Chapter 2: Networking Standards and the OSI Model

1
Chapter 2 Networking Standards and the OSI
Model
Network Guide to Networks
2
Networking Standards Organizations

• Standards are documented agreements containing
  technical specifications
• ANSI (American National Standards Institute) is
  an organization composed of more than a thousand
  representatives from industry and government who
  together determine standards for the electronics
  industry and other fields, such as chemical and
  nuclear engineering, health and safety, and
  construction

3
Networking Standards Organizations (continued)

• ANSI also represents the United States in setting
  international standards
• EIA (Electronic Industries Alliance) is a trade
  organization composed of representatives from
  electronics manufacturing firms across the United
  States

4
Networking Standards Organizations (continued)

• TIA (Telecommunications Industry Association)
  Focuses on standards for information technology,
  wireless, satellite, fiber optics, and telephone
  equipment
• TIA/EIA alliance are its guidelines for how
  network cable should be installed in commercial
  buildings, known as the TIA/EIA 568-B Series.

5
Networking Standards Organizations (continued)

• IEEE (Institute of Electrical and Electronics
  Engineers), or I-triple-E, is an international
  society composed of engineering professionals
• IEEE goals are to promote development and
  education in the electrical engineering and
  computer science fields

6
Networking Standards Organizations (continued)

• ISO (International Organization for
  Standardization), headquartered in Geneva,
  Switzerland, is a collection of standards and
  organizations representing 148 countries
• ISOs goal is to establish international
  technological standards to facilitate global
  exchange of information and barrier-free trade

7
Networking Standards Organizations (continued)

• The ITU (International Telecommunication Union)
  is a specialized United Nations agency that
  regulates international telecommunications,
  including radio and TV frequencies, satellite and
  telephony specifications, networking
  infrastructure, and tariffs applied to global
  communications

8
Networking Standards Organizations (continued)

• ISOC (Internet Society), founded in 1992, is a
  professional membership society that helps to
  establish technical standards for the Internet
• ISOC oversees groups with specific missions, such
  as the IAB and IETF

9
Networking Standards Organizations (continued)

• IAB (Internet Architecture Board) is a technical
  advisory group of researchers and technical
  professionals interested in overseeing the
  Internets design and management
• IETF (Internet Engineering Task Force), the
  organization that sets standards for how systems
  communicate over the Internetin particular, how
  protocols operate and interact

10
Networking Standards Organizations (continued)

• IANA and ICANN
• Every computer / host on a network must have a
  unique address
• Internet Assigned Numbers Authority (IANA) kept
  records of available and reserved IP addresses
  and determined how addresses were issued out
• Internet Corporation for Assigned Names and
  Numbers (ICANN), a private, nonprofit corporation
  and is now ultimately responsible for IP
  addressing and domain name management

11
The OSI Model

• In the early 1980s, ISO began work on a universal
  set of specifications that would enable computer
  platforms across the world to communicate openly
• This model, called the Open Systems
  Interconnection (OSI) Model, divides network
  communications into seven layers

12
The OSI Model (continued)
13
The OSI Model (continued)

• Application Layer
• Separates data into protocol data units (PDUs)
• Application layer PDUs progress down through OSI
  Model layers 6, 5, 4, 3, 2, and 1
• Data traverses the network until it reaches the
  second computers Physical layer
• Transfer of information happens in milliseconds

14
The OSI Model (continued)
15
The OSI Model (continued)

• Application Layer
• Does not include software applications, such as
  Microsoft Word or Netscape
• Services communicate between software programs
  and lower-layer network services
• File, print, message, database, and application
  services

16
The OSI Model (continued)

• Application Layer
• World Wide Web (WWW)
• Email - SMTP (Simple Mail Transport Protocol or
  the X.400)

17
The OSI Model (continued)
18
The OSI Model (continued)
19
The OSI Model (continued)

• Presentation Layer
• Protocols at the Presentation layer accept
  Application layer data and format it
• Serves as a translator and are the standards
  which are involved in multimedia
• Presentation layer protocols perform the coding,
  compression and also manage data encryption and
  decryption

20
The OSI Model (continued)

• Session Layer
• Protocols in the Session layer coordinate and
  maintain communications between two nodes
• Session refers to a connection for ongoing data
  exchange between two parties

21
The OSI Model (continued)

• Session Layer (continued)
• Session layers functions are establishing and
  keeping alive the communications link for the
  duration of the session
• Keep the communication secure
• Synchronizing the dialog between the two nodes
• Determining whether communications have been cut
  off, and, if so, figuring out where to restart
  transmission and terminating communications

22
The OSI Model (continued)

• Transport Layer
• Protocols in the Transport layer accept data from
  the Session layer and manage end to-end delivery
• Ensures that the data is transferred from point A
  to point B reliably, in the correct sequence, and
  without errors

23
The OSI Model (continued)

• Transport Layer (continued)
• Without Transport layer services, data could not
  be verified or interpreted by its recipient
• Handles flow control
• Some Transport layer protocols take steps to
  ensure that data arrives exactly as it was sent.

