Wild Dolphin Project 11-751 Speech Final Project

• by
• Jiazhi Ou jzou_at_cs.cmu.edu
• Tal Blum blum_at_cs.cmu.edu

2
Outline

• Wild Dolphin Project, Dolphin Speech
• Data, Labeling, Labeling problems
• Previous work
• Models training
• Experiments Results
• Conclusions

3
The Wild Dolphin Project (WDP)

• The Wild Dolphin Project (WDP), founded by Dr.
  Denise Herzing in 1985, is engaged in an
  ambitious, long-term scientific study of a
  specific pod of Atlantic spotted dolphins that
  live 40 miles off the coast of the Bahamas, in
  the Atlantic Ocean. For about 100 days each year,
  Phase I research has involved the photographing,
  videotaping, and audio taping of a group of
  resident dolphins, aiming to learn about their
  lives.
• http//www.wilddolphinproject.org/index.cfm

4
Dolphins Speech

• Dolphins Speech is very different than mans
  speech

• Range of frequencies is wider
• Two mechanisms for producing sound simultaneously
• Directionality of some of the frequencies
• Carried in water
• Can travel large distances

5
Dolphins Speech(2)

• Is used for
• Identification
• Communicating
• Fighting
• Defending
• Courting
• Warning
• Calling
• Hunting

6
Dolphins Speech(3)

• 3 main types
• Whistles
• Signature
• Non-signature
• Clicks
• Spike trains

7
What do we know

• Not much
• We know that each dolphin has a unique whistle
  called signature whistle.
• The signature whistle is similar to those that
  are in close contact with the baby dolphin

8
Data

• 164 files containing sounds of one dolphin whose
  name is known.
• Average file length is 7 sec
• Total data length less than 20 minutes out of
  which about half is silence
• The data does not contain all of the relevant
  frequencies

9
Labeling

• Dolphin Names
• Dolphin ID project
• Pause, Noise, Dolphin Signature Whistles, Dolphin
  Non-Signature whistles.

10
Labeling Problems

• How do we distinguish between those 2 whistles?
• How to distinguish between whistles and
  non-whistles?
• They co-occur
• How to determine the duration of the label?
• Should close labels be labeled as one label?
• This has an effect on the model
• Some signals are weak, probably due to a change
  in the dolphins direction

11
Mapping from Labels to Models
Label Model
d Signature Whistles
dp, md Non-Signature Whistles
click, electnoise, electricnoise, h, H, MachineSpike, s GARBAGE
pau PAUSE (Water)
12
Label Statistics
PAUSE SIGWHISTLE GARBAGE DOLPHIN
occurrences 756 633 13 24
Accumulated time (in secs) 466 320 7.1 11.3
Average time per occurrence 0.6 0.5 0.55 0.47
13
Previous Work

• Dolphin-ID Project by Tanja, Alan and Yue
• Task To identify dolphin ID using their
  signature whistles
• 51 labeled files by Alan
• 13 HMMs 10 for each dolphin DOLPHIN, PAUSE,
  and GARBAGE
• Use Janus to do training and testing
• Try different kinds of features

14
Our Work

• Model Generalized Signature Whistles
• Label More Files
• Create HMMs for signature whistles, non-signature
  whistles, garbage, and pause
• Train and test the HMMs using Janus
• Evaluate the test results with our own method
• Compare different model selections

15
Signal Processing

• Tanja scripts
• Down sampling
• High Pass Filter
• FFT
• LDA

16
HMM Topologies
Signature Whistles
Non-Signature Whistles
Garbage
Pause (Water)
17
Model Selection

• Scheme 1
• Signature Whistles, Non-Signature Whistles,
  GARBAGE, PAUSE
• Scheme 2
• Signature Whistles, GARBAGE, PAUSE
• Scheme 3
• 10 HMMs (one for each dolphin), GARBAGE, PAUSE

18
Evaluation

• We can not use WER here since there are no words,
  just segments.
• The method we used was to compute a confusion
  matrix over hidden states.
• Janus treat silence differently and doesnt show
  silence classification which complicates the
  evaluation.

19
Experiments

• Data
• 162 labeled files were used
• Half of the data for training, half for testing
• Swap the training set and test set
• 162 test results all together
• Features
• The same as those in dolphin-ID project
• Model Selection
• 3 different schemes

20
Results Scheme 1
Sig Non-Sig Garbage Pause
Sig 58 6 18 34
Non-Sig 33 8 37 22
Garbage 77 0 5 18
Pause 31 6 27 34
21
Results Scheme 2
Sig Garbage Pause
Sig 79 9 21
Garbage 52 21 27
Pause 48 14 38
22
Results Scheme 3
Sig Garbage Pause
Sig 91 0.6 8
Garbage 80 10 10
Pause 69 1 30
23
Analysis of Results

• You can only get as good as your labels
• Scheme 3 is the best to align signature whistles
  -- speaker dependent
• Scheme 1 is the worst Not enough data to model
  non-signature whistles and garbage
• Scheme 2 is in the middle speaker independent
• Pause is the most difficult to model It
  contains all different things. We modeled it with
  only 1 state

24
Conclusion

• Analyzing dolphin sounds is quite different than
  analyzing human speech. The methods used have to
  be adjusted to the characteristics of the dolphin
  sounds.
• There is a lot of work to be done in the signal
  processing stage
• Partly supervised training
• It might be better just to construct a model for
  the labels we are sure and let the model learn
  what are signature whistles or units that
  discriminate between different labels.

25
We also tried

• One-state model for non-signature whistles,
  garbage, and pause
• -- Segmentation fault in training
• Loop back model for signature whistles
• -- The loop back transition makes no difference

26
Acknowledgement

• Tanja Schultz
• Yue Pan
• Alan W Black
• Szu-Chen Stan Jou
• Hua Yu

27
Thank You!

• Jiazhi Ou
• Tal Blue
• jzou, tblum_at_cs.cmu.edu
