Transparency Masters for Software Engineering: A Practitioner's Approach, 4e

1
The Road Ahead

• 2003. 12. 5(?)
• ???? ??? ???
• ?? ??? ??? ???

2
Contents
1. Overview 2. The Importance of
Software-Revisited 3. The Scope of Change 4.
People and The Way They Build systems 5. The
New Software Engineering Process 6. New Modes
for Representing Information 7. Technology as a
Driver 8. Concluding Comment
3
Overview

• Some issues to consider when trying understand
  how software and software engineering will change
  in the future
• Predicting future trends in any field requires
  collecting data, organizing it, looking for
  subtle associations to extract knowledge, and
  using this knowledge to suggest probable future
  occurrences
• A short-term prediction may or may not prove to
  be true and yet, may still be true in the long
  term

4
An Information Spectrum
5
Conversion of Hardware
Reduced instruction
set computers
Extremely high-bandwidth
communication
high-density optical/
?
magnetic storage
massively parallel
?
machines
?
Optical processors
network
?
molecular computers
architectures
mobile computing
?
?
optoelectronic
advanced RISC
devices
machines
advanced
information retrieval
?????
??
????
5
10
15
6
Conversion of Software
7
Importance of Software(1/2)

• Software as a differentiator (products, systems,
  services, competitive advantages in the
  marketplace)
• Software generates valuable information
  (programs, documents, data)
• Mechanism for automating business, industry, and
  government

8
Importance of Software(2/2)

• Medium for transferring new technologies
• Means of capturing people's expertise for use by
  others
• Software is a hidden technology, embedded in
  daily activities and used without customers
  thinking about it

9
Scope of Change(1/2)

• Changes in computing over the past 50 years have
  been driven by advances in the hard sciences
  (physics, chemistry, materials science,
  engineering)
• During the next several decades changes in
  computing are likely to be driven by the soft
  sciences (human psychology, biology,
  neurophysiology, sociology, philosophy)

10
Scope of Change(2/2)

• Changes in software engineering will be
  influenced by
• ? people who do the work
• ? processes they apply
• ? nature of information
• ? underlying computer technology

11
People Systems Construction(1/2)

• Systems are becoming more complex, requiring
  larger programs and more people involved in their
  construction
• Communications between individual software
  engineers and between specialized teams working
  on the same project will need to be improved to
  avoid losing information

12
People Systems Construction(2/2)

• The evolution of intelligent agents may change
  the work patterns of software engineers by
  extending the capabilities of software tools
• The World Wide Web has made many changes in the
  ways that people acquire and access knowledge

13
New Software Engineering Process(1/3)

• The first two decades of software engineering
  were characterized by linear thinking, yet linear
  systems development runs contrary to the ways in
  which most software systems are actually built
• Evolutionary process models recognize that
  uncertainty dominates most development activities

14
New Software Engineering Process(2/3)

• Modern development time lines are impossibly
  short, iterative delivery of partial products
  provides crucial functionality when complete
  product delivery is not possible
• The Capability Maturity Model provides a good
  indicator about what attributes should exist when
  solid software engineering is practiced
• Object technologies coupled with component-based
  software engineering are a natural outgrowth of
  the evolutionary process model trend

15
New Software Engineering Process(3/3)

• Customer involvement early in the design process
  is likely to be observed more frequently
• Rapid growth in Web-based applications
  development is changing both the software
  engineering process and its participants

16
New Modes for Representing Information (1/2)

• Data processing has been replaced by the term
  information technology
• Emphasis is shifting from managing large
  quantities of data to extracting meaningful
  information from data

17
New Modes for Representing Information (2/2)

• Knowledge engineering techniques may begin
  migrating form the artificial intelligence
  laboratories to the application domain as people
  seeks ways to associate information from more
  than one context
• Software systems may be viewed in the future as
  systems the extract knowledge from data and
  information (many knowledge bases have already
  been created)

