Glenn Paulley

1
Self-management featuresin SQL Anywhere server

• Glenn Paulley
• Director, Engineering
• http//iablog.sybase.com/paulley

2
Sybase iAnywhere products

• SQL Anywhere
• Full-function, small-footprint relational DBMS
  with support for triggers, stored procedures,
  materialized views, intra-query parallelism, hot
  failover, ANSI SQL 2003 support including OLAP
  queries, multidatabase capability
• Mobilink/SQL Remote
• Two-way data replication/synchronization
  technologies for replicating data through
  different mechanisms to support
  occasionally-connected devices
• Ultralite
• fingerprint database supports ad-hoc SQL on
  very small devices
• UltraliteJ
• 100 Java fingerprint database for Blackberry and
  iPhone

3
Design goals of SQL Anywhere

• Ease of administration
• Comprehensive yet comprehensible tools
• Good out-of-the-box performance
• Embeddability features ? self-tuning
• Many environments have no DBAs
• Cross-platform support
• 32- and 64-bit Windows (XP, Server, 2003, 2000,
  9x), Windows CE/Pocket PC, Linux 32- and 64-bit,
  HP-UX, AIX, Solaris (SPARC and Intel), Mac OS/X,
  Compaq Tru-64
• Interoperability

4
Why is self-management important?

• In a word complexity
• Application development is becoming more complex
  new development paradigms such as ORM toolkits,
  distributed computation with synchronization
  amongst database replicas, and so on
• Databases are now ubiquitous in IT because they
  solve a variety of difficult problems
• Yet most companies continue to own and manage a
  variety of different DBMS products, which
  increases administrative costs
• Ubiquity brings scale, in several ways
• To keep TCO constant, one must improve the
  productivity of each developer

5
Embeddability
6
Physical database design
7
Physical database design

• Logical and physical database design tradeoffs
  have a significant impact on performance
• The fundamental problem is that the potential
  benefits of design changes must be amortized over
  the execution characteristics of a workload
• Representative workloads are difficult to create
• Issues include data skew, correlation, mitigating
  artificial contention that occurs as a result of
  simulating the actual system
• Most DBMS vendors now offer tools to assist in
  index or materialized view creation (more on this
  later)
• However, not all implications are covered by any
  of these tools

8
Physical database design with SQL Anywhere

• A SQL Anywhere database is composed of up to 15
  dbspaces
• Each dbspace is an OS file
• One each used for temporary file, transaction log
• Others are for user data
• UNIX raw partitions are not supported
• Image copy is done via simple OS file copy
• No image copy utility is necessary
• Easy to deploy a database to a separate machine
  or CE device
• Files are interoperable on all supported
  platforms without user intervention
• on-the-fly data conversion done when necessary

9
Physical database design

• By default, databases are created with
• Case-insensitive searching enabled
• Not blank-padded no difference in the storage of
  CHAR vs. VARCHAR attributes on the disk
• SQL Anywhere supports different character sets,
  collations for international contexts
• Includes support for NCHAR data type using
  multi-byte UTF8 charset
• Supported page sizes are 2K, 4K, 8K, 16K, 32K
• All dbspaces must use the same page size
• No hard limits on row length, number of BLOB
  columns
• BLOB values (up to 2GB each) stored in separate
  page arena

10
Physical database design

• Database files grow automatically as necessary to
  accommodate any increase in data volume
• Server can execute a user call-out procedure when
  a disk-full panic occurs
• Server offers a temporary file governor to ensure
  that connections cannot be starved when they
  require space for intermediate results
• Indexes on primary, foreign keys created
  automatically
• Server will automatically detect redundant
  (duplicate or subsumed) indexes
• two or more logical indexes share the same
  physical structure

11
Physical database design

• Transaction log
• SQL Anywhere uses a logical logging and recovery
  scheme at the row level (not physiological, or
  page-based)
• Transaction log can be translated directly into
  INSERT, UPDATE, DELETE SQL statements
• DBTRAN utility ships with the software
• Assists in recovery from catastrophic failures
• Provides the backbone for two-way synchronization
  with Mobilink, SQL Remote

12
Self-management features
13
Memory management

• SQL Anywhere uses a single heterogeneous buffer
  pool with few predefined limits
• Buffer pool can automatically grow and shrink
  depending on database workload and OS
  requirements for other applications
• Buffer pool comprises
• Table data pages
• Index pages
• Checkpoint log pages
• Bitmap pages
• Heap pages (data structures for connections,
  stored procedures, triggers)
• Free (available) pages
• All page frames are the same size

