Hot Isostatic Pressing Technology for Indian Test Blanket Module Fabrication

1
Hot Isostatic Pressing Technology for Indian Test
Blanket Module Fabrication
Dr. G. Appa Rao
Defence Metallurgical Research Laboratory
Kanchanbagh PO, Hyderabad-500058, India.
Email gouduapparao_at_rediffmail.com
22 July 2008.
2
Introduction

• Selection of appropriate materials and
  fabrication technologies for various components
  for fusion reactors relies on trade-off between
  multiple requirements which are mainly driven by
• Economic
• Safety and
• Environmental effects

• Materials
• Martensitic steels
• Non-Ferrous alloys
• Ceramics
• Vanadium alloys
• SiC/SiC Composites
• Ti and Cr alloys

• Fabrication Technologies
• Cutting and machining
• Special welding techniques
• Investment casting
• Hot isostatic pressing (HIP)

3
Significance of HIP Technology

• Implementation and joining of F/M steels are an
  important
• goal due to the complex geometry of the
  blanket modules.
• Necessity for reducing the leak level and
  maintenance.
• Advanced techniques based on solid or powder
  HIP are to
• be established

4
Principles of Isostatic Pressing
Pascals Law
5
(No Transcript)
6
Hot Isostatic Pressing

• HIP is a an innovative thermal treatment
  process subjects the
• material / component to a combination of
  high pressure and
• elevated temperature
• HIP results in near theoretical density,
  uniform microstructure
• and consistent mechanical properties

HIPing Parameters Temperature 0.7 - 0.9
Tm Pressure 100-200 MPa Time
2- 4 h.
7
Details of HIP Equipment
8
Densification Mechanisms of HIPing

• Particle rearrangement
• Plasticity
• Power-law creep and
• Volume and grain boundary diffusion

9
Stages of HIP Densification
10
HIP Diagrams
11
Applications of HIP Technology

• Cladding
• Diffusion Bonding
• Consolidation of Encapsulated Powder
• Densification of Metal castings
• Specialized Applications
• Medical Implants
• HIP of ultra fine Tungsten Carbide Cobalt Hard
  Metals
• Rejuvenation of Deteriorated Components
• Formation and Control of Pores
• Joining of Fusion Reactor Components

12
Cost Reduction Potential for a Selected Group of
Superalloy Parts
13
CIP and HIP Facilities at DMRL
(200 Dia. X 600 HT.) mm 400 MPa
(100 Dia. X 200 HT.) mm, 200 MPa 1450, 2000 ºC
(650 Dia. X 1200 HT.) mm, 200 MPa 1450ºC
(270 Dia. X 990 HT.) mm, 200 MPa 1450ºC
14
HIPing of Stainless Steel Powder
G. Appa Rao and M.Kumar, Mater.Sci. and Technol.
1997
15
Potential of HIP for Complex Shapes
16
HIP Diffusion Bonding of Materials

• Advantages
• Similar and dissimilar material can be joined
• Complex shape can be joined easily
• Original microstructure remains intact
• ODS and FRM can be joined
• Joint integrity is better than that of
  conventional one

• Material forms for HIP bonding
• Powder-powder
• Powder-solid
• Solid -solid

17
Microstructure of HIP Diffusion Bonded Materials
G. Appa Rao et. al, DMRL TR2000265 (2000)
18
Mechanical Properties of HIP Diffusion Bonded
Alloys
Failure did not occur at the joint
19
P/M(HIP) Diffusion Bonded Hardware (DMRL)
Prototype thrust chamber clouseout
Ni-base superalloy components
20
Overview of Blanket Module Fabrication (Literature
)

• Reduced Activation Ferritic Martensitic (RAFMA)
  steel is the
• structural material for TBMs
• Fabrication concepts rely on plates with
  internal cooling channels

Main technologies for fabrication of TBMs

• Cutting and machining of semi finished products
• Joining of parts to produce the plates with
  internal channels
• Bending of cooling plates
• Heat treatment to improve the structure and
  properties

21
Configuration Details of Blanket Module
22
First Wall Fabrication Procedures
(a) Two-Step HIPing Method

• Involves machined grooved plates
• Use of Mo- alloy massive stiffening /
  supporting plates between
• the encapsulation and the FW/CP plates
• HIPing at low pressure to achieve bonding at
  the Interface
• Removal of encapsulation and Mo plates and
  drilling of channels
• The FW is further HIPed at high pressure to
  achieve full bonding
• Heat treatment, testing and evaluation

23
(b) Single High Pressure HIPing Method / HIP
forming Process

• Involves insertion of round tubes in the
  rectangular grooves
• Ends of the tubes are welded to the plates but
  the tubes are not closed
• During HIPing, the tubes expand and conform to
  the grooves
• Mo- alloy supporting plates are not required
• Heat treatment, testing and evaluation.

24
(c) Rectangular Tube (RT) Process

• Involves diffusion welding of RTs. and cover
  plates
• HIPing to improve the joint integrity
• No need for stiffening plates
• There is a scope for bending the RTs. and cover
  plates before HIPing.
• Heat treatment, testing and evaluation

25
FW mock up manufactured by HIP forming ( top
parts before HIP bottom mock up after HIP,
bending and marching.
26
Conclusions

• Fabrication of test blanket modules (TBMs) is a
  technologically
• challenging task
• Hot isostatic pressing (HIP) is a promising
  technology for
• fabrication of TBMs
• Considerable expertise on several aspects of HIP
  technology is
• available at DMRL to address various issues
  in this
• field
• Study on development of prototype TBM
  components can be
• taken up with the existing infrastructure.

27
Thank you
