Superscalar Processors by

1
Superscalar Processors by

• Sherri Sparks

2
Overview

1. What are superscalar processors?
2. Program Representation, Dependencies, Parallel
   Execution
3. Micro architecture of a typical superscalar
   processor
4. A look at 3 superscalar implementations
5. Conclusion The future of superscalar processing

3
What are superscalars and how do they differ
from pipelines?

• In simple pipelining, you are limited to fetching
  1 single instruction into the pipeline per clock
  cycle. This causes a performance bottleneck.
• Superscalar processors overcome the 1 instruction
  per clock cycle limit of simple pipelines and
  possess the ability to fetch multiple
  instructions during the same clock cycle. They
  also employ advanced techniques like branch
  prediction to ensure an uninterrupted stream of
  instructions.

4
Development History of Superscalars

• Pipelining was developed in the late 1950s and
  became popular in the 1960s.
• Examples of early pipelined architectures are the
  CDC 6600 and the IBM 360/91 (Tomasulos
  algorithm)
• Superscalars appeared in the mid to late 1980s

5
Instruction Processing Model

• Need to maintain software compatibility.
• The assembly instruction set was the level chosen
  to maintain compatibility because it did not
  affect existing software.
• Need to maintain at least a semblance of a
  sequential execution model for programmers who
  rely on the concept of sequential execution in
  software design.
• A superscalar processor may execute instructions
  out of order at the hardware level, but execution
  must appear sequential at the programming
  level.

6
Superscalar Implementation

• Instruction fetch strategies that simultaneously
  fetch multiple instructions often by using branch
  prediction techniques.
• Methods for determining data dependencies and
  keeping track of register values during execution
• Methods for issuing multiple instructions in
  parallel
• Resources for parallel execution of many
  instructions including multiple pipelined
  functional units and memory hierarchies capable
  of simultaneously servicing multiple memory
  references.
• Methods for communicating data values through
  memory through load and store instructions.
• Methods for committing the process state in
  correct order. This is to maintain the outward
  appearance of sequential execution.

7
From Sequential to Parallel

• Parallel execution often results in instructions
  completing non sequentially.
• Speculative execution means that some
  instructions may be executed when they would not
  have been executed at all according to the
  sequential model (i.e. incorrect branch
  prediction).
• To maintain the outward appearance of sequential
  execution for the programmer, storage cannot be
  updated immediately. The results must be held in
  temporary status until the storage us updated.
  Meanwhile, these temporary results must be usable
  by dependant instructions.
• When its determined that the sequential model
  would have executed an instruction, the temporary
  results are made permanent by updating the
  outward state of the machine. This process is
  called committing the instruction.

8
Dependencies

• Parallel Execution introduces 2 types of
  dependencies
• Control dependencies due to incrementing or
  updating the program counter in response to
  conditional branch instructions.
• Data dependencies due to resource contention as
  instructions may need to read / write to the same
  storage or memory locations.

9
Overcoming Control Dependencies Example

• L2 mov r3,r7
• lw r8,(r3)
• add r3,r3,4
• lw r9,(r3)
• ble r8,r9,L3
• move r3,r7
• sw r9,(r3)
• add r3,r3,4
• sw r8,(r3)
• add r5,r5,1
• L3 add r6,r6,1
• add r7,r7,4
• blt r6,r4,L2
• Blocks are issued are initiated into the window
  of execution.

Block 1
Block 2
Block 3
10
Control Dependencies Branch Predicition

• To gain the most parallelism, control
  dependencies due to conditional branches has to
  be overcome.
• Branch prediction attempts to overcome this by
  predicting the outcome of a branch and
  speculatively fetching and executing instructions
  from the predicted path.
• If the predicted path is correct, the speculative
  status of the instructions is removed and they
  affect the state of the machine like any other
  instruction.
• If the predicted path is wrong, then recovery
  actions are taken so as not to incorrectly modify
  the state of the machine.

11
Data Dependencies

• Data dependencies occur because instructions may
  access the same register or memory location
• 3 Types of data dependencies or hazards
• RAW (read after write) occurs because a later
  instruction can only read a value after a
  previous instruction has written it.
• WAR (write after read) occurs when an
  instruction needs to write a new value into a
  storage location but must wait until all
  preceding instructions needing to read the old
  value have done so.
• WAW (write after write) occurs when multiple
  instructions update the same storage location it
  must appear that these updates occur in the
  proper sequence.

12
Data Dependency Example

• mov r3,r7
• lw r8,(r3)
• add r3,r3,4
• lw r9,(r3)
• ble r8,r9,L3

RAW
WAW
WAR
13
Parallel Execution Method

1. Instructions are fetched using branch prediction
   to form a dynamic stream of instructions
2. Instructions are examined for dependencies and
   dependencies are removed
3. Examined instructions are dispatched to the
   window of execution (These instructions are no
   longer in sequential order, but are ordered
   according to their data dependencies.
4. Instructions are issued from the window in an
   order determined by their dependencies and
   hardware resource availability.
5. Following execution, instructions are put back
   into their sequential program order and then
   committed so their results update the machine
   state.