14
Page replacement scheme

• Buffer pool has no preset bounds for sort space,
  heap space, table pages
• Buffer pools page replacement scheme must be
  able to manage various categories of pages and
  requests on a demand basis
• Workloads change over time periods
• Static configurations must tradeoff service
  levels for administrative effort
• One basic requirement avoid polluting the cache
  with the results of pages from sequential scans
• Identify pages that are frequently used

15
Page replacement scheme

• Pages flow through the buffer pool over time
• Window (the size of the cache) is stratified into
  eight segments based on time of reference
• A pages score is incremented as it moves from
  segment to segment
• Need to differentiate reference locality (ie
  multiple references to a single page based on row
  fetch) from other forms of reuse
• Replacement based on individual page score
• A modified Clock algorithm goes through each
  page in turn if a pages score is less than a
  threshold value, page is reused
• If page is retained, score is decayed
• LRU-k and 2Q algorithms are frequently referenced
  in the literaturehowever we have found their
  overheads to be too high

16
Task scheduling model

• Basic idea reduce server resource requirements
  by establishing a limited pool of worker
  threads to execute requests
• Reduces address space, virtual and real memory
  requirements
• Introduces possibility of thread deadlock
• Task implementation differs depending on the
  platform fibers are used on Windows and Linux
  platforms
• Scheduler assigns work across a pool of workers
• Worker thread pool typically small, default is 20
• Size of pool establishes the multiprogramming
  level
• Workers are assigned dynamically to connections
  on demand

17
Task scheduling model

• Unassigned requests wait for an available thread
• Server uses cooperative multitasking to switch
  between requests
• Server supports intra-query parallelism
• With queries, optimizer determines degree of
  parallelism at optimization time

18
Task scheduling model

• Waiting requests are candidates for swapping
• Try to maintain constant memory footprint by
  using a virtual memory technique
• Heaps for user connections can be swapped to
  disk if server load demands it
• Originally implemented in the first SQL Anywhere
  release in 1989
• Pointers within the heap are swizzled to permit
  reloading of heaps on a demand basis
• Diagnostic connections can use a special,
  reserved thread to execute its requests
• Enables diagnosis of a hung engine

19
Dynamic memory management

• A SQL Anywhere server will grow and shrink the
  buffer pool as necessary to accommodate both
• Database server load
• Physical memory requirements of other
  applications
• Enabled by default on all supported platforms
• User can set lower, upper bounds, default initial
  size
• OS provides API to determine memory size
  (requires virtual memory support)
• Implementation varies slightly by platform

20
Dynamic memory management

• Basic idea match buffer pool size to operating
  systems working set size
• Feedback control loop

21
Memory allocation to server threads

• Query optimizer assumes the availability of an
  amount of available memory for each computation
• Some execution operators (notably hash-based
  operators) have the ability to free memory
  without changing the computation (just making it
  less efficient)
• Release of memory is done partition-at-a-time so
  effect is not abrupt
• Other operators can be constructed with
  alternative plans that offer a cheaper execution
  technique if either
• the optimizers choices are found to be
  suboptimal at run-time, or
• the operator requires a low-memory strategy at
  the behest of the memory governor

22
Other self-management features

• On startup, buffer pool is automatically loaded
  with those database pages that were first
  requested on the last startup
• SQL Anywhere supports events
• fired on a schedule, or when specific server
  events occur, such as
• Idle time greater than a threshold
• Backup
• Connect/disconnect
• File size
• Disk space

23
Self-tuning query optimization

• and adaptive query execution strategies

24
Automatic statistics management

• A feature of SQL Anywhere since 1992
• Early implementations used a hash-based structure
  to manage column density and frequent-value
  statistics
• See Lynch, 14th VLDB (1988) for a similar
  approach
• Today
• Self-tuning column histograms
• On both base and temporary tables
• Statistics are updated on-the-fly automatically
• Join histograms built for intermediate result
  analysis
• Server maintains index statistics in real-time
• Index sampling during optimization

25
Column histograms

• Self-tuning implementation
• Incorporates both standard range buckets and
  frequent-value statistics
• Updated in real-time with the results of
  predicate evaluation and update DML statements
• By default, statistics are computed during the
  execution of every DML request
• Novel technique used to capture statistics on
  strings for use in optimizing LIKE predicates
• Histograms computed automatically on LOAD TABLE
  or CREATE INDEX statements
• Can be created/dropped explicitly if necessary
• But retained by default across unload/reload

