Review of Autumn 2006 WLRN Educational Proficiency Testing Exercise

1
Review of Autumn 2006 WLRN Educational
Proficiency Testing Exercise

• November 8, 2006
• Carol Kirk
• Laboratory Network Coordinator
• Wisconsin State Laboratory of Hygiene
• Phone [phone]
• Email cjk_at_mail.slh.wisc.edu

2
WLRN Proficiency Testing Notification/Shipping
Exercises

• Exercises provided twice a year subset of
  laboratories follow notification/shipping
  protocol
• Each exercise is followed by an audioconference
• Participation in exercises is voluntary, not
  connected to any regulatory agencies
• Individual results are not shared with anyone
  other than the participating laboratory
• Purpose of exercises
• Practice rule out testing
• Identify gaps in emergency lab response system
• Practice assess notification transport.

3
Autumn 2006 WLRN Educational Proficiency Testing
Exercise

• 2 samples sent to 135 labs
• 107 reported test results (79)
• 15 chose not to participate
• 13 did not respond
• Sample BPE 06-2-1
• Acinetobacter baumannii
• Sample BPE 06-2-2
• Haemophilus influenzae
• Samples intended to simulate Francisella
  tularensis and Brucella spp. in rule out testing

4
Results of Rule out Tests
5
Results of Rule out Tests (cont.)
6
Results of Rule out Tests
7
Results of Rule out Tests
8
Results of Rule out Tests
9
Results of Rule out Tests
10
Emergency Laboratory Response Exercise
Combining with PT seems to cause problem with
return
11
Emergency Laboratory Response Exercise
Of participants each year - most notified WSLH
of intended referral
12
Emergency Laboratory Response Exercise
Most participants each year used Dunham Express
for transport to WSLH
13
Emergency Laboratory Response Exercise
Time from 24/7 notification to receipt of
sample 2004 15 notified 24/7 2005 20
notified 24/7 2006-1 12 notified 24/7 2006-2
11 notified 24/7
14
Emergency Laboratory Response Exercise
Number of participants that used class 6.2
shipper for commercial or USPS transport.
15
Emergency Laboratory Response Exercise
Number of participants that completely sealed
primary container for transport.
16
Emergency Laboratory Response Exercise
Number of participants that addressed the package
to WSLH Rapid/Emergency Response
17
Emergency Laboratory Response Exercise
Correct Address Label (per WERG
instructions) Rapid Response
BT/CT/Outbreak Wisconsin State Laboratory of
Hygiene -Communicable Diseases 465 Henry
Mall Madison, WI 53706 - Circle BT on the
label if bioterrorism-related, - Circle CT
on the label if chemical terrorism-related, -
Circle Outbreak on the label if
outbreak-related.
18
Emergency Laboratory Response Exercise

• LHD Shipper Repository Use
• 4 labs used a shipper from a local health
  department (LHD) shipper repository
• Still concerns about after-hours access and ease
  of access.
• WSLH will provide emergency shippers to
  laboratories that indicated they want them on the
  survey.

19
Thank you to all the participating laboratories!
20
Dave Warshauer, Ph.D., D(ABMM) Deputy
Director Communicable Disease Division WSLH Phone
[phone] E-mail warshadm_at_slh.wisc.edu
21
REMIND/REFRESH/THINK
Brucella spp. Francisella tularensis Bacillus
anthracis Yersinia pestis Others
RARE ISOLATES IN THE CLINICAL LABORATORY
22
BRUCELLOSIS

• A zoonotic disease caused by any of 4 Brucella
  sp. abortus, melitensis, suis, and canis
• B. melitensis most common
• A systemic infection characterized by an undulant
  fever pattern
• But relatively rare in the U.S. with
  approximately 100 cases/yr

23

• Brucellosis in the U.S.,1930-1990
• Public Health Success Story

1. National elimination program started
2. Strain 19 vaccine for cattle
3. Mandatory herd testing
4. Revitalization
24
MMWR vol. 53, no. 53, 2006
25
MMWR vol. 53, no. 53, 2006
26
BRUCELLOSISTRANSMISSION

• Unpasteurized dairy products
• The most common mode of transmission
• Direct skin contact
• Occupational hazard for farmers, butchers,
  veterinarians, and laboratory personnel
• Aerosols
• Highly infectious (Infective Dose 10-100 organisms

27
Infectious Dose
Bacteria Dose Route of Inoculation F.
tularensis 10 inhalation C.
burnetii 10 inhalation M.
tuberculosis lt10 inhalation Brucella
spp. 10-100 inhalation S. typhi 105
ingestion F. tularensis 108
ingestion
28
Clinical Manifestations

• Fever
• Chills
• Weight loss
• Night sweats

• Headache
• Muscle aches
• Fatigue
• depression

29
Brucella spp.Specimen Selection

• Blood or bone marrow
• Sources from which Brucellae are most often
  isolated
• Tissue (spleen, liver)
• Brucellae occasionally isolated
• Serum
• The diagnosis of brucellosis is frequently
  achieved by serology. An acute convalescent
  phase specimen should be collected (21d apart)