14
Superscalar Microarchitecture

• Parallel Execution Method Summarized in 5 phases
• 1. Instruction Fetch Branch Prediction
• 2. Decode Register Dependence Analysis
• 3. Issue Execution
• 4. Memory Operation Analysis Execution
• 5. Instruction Reorder Commit

15
Superscalar Microarchitecture
16
Instruction Fetch Branch Prediction

• Fetch phase must fetch multiple instructions per
  cycle from cache memory to keep a steady feed of
  instructions going to the other stages.
• The number of instructions fetched per cycle
  should match or be greater than the peak
  instruction decode execution rate (to allow for
  cache misses or occasions where the max of
  instructions cant be fetched)
• For conditional branches, fetch mechanism must be
  redirected to fetch instructions from branch
  targets.
• 4 steps to processing conditional branch
  instructions
• 1. Recognizing that in instruction is a
  conditional branch
• 2. Determining the branch outcome (taken or not
  taken)
• 3. Computing the branch target
• 4. Transferring control by redirecting
  instruction fetch (as in the case of a taken
  branch)

17
Processing Conditional Branches

• STEP 1 Recognizing Conditional Branches
• Instruction decode information is held in the
  instruction cache. These extra bits are used to
  identify the basic instruction types.

18
Processing Conditional Branches

• STEP 2 Determining Branch Outcome
• Static Predictions (information determined from
  static binary). Ex Certain opcode types might
  result in more branches taken than others or a
  backwards branch direction might be more likely
  in loops.
• Predictions based on profiling information
  (execution statistics collected during a previous
  run of the program).
• Dynamic Predictions (information gathered during
  program execution about past history of branch
  outcomes). Branch history outcomes are stored in
  a branch history table or a branch prediction
  table.

19
Processing Conditional Branches

• STEP 3 Computing Branch Targets
• Branch targets are usually relative to the
  program counter and are computed as
• branch target program counter offset
• Finding target addresses can be sped up by having
  a branch target buffer which holds the target
  address used the last time the branch was
  executed.
• EX Branch Target Address Cache used in PowerPC
  604

20
Processing Conditional Branches

• STEP 4 Transferring Control
• Problem Thee is often a delay in recognizing a
  branch, modifying the program counter and
  fetching the target instructions.
• Several Solutions
• Use the stockpiled instructions in the
  instructions buffer to mask the delay
• Use a buffer that contains instructions from both
  taken and not taken branch paths
• Delayed Branches Branch does not take effect
  until instruction after the branch. This allowed
  the fetch of target instructions to overlap
  execution of the instruction following the
  branch. The also introduce assumptions about
  pipeline structure and therefore delayed branches
  are rarely used anymore.

21
Instruction Decoding, Renaming, Dispatch

• Instructions are removed from the fetch buffers,
  decoded and examined for control and data
  dependencies.
• Instructions are dispatched to buffers associated
  with hardware functional units for later issuing
  and execution.

22
Instruction Decoding

• The decode phase sets up execution tuples for
  each instruction.
• An execution tuple contains
• An operation to be executed
• The identities of storage elements where input
  operands will eventually reside
• The locations where an instructions result must
  be placed

23
Register Renaming

• Used to eliminate WAW and RAW dependencies.
• 2 Types
• Physical register file is larger than logical
  register file and a mapping table is used to
  associate physical register values with logical
  register values. Physical registers are assigned
  from a free list.
• Reorder Buffer Uses the same size physical and
  logical register files. There is also a reorder
  buffer that contains 1 entry per active
  instruction and maintains the sequential ordering
  of instructions. It is a circular queue
  implemented in hardware. As instructions are
  dispatched they enter the queue at the tail. As
  instructions complete, their results are inserted
  into their assigned locations in the reorder
  buffer. When an instructions reaches the head of
  the queue, its entry is removed and its result
  placed in the register file.

24
Register Renaming I
25
Register Renaming II(using a reorder buffer)
26
Instruction Issuing Parallel Execution

• Instruction issuing is defined as the run-time
  checking for availability of data and resources.
• Constraints on instruction issue
• Availability of physical resources like
  instruction units, interconnect, and register
  file
• Organization of buffers holding execution tuples

27
Single Queue Method

• If there is no out of order issuing, operand
  availability can be managed via reservation bits
  assigned to each register.
• A register is reserved when an instruction
  modifying the register issues.
• A register is cleared when the instruction
  completes.
• Instructions may issue if there are no
  reservations on its operands.

28
Multiple Queue Method

• There are multiple queues organized according to
  instruction type.
• Instructions issue from individual queues in
  sequential order.
• Individual queues may issue out of order with
  respect to one another.

29
Reservation Stations

• Instructions issue out of order
• Reservation stations hold information about
• source operands for an operation.
• When all operands are present, the instruction
  may issue.
• Reservation stations may be partitioned according
  to instruction type or pooled into a single large
  block.

