Response/Report Schema Status

1
Response/Report Schema Status

• Dan Gunter
• Lawrence Berkeley National Laboratory

2
Why response / report ?
Perform Measurement?
(1)
request
client
server
Query archive?
response
(1..N)
archive
Measurement system
report
(1..N)
3
Existing Versions

• Two versions, old and new
• Old
• Single W3C XML-Schema
• has some prototype implementations
• New henceforth, the schema
• Modularized, RELAX-NG
• No implementations yet
• Note generated XML-Schemas tricky for current
  tooling

4
Report Schemata
Report
includes
Subject
Result
Params
Tool
Time
Values
Extend
Utility types
5
Report Schema1

• NetworkMeasurement (1..)
• Characteristic
• Subject
• Node Path
• Methodology (1..)
• Endpoint
• Tool
• Parameter (0..)
• ResultSet
• Time interval (0..1)
• Result (0..)
• Statistic (0..)

6
Report Schema2
Based on new requirements document

• Metadata section (0..N)
• ltmetadata identifierigt
• Characteristic Subject Methodology
• Result section (0..N)
• ltmetadata identifierjgt
• ResultSet ResultSetRef

• Time interval (0..1)
• Result (0..N)
• Statistic (0..N)

Result delivery info Use WS-?something? For
now place-holder
7
Result batching

• For efficiency, results may be delivered in
  batches
• Each result section indicates
• Batch
• (optional) total of batches
• (optional) batch size hint about of contained
  atomic measurements
• To represent a single measurement
• ltbatch total1gt1lt/batchgt

8
To-Do Before Hawaii

• Finish version 2
• Match requirements
• Reconcile with Request schema
• Test
• May require some hand-translation of RELAX-NG ?
  XML-Schema for existing Java, Perl, and Python
  tooling
• Iterate..
