Quantifying Cardiac Deformation by strain
(-rate) imaging
Hans Torp Department of Circulation and Medical
Imaging Norwegian University of Science and
Technology Norway
2
Quantifying Cardiac Deformation by strain
(-rate) imaging

• Describe deformation by strain and strain rate
• Ultrasound methods for strain rate
• speckle tracking versus Doppler methods
• Clutter noise and thermal noise
• angle dependency
• Frame rate issues
• Visualization of strain and strain-rate

3
(No Transcript)
4
Velocity gradient strain rate
V2 V1 L
Velocity gradient
Rate of deformation Strain Rate
V2
L
V1
(Myocardial) velocity gradient is an
instantaneous property
5
Integrated velocity gradientversus strain
Growth function Strain exp IVG - 1
6
Integrated velocity gradientversus strain
7
Envelope
8
What is the best velocity estimator?
velocity angle(R)
Rx1?x2
s2
x2
s1
x1
Autocorrelation method is optimal (Maximum
likelihood estimator)
RF signals
IQ signals
9
What is the best velocity estimator?
vc/4piT angle(R)
Rx1?x2
10
Estimation error is minimumwhen correlation is
maximum
Velocity estimate
Correlation magnitude
11
Estimate of velocity gradient (strain rate)
0.03
0.025
0.02
Velocity m/sec
0.015
0.01
0
0.005
0.01
0.015
depth range mm
12
Simulation experimentStrain rate estimators
Linear regression
Strain rate
Weighted Linear regression (Maximun likelihood)
Simulation no
13
Clutter noise
14
Clutter noise

• bias towards zero for velocity measurements
• increased variance for strain rate

• Clutter filter helps when tissue velocity is high
• limited effect in apical region
• Second harmonic (octave) imaging reduces clutter
• independent of tissue velocity

15
Fundamental and second harmonic signal separated
by filter
50
100
150
200
250
300
350
400
450
20
40
60
80
100
Fundamental
Signal from septum
Noise from LV cavity
16
Second Harmonic TDI
Fundamental, f1.67MHz

• Fundamental and second harmonic calculated from
  the same data set
• No significant noise difference
• Second harmonic TDI gives more aliasing.

Second harmonic, f3.33MHz
17
Second Harmonic SRI

• Fundamental and second harmonic calculated from
  the same data set
• Significant noise reduction when using the second
  harmonic frequency band
• Aliasing is not a problem due to small velocity
  differences

18
Frame rate issues in tissue velocity and strain
rate imaging

• Packet acquisition
• 30 - 80 frames/sec

Packet acquisition tissue interleaving 100 - 150
frames/sec
Continuous acquisition tissue interleaving 250 -
350 frames/sec - TVI aliasing Offline
spectral Doppler (Work in progress)
Image sector 70 deg. Parallell beams 2
19
Packet acquisition - continuous acquisition
20
Myocardial velocity and strain ratewith 300
frames/sec
Velocity
Strain rate
Time
21
Lateral movement
22
Angle corrected strain
23
Summary 1

• Strain rate from Tissue Doppler is possible for
  motion along the ultrasound beam with high
  temporal resolution
• Weighted linear regression gives minimum
  estimation error
• Second harmonic Tissue Doppler reduce clutter
  noise artefacts in strain rate imaging

24
Summary 2

• Integrated strain is improved by tracking
  material points
• 2D speckle-tracking gives angle-independent
  strain, with reduced temporal resolution
• A combination of high frame rate tissue Doppler
  and lower frame rate speckle tracking is probably
  the best solution for strain imaging
• 3D reconstruction of strain (-rate) covering the
  left ventricle can be obtained from 3 standard
  apical views
