hierarchies more objects

• Example Board, 3DBoard

21
OOD advices
22
Error handling in OO systems

• Exception-handling is not local (i.e. exception
  are thrown in one part of the program and handled
  elsewhere) ? We need a simple, explicit, and
  global strategy.
• Error handling involves a multi-level approach
  each level copes with as many errors as it can
• terminate() used if error handling system is
  corrupted
• unexpected() intended to provide an escape
  when exception-specifications firewall fails
  (function written in other languages dont obey
  to this, implementing locally reliability
  dramatically increases complexity and overhead of
  large programs)
• Use a consistent error handling mechanism
  (based on exceptions) ? we need to convert/adapt
  other mechanism (e.g. based on errno global
  variable, or based on return codes) to the common
  one
• Use hierarchies to handle various types of
  error Advantages easy to understand, avoid
  infinite loops, embodies semantic information in
  types.
• Use resource allocation is initialization and
  other similar techniques to make the code more
  regular.

Stroustrup, 1997 Bjarne Stroustrup The C
Programming Language 3rd Edition, Addison Wesley,
1997 Section 14.9
23
Case study (I)

• Class Diagrams

• This diagram shows that Teacher and Student are
  both subclasses of Person.
• Each Person object contains a name and an
  address.
• Each Teacher object contains a name and an
  address (both inherited from Person) and a title.
• Each Student object contains a name and an
  address (again inherited from Person) and a total
  number of credits received so far.

24
Case study (II)

• Class Diagrams

• These diagrams show the view classes associated
  with the University, Department, Course and
  Section classes.
• The UniversityView class contains a method which
  creates a university window. This window displays
  the Universitys name, address, and phone number.
  It also displays a list of the departments in the
  university.
• The UniversityView class also contains code for
  creating a small dialog where the name of a new
  department can be entered. This dialog is brought
  up by pressing the Add Department button on the
  university window.
• The DepartView class contains a method which
  creates a department window. This window displays
  the departments name. It displays a list of the
  teachers employed by the department. It displays
  a list of the students supervised by the
  department. The last item displayed by the window
  is a list of the courses offered by the
  department. There are buttons on the window for
  adding new teachers, new students, and new
  courses.
• The DepartView class also contains code which
  creates a small dialog where a new courses
  number and title can be entered. This dialog is
  brought up by pressing the Add New Course
  button on the department window.
• The AddSectionView class contains a method for
  creating the AddSection window. This window has
  fields for entering a new sections course
  number, teachers name, days of the week, and
  start and end times. The OK button at the bottom
  is pressed to actually add the section to the
  system. The new section will be assigned the next
  available section number, ie. if the course
  already has sections 1 and 2, then this section
  will get a section number of 3.
• The AddStudentToSectionView class contains
  methods for interacting with a student via a
  touch-tone telephone. The student can enter the
  course number and section number and their name.
• The CourseView class contains a method which
  creates a Course window. This window displays the
  courses title, number, description, and credits.
  This window also displays a list of the sections
  offered.
• The SectionView class contains a method which
  creates a Section window. This window displays
  the sections number, days of the week, and start
  and end times. The window also displays the
  teacher teaching this section and a list of the
  students signed up for this section.

25
Case study (III)

• Collaboration / Sequence Diagrams

• Add Department - this diagram shows how new
  departments are added to the system. The process
  starts by the user pressing the Add Department
  button on the University window. This brings up a
  small dialog where the name of the new department
  can be entered. When the user presses OK, a
  create message is sent to create the new
  Department. This message contains a single
  attribute the name of the new Department.

• Add Section - this diagram shows how a new
  section is added to the system. The process
  starts in the AddSectionView where a course
  number, teachers name, days of the week, and
  start and end times are entered. When the user
  presses the OK button, an addSection message is
  sent to the Department object. This message
  contains all the information entered.
• The Department object receives this message and
  converts the course number to a pointer to the
  Course object so that it can then send a message
  to this Course Object. The teachers name is
  converted to a pointer to the Teacher object.
  Then an addSection message is sent from the
  Department object to the Course object. This
  message contains a pointer to the teacher who is
  teaching the course, the days of the week, and
  the start and end times.
• The Course object receives this message and then
  sends a create message to get this new Section
  object created. This create message contains six
  arguments a pointer back to the Course object
  (needed because all Section objects have links
  back to the associated Course object), a pointer
  to the teacher teaching this Course, the number
  of this Section (computed by the Course object
  since it will know how many Sections have already
  been created), the days of the week, and the
  start and end times. The Course object will get
  back a pointer to this new Section which it
  should add to its list of Sections.
• During the creation of the new Section, an
  addSection message must be sent to the Teacher
  who is teaching the course so that this Teacher
  object can update its list of Sections which it
  is teaching.
• To consider
• How does the CSDept object convert Mary Smith
  to a pointer (t) to the corresponding teacher
  object?
• How does the CSDept object convert 302 to the
  CS302 Course object?

26
Case study (IV)

• Homework

• Complete the design phase (for the following
  functionalities add course, add teacher, add
  student, add student to section, print students
  course list, print teachers section rosters)
• Implement the system in C

27
Further Reading

• McLaughlin, 2006 Brett McLaughlin, Gary
  Pollice, David West Head First Object-Oriented
  Analysis and Design, O'Reilly, 2006 Pages
  376-406
• Sussenbach, 1999 Rick Sussenbach
  Object-oriented Analysis Design (5 Days), DDC
  Publishing Inc, 1999, ISBN 1562439820, Chapter
  13, 14
• Yourdon, 1994 Edward Yourdon
  Object-oriented Systems Design, Prentice-Hall
  International Inc, 1994 Chapter 12, 13, 14
• Stroustrup, 1997 Bjarne Stroustrup The C
  Programming Language 3rd Edition, Addison Wesley,
  1997 Section 12.4 12.6 A OOD case study for
  a user interface hierarchy