18
Technology as a driver(1/3)

• Historically hardware has served as the
  technology driver in computing
• A new hardware technology provides potential
• So, Software builders demand in an attempt to tap
  the potential

19
Technology as a driver(2/3)

• Road ahead for H/W technology
• ? H/W technology will continue to evolve at a
  rapid pace
• ? Nontraditional H/W architecture may cause
  radical changes in the kind of S/W
• Road ahead for S/W engineering is driven by S/W
  technologies
• as reuse, component-based S/w

20
Technology as a driver(3/3)

• Many kinds of venders
• ? build discrete devices (reusable software
  component)
• ? build system components (set of tools for
  human/computer
• interaction
• ? build system integrators that provide
  solutions for the end-user
• Regardless of how radical the changes are, we can
  be assured that quality will never lose its
  importance

21
A concluding Comment
22
The Past, Present, and Future of S/W Process
Improvement
Stephen E. Cross????? ???? ??????????? 2003?
4?
23
Contents
1. Software Process Basics 2. Survey of Process
Modeling Approaches 3. Industry Adoption 4.
Globalization 5. Evolving Standards 6. Related
Trends 7. Future Trends
24
Software Process Basics (1/2)

• A process
• A sequence of steps, actions, or activities that
  members of an organization perform to achieve a
  goal
• Capability Maturity Models (SW-CMM)
• Judging the maturity of the software processes of
  an organization and for identifying the key
  practices that are required to increase the
  maturity of these processes

25
Software Process Basics (2/2)

• Capability Maturity Models
• Become a standard for assessing and improving
  software processes
• Process areas
• Identify the issues that must be addressed to
  achieve a maturity level
• Defined to reside at a single maturity level

26
Software Process Basics

• Structure of CMM
• Maturity Levels
• A layered framework providing a progression to
  the discipline needed to engage in continuous
  improvement
• Key Process Areas
• Key process area (KPA) identifies a cluster of
  related activities that, when performed
  collectively, achieve a set of goals considered
  important

27
Software Process Basics

• Structure of CMM (Cont.)
• Goals
• The goals of a key process area summarize the
  states that must exist for that key process area
  to have been implemented in an effective and
  lasting way
• Common Features
• Common features include practices that implement
  and institutionalize a key process area
• Key Practices
• The key practices describe the elements of
  infrastructure and practice that contribute most
  effectively to the implementation and
  institutionalization of the key process areas

28
Survey of Process Modeling Approaches (1/2)

• SPICE (Software process Improvement and
  Capability Determination)
• A major international initiative to support the
  development of an International Standard for
  Software Process Assessment
• Three principal goals
• To develop a working draft for a standard for
  software process assessment
• To conduct industry trials of the emerging
  standard.
• To promote the technology transfer of software
  process assessment into the software industry
  world-wide

29
Survey of Process Modeling Approaches (2/2)

• Bootstrap (based CMM)
• Provides some more detailed capability profiles
  that organizations can use to identify important
  areas for further improvement
• ISO 9000 series
• TickIT
• British Department of Industry and Trade
• Software quality Assurance
• TickIT Guide

30
Industry Adoption

• Boeing (Maturity Level 3)
• The productivity of projects increased by 62
• Cycle time improved by 36
• Boeing Space and Transportation Systems (Lv5)
• Defects are nearly all found and fixed
• Reduced from 11 to 0 for escaping into the
  field
• While peer reviews increase total project costs
  by 4, rework during testing is reduced by 31
• Lockheed martin (military aircraft)
• Manassas Owego (Lv5)
• Errors have declined productivity has increased
  by 80 percent
• Performance measures have improved
• Productivity gains of 452.9 between 1982 and
  2000
• Motorola

