A Cognitive Map for an Artificial Agent

1
A Cognitive Map for an Artificial Agent

• Unmesh Kurup
• RPI
• kurupu_at_rpi.edu
• B. Chandrasekaran
• The Ohio State University
• chandra_at_cse.ohio-state.edu

2
Overview

• Cognitive map
• Features
• Goals
• biSoar architecture
• Cognitive Map in biSoar
• Examples

3
Cognitive Map
4
Cognitive Map

• Representation of large-scale space

5
Cognitive Map

• Representation of large-scale space
• Layout of a city

6
Cognitive Map

• Representation of large-scale space
• Layout of a city or a building

7
Cognitive Map

• Representation of large-scale space
• Layout of a city or a building
• Supports a number of problem solving tasks.

8
Cognitive Map

• Representation of large-scale space
• Layout of a city or a building
• Supports a number of problem solving tasks.
• Route-finding How can I get to the Radisson from
  here?
• Exit the hotel, Take a left, Right at 23rd St,
  Right on Clark.

9
Cognitive Map

• Representation of large-scale space
• Layout of a city or a building
• Supports a number of problem solving tasks.
• Geo Recall Is your hotel to the west of this
  hotel?

10
Cognitive Map

• Representation of large-scale space
• Layout of a city or a building
• Supports a number of problem solving tasks.
• Finding shortcuts Is there a shorter way to my
  hotel?
• Possible Take a right on 20th st.

11
Features of the Cognitive Map
12
Features of the Cognitive Map

• Non-holistic

13
Features of the Cognitive Map

• Non-holistic

If you take a left on Crystal Dr, you will get to
the intersection of Crystal Dr and 23rd St
If you take a right on 23rd St, you will get to
the intersection of 23rd St and Clark.
14
Features of the Cognitive Map

• Non-holistic
• manageable

15
Features of the Cognitive Map

• Non-holistic
• Manageable

16
Features of the Cognitive Map

• Non-holistic
• Manageable

If you take a left on Crystal Dr, you will get to
the intersection of Crystal Dr and 23rd St
If you take a right on 23rd St, you will get to
the intersection of 23rd St and Clark.
vs
If you take a right on Clark you will get to your
hotel
17
Features of the Cognitive Map

• Non-holistic
• Manageable, updateable,

18
Features of the Cognitive Map

• Non-holistic
• Manageable, updateable,

If you take a left on Crystal Dr, you will get to
the intersection of Crystal Dr and 23rd St
If you take a right on 20th St, you will get to
the intersection of 20th St and Clark.
If you take a right on 23rd St, you will get to
the intersection of 23rd St and Clark.
New info? Just add it!
If you take a right on Clark you will get to your
hotel
19
Features of the Cognitive Map

• Non-holistic
• Manageable, updateable, composable

20
Features of the Cognitive Map

• Non-holistic
• Manageable, updateable, composable

If you take a left on Crystal Dr, you will get to
the intersection of Crystal Dr and 23rd St
If you take a right on 20th St, you will get to
the intersection of 20th St and Clark.
If you take a right on Clark you will get to your
hotel
21
Features of the Cognitive Map

• Non-holistic
• Manageable, updateable, composable
• Has both symbolic and metric aspects

22
Features of the Cognitive Map

• Non-holistic
• Manageable, updateable, composable
• Has both symbolic and metric aspects

If you take a left on Crystal Dr, you will get to
the intersection of Crystal Dr and 23rd St
23
Goals

• Capture features
• A nonholistic representation with both symbolic
  and metric aspects

24
Goals

• Capture features
• A nonholistic representation with both symbolic
  and metric aspects
• Cognitive architecture approach

25
biSoar

• A Bimodal Cognitive Architecture

26
biSoar

• Soar Diagrammatic Representation System (DRS)

27
DRS - Diagrammatic Representation System (Chandra
et. al. 2004)

• Diagrams consist of three types of objects
  Points, Curves Regions.

28
DRS - Diagrammatic Representation System (Chandra
et. al. 2004)

• Perceptual routines allow extraction of
  relationships between objects in the diagram.
• Ex LeftOf, RightOf etc
• Action routines allow the diagram to be modified
• AddPoint, AddCurve etc

29
biSoar
Soar
World
Working Memory Block (A), Block (B), Block (C),
On (A,B), On (B,C)
Selected Operator None
biSoar
Soar WM
DRS
30
LTM and Learning in biSoar

• No change to LHS of LTM rules in biSoar
• RHS can extract information from or modify
  diagrammatic component as well.
• If a and b are clear and goal is on(a,b) then
  translate(a on b)
• Chunking in the bimodal case is straightforward.

31
biSoar

• Soar Diagrammatic Representation System (DRS)
• biSoar does not do
• Any sort of image processing
• Object recognition
• Assumes
• a diagrammatic representation (DRS form) of the
  input is available.

32
Representing LSS in biSoar

• If goal is find_next_location and curr location
  is x and traveling in direction Dx on route Rx,
  then
• destination is location y, diagram is DRSx

33
Representing LSS in biSoar

• If goal is find_next_location and curr location
  is A and traveling in direction Dx on route Rx,
  then
• destination is location B, diagram is DRSx

If goal is find_next_location and curr location
is R2R5 and traveling Right on Route R2, then
destination is P2, diagram is DRS1
34
Examples Route-finding

• Given a map, find route from P1 to P2

• Route-finding Strategy
• locate the starting destination locations in
  the map
• make the starting location the current location
• Find the routes on which the current location
  lies
• For each route, find the directions of travel
• for each route and direction of travel, find the
  next location
• calculate the Euclidean distance between these
  new locations and the destinations
• pick the location that is closest to the
  destination and make that the current point
• repeat 3-8 until destination is reached

35
Learning while route-finding
Example rules learned during wayfinding
36
Within-task transfer

• Task1 P1 to R3R5

37
Within-task transfer

• Task1 P1 to R3R5, Task2 P4 to P2

38
Within-task transfer

• Task1 P1 to R3R5, Task2 P4 to P2
• New route-finding task P4 to R3R5

39
Between-task transfer

• Geographic Recall problem
• Whats the spatial relation between R1R3 and
  R3R5?

40
Finding short-cuts
R4
If goal is find_routes and at R2R5 then there is
a route r5 in the up direction.
R1
R3
R2
41
Finding short-cuts
R4
If goal is find_routes and at R2R5 then there is
a route r5 in the up direction.
R1
R3
Find route from P2 to P5
R2
42
Finding short-cuts
R4
If goal is find_routes and at R2R5 then there is
a route r5 in the up direction.
R1
R3
Find route from P2 to P5
R2
R3
R5
R2
43
Conclusion

• biSoars CM (representation of LSS)
• Is non-holistic
• has metric and non-metric information
• Can be used to solve a variety of tasks involving
  LSS.
• Supports learning and transfer of learned
  information within and between tasks.

44
Thanks!
