Automatic Person Location Technologies and Solutions for Public Safety Users

1
Automatic Person Location Technologies and
Solutions for Public Safety Users

• Peter Hudson
• Sepura

28.10.2005
2
Introduction

• Market requirements for APLS for Public Safety
  users
• The command and control requirements of an APLS
  solution
• Review of location technologies
• TETRA services used for location solutions
• Future of APLS enabled products for public safety
  users

3
Market Requirement Drivers APLS

• FCC E911 Mandate in the US
• Call centres
• Terminal or network implemented solutions
• 50 - 100 metre accuracy for at least 67 of cases
• 150 - 300 metre accuracy for at least 95 of
  cases
• EU E112 Mandate in Europe
• Still not implemented !
• No defined accuracy specified !
• Both systems proposing using either TDOA or GPS
  location techniques
• Many emergency services now
  mandating APLS

4
Location Technology - Public Safety

• Know where someone is save LIFE.
• Better allocation of resources, prompt reaction
  to an Emergency save TIME.
• Better Control of the fleet save MONEY
• Improve job satisfaction save CHURN

5
Solution Influencing Factors

• Price
• Accuracy verses coverage
• Ergonomics
• Power consumption
• Timing of solution to reach the market
• Standard solution or proprietary ?
• Can the solution be supported by TETRA ?

6
Command Control Requirements

• Effective management
• Requirements differ from AVLS
• User needs to feel unthreatened by APLS
• Updated positioning details fixed to various
  duties or skills
• Linking of various systems/databases to provide
  officer with advance warning of possible dangers

7
Resource management - AVLS
8
Resource management - APLS
9
Resource management
10
Importance of knowing location
High Accuracy
Low Accuracy
11
Location Solutions Performance

• Low accuracy, low cost solutions
• Time difference of arrival
• Enhanced observed time difference
• Medium accuracy, medium cost solutions
• Standard GPS
• Assisted GPS
• Low signal strength GPS
• High accuracy, high cost solutions
• Differential GPS
• Combinations of Solutions

12
Low accuracy, low cost (terminal) solutions

• Time Difference Of Arrival (TDOA)
• very costly to implement in the network
• accuracy of location is /- 500 metres
• Enhanced Observed Time Difference (EOTD)
• no base station support now claimed
• accuracy of location is 200m - 2km
• Both technologies
• have good indoor/urban canyon penetration, but
  with very poor accuracy - a general show stopping
  issue for network based solutions where location
  accuracy could be critical
• are bandwidth hungry therefore not suitable for
  TETRA

13
Network Based Solutions
GIS or
Mapping
Application
LMU
LMU
TETRA
Radio tower
Radio tower
Gateway
GIS or
Mapping
Application
CC
Server
Network Based Solutions
Current Accuracy 200m - 2km
Future Accuracy 100m - 500m
LMU
LMU
Radio tower
14
Medium accuracy, medium cost solutions

• Standard GPS
• time to first acquisition (fix) is typically 3
  mins
• gt30 metres accuracy, no indoors or urban canyon
  coverage
• Assisted GPS
• time to first acquisition is typically 30 secs
• gt30 metres accuracy
• Low Signal Strength GPS (high sensitivity)
• time to first acquisition is typically 45 secs
• lt30 metres accuracy
• indoors/urban canyons
• All the above have a location accuracy of lt10
  metres for 95 of cases in open space

15
GPS How Does It Work ?

• To enable a location measurement to be made, the
  GPS receiver needs to know were the satellites
  are
• It receives two kinds of data from the
  satellites
• Almanac data
• Ephemeris data
• Once the receiver has obtained this information
  it needs to synchronise time before an accurate
  location measurement can be made.
• By knowing time taken to receive signal from each
  satellite, the receiver can determine exactly how
  far away it is.

16
GPS based solutions
Mapping Server
Mapping Application
CC Firewall
C C LAN
TETRA Network
TETRA gateway
Dispatch workstations
SDS
C C Servers
Radio tower
Base station
17
High accuracy, high cost solutions

• Differential GPS
• open space accuracy lt10 metres off
• expensive to implement with land based
  differential base stations required and regular
  network broadcasts
• Network bandwidth hungry
• Solution Combinations (GPSBeaconsOdometer)
• accuracy anywhere between 0 - 10 metres
• very expensive beacon network required to
  support this

18
GPS - High accuracy
TETRA
Network
GIS or
Mapping
Application
TETRA
Radio tower
Radio tower
Gateway
GIS or
Mapping
GPS
Application
Server
CC
GPS Station
Radio tower
Radio tower
19
Data over network - Size of problem!
Typically, position report messages could carry
some or all of the following

• Date
• Time
• Latitude
• Longitude
• Altitude
• Speed

• Heading
• Fix type
• Confidence Level
• Status
• Fix Reason
• Terminal ID

Amount of message traffic generated by APLS
systems is much larger than for AVLS
20
TETRA services for APLS

• TETRA services allow use of SDS messaging for
  transmission of GPS data-
• EN 300 392-2 TETRA (Voice plus Data (VD),
  part 2 Air Interface, v2.3.2
• SDS4 and SDS-TL delivers variable length
  messages to 2047 bits(255 bytes)
• GPS location data is provided in the NMEA
  formats, GLL, GSA, GGA etc.
• Typical GLL mesage could contain as much as 48
  bytes of data!
• Location Information Protocol TS 100 392-18-1
  v1.1.1 Jan 2005
• Specifies the effective use of network by using
  compact message formats
• Typical message (compared to GLL) is 11 bytes
  long!

21
Future of APLS TETRA Terminals

• Technology Influenced Solutions

• Continuing integration of ICs and components
  enables space saving in handsets and is an
  opportunity to integrate location devices like
  GPS.

• The European Galileo system should be operational
  by 2008 and this is supposed to perform better
  than the existing US DoD GPS system.

22
GPS Performance - Trend
Galileo
L1, L2 L5 Frequency ( Galileo?)
Clear Sky Under Foliage Wooden
Building Urban Canyon Single Storey Brick
Building Multi Storey Concrete
building Underground?
High Quality Receiver
Future GPS ?
High Quality Hand Held Receiver
High sensitivity GPS
Other Sensors e.g. Gyroscope, Accelerometers
2002 2003 2004 2005 2006 2007 2008
2010.. 2015 2020 2030
23
Benefits of GPS in Public Safety

• Enhances user safety
• Lone worker Emergency Button GPS
• Accurate Location
• Improves resource usage
• Improves response times
• Selection of most appropriate resource
• Reduce wasted resource
• Improves reporting accuracy
• Knowing precisely where an incident took place
• Improves user job satisfaction
• User feels safer and more confident