31
Globalization

• Every organization in the world must be concerned
  with software quality
• An example of how adoption of S/W process
  improvement methods can help organizations
• Indian software companies professionals
• Managing director of Phoenix Global Solutions
  India
• Its almost shameful for them to admit they are
  a Level 2 company or that they didnt get ISO
  9000 certification
• Indian S/W firms achieved Lv3 or Lv4 in formal
  CMM
• S/W development costs are about one-third in the
  U.S.
• But, disappear in three to five years

32
Evolving Standards

• ISO/IEC 12007 in 1995
• The processes for acquiring, developing,
  supplying, operating, and maintaining S/W
• IEEE/EIA 12207
• Provide an architecture of the full S/W life
  cycle, including product conception,
  implementation, maintenance, and S/W retirement
• Specifies the processes, activities, and tasks
  during the life cycle
• ISO/IEC 15504
• An emerging international standard on S/W process
  assessment
• Defines a number of S/W engineering processes

33
Related Trends

• Two significant trends during the past few years
• First A proliferation of process models
• CMM Integration (CMMI)
• Second A strong desire to accelerate the time
• Personal Software Process (PSP)
• Team Software Process (TSP)
• Extreme Programming

34
Related Trends

• CMM Integration (CMMI)
• SEI develop additional CMM approaches in other
  disciplines
• Systems Engineering CMM (SE-CMM)
• Integrated Product Develop CMM (IPD-CMM)
• Organizational and project management processes
• The development of multiple CMM was greeted
• Ideally
• Should work together harmoniously for the benefit
  of organizations
• Be repeated Training, assessments and improvement
  activities

35
Related Trends

• CMM Integration (CMMI) (Cont.)
• CMMI for Systems Engineering and S/W Engineering
  (CMMI-SE/SW)
• CMMI for Systems E S/W E IPPD
  (CMMI-SE/SW/IPPD)
• CMMI for Systems E S/W E IPPD Supplier
  Sourcing
• CMMI for Software Engineering (CMMI-SW)
• CMMI product
• CMMI models, a framework, training materials, and
  assessment methods
• Example Lockheed Martin
• Apply the highest standards of engineering
  excellence to all procests
• Korea Securities Computer Corp. is Lv3

36
Related Trends

• PSP and TSP
• CMM is what organizations should do and not
  how they should do it
• Problem
• Engineers only believe new methods work after
  they use them and see the results, but they will
  not use methods until they believe they work
• Object
• To convince S/W engineers of the value of better
  methods
• PSP
• They leave their day-to-day env. And go through a
  rigorous training course

37
Related Trends

• PSP and TSP (Cont.)
• When everyone on a team of engineers is PSP
  trained, they still must figure out how to
  combine their personal processes into an overall
  team process
• TSP
• Extends and refines the CMM and PSP methods
• How to build self-directed teams
• How to perform as effective team members
• How to guide and support these teams
• How to maintain an env.
• Benefit
• Show engineers how to produce quality products
  for panned costs and on aggressive schedules

38
Future Trends

• In the future
• S/W product quality will be less about defects
  and more about how well a product achieves
  desired levels of functionality, reliability,
  security, usability, efficiency, maintainability,
  and portability
• CMMI, TSP, the SEIs work in architecture tradoff
  analysis, and ISO/IEC 9126
• Three other future
• Software reuse
• Technology to support the use of S/W engineering
  processes
• Technology to support virtual organizations

39
Future Trends

• Software Reuse
• When they reuse high-quality code, they have an
  extreme competitive advantage
• gt SEIs Framework for Product Line Practice
• Benefit
• Significant Productivity, cycle time, and quality
  improvements
• IEEE 1517 Software Reuse Standard

40
Future Trends

• Software Process Technology
• Coordinate the efforts of people, computers, and
  software tools to support key software
  development activities, such as collaborative
  design and S/W testing and analysis
• Virtual Organizations
• 24x7 (i.e., they work 24 hours a day, 7 days a
  week)
• Development organizations in Europe and Korea
  where work is done continuously and
  collaboratively during the daylight hours in each
  part of the world
• Continuing research
