On the Criteria to Be Used in Decomposing Systems into Modules

1
On the Criteria to Be Used in Decomposing Systems
into Modules

• Group 1
• Lisa Anthony, Erik Hayes,
• Luiza Helena da Silva, and Diana Tetelman

2
Summary

• Modular decomposition should focus more on
  information hiding than related functionality
• This formulation should be an early design
  decision
• Module interfaces should provide only means to
  accessing internal information
• Evaluate decomposition through change assessment
• Hierarchical and modular breakdown are independent

3
Compiler Phases/Processes/DataStructures

• Symbol Table ? Data structure containing a record
  for each identifier, with fields for the
  attributes of the identifiers.
• Lexical Analyzer ? Reads the characters in the
  source program and groups them into a stream of
  tokens in which each token represents a
  logically cohesive sequence of characters, such
  as an identifier, and keyword. Uses Symbol
  Table.
• Syntax Analyzer ? Imposes a hierarchical
  structure on the token stream, which can be
  portrayed with a syntax tree.
• Semantic Analyzer ? Checks the syntax tree for
  semantic errors and gathers type information for
  the subsequent code-generation phase.
• Intermediate Code Generation ? Generates an
  intermediate form of the program. This form is
  very simple but not as low level as assembly
  code.
• Code Optimizer ? Optimizes the intermediate form
  of the program.
• Code Generator ? Generates the actual target
  code, consisting of assembly code.

4
Decomposition Criterion Data Flow
Source Program
Lexical Analyzer
Syntax Analyzer
Symbol-table Manager
Error Handler
Semantic Analyzer
Intermediate Code Generator
Code Optimizer
Code Generator
Target Program
5
Decomposition Criterion Data Hiding
Semantic Analyzer
Code Optimizer
Syntax Tree
Intermediate Code Generator
Lexical Analyzer
SyntaxTree Generator
Intermediate Code
Code Generator
Symbol-table Manager
I/O Manager
6
Rationale for Data Flow Design

• In the FLOW diagram design, the break down of the
  modules is based simply on the data flow.
• This decomposition criterion creates an
  architecture that is very similar to the
  contemporary model of the pipe-and-filter design
  pattern.
• Source Program file is fed right into the Lexical
  Analyzer, and the Target Program file is created
  directly by the Code Generator.

7
Rationale for Data Hiding Design

• In this design, the criterion used was data
  hiding, much like what Parnas attempted to
  demonstrate in his second breakdown of the KWIC
  program.
• The objects are fairly independent. They also
  perform their own error handling.
• Functions that use the same Data Structures were
  combined under a common object to reinforce the
  Data Hiding Theme.
• I/O was combined into an object.

8
How are they similar? Different?

• Similarities
• Achieve same end result
• Order of execution of processes still
  predetermined
• Differences
• Tools operate on internal representation (not
  text of program)
• Hybrid repository pipeline (from lecture)
• Versions may be identical in execution, but not
  in changing, documentation, understanding, and
  maintenance

9
Design Differences

• Pipeline
• flowchart idea
• each module heavily dependent on previous
• outdated
• Hybrid
• information hiding
• each module has its own design decisions hidden
  from the others
• modularization lends itself to encapsulation/reuse

10
Why is the Hybrid Better? Changeability

• Make design decisions based on what is likely to
  change
• Hybrid allows changes to
• Data representation/Abstraction (symbol table
  mechanism/parse tree)
• Future flexibility in order of execution?
• Reuse of modules for parsers of other languages

11
Why is the Hybrid Better? Independent Development

• Reduce interfaces between modules to decrease
  discussion among developers of different modules
  about required formatting and function call
  conventions
• Hybrid
• Each module depends only on symbol table
  (pipeline does not know id of
  upstream/downstream filters)
• Sequence of processing does not affect
  development of successful modules

12
Why is the Hybrid Better? Comprehensibility

• Modules must be able to stand alone
• New developer/maintainer should not have to learn
  entire system to change one piece of code
• Hybrid allows
• Effective minimal interfaces mean learning
  internal representation of symbol table not
  necessary for any parse module
• Symbol table implementation does not depend on
  order of execution or other module processing

13
Historical Content in Present Context

• Paper is 30 years old, but only some details
  might make this fact apparent
• Terminology
• Previous concerns
• Past design processes (flowcharts)
• Changing guidelines
• Code reuse (not a major point)

14
Terminology
Parnas uses some terms that are not used anymore,
or are used nowadays with different meanings,
such as - CORE Then main memory, general
storage space Now internal functionality,
internals - JOB Then Implied batch
processing Now ??? - Nowadays, we speak of
memory in a more abstract way (data structures,
etc). Memory was more often understood as
referring to physical storage (addresses,
records)
15
Previous Concerns

• Parnas mentions as major advancements in the
  area of modular programming
• The development of ASSEMBLERS
• Nowadays, we could mention higher level
  languages, mainly object-oriented languages that
  better
• (1) allow one module to be written with little
  knowledge of the code in another module, and
• (2) allow modules to be reassembled and replaced
  without reassembly of the whole system

16
Past Design Processes

• Use of flowcharts
• When paper was written, the use of flowchart by
  programmers before was almost mandatory. With a
  flowchart in hands, the programmer would move
  from there to a detailed implementation. This
  caused modularizations like the first one to be
  created.
• Parnas could see the problem with this approach
  and condemned it A flowchart would work ok for a
  small system, but not with a larger one.

17
Changing Guidelines

• The sequencing of instructions necessary to call
  a given routine and the routine itself are part
  of the same module.
• This pertain to worries of programmers at the
  time because they were programming in assembly
  and other low-level languages. Concerns such as
  code optimization were very important and
  involved creating smaller sets of machine
  instructions for a given task.
• The sequence in which certain items will be
  processed should be hidden within a single
  module.
• It has become irrelevant most times.

18
Code Reuse

• Parnas does not emphasize code reuse so much in
  this paper. The reason might be the nature of
  programs written in assembly or lower-level
  languages programmers (not very
  portable/reusable).
• If the paper were to be reviewed by Parnas,
  reuse would certainly be a point he would
  emphasize more.
• It is important to notice that these points do
  not disturb the relevance of Parnas ideas for us
  nowadays.

19
Effects on Current Programming

• Fathered key ideas of OOP
• Information hiding
• Encapsulation before functional relations
• Easier understandability/maintainability
• Design more important than implementation
• Good design leads to good implementation
• Proper design allows for different
  implementations (easily modifiable)

20
Effects Continued

• Separation of hierarchy and modularization
• Hierarchy allows functional layers
• Modules do not have to be layers in order to be
  placed in a hierarchy
• Evolution of more complex and capable systems
