Krivljenje slike - warping
2
Princip 2D krivljenja
Demo
3
Krivljenje (Warping)

• Krivljenje (warp) je 2-D geometrijska
  transformacija in ob uporabi na neki sliki tvori
  popaceno sliko
• Dva nacina krivljenja slik- ? Preslikava
  naprej (Forward mapping). ? preslikava nazaj
  (Reverse mapping).

4
Krivljenje (Warping)
warp
Destination image
Source image
5
Preslikava (mapping)
6
Primer preslikave
7
Primer preslikave
8
Primer preslikave
9
Primer krivljenja
10
Druge preslikave
11
Implementacija krivljenja slike
12
Preslikava naprej
13
Preslikava naprej
14
Preslikava naprej
15
Problemi preslikave naprej
16
Problemi preslikave naprej
V rezultirajoci sliki lahko pride do lukenj
17
Problemi preslikave naprej
18
Preslikava nazaj (backward mapping)
19
Implementacija krivljenja slike (2)
20
Preslikava nazaj
21
Problemi preslikave nazaj
22
Problemi preslikave nazaj
23
Forward and Reverse Mapping

• Forward ? Some pixels in the destination might
  not get painted, and would have to be
  interpolated.
• Reverse ? Every pixel in the destination image
  gets set to something appropriate.

24
Ponovno vzorcenje (Resampling)

• Evaluate source image at arbitrary (u, v)
• (u, v) does not usually have integer coordinates
• Some kinds of resampling
• Point resampling
• Triangle filter
• Gaussian filter

Source Image
Destination Image
25
Vzorcenje tock (Point Sampling)

• Take value at closest pixel
• int iu trunc(u 0.5)
• int iv trunc(v 0.5)
• dst(x, y) src(iu, iv)
• Simple, but causes aliasing

26
Trikotni filter

• Konvolucija s trikotnim filtrom

27
Trikotni filter

• Bilinearna interpolacija 4 najbližjih pikslov
• a linear interpolation of src(u1, v2) and
  src(u2, v2)
• b linear interpolation of src(u1, v1) and
  src(u2, v1)
• dst(x, y) linear interpolation of a and b

28
Konvolucija z Gaussovim filtrom
Width of Gaussian kernel affects bluriness
29
Primerjava metod filtriranja

• Kompromisi
• Aliasing nasproti zamegljevanju
• Hitrost racunanja

30
Implementacija krivljenja slike
31
Implementacija krivljenja slike
32
Primer skaliranje
33
Primer vrtenje
34
Primer vrtinec (swirl)
35
Povzetek krivljenja slik
36
Preslikava naprej in nazaj

• In either case, the problem is to determine the
  way in which the pixels in one image should be
  mapped to the pixels in the other image.
• So, we need to specify how each pixel moves
  between the two images.
• This could be done by specifying the mapping for
  a few important pixels.

37
2D krivljenje objektov
38
2D krivljenje objektov

• The shape modification can also be performed on a
  vertex-basis instead of on a space-basis.
• A displacement for a seed vertex can be specified
  by the user and this displacement can be
  propagated to nearby vertices.
• The displacement can be attenuated as a function
  of the distance that the vertex to be displaced
  is away from the seed vertex.

39
2D krivljenje objektov

• The distance function can be chosen to trade-off
  quality of results and computational complexity.
• Minimum number of edges connecting the vertex to
  be displaced from the seed vertex.
• Minimum distance traveled over the surface of the
  object to get from the vertex to be displaced to
  the seed vertex.
• Power functions to control the amount of
  attenuation.
• The user could select the maximum distance at
  which the displacement would have an affect.

40
Preslikava tekstur
41
Preslikava tekstur