26
Query optimizer

• SQL Anywhere optimizes requests each time they
  are executed
• Optimizer takes into account server context
• Working set
• Available cache
• Values of procedure, host variables
• Assumption optimization is cheap
• SQL Anywhere uses a proprietary, cost-based join
  enumeration algorithm that primarily constructs
  left-deep trees
• Optimization process includes both heuristic and
  cost-based complex rewritings
• Advantages plans are responsive to server
  environment, buffer pool contents/size, data
  skew no need to administer packages

27
Join enumeration

• Optimization space is over left-deep trees
• Optimization process includes both heuristic and
  cost-based complex rewritings
• Exceptions for complex, right-deep nested LEFT
  OUTER JOINS
• Space pruning based on a governor that
  allocates quota to different portions of the
  search space
• Join method, degree of parallelism, physical scan
  method (index selection), and expensive predicate
  evaluation are also part of search space
• Each choice is re-evaluated at each step
• Superb optimization times even for complex
  queries
• No hard limits tested with
• 500 quantifiers in a single block
• 100-way join on a CE device with 3MB buffer pool

28
Bypassing the query optimizer

• Simple, single-table queries are optimized
  heuristically
• Access plans for queries in stored
  procedures/triggers/events are cached
• Plans undergo a training period where plan
  variance is determined
• If no variance (even without variable values),
  plan is cached and reused
• Query is periodically re-optimized on a
  logarithmic scale to ensure plan does not become
  sub-optimal

29
Adaptive query processing

• In some cases the optimizer will generate
  alternative access plans that can be executed if
  actual intermediate result sizes are poorly
  estimated
• Server switches to alternative plan automatically
  at run time
• Memory-intensive operators, such as hash join,
  have low-memory strategies that are used when
  buffer pool utilization is high

30
Adaptive query processing

• Some operations, such as database backup, contain
  sampling processes to determine the
  characteristics of the I/O device used for
  storage
• Primary goal is to determine the number of disk
  heads available
• Processes can utilize the right number of CPUs
  to maximize throughput
• Algorithms are sensitive to CPU requirements of
  the rest of the system, and automatically scale
  down CPU usage as necessary

31
Intra-query parallelism

• SQL Anywheres approach is to parallelize a
  left-deep plan when doing so is advantageous
• There is an upper bound to the number of EXCHANGE
  operators in a data-flow tree can be set by the
  user to override
• Work is partitioned independently of the
  availability of worker threads at run-time
• Plans are largely self-tuning with respect to
  degree of parallelism
• Prevents starvation of any specific subplan when
  the number of available workers is less than
  optimal for some period

32
Management tools
33
Management tools

• Framework
• DBISQL interactive SQL query tool
• Sybase Central administration/development tool
• Tools
• Graphical query plans
• Stored procedure debugger
• Stored procedure profiler
• Index consultant
• Request-level logging
• Optimization logging

34
Graphical query plans
35
Stored procedure debugger

• Enables debugging of a PSM or Java stored
  procedure
• Features
• set/unset breakpoints and watch settings
• determine value of variables
• traverse the call stack
• execute queries with the values of variables at
  the time of the break

36
Application Profiling scenarios
37
Application Profiling architecture
38
Stored procedure profiler

• Offers the ability to analyze the performance of
  a stored procedure/trigger/event
• Computes the cumulative invocations and elapsed
  time for each statement in a procedure

39
Index consultant

• Recommends indexes to improve query performance
• Main idea is to improve application performance
• Particularly useful when DBA has limited
  experience
• Permits what-if analysis on an existing query
  load and database instance
• Allows DBA to find statements that are the most
  sensitive to the presence of an index
• Can be used to find indexes that are unnecessary,
  i.e. those that are not utilized by the optimizer
• Can be used to estimate disk storage overhead of
  additional indexes

40
Future plans

• Increasingly difficult to keep optimization costs
  low in the face of increasingly more challenging
  workloads
• Tradeoff time for space (cached access plans)
• Advantages of plan caching are workload-specific
  caching expense pays off only if optimization
  costs can be amortized over several executions
• Improve statistics, cost model management to
  permit self-repair, which will improve access
  plan quality
• Numerous other opportunities for self-tuning
  using feedback control mechanisms
• Memory allocation, multiprogramming level,
  intra-query parallelism controls, additional
  adaptive query optimization techniques
• Integrate server internals management with VM
  hypervisors to improve operation within guest VMs