30
Memory Operation Analysis Execution

• To reduce latency, memory hierarchies are used
  may contain primary and secondary caches.
• Address translation to physical addresses is
  improved by using a translation lookaside
  buffer which contains a cache of recently
  accessed pages.
• Multiported memory hierarchy is used to allow
  multiple memory requests to be serviced
  simultaneously. Multiporting is achieved by
  having multiple memory banks or making multiple
  serial requests during the same cycle.
• Store address buffers are used to make sure
  memory operations dont violate hazard
  conditions. Store address buffers contain the
  addresses of all pending store operations.

31
Memory Hazard Detection
32
Instruction Reorder Commit

• When an instruction is committed, its result is
  allowed to modify the logical state of the
  machine.
• The purpose of the commit phase is to maintain
  the illusion of a sequential execution model.
• 2 methods
• 1. The state of the machine is saved in a
  history buffer. Instruction update the state of
  the machine as they execute and when there is a
  problem, the state of the machine can be
  recovered from the history buffer. The commit
  phase gets rid of the history state thats no
  longer needed.
• 2. The state of the machine is separated into a
  physical state and a logical state. The physical
  state is updated in memory as instructions
  complete. The logical state is updated in a
  sequential order as the speculative status of
  instructions is cleared. The speculative state is
  maintained in a reorder buffer and during the
  commit phase, the result of an operation is moved
  from the reorder buffer to a logical register or
  memory.

33
The Role of Software

• Superscalars can be made more efficient if
  parallelism in software can be increased.
• 1. By increasing the likelihood that a group of
  instructions can be issued simultaneously
• 2. By decreasing the likelihood that an
  instruction has to wait for the result of a
  previous instruction

34
A Look At 3 Superscalar Processors

1. MIPS R10000
2. DEC Alpha 21164
3. AMD K5

35
MIPS R10000

• Typical superscalar processor
• Able to fetch 4 instructions at a time
• Uses predecode to generate bits to assist with
  branch prediction (512 entry prediction table)
• Resume cache is used to fetch not taken
  instructions and has space to handle 4 branch
  predictions at a time
• Register renaming uses a physical register file
  2x the size of the logical register file.
  Physical registers are allocated from a free list
• 3 instruction queues memory, integer, and
  floating point
• 5 functional units (an address adder, 2 integer
  ALUs, a floating point multiplier / divider /
  square rooter, floating point adder)
• Supports on-chip primary data cache (32 KB, 2 way
  set associative) and an off-chip secondary cache.
• Uses reorder buffer mechanism to maintain machine
  state during execptions.
• Instructions are committed 4 at a time

36
Alpha 21164

• Simple superscalar that forgoes the advantage of
  dynamic scheduling in favor of a high clock rate
• 4 Instructions at a time are fetched from an 8K
  instruction cache
• 2 instruction buffers that issue instructions in
  program order
• Branches are predicted using a history table
  associated with the instruction cache
• Uses the single queue method of instruction
  issuing
• 4 functional units (2 ALUs, a floating point
  adder, and a floating point multiplier)
• 2 level cache memory (primary 8K cache
  secondary 96 K 3way set associative cache)
• Sequential machine state is maintained during
  interrupts because instructions are not issued
  out of order
• The pipeline functions as a simple reorder buffer
  since instructions in the pipeline are maintained
  in sequential order

37
Alpha 21164 Superscalar Organization
38
AMD-K5

• Implements the complex Intel x86 instruction set
• Use 5 pre-decode bits for decoding variable
  length instructions
• Instructions are fetched from the instruction
  cache at a rate of 16 bytes / cycle placed in a
  16 element queue.
• Branch prediction is integrated with the
  instruction cache. There is 1 prediction entry
  per cache line.
• Due to instruction set complexity, 2 cycles are
  required to decode
• Instructions are converted to ROPS (simple risc
  like operations)
• Instructions read operand data are dispatched
  to functional unit reservation stations
• There are 6 functional units 2 integer ALUs, 1
  floating point unit, 2 load/ store units a
  branch unit.
• Up to 4 ROPs can be issued per clock cycle
• Has an 8K data cache with 4 banks. Dual load/
  stores are allowed to different banks.
• 16 entry reorder buffer maintains machine state
  when there is an exception and recovers from
  incorrect branch predictions

39
AMD K5 Superscalar Organization
40
The Future of Superscalar Processing

• Superscalar design performance gain
• BUT increasing hardware parallelism may be a case
  of diminishing returns.
• There are limits to instruction level parallelism
  in programs that can be exploited.
• Simultaneously issuing more instructions
  increases complexity and requires more cross
  checking. This will eventually affect the clock
  rate.
• There is a widening gap between processor and
  memory performance
• Many believe that the 8-way superscalar is the
  limit and that we will reach this limit within 2
  years.
• Some believe VLIW will replace superscalars and
  offers advantages
• Because software is responsible for creating the
  execution schedule, the size of the instruction
  window that can be examined for parallelism is
  larger than a superscalar can do in hardware
• Since there is no dependence checking by the
  processor VLIW hardware is simpler to implement
  and may allow a faster clock.

41
Reference

• The Microarchitecture of Superscalar Processors
  by James E. Smith, IEEE and Gurindar S. Sohi,
  senior member, IEEE

42

• ?