24
The OSI Model (continued)

• Transport Layer (continued)
• Such protocols are known as connection-oriented,
• TCP is one example of a connection-oriented
  protocol
• Three Step Process
• Request (Client sends)
• Acknowledgment (ACK)
• Client Acknowledgement (ACK)

25
The OSI Model (continued)

• Transport Layer (continued)
• Checksum method of error checking
• Connectionless protocols
• Process is known as segmentation
• Necessary for data units to match a networks
  maximum transmission unit (MTU)

26
The OSI Model (continued)

• Transport Layer (continued)
• Reassembly
• Sequencing
• Identifying segments that belong to the same
  group

27
The OSI Model (continued)
28
The OSI Model (continued)
29
The OSI Model (continued)

• Network Layer
• Primary function of protocols at the Network
  layer
• Translate network addresses
• Decide how to route data
• Network layer addresses
• Also called logical addresses or virtual
  addresses

30
The OSI Model (continued)

• Network Layer (continued)
• Routers belong in the Network layer
• Perform Fragmentation

31
The OSI Model (continued)
32
The OSI Model (continued)

• Data Link Layer
• Primary function of protocols is to divide data
  into distinct frames that can then be transmitted
  by the Physical layer
• IEEE has divided the Data Link layer into two
  sublayers
• Logical Link Control (LLC)
• Media Access Control (MAC)

33
The OSI Model (continued)
34
The OSI Model (continued)

• Physical Layer
• Lowest, or first, layer of the OSI Model
• Protocols at the Physical layer
• Accept frames from the Data Link layer
• Generate voltage so as to transmit signals
• Receiving data detect voltage and accept signals
• Pass on to the Data Link layer

35
Applying The OSI Model
36
Applying The OSI Model (continued)

• Communication Between Two Systems
• At each layer of the OSI Model, some information
  is added to the original data

37
Applying The OSI Model (continued)
38
Applying The OSI Model (continued)

• Frame Specifications
• Two major categories of frame types
• Ethernet
• developed at Xerox in the early 1970s
• Token Ring
• developed by IBM in the 1980s

39
IEEE Networking Specifications

• Project 802
• Effort to standardize physical and logical
  elements of a network
• Frame types and addressing
• Connectivity,
• Networking media,
• Error checking algorithms,
• Encryption,

40
IEEE Networking Specifications (continued)

• Project 802 (continued)
• Emerging technologies,
• And more
• Can be applied to the layers of the OSI Model

41
IEEE Networking Specifications (continued)
42
Chapter Summary

• Standards are documented agreements containing
  precise criteria
• Significant standards organizations
• ANSI, EIA/TIA, IEEE, ISO, ITU, ISOC, IANA, and
  ICANN

43
Chapter Summary (continued)

• Excellent model for understanding communications
• Protocols in the Application layer, the seventh
  layer of the OSI Model, enable software programs
  to negotiate

44
Chapter Summary (continued)

• Protocols in the Presentation layer, the sixth
  OSI Model layer, serve as translators between the
  application and the network

45
Chapter Summary (continued)

• Protocols in the Session layer, the fifth OSI
  Model layer,
• coordinate and maintain links between two devices

• synchronize dialog
• Primary function of protocols in the Transport
  layer, the fourth OSI Model layer, is to oversee
  end-to-end data delivery

46
Chapter Summary (continued)

• Protocols in the Network layer, the third OSI
  Model layer, manage logical addressing and
  determine routes

47
Chapter Summary (continued)

• Network layer addresses, also called logical or
  virtual addresses, are assigned to devices
  through operating system software
• Primary function of protocols at the Data Link
  layer, the second layer of the OSI Model, is to
  organize data they receive from the Network layer
  into frames

48
Chapter Summary (continued)

• Data Link layer is subdivided into the Logical
  Link Control and MAC sublayers
• LLC sublayer ensures a common interface
• MAC sublayer is responsible for adding physical
  address data to frames
• Protocols at the Physical layer generate and
  detect voltage

49
Chapter Summary (continued)

• Protocols at the Physical layer generate and
  detect voltage

50
Chapter Summary (continued)

• Data request from a software program is received
  by the Application layer protocols and is
  transferred down through the layers of the OSI
  Model until it reaches the Physical layer
• Data frames are small blocks of data with
  control, addressing, and handling information
  attached to them

51
Chapter Summary (continued)

• Data request from a software program is received
  by the Application layer protocols and is
  transferred down through the layers of the OSI
  Model until it reaches the Physical layer
• Data frames are small blocks of data with
  control, addressing, and handling information
  attached to them

52
Chapter Summary (continued)

• In addition to frame types and addressing
  schemes, the IEEE Networking Specifications apply
  to connectivity, networking media, error checking
  algorithms, encryption, emerging technologies,
  and more
• Significant 802 standards are 802.3, which
  describes Ethernet 802.5, which describes Token
  Ring and 802.11, which describes wireless
  networking