30
REVIEW OF THE WLRNBIOTERRORISM
PROFICIECYEXERCISE
November 8, 2006
Rule Out or Refer - Brucella spp.
- Franciscella tularensis
Raymond P. Podzorski, Ph.D., D(ABMM) Clinical
Microbiologist Department of Pathology Oconomowoc
Memorial Hospital Waukesha Memorial Hospital
30
31
Culture Brucella spp.
Blood Incubate for 10 days in automated systems
and perform terminal subcultures at 7 days (hold
plates for 7 days, seal plates) Blood Incubate
for 21 days in non-automated broth blood Cultures
with blind subcultures every 7 days (hold plates
for 7 days, seal plates) Tissue inoculate BAP,
Choc, and MacConkey (EMB) and incubate for 7
days at 35? C with 5-10 CO2, in humidity (seal
plates)
32
Growth Characteristics Brucella spp.
Sheep Blood Agar, 35? C 24 Hours - colonies very
small, haze in area of original
inoculum 48 Hours - colonies are tiny, white,
convex, non-hemolytic, moist, and
glistening Grows on Chocolate agar, Martin-Lewis
agar, Thayer- Martin agar, BCYE, and some strains
grow on MacConkey agar
33
Brucella spp. on Sheep Blood Agar at 48 Hours
34
Brucella spp. Gram Stain
fine sand appearance on Gram stain
35
Brucella spp. Handling
Working with Suspected Specimens Do all work
with specimen in a hood using BSL-2
practice Culture plates should be
sealed Working with Suspected Isolates Do all
work with the culture in a hood using BSL-3
practice Do not attempt to set up automated or
semi-automated ID You dont want to be
sniffing the plates Culture plates should be
sealed
36
Screening Colonies for Brucella spp.
Gram stain - tiny gram negative (fine sand)
coccobacilli Growth sheep blood agar (poor),
chocolate agar X V Factors not required for
growth on SBA Oxidase Positive Catalase
Positive Urease Positive
Cannot rule out Brucella spp. CONTACT WSLH OR
REFER TO LRN REFERENCE LABORATORY
37
LRN Reference Laboratory Tests for Brucella spp.
Conventional culture and biochemical
identification PCR based identification Time-res
olved fluorescence Tbilisi phage susceptibility
test Slide agglutination Serological testing of
the suspected patient
38
Francisella tularensis
39
Reported Cases of Tularemia-1990-1998
40
MMWR vol. 53, no. 53, 2006
41
Francisella tularensis---Epidemiology

• Summer peak
• June - August
• December peak
• Occupational risks
• Laboratory workers
• farmers
• veterinarians
• hunters
• meat handlers
• 75 male

42
Clinical Manifestations

• Ulceroglandular 70-80
• Papule developing into a tender ulcer
• Localized lymphadenopathy
• Glandular 3-20
• No ulcer present
• Oculoglandular 1
• Oropharyngeal 0-12
• Pneumonic 7-20
• Typhoidal (Septicemic) 5-30

43
Ulceroglandular Disease
Ulcer on scalp
Hand Ulcer
44
Transmission

• Handling carcasses or skin of infected animals
• Rodents,
• Rabbits
• Beavers and muskrats
• Insect vectors
• Ticks
• Deerflies
• Waterborne

45
F. tularensis
F. tularensis most common (F.
philomiragia) Specimen exposure/risk skin
lesion exudates, respiratory
secretions, CSF, tissue Have been identified as
Haemophilus influenzae Actinobacillus
spp. Pasteurella multocida
46
Culture F. tularensis
Serological testing is the most common method for
diagnosing Tularemia. Media most strains
require cysteine or cystine and the preferred
media was glucose-cysteine blood agar. Skin
lesions, respiratory specimens, tissue
inoculate BAP, Chocolate, and MacConkey
(EMB) Incubate for 7 days at 35? C with 5-10
CO2, in humidity (seal plates)
47
Growth CharacteristicsFranciscella tularensis
Sheep Blood Agar - 35? C, fastidious, grows
poorly or not at all, if it does grow
on SBA, small colonies, gray-white,
non- or ?-hemolytic may grow
initially on SBA, but fail to grow on
a SBA subculture Chocolate Agar - 24-48 hours,
if growth, colonies very small, haze in
area of original inoculum - 72 hours,
colonies are 1-2 mm, blue-gray to, light
gray, flat, smooth, and shiny
Grows on Thayer-Martin agar, BCYE
48
Francisella tularensis on sheep blood agar at 48
hours
49
Franciscella tularensis on chocolate agar at 72
hours
50
Gram stain of Francisella tularensis
51
F. Tularensis Handling
Working with Suspected Specimens Do all work
with specimen in a hood using BSL-2
practice Plates should be sealed Working with
Suspected Isolates Do all work with the culture
in a hood using BSL-3 practice Do not attempt to
set up automated or semi-automated ID You dont
want to be sniffing the plates Plates should
be sealed
52
Screening Colonies for F. tularensis
Gram stain tiny, faintly staining, gram
negative coccobacilli Growth
sheep blood agar (no growth or poor growth)
chocolate agar, BCYE, cysteine-supplemented
agar after 48 to 72 hours X V
Factors not required for growth on SBA Oxidase
Negative Catalase Weak Positive Urease
Negative
Cannot rule out F. tularensis CONTACT WSLH OR
REFER TO LRN REFERENCE LABORATORY
53
LRN Reference Laboratory Tests for F. tularensis
Conventional culture and biochemical
identification PCR based identification Time-res
olved fluorescence Direct fluorescent antibody
testing of isolate Slide agglutination Serologic
al testing of the suspected patient
54
Organism Test catalase
oxidase urea XV gram stain F.
tularensis (w) - -
- tiny ccb Brucella spp.
- tiny ccb Pasteurella
spp. v -
rod, ccb Acinetobacter sp. -
v - fat ccb Psychrobacter phenyl
pyruvicus -
fat ccb Actinobacillus spp. v
- rod, ccb Oligella
sp. -
tiny ccb Bordetella bronchiseptica
- rod,
ccb Haemophilus influenzae v
v ccb
wweak, ccbcoccobacilli, vvariable
55
Brucella/Franciscella
KEEP THESE ORGANISMS IN MIND VERY UNCOMMON IN
WISCONSIN THREE IN ONE WEEK? SOMETHING IS
UP RULE OUT OR REFER DO NOT WORK UP THESE
ORGANISMS
